B8-S manual Page 1 UIC BEZEL8-S BEZEL8-S Credit card Reader Specification: Specification Processor Microchip SAMA5D23 Memory DDR3 256MB Storage QSPI-Flash 32MB Display Graphic LCD @ 128 x 64 OS Linux Audio Buzzer≧70dB @ 10cm Reader Magnetic Card Reader Bi-directional, support triple tracks ISO7811 Speed 5 to 40 IPS 1,000,000. swipe times Smart Card Reader ISO7816, T=0 , T=1 EMV Level 1, Support 5V/3V 500,000. inserted times Contactless Support ISO 14443 Type A/B and Mifare with 4 LEDs, EMV contactless L1 I/O RS-232/USB USB(VCOM) or RS232, Cable-select AUX RS232, as auxiliary port LAN 10BASE-T/100BASE-T ethernet DC in 5V, 1A SAM x 1 Debug console Special cable through auxiliary port LED indicator x 4 for RFID, 1 set for MSR, 1 set for ICC Buttons Rubber button x 2 Communication Ethernet x 1 (Optional) Wifi x 1 (Optional) Environment Operating Temperature -20°C to +70°C Storage Temperature -30°C to +80°C Humidity 5% to 90% Reliability Requirements MTBF 50,000 hours ESD Contact：+/- 8KV Air：+/-15KV Centurion/ Metal card：+/- 8KV(insert half of the card) B8-S manual Page 2 Button 1M times IP Level IP54 IK Level IK06 UV UV exposure resistance Installation guide(RS232 Interface) 1 Plug the RS232 cable to the port of PC or system 2 The reader will boot up automatically 3 The reader will boot up automatically Photos: FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/ TV technician for help. CAUTION: B8-S manual Page 3 Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF exposure statements 1. This Transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. 2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body or nearby persons.. Uniform Industrial Corp. 2901 Bayview Dr, Fremont, CA 94538 TEL : +1-510-438-6799 FAX : +1-510-438-6790 E-Mail : [email protected]
