TKZAWUHN2487WIFI USB DONGLE VERSA3

1/64 Wireless LAN USB Adapter User Manual 1.0 © 2010 2/64 Contents 1. Windows Wireless Utility ...................................................................................... 4 1.1 Windows Zero Configuration for XP ............................................................. 4 1.1.1 Ralink Wireless Utility and Windows Zero Configuration ................ 4 1.1.2 Windows Zero Configuration (WZC) ................................................ 5 1.2 Windows AutoConfig Service for Vista ....................................................... 10 1.2.1 Ralink Wireless Utility and Windows AutoConfig Service ............. 10 1.2.2 Windows AutoConfig Service ......................................................... 11 2. Ralink Wireless Utility (RaUI) ............................................................................ 18 2.1 Start .............................................................................................................. 18 2.1.1 Start RaUI ........................................................................................ 18 2.2 Profile ........................................................................................................... 21 2.2.1 Profile ............................................................................................... 21 2.2.2 Add/Edit Profile ............................................................................... 22 2.2.3 Example to Add Profile in Profile .................................................... 25 2.2.4 Pre-logon Connect ........................................................................... 27 2.3 Network........................................................................................................ 27 2.3.1 Network............................................................................................ 27 2.3.2 Example on Adding Profile in Network........................................... 29 2.4 Advanced ..................................................................................................... 31 2.4.1 Advanced ......................................................................................... 31 2.4.2 Certificate Management ................................................................... 32 2.5 Link Information .......................................................................................... 33 2.5.1 Link Status ....................................................................................... 33 2.5.2 Throughput ....................................................................................... 34 2.5.3 Statistics ........................................................................................... 34 2.6 About............................................................................................................ 35 2.6.1 About................................................................................................ 35 2.7 WPS ............................................................................................................. 36 2.7.1 WPS ................................................................................................. 36 2.7.2 Example to Add to Registrar Using PIN Method ............................ 38 2.7.3 Example to Add to Registrar Using PBC Method ........................... 41 2.7.4 Example to Configure a Network/AP Using PIN or PBC Method .. 45 3. Security ................................................................................................................ 47 3.1 Auth.\ Encry. Setting – WEP/TKIP/AES ..................................................... 47 3.2 802.1x Setting .............................................................................................. 48 3.3 Example to Configure Connection with WEP on ........................................ 51 3.4 Example to Configure Connection with WPA-PSK .................................... 53 3/64 3.5 Example to Configure Connection with WPA ............................................. 55 4. Appendix .............................................................................................................. 60 4.1 Country Channel List ................................................................................... 60 4.2 Acknowledgements ...................................................................................... 62 5. Installation............................................................................................................ 63 4/64 1. Windows Wireless Utility 1.1 Windows Zero Configuration for XP 1.1.1 Ralink Wireless Utility and Windows Zero Configuration Windows XP includes a wireless configuration utility named "Windows Zero configuration" (WZC) which provides basic configuration functions to the Ralink Wireless NIC. Ralink's utility (RaUI) additionally provides WPA functionality. To make it easier for the user to select the correct utility. RaUI will let users make a selection when it first runs after windows XP boots. Right-clicking the icon will bring up the selection window and allow the user to make a selection. Figure 1-1 RaUI.exe RaUI can co-exist with WZC . When coexisting with WZC, RaUI only provides monitoring functions, such as surveying the link status, network status, statistic counters, advanced feature status, WMM status and WPS status. It won't interfere with WZC's configuration or profile functions. It is shown as Figure 1-2. Figure 1-2 Select WZC or RaUI If "Use RaConfig as Configuration utility" is selected, please jump to Section 2 on running RaUI. If "Use Zero Configuration as Configuration utility" is selected, please continue. We will explain the difference between RaUI and WZC. Figure 1-3 shows the RaUI status when WZC is activated as the main control utility. Figure 1-3 RaUI status with WZC active 5/64 When activating WZC, there are several difference with the RaUI status, compared to the RaUI status without WZC running.  The profile button will be gray. Profile functi…

Text truncated - open the document above for the full version.

AsiaRF Ltd Date: November 1, 2013 Federal Communications Commission Authorization and Evaluation Division FCC ID: TKZAWUHN2487 ATTESTATION FCC ID: TKZAWUHN2487 Product: WiFi USB Dongle Versa3 Model: AWUHN2487 We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA. Sincerely, __________________ Paul Lai AsiaRF Ltd Annex I J Series J001, J002, J003, J004, J005, J006, J007, J008, J009, J010, J011, J012, J013, J014, J015, J016, J017, J018, J019, J020, J021, J022, J023, J024, J025, J026, J027, J028, J029, J030, J031, J032, J033, J034, J035, J036, J037, J038, J039, J040, J050, J052, J055, J058, J060, J065, J068, J070, J080, J090, J095, J098, S Series S001, S002, S003, S004, S005, S006, S007, S008, S009, S010, S011, S012, S013, S014, S015, S016, S018, S020, S022, S024, S028, S030, S036, S040, S050, S058, S060, S070, S080, S090, S198, S1000，S298, S398, S498, S598, S698, S798, S898, S518, S700, S900, S1000, S2000 ,S998, K Series K1000, K2000, K3000, K4000, K5000, K6000, K7000, K8000, K9000 T Series T1, T2, T4, T5, T6, T7, T8, T9, T10, T11, T12, T13, T14, T15, T16, T17, T18, T19, T20, T21, T22, T23, T24, T25, T26, T27, T28, T29, T30, T40, T50, T60, T70, T80, T90, X Series X1, X2, X3, X4, X5, X6, X7, X8, X9, X10, X11, X12, X13, X14, X15, X16, X17, X18, X19, X20, X22, X24, X25, X28, X35, X40, X50, X60, X70, X80, X90, A Series A001, A002, A003, A004, A005, A006, A007, A008, A009, A010, A011, A012, A013，A014, A015, A016, A017， A018, A019, A020, A030, A040, A050, A060, A070, A080, A090, D Series D001, D002, D003, D004, D005, D006, D007, D008, D009, D010, D010, D012, D013, D014, D015, D016, D017, D018, D019, D020, D030, D040, D050, D060, D070, D080, D090, F Series F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, F13, F14, F16, F18, F20, F30, F40, F50, F60, F70, F80, F90,

1 of 6 External Photo (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo (9) EUT Photo (Antenna AG-24015) (10) EUT Photo (Antenna AO-24008.1) (11) EUT Photo (Antenna A-2409D)

1 of 2 Internal Photo (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo

MRT Technology (Suzhou) Co., Ltd Report No.: 1311RSU00202 Phone: +86-512-66308358 Fax: +86-512-66308368 Report Version: V01 www.mrt-cert.com RF Exposure Evaluation Declaration Applicant : AsiaRF Ltd. Product : WiFi USB Dongle Versa3 Model No. : AWUHN2487 FCC ID : TKZAWUHN2487 Test Date : November 07 ~ 26, 2013 Reviewed By : ( Engineer: Sunny Sun ) Approved By : ( Manager: Marlin Chen ) The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 1311RSU00202 Page: 2 of 4 Revision History Report No. Version Description Issue Date 1311RSU00202 Rev. 01 Initial report 11-27-2013 Report No.: 1311RSU00202 Page: 3 of 4 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1mW/cm². If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Report No.: 1311RSU00202 Page: 4 of 4 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°C and 78% RH. 1.3. Test Result of RF Exposure Evaluation Product WiFi USB Dongle Versa3 Test Item RF Exposure Evaluation Antenna Gain: The maximum Gain measured in fully anechoic chamber is 15dBi for 2.4GHz in logarithm scale. Output Power into Antenna: Operation Mode Frequency Range (MHz) Maximum Average Output Power (dBm) Power Density at R = 20 cm (mW/cm 2 ) Limit of Power Density S(mW/cm 2 ) 802.11b/g//n(20MHz) 2412~2462 16.33 0.270 1 802.11n(40MHz) 2422~2452 8.34 0.043 1 Note: Antenna to user separation ≥ 20cm The End

MRT Technology (Suzhou) Co., Ltd Report No.: 1311RSU00201 Phone: +86-512-66308358 Fax: +86-512-66308368 Report Version: V02 www.mrt-cert.com 1 of 99 FCC15.247 Test Report Applicant : AsiaRF Ltd. Product : WiFi USB Dongle Versa3 Model No. : AWUHN2487 FCC ID : TKZAWUHN2487 Standards : FCC CFR Title 47 Part 15 Subpart C: 2013 ANSI C63.4: 2009 ANSI C63.10: 2009 Test Date : November 07 ~ 26, 2013 Reviewed By : ( Engineer: Sunny Sun ) Approved By : ( Manager: Marlin Chen ) The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 1311RSU00201 2 of 99 Revision History Report No. Version Description Issue Date 1311RSU00201 Rev. 01 Initial report 11-27-2013 1311RSU00201 Rev. 02 Add calibration interval for equipment 12-04-2013 Report No.: 1311RSU00201 3 of 99 Test Summary FCC Part Section(s) Test Description Test Result (Pass/Fail) Reference 15.203 & 15.247(c)(1)(i) Antenna Requirement Pass Section 3 15.207 Conducted Emission Pass Section 4 15.205 15.209 Radiated Emission Pass Section 5 15.247(d) RF Antenna Conducted Spurious Pass Section 6 15.247(d) Radiated Emission Band Edge Pass Section 7 15.215(c) Operation Frequency Range of 20dB Bandwidth Pass Section 8 15.247(a)(2) Occupied Bandwidth Pass Section 9 15.247(b)(3) Power Output Pass Section 10 15.247(e) Power Spectral Density Pass Section 11 Report No.: 1311RSU00201 4 of 99 CONTENTS Description Page 1. General Information .................................................................................................................. 6 1.1. Applicant .......................................................................................................................... 6 1.2. Manufacturer ................................................................................................................... 6 1.3. Feature of Product ........................................................................................................... 6 1.4. Testing Facility ................................................................................................................. 7 2. Test Configuration of Equipment Under Test ......................................................................... 8 2.1. Test Mode ........................................................................................................................ 8 2.2. Configuration of Tested System ...................................................................................... 8 2.3. Test System Details ......................................................................................................... 9 2.4. Test Software ................................................................................................................... 9 3. Antenna Requirement ............................................................................................................ 10 3.1. Standard Applicable ....................................................................................................... 10 3.2. Conclusion ..................................................................................................................... 10 4. Conducted Emission .............................................................................................................. 11 4.1. Limit of Conducted Emission ......................................................................................... 11 4.2. Test Setup ..................................................................................................................... 11 4.3. Test Procedure .............................................................................................................. 12 4.4. Test Result ..................................................................................................................... 13 5. Radiated Emission .................................................................................................................. 15 5.1. Limit ............................................................................................................................... 15 5.2. Test Setup ..................................................................................................................... 15 5.3. Test Procedure .............................................................................................................. 17 5.4. Test Result ..................................................................................................................... 17 6. RF Antenna Conducted Spurious ......................................................................................... 24 6.1. Limit ............................................................................................................................... 24 6.2. Test Setup ..................................................................................................................... 24 6.3. Test Procedure .............................................................................................................. 24 6.4. Test Result ..................................................................................................................... 25 7. Radiated Emission Band Edge .............................................................................................. 37 7.1. Limit ............................................................................................................................... 37 7.2. Test Setup ..................................................................................................................... 37 7.3. Test Procedure ..............................................................................................................…

Text truncated - open the document above for the full version.

1 of 9 Test Setup Photo Description: Front view of Conducted Emission Test Setup(With Antenna AG-24015) Description: Back view of Conducted Emission Test Setup(With Antenna AG-24015) Description: Front view of Conducted Emission Test Setup(With Antenna AO-24008.1) Description: Back view of Conducted Emission Test Setup(With Antenna AO-24008.1) Description: Front view of Conducted Emission Test Setup(With Antenna A-2409D) Description: Back view of Conducted Emission Test Setup(With Antenna A-2409D) Description: Radiated Emission Test Setup for Below 30MHz(With Antenna AG-24015) Description: Radiated Emission Test Setup for Below 30MHz(With Antenna AO-24008.1) Description: Radiated Emission Test Setup for Below 30MHz(With Antenna A-2409D) Description: Radiated Emission Test Setup for Below 1GHz(With Antenna AG-24015) Description: Radiated Emission Test Setup for Below 1GHz(With Antenna AO-24008.1) Description: Radiated Emission Test Setup for Below 1GHz(With Antenna A-2409D) Description: Radiated Emission Test Setup for 1~18GHz(With Antenna AG-24015) Description: Radiated Emission Test Setup for 1~18GHz(With Antenna AO-24008.1) Description: Radiated Emission Test Setup for 1~18GHz(With Antenna A-2409D) Description: Radiated Emission Test Setup for Above 18GHz(With Antenna AG-24015) Description: Radiated Emission Test Setup for Above 18GHz(With Antenna AO-24008.1) Description: Radiated Emission Test Setup for Above 18GHz(With Antenna A-2409D)
