TX2-RTL8188CUS802.11 b/g/n RTL8188CUS Slim Solo Card

Realtek Semiconductor Corp.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Nov 23, 2010
Application Purpose: Original Equipment
Date of Application: Nov 23, 2010
Equipment Note: 802.11 b/g/n RTL8188CUS Slim Solo Card
Frequency Range: 2422.00000000 - 2452.00000000
Company: Realtek Semiconductor Corp.
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

RTL8188CUS Slim Module Solo Card User’s Manual Rev. 1.0 15 Oct 2010 Realtek Semiconductor Corp. No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Tel.: +886-3-578-0211. Fax: +886-3-577-6047 www.realtek.com.tw RTL8188CUS Slim Module Solo Card User Manual COPYRIGHT ©2009 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of Realtek Semiconductor Corp. DISCLAIMER Realtek provides this document “as is”, without warranty of any kind, neither expressed nor implied, including, but not limited to, the particular purpose. Realtek may make improvements and/or changes in this document or in the product described in this document at any time. This document could include technical inaccuracies or typographical errors. TRADEMARKS Realtek is a trademark of Realtek Semiconductor Corporation. Other names mentioned in this document are trademarks/registered trademarks of their respective owners. USING THIS DOCUMENT This document is intended for the software engineer’s reference and provides detailed programming information. Though every effort has been made to ensure that this document is current and accurate, more information may have become available subsequent to the production of this guide. In that event, please contact your Realtek representative for additional information that may help in the development process. ii Rev.1.0 RTL8188CUS Slim Module Solo Card User Manual Table of Contents 1. GENERAL DESCRIPTION................................................................................................................................................1 1.1. RTL8188CUS.................................................................................................................................................................1 2. FEATURES...........................................................................................................................................................................2 2.1. RTL8188CUS.................................................................................................................................................................2 PRODUCT SPECIFICATIONS .................................................................................................................................................4 2.3. CONNECTER PIN ASSIGNMENT.........................................................................................................................................4 2.4. MECHANICAL..................................................................................................................................................................5 2.5. ENVIRONMENTAL............................................................................................................................................................6 2.5.1. Operating ...............................................................................................................................................................6 2.5.2. Storage....................................................................................................................................................................6 2.6. FUNCTIONAL SPECIFICATIONS.........................................................................................................................................7 2.7. WARNING........................................................................................................................................................................8 4.5.1 Federal Communication Commission Interference Statement ......................................................................................8 4.5.2 Industry Canada Statement ........................................................................................................................................10 4.5.3 NCC警語................................................................................................................................................................... 11 List of Tables TABLE 1. CONNECTER PIN ASSIGNMENT.................................................................................................................................4 TABLE 2. FUNCTIONAL SPECIFICATIONS.......................................................................................................................................7 List of Figures FIGURE 1. RTL8188CUS SLIM MODULE MECHANICAL SPECIFICATION.......................................................................................5 iii Rev.1.0 RTL8188CUS Slim Module Solo Card User Manual 1 Rev.1.0 1. General Description 1.1. RTL8188CUS The Realtek RTL8188CUS is a highly integrated single-chip Wireless LAN (WLAN) controller compatible with the IEEE 802.11n specification. It combines a MAC, a 1T1R capable baseband, and RF in a single chip. The RTL8188CUS provides a complete solution for a high-performance wireless client. The RTL8188CUS baseband implements Multiple Input, Multiple Output (MIMO) Orthogonal Frequency Division Multiplexing (OFDM) with one transmit and one receive path (1T1R). Features include one spatial stream transmission, short Guard Interval (GI) of 400ns, spatial spreading, and support for both 20MHz and 40MHz channel bandwidth. For legacy compatibility, Direct Sequence Spread Spectrum (DSSS), Complementary Code Keying (CCK) and OFDM baseband processing are included to support all IEEE 802.11b, and 802.11g data rates. Differential phase shift keying modulation schemes, DBPSK and DQPSK with data scrambling capability are available, and CCK provides support for legacy data rates, with long or short preamble. The high speed FFT/IFFT paths, combined with BPSK, QPSK, 16QAM, and 64QAM modulation of the individual subcarriers, and rate compatible punctured convolutional …

Text truncated - open the document above for the full version.

Cover Letter(s)

Page No. : 18 Limited Module Approval Request Letter Subject: Limited Module Approval Date: 2010/11/2 FCC ID: TX2-RTL8188CUS Dear Reviewer, We, Sporton International Inc., are authorized by Realtek Semiconductor Corp. to have their state-of-the-art 802.11b/g/n RTL8188CUS Slim Solo Card approved under limited module approval authorization. The application of this module is specified to mobile host equipment. The requirements regulated in Public Notice DA00-1407 have been fulfilled and clearly explained below. 1. The requirement of RF shielding: The shielding of the radio portion can be demonstrated in exhibition External Photo. 2. The requirement of buffered inputs: Buffered data inputs stage has been integrated in chip RTL8188CUS. 3. The requirement of power supply regulation: No power regulator can provide stability power source. But specific of hosts have 3.3Vdc regulator to provide stability power via mini-PCI interface to EUT. 4. The requirements of section 15.203 and 15.204(C): The requirements of antenna connector and spurious emission have been fulfilled. Please reference the exhibition Test Report. 5. The requirement of stand-alone test configuration: Please reference exhibition Test Configuration Photo for the stand-alone test configuration. 6. The requirement of labeling: The instruction on the labeling rule of the end product has been stated in the users manual of this module. Please also see the exhibition Label Sample. 7. The requirement of compliance on specific rule or operating requirements: The required FCC rule has been fulfilled and all the instructions for maintaining compliance has been clearly stated in the Users Manual. 8. The requirement of RF exposure: Please refer exhibition RF Exposure for the compliance of MPE RF exposure rule. Please do not hesitate to contact me for any questions of this request letter. Thank you. Company name : Sporton International Inc. Company Address : No.8, Lane 724, Bo-ai St., Jhubei City, Hsinchu County 302, Taiwan, R.O.C. Signature : Name : Leo Huang Job Title : Manager

External Photos

SPORTON International Inc. PAGE NUMBER : A1 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 APPENDIX A. Photographs of EUT SPORTON International Inc. PAGE NUMBER : A2 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 <Main Source> EUT + Ant. A (Printed Antenna) SPORTON International Inc. PAGE NUMBER : A3 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 <Main Source> EUT + Ant. B (PIFA Antenna) SPORTON International Inc. PAGE NUMBER : A4 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 <Second Source> EUT + Ant. A (Printed Antenna) SPORTON International Inc. PAGE NUMBER : A5 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 <Second Source> EUT + Ant. B (PIFA Antenna) SPORTON International Inc. PAGE NUMBER : A6 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A7 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255

ID Label/Location Info

Realtek RTL8188CUS Label description Label location Label sample Equality Ratio: 100% FCC ID: TX2-RTL8188CUS

Internal Photos

SPORTON International Inc. PAGE NUMBER : A1 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 APPENDIX A. Photographs of EUT <Main Source> EUT + Ant. A (Printed Antenna) SPORTON International Inc. PAGE NUMBER : A2 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A3 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A4 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 <Main Source> EUT + Ant. B (PIFA Antenna) SPORTON International Inc. PAGE NUMBER : A5 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A6 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A7 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 <Second Source> EUT + Ant. A (Printed Antenna) SPORTON International Inc. PAGE NUMBER : A8 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A9 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A10 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 <Second Source> EUT + Ant. B (PIFA Antenna) SPORTON International Inc. PAGE NUMBER : A11 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A12 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A13 OF A13 TEL : 886-2-2696-2468 ISSUED DATE : Nov. 15, 2010 FAX : 886-2-2696-2255

RF Exposure Info

Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 1 of 3 Appendix C. Maximum Permissible Exposure Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 2 of 3 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP××30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP × ×× From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 3 of 3 1.3. Calculated Result and Limit <For Main Source – Mode 1 with Printed Antenna>: Antenna Type : Printed Antenna Max Peak Output Power for IEEE 802.11g Ant. A: 25.68 dBm Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 2.72 1.8707 25.6800 369.8282 0.137705 1 Complies <For Main Source – Mode 2 with PIFA Antenna>: Antenna Type : PIFA Antenna Max Conducted Power for IEEE 802.11g Ant. B: 26.40 dBm Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 3.90 2.4547 26.4000 436.5158 0.213280 1 Complies <For Second Source – Mode 1 with Printed Antenna>: Antenna Type : Printed Antenna Max Conducted Power for IEEE 802.11g Ant. A: 25.63 dBm Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 2.72 1.8707 25.6300 365.5948 0.136129 1 Complies <For Second Source – Mode 2 with PIFA Antenna>: Antenna Type : PIFA Antenna Max Conducted Power for IEEE 802.11n MCS0 20MHz Ant. B: 26.11 dBm Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 3.90 2.4547 26.1100 408.3194 0.199503 1 Complies

Test Report

SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: 01 FCC RADIO TEST REPORT Applicant’s company Realtek Semiconductor Corp. Applicant Address No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan FCC ID TX2-RTL8188CUS Manufacturer’s company Realtek Semiconductor Corp. Manufacturer Address No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Product Name 802.11b/g/n RTL8188CUS Slim Solo Card Brand Name Realtek Model Name RTL8188CUS Test Rule 47 CFR FCC Part 15 Subpart C § 15.247 Test Freq. Range 2400 ~ 2483.5MHz Received Date Sep. 30, 2010 Final Test Date Oct. 30, 2010 Submission Type Original Equipment Statement Test result included in this report is for the IEEE 802.11n and IEEE 802.11b/g part of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR0O0635-01 Report Format Version: 01 Page No. : iof ii FCC ID: TX2-RTL8188CUS Issued Date : Nov. 12, 2010 Table of Contents 1. CERTIFICATE OF COMPLIANCE ......................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT .......................................................................................................................... 2 3. GENERAL INFORMATION .................................................................................................................................. 3 3.1. Product Details....................................................................................................................................................................................3 3.2. Accessories .........................................................................................................................................................................................5 3.3. Table for Filed Antenna.......................................................................................................................................................................5 3.4. Table for Carrier Frequencies .............................................................................................................................................................5 3.5. Table for Test Modes ...........................................................................................................................................................................6 3.6. Table for Testing Locations..................................................................................................................................................................7 3.7. Table for Supporting Units ...................................................................................................................................................................7 3.8. Table for Parameters of Test Software Setting .....................................................................................................................................8 3.9. Test Configurations ...........................................................................................................................................................................10 4. TEST RESULT ................................................................................................................................................... 13 4.1. AC Power Line Conducted Emissions Measurement.........................................................................................................................13 4.2. Conducted Peak Output Power Measurement.................................................................................................................................23 4.3. Power Spectral Density Measurement ..............................................................................................................................................32 4.4. 6dB Spectrum Bandwidth Measurement ..........................................................................................................................................53 4.5. Radiated Emissions Measurement ....................................................................................................................................................74 4.6. Band Edge Emissions Measurement ...............................................................................................................................................134 4.7. Antenna Requirements ...................................................................................................................................................................167 5. LIST OF MEASURING EQUIPMENTS ................................................................................................................. 168 6. TEST LOCATION............................................................................................................................................ 170 7. TAF CERTIFICATE OF ACCREDITATION ........................................................................................................... 171 APPENDIX A. PHOTOGRAPHS OF EUT.........................................................................................................A1 ~ A19 APPENDIX B. TEST PHOTOS........................................................................................................................ B1 ~ B1 4 APPENDIX C. MAXIMUM PERMISSIBLE EXPOSURE............…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 1 of 14 Appendix B. Test Photos Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 2 of 14 1. Photographs of Conducted Emissions Test Configuration <For Main Source, Second Source – Mode 1>: FRONT VIEW REAR VIEW Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 3 of 14 <For Main Source, Second Source – Mode 2>: FRONT VIEW REAR VIEW Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 4 of 14 2. Photographs of Radiated Emissions Test Configuration Test Configuration: 9kHz ~30MHz FRONT VIEW REAR VIEW Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 5 of 14 Test Configuration: 30MHz~1GHz <Main Source – Mode 1>: FRONT VIEW REAR VIEW Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 6 of 14 SIDE VIEW Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 7 of 14 Test Configuration: 30MHz~1GHz <Main Source – Mode 2>: FRONT VIEW REAR VIEW Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 8 of 14 SIDE VIEW Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 9 of 14 Test Configuration: 30MHz~1GHz <Second Source – Mode 1>: FRONT VIEW REAR VIEW Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 10 of 14 SIDE VIEW Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 11 of 14 Test Configuration: 30MHz~1GHz <Second Source – Mode 2>: FRONT VIEW REAR VIEW Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 12 of 14 SIDE VIEW Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 13 of 14 Test Configuration: Above 1GHz < Main Source, Second Source – Mode 1>: FRONT VIEW REAR VIEW Report No.: FR0O0635-01 FCC ID: TX2-RTL8188CUS Page No. : 14 of 14 Test Configuration: Above 1GHz < Main Source, Second Source – Mode 2>: FRONT VIEW REAR VIEW

Contact Information

Applicant

Dana Liaw(Project Manager)

[email protected]886-3-5780211Fax: 886-3-5776598

Test Firm

Sporton International Inc.Alex Chen

[email protected]886-3-327-3456Fax: 886-3-327-0973

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.42 GHz - 2.45 GHz	330.00 mW

Modular Type

Limited Single Modular Approval

Confidentiality

Long Term

Grant Notes

Power Output listed is conducted. Approval is limited to OEM installation only, and the host in which this module is integrated should provide stable 3.3 VDC power to this module through regulator circuit. The only antennas approved for use with this module are those documented in the filing, and must be installed in the manner specified therein. This device approved for use in products which operate as a mobile transmitting device with respect to Rule Part 2.1091. This modular device and its antenna must operate with a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. OEM integrators must be provided with antenna installation instructions. Compliance of this module in its final configuration is the responsibility of Grantee. Separate approval is required for portable configurations with respect to Rule Part 2.1093. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 1T1R Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 2422 to 2452 MHz.
