095209 Wireless Optical Mouse User Manual Welcome Thank you for selecting this product! Your RF wireless optical mouse uses a newly developed RF wireless technology 27MHz that replaces the traditional wired mouse. You can use your wireless optical mouse freely and improve your efficiency and enjoy your beautiful life from the high technology. The receiver of this mouse can be put into its transmitter, and it is an outstanding design. Product Features 1，Radio frequency 27MHz, enjoy your freely wireless space 2， It has 256 ID code, there is no interference even many mice being used at the same time. 3，Automatically save power sleeping functions, battery life be prolonged. 4，5 buttons and free definition functions . Systems Compatibility IBM PC and Win 95/98/Me/2000/XP, No need driver The Steps of Install Battery 1，Please prepare for two PCS new AA alkaline batteries 2，Press the two sides of the mouse transmitter and pull the battery cover rearward (Please see the reference picture) 3 ， Please insert the batteries correctly according to the polarity marks of the battery grooves. 4 ， Pull the battery covers forward, when you hear “crack” sound which shows the battery cover is locked successfully. 。 Receiver Installation 1，please use extended cable, and put the receiver and transmitter on one desktop, in this way, you may have higher working efficiency. 2， If you use PS/2 connector, please use the USB to PS/2 adaptor and connect with the connector before your computer start-up For laptop, you may connect the receiver directly with the USB connector. ID Setup 1，Please move the mouse near to the receiver 2，press the ID button I the front of the receiver,the light of the receiver begains to flicker. 3，Press the ID button of the mouse bottom with some hard and acuate object within 10 seconds, the receiver light will flash very fast, a few seconds later it will be on which shows it is successfully to finish the digital transmission between the mouse and the receiver. You may start to use it. 4 ， Working distance: within 1-2 m. user-defined buttons after the installation of drive program,users can self define the buttons freely, as long as to press the button predefined, we can turn on the preseted function 。 before use self defined buttons, please install drive program first, so that we can use software to define functions Installation of drive program put the drive program disk into the CD-room,unfold the disk and run the file named setup.exe.The system will run files automatically and appear the picture below 3 4 click “next” button choose “5 Button Mouse” and click the “next” button the system requires the address of installation,we can choose windows default and then click “next” button system requires the catalog of installation,click “next” to use the windows default information of copy files appears,click “next” to copy files when copy finished,system requires to restart PC.choose “finish” and PC begines to restart settings of self-defined buttons after PC restarted,there is a icon appeared in taskbar,double click this icon and enter the picture of self-definition for scroll wheel and buttons as this picture show,the upside is for setting mode of scroll wheel,the underside is for setting speed of scroll wheel System default(Intelli-Mouse) mode Enhanced scroll mode Scroll ** lines per scroll unit Scroll one page scroll unit Click “button setting”and enter the picture below in this setting,the third,forth,fifth buttons can be defined freely,click the little triangle at the right side can select functions below Auto scroll Back space Close Application Connect To Internet Control Lock 56 78 Control Panel Copy Cut Delete Double click Down Drag Lock End Enter Esc Explorer F1~F10 Find computer Find File Home Horizontal wheel Internet Explorer Backward Internet Explorer forward Launch Default Browser Launch Default E-mail Left Maximize Window Middle Button Minimize All Windows Minimize windows Page Down Page Up Paste Redo Right Run Shift Lock Space Start Menu System Default System Help System Property Tab Undo Undo Minimize All Windows Universal Scroll Universal Zoom Up Attention Please 1, Please don’t make the mouse far away from the receiver in order to work more smoothly. 2, You’d better use the mouse on the white desk, in this way the batteries can be used longer time. Please remove the batteries if the mouse will not be used for a long time. 3, This mouse with save power sleeping functions, please press any key or scroll the wheel to wake up the mouse when it is sleeping. 4, you want to take off the mouse power, please continue to press the ID switch of the mouse bottom over 3 seconds. If you want to take on the power, please click the ID switch once again. 5 ， The optical mouse will not work freely on a smooth desk ,glass, any reflecting surface, 3D mouse pad. 6 ， No need to check the digital connection within 10 seconds when change the batteries, if more than that please according to the above way to re-operate. Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer- ence to radio com- munications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna…

Text truncated - open the document above for the full version.

095209 TX Block Diagram Antenna FM Modulator 27.045MHZ±3KHZ MCU X1 oscillatio n 76.8KHZ DC-DC Setup Optical sensor X3 oscillatio n 18MHZ Key &Encoder C A B TX 27.045MHZ RF Amplifier RF Generator X2 27.042MHZ

External Photos EUT-Front View EUT-Rear View

ID Label Label FCC ID: TL4095209

ID Label/Location Label Location Information Specifications: Text is Black or white in color and is left justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Label Location

Internal Photos EUT-Uncovered View (1) EUT-Uncovered View (2) EUT-PCB Top View EUT-PCB Bottom View

ET TECH BOM MODEL ： 095209 TX VER ： A0 DATE ： 2005-05-21 No： ET-05211601T By:yuheping QR-098 No component name model quartity remark 1 PCB 1.0 × 76.7 × 35mm 1 2116-A Rev06 2 IC A2051 DIP16pin 1 U1 3 IC MA6221-s7K SSOP28pin 1 U2 4 IC TP301A SOT-89 1 U3 5 IC TP361A SOT-89 1 U4 6 DIODE HLMP-ED80-KP000 1 D4 7 LENSE HDNS-2100 1 8 Switch MTS2-70 2 SWR ， SWL 9 Switch 6 × 6 × 5mm 1 SWM 10 Switch 2 SWF,SWB 11 Switch 100gf 6 × 6 × 4.3mm 1 SWID 12 Encoder H=7mm 1 SWEN 13 DIODE 1N5817 1206 1 D1 ， D2 14 crystal 76 ． 8KHZ DIP 1 X1 15 crystal 27 ． 042MHZ 16pF 49S 1 X2 16 crystal 18.00MHz DIP 1 X3 17 inductance 220uH RL0406-221K 2 L1 ， L2 18 inductance 0.82uH 0805 1 L3 19 Resistance 15K 0603 1 R2 20 Resistance 4M7 0603 1 R3 21 Resistance 1K 0603 1 R4 22 capacitance 10uF/ 6v A （ 1206 ） 2 C1 ， C16 23 capacitance 220uF/ 6v B （ 1210 ） 2 C2 ， C17 24 capacitance 104 0603 3 C3 ， C11 ， C15 25 capacitance 15pF 0603 1 C5 26 capacitance 22pF 0603 2 C6 ， C7 27 capacitance 1pF 0603 1 C8 ET TECH BOM MODEL ： 095209 TX VER ： A0 DATE ： 2005-05-21 No： ET-05211601T By:yuheping QR-098 28 capacitance 30pF 0603 1 C9 29 capacitance 33pF 0603 1 C10 30 capacitance 75pF 0603 1 C12 31 capacitance 30pF 0603 1 C13

095209 TX 1 2 34 A B C D 4 3 2 1 D C B A Title Number Revision Size A4 Date: 10-Aug-2005 Sheet of File: F:\yuheping\RD\2116A\2116A.ddb Drawn By: PCBANT SWEN R3 L3 D1 C6C7 C11 SW_ID C12 C10 C8 X1 C9 PD SW_RSW_MSW_L + C17 SCLK SDIO C15 R2 + C16 X3 D4 PD VDD REFB 8 REFA 7 XY_LED 6 YA 5 YB 4 XB 3 XA 2 SCLK 1 OSC_IN 9 GND 10 OSC_OUT 11 GND 12 VDD 13 R_BIN 14 PD 15 SDIO 16 U1 SDIO SCLK LBUT 7 MBUT 6 RBUT 5 VDD 4 OSC2 3 VSS 2 OSC1 1 RFOUT 8 ORFIN0 9 ORFIN1 10 ORFO 11 TXD 12 PD 13 WA 14 WB 15 Z1IN 16 Z2IN 17 SDIO 18 SCLK 19 BATL 20 TYPE 21 TXCB 22 BBUT 23 FBUT 24 SVD_IN 25 DCVR 26 VL 27 VL_NM 28 U2 C13 C4 X2 C5 -+ VBAT L1 + C1 L4 VSS 1 OUT 2 LX 3 U4 VDD D4 + C2 VSS 1 OUT 2 LX 3 U3 R1 VDD VBT vcc U1 Add Remove A2030A2051 R1 U4,L4,D4 U3,L1,D1 R1 C3 R4

Note: The test report is specially limited to the above company and this particular sample only. It may not be duplicated without prior written consent of Bay Area Compliance Lab Corp. (ShenZhen). This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST or any agency of the US Government. FCC PART 15.227 EMI MEASUREMENT AND TEST REPORT For Verbatim 1200 West W.T. Harris Blvd.Charlotte, NC 28262, USA FCC ID: TL4095209 August 26, 2005 This Report Concerns: Original Report Equipment Type: Transmitter, Wireless optical mouse Test Engineer: Louise Lu Report No.: RSZ05071502 Test Date: August 16-25, 2005 Reviewed By: Chris Zeng Prepared By: Bay Area Compliance Lab Corp. (ShenZhen) 6/F, the 3rd Phase of WanLi Industrial Building, ShiHua Road, FuTian Free Trade Zone, ShenZhen, Guangdong 518038, P.R.China Tel: 86-755-33320018 Fax: 86-755-33320008 Verbatim FCC ID: TL4095209 Report # RSZ05071502 Page 2 of 15 FCC PART 15.227 Report TABLE OF CONTENTS GENERAL INFORMATION.......................................................................................................................................3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................................................3 OBJECTIVE...................................................................................................................................................................3 RELATED SUBMITTAL(S)/GRANT(S).............................................................................................................................3 TEST METHODOLOGY..................................................................................................................................................3 TEST FACILITY.............................................................................................................................................................3 SYSTEM TEST CONFIGURATION ..........................................................................................................................4 JUSTIFICATION.............................................................................................................................................................4 EUT EXERCISE SOFTWARE..........................................................................................................................................4 SPECIAL ACCESSORIES.................................................................................................................................................4 EQUIPMENT MODIFICATIONS.......................................................................................................................................4 CONFIGURATION OF TEST SETUP.................................................................................................................................5 BLOCK DIAGRAM OF TEST SETUP................................................................................................................................5 SUMMARY OF TEST RESULTS ...............................................................................................................................6 §15.203 - ANTENNA REQUIREMENT......................................................................................................................7 STANDARD APPLICABLE..............................................................................................................................................7 §15.205, §15.209, §15.227(A) - RADIATED EMISSIONS TEST ..............................................................................8 MEASUREMENT UNCERTAINTY....................................................................................................................................8 EUT SETUP..................................................................................................................................................................8 EMI TEST RECEIVER SETUP........................................................................................................................................8 TEST EQUIPMENT LIST AND DETAILS...........................................................................................................................8 TEST PROCEDURE........................................................................................................................................................8 CORRECTED AMPLITUDE & MARGIN CALCULATION...................................................................................................9 TEST RESULTS SUMMARY............................................................................................................................................9 TEST DATA................................................................................................................................................................10 PLOT(S) OF TEST DATA..............................................................................................................................................10 §15.227(B) - OUT OF BAND EMISSION .................................................................................................................13 EMI TEST RECEIVER SETUP......................................................................................................................................13 TEST EQUIPMENT LIST AND DETAILS.........................................................................................................................13 TEST PROCEDURE......................................................................................................................................................13 TEST DATA................................................................................................................................................................13 Verbatim FCC ID: TL4095209 Report # RSZ05071502 …

Text truncated - open the document above for the full version.

Test Setup Photos Radiated Emissions-Front View Radiated Emissions-Rear View
