TQ6BTAV101Bluetooth AV Adapter

Flaircomm Technologies Inc. 1 Address：No 211 North Urumchi Road, Suite 616, Shanghai, PRC, 200040 Telephone：86-21-62495778, 86-21-62496778, 86-21-62496878 Fax：86-21-62494858 www.flaircomm.com . AV Adapter User Manual Model：BlueTone™BTAV101 Declaration: Without written permission from original manufacturer, reproduction, transfer, distribution or storage of part or all of the contents in this document in any form is prohibited. The company reserves rights to make any changes and improvements to the product described in this document without prior notice. Flaircomm Technologies Inc. 2 Address：No 211 North Urumchi Road, Suite 616, Shanghai, PRC, 200040 Telephone：86-21-62495778, 86-21-62496778, 86-21-62496878 Fax：86-21-62494858 www.flaircomm.com . This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/ TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. RF exposure warning · The equipment complies with FCC RF exposure limits set forth for an uncontrolled environment. The equipment must not be co-located or operating in conjunction with any other antenna or transmitter. Warning：Users should not make changes or modify the device in any way. Changes or modifications without expressly approved by the party responsible for compliance could void the user’s authority to operate the device. Flaircomm Technologies Inc. 3 Address：No 211 North Urumchi Road, Suite 616, Shanghai, PRC, 200040 Telephone：86-21-62495778, 86-21-62496778, 86-21-62496878 Fax：86-21-62494858 www.flaircomm.com . ------ Introduction ----------------------------------------------- Bluetooth Technology Bluetooth is an internationally standardized technology supporting short distance wireless communications. Any two Bluetooth-compatible equipments, such as mobile phone, PDA、PC, headset, mouse, keyboards, printer, etc. can wirelessly communicate with each other via Bluetooth connection. To ensure worldwide compatibility, Bluetooth operates on the globally available ISM (Industrial Scientific and Medical) frequency band. Within 2.4 GHz and 2.48 GHz, Bluetooth transmits data up to either 10 meters (CLASS II mode) or 100 meters (CLASS I mode) using 79 frequency hopping channels. Though line-of-sight is not required, Bluetooth connections could be subject to interferences from obstructions such as walls, human bodies, and other electronic devices. In addition, due to variations on product implementation, it is likely that Bluetooth equipments from different manufactures have interoperability issues. In that case, you may consult with manufactures to check product compatibility. Note that, there could be some restrictions imposing on using Bluetooth devices in some countries. Please check with your local authorities. Bluetooth AV Adapter Flaircomm Bluetooth AV adapter model BlueTone™BTAV101 was developed using the latest Bluetooth technologies. This portable, stylish, mini-sized, and lightweight product offers the fastest shot-cut and most cost- effective solution to add Bluetooth wireless connection capability to various wireless-incapable multimedia players such as MP3 player, PMP, TV, DVD player, WALKMAN/DISKMAN, handset with MP3 function, etc., via stereo sound output jack. Using a Bluetooth stereo headset (such as Flaircomm’s BlueTone TM Model BTSHS102), consumers can listen to the music without wiring between the headset and the multimedia player, and thus enjoy the great freedom brought from the state-of-art wireless communications technologies. Product Features ™ Use with any multimedia player such as MPS, PMP, WALKMAN/DISKMAN, etc. with stereo output ™ Allow user to enjoy music wirelessly with a companion Bluetooth stereo headset ™ Bluetooth 1.2 specification compliant, interference-tolerable with WLAN devices ™ Data rate up to 723Kbps. ™ Class II, 10 meters (33 feet) range. ™ Long playing and standby time ™ Robust performance, accurate and sensible search of devices in range ™ User friendly and plug-and-play ™ Portable, stylish, lightweight, and mini-sized Overview Flaircomm Technologies Inc. 4 Address：No 211 North Urumchi Road, Suite 616, Shanghai, PRC, 200040 Telephone：86-21-62495778, 86-21-62496778, 86-21-62496878 Fax：86-21-62494858 www.flaircomm.com . 1. Key, for operating the device 2. Charging Port or USB Port, for connecting to the travel charger or USB cable 3. Red/Blue LED, for indicating device status 4. Line-in port, for connecting to the line-in jack of the multimedia player or PC ------Getting Started----------------------------------------------- Battery Charging and Usage Battery Charging Connect the …

Text truncated - open the document above for the full version.

Data June 14, 2006 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 SuZhou EMC laboratory of QuitTek Technology (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China To Whom It May Concern: The Shanghai Flaircomm Technologies, the undersigned, hereby authorizes QuitTek Technology (Suzhou) Co., Ltd., to act on the behalf of the Shanghai Flaircomm Technologies. Solely in matters relating to the application for an FCC equipment authorization for FCC ID: TQ6BTAV101 including the signing of documents in connection with this Application. Necessary acts carried out by Shanghai Flaircomm Technologies. On out behalf of the Shanghai Flaircomm Technologies. In connection with the Application shall have the same effect as acts of Shanghai Flaircomm Technologies. Shanghai Flaircomm Technologies. Also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a) Yours Sincerely, Mr Dawen Hardware engineer

Shanghai Flaircomm Technologies Date: June 6, 2006 Federal Communications Commission Authorization and Evaluation Division FCC ID: TQ6BTAV101 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Block Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Dawen Yang/engineer Shanghai Flaircomm Technologies

Bluetooth AV Adapter (BTAV101) (1) EUT Photo (2) EUT Photo

Bluetooth AV Adapter (BTAV101) FCC Label Position FCC Label Position

Bluetooth AV Adapter (BTAV101) (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo

Report No. 066L049 Page: 1 of 3 Version: 1.0 RF Exposure Evaluation declaration Product Name : Bluetooth AV Adapter Model No. : BTAV101 FCC ID. : TQ6BTAV101 Applicant : Shanghai Flaircomm Technologies Address : No211 North Urumqi Road, Suite 616, Shanghai 200040 P.R. China Date of Receipt : April 20, 2006 Date of Declaration: June 13, 2006 Report No. : 066L049 The declaration results relate only to the samples calculated. The declaration shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No. 066L049 Page: 2 of 3 Version: 1.0 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. Report No. 066L049 Page: 3 of 3 Version: 1.0 1.3. Test Result of RF Exposure Evaluation Product : Bluetooth AV Adapter Test Item : RF Exposure Evaluation Test Site : AC-3 Test Mode : Transmitter Antenna Gain Antenna Gain: The maximum Gain measured in fully anechoic chamber is 0dBi or 1.0 in linear scale. Output Power Into Antenna & RF Exposure Evaluation Distance: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 2.5 cm (mW/cm 2 ) 1 2402.00 0.6950 0.0088 6 2441.00 0.8072 0.0103 11 2480.00 0.7834 0.0100 The power density Pd (4th column) at a distance of 2.5 cm calculated from the Friis transmission formula is far below the limit of 1 mW/cm 2 .

Bluetooth AV Adapter (BTAV101) Test Mode : Mode 1: Transmitter Description : Front View of Conducted Test Test Mode : Mode 1: Transmitter Description : Back View of Conducted Test Test Mode : Mode 1: Transmitter Description : Front View of Radiated Test for Under 1GHz Test Mode : Mode 1: Transmitter Description : Back View of Radiated Test for Under 1GHz Test Mode : Mode 1: Transmitter Description : Front View of Radiated Test for Above 1GHz Test Mode : Mode 1: Transmitter Description : Back View of Radiated Test for Above 1GHz
