TX2-RTL8723BS802.11b/g/n RTL8723BS Combo module

Realtek Semiconductor Corp.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: May 13, 2014
Application Purpose: Original Equipment
Date of Application: May 13, 2014
Equipment Note: 802.11b/g/n RTL8723BS Combo module
Frequency Range: 2402.00000000 - 2480.00000000
Company: Realtek Semiconductor Corp.
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Combo NGFF1216 User’s Manual Rev. 1.0 20 March 2014 Realtek Semiconductor Corp. No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Tel.: +886-3-578-0211. Fax: +886-3-577-6047 www.realtek.com.tw RTL8723BS RTL8723BS Combo NGFF1216 User Manual ii Rev.1.0 COPYRIGHT ©2013 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of Realtek Semiconductor Corp. DISCLAIMER Realtek provides this document “as is”, without warranty of any kind, neither expressed nor implied, including, but not limited to, the particular purpose. Realtek may make improvements and/or changes in this document or in the product described in this document at any time. This document could include technical inaccuracies or typographical errors. TRADEMARKS Realtek is a trademark of Realtek Semiconductor Corporation. Other names mentioned in this document are trademarks/registered trademarks of their respective owners. USING THIS DOCUMENT This document is intended for the software engineer’s reference and provides detailed programming information. Though every effort has been made to ensure that this document is current and accurate, more information may have become available subsequent to the production of this guide. In that event, please contact your Realtek representative for additional information that may help in the development process. RTL8723BS Combo NGFF1216 User Manual iii Rev.1.0 Table of Contents 1. GENERAL DESCRIPTION................................................................................................................................................ 4 1.1. RTL8723BS .................................................................................................................................................................... 4 1.2. ENVIRONMENTAL ............................................................................................................................................................. 4 1.2.1. Operating ............................................................................................................................................................... 4 1.2.2. Storage.................................................................................................................................................................... 4 1.3. FUNCTIONAL SPECIFICATIONS .......................................................................................................................................... 4 1.4. WARNING......................................................................................................................................................................... 6 1.4.1 Federal Communication Commission Interference Statement ...................................................................................... 6 1.4.2 Industry Canada Statement .......................................................................................................................................... 7 1.4.3 NCC警語 ................................................................................................................................................................... 10 1.4.4 Japan Statement ......................................................................................................................................................... 10 List of Tables TABLE 2. FUNCTIONAL SPECIFICATIONS ......................................................................................................................................... 4 List of Figures RTL8723BS Combo NGFF1216 User Manual 4 Rev.1.0 1. General Description 1.1. RTL8723BS The Realtek RTL8723BS is a highly integrated single-chip 802.11n Wireless LAN (WLAN) SDIO network interface controller with integrated Bluetooth 2.1/3/0/4.0 USB interface controller. It combines a WLAN MAC, a 1T1R capable WLAN baseband, and RF in s single chip. The RTL8723BS provides a complete solution for a high-performance integrated wireless and Bluetooth device. The integration provides better coordination between 802.11 and Bluetooth, and with sophisticated dynamic power control and packet traffic arbitration, RTL8723BS is able to provide the best coexistence performance. RTL8723BS also integrates RF/PA/LNA for both 802.11n and Bluetooth so that the number of external components is reduced to minimum. The 802.11 part supports 150Mbps PHY rate and delivers reliable throughput from an extended distance. The Bluetooth part supports latest 3.0+HS/4.0+LE operation and provides smooth user experience under all usage scenarios. Optimized RF architecture and baseband algorithms provide superb performance and lowest power consumption. 1.2. Environmental 1.2.1. Operating Operating Temperature: 0 to 70 C Relative Humidity: 5-90% (non-condensing) 1.2.2. Storage Temperature: -55 to 125 C Relevant Humidity: 5-95% (non-condensing) 1.3. Functional Specifications Table 1. Functional Specifications Standards WiFi: IEEE 802.11b, IEEE 802.11g, Draft IEEE 802.11n, IEEE 802.11d, IEEE 802.11e, IEEE 802.11h, IEEE 802.11i BT: BT v3.0, v4.0 Bus Interface WiFi: SDIO BT: UART Form Factor NGFF1216 Data Rate 802.11b: 11, 5.5, 2, 1 Mbps; 802.11g: RTL8723BS Combo NGFF1216 User Manual 5 Rev.1.0 54, 48, 36, 24, 18, 12, 9, 6 Mbps 802.11n: MCS 0 to 7 for HT20MHz; MCS 0 to 7 for HT40MHz BT: 1/2/3 Mbps Media Access Control WiFi: CSMA/CA with ACK WiFi + BT: AFH, Time Division Modulation Techniques 802.11b: CCK, DQPSK, DBPSK 802.11g: 64 QAM, 16 QAM, QPSK, BPSK 802.11n: BPSK, QPSK, 16-QAM, 64-QAM BT: GFSK, /4 DQPSK, 8DPSK Network Architecture WiFi: Ad-hoc mode (Peer-to-Peer ) Infrastructure mode Operating Channel WiFi 2.4GHz: 11: (Ch. 1-11) – United States 13: (Ch. 1-13) – Europe 13: (Ch. 1-14) – Japan BT 2.4GHz: Ch. 0 ~78 Frequency Range 2.400GHz ~ 2.4835 GHz Security WiFi : WP…

Text truncated - open the document above for the full version.

Cover Letter(s)

Page No. : 3 Realtek Semiconductor Corp. No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Tel: 886-3-5780211 / Fax: 886-3-5776598 Confidential Letter Date: 2014/4/7 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Confidentiality Request for FCC ID：TX2-RTL8723BS Gentlemen: The form 731 and application have been electronically submitted and any attachments will be up loaded to your web site to be used in obtaining a grant of certification. Short-term Pursuant to DA 04-1705 of the Commission’s pubic notice, we request short-term confidential treatment for the following information until 180 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: 1. External Photos 2. Internal Photos 3. Test Setup photos 4. User’s Manual Permanent Realtek Semiconductor Corp. requests that the material in the following files be withheld from public disclosure in accordance with Section 0.457 of the Commission’s Rules, 47 C.F.R. 0.459, following grant of the application. 1. Block Diagram 2. Circuit Diagram 3. Operational Description Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Note: The registered grantee contact is not available, Judy Hsu is signing for grantee contact. He/She can be reached at email: [email protected]. Sincerely, Applicant’s company name : Realtek Semiconductor Corp. Applicant’s company address : No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Signature : Signed for Dana Liaw Name and Job Title : Dana Liaw / Project Manager E-Mail : [email protected] Page No. : 4 Tel. : 886-3-5780211

Cover Letter(s)

Page No. : 6 Realtek Semiconductor Corp. No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Tel: 886-3-5780211 / Fax: 886-3-5776598 Ad Hoc Mode Function Declaration Date: 2014/4/7 FCC ID：TX2-RTL8723BS To Whom it may concern, We, the undersigned, declare that the EUT (Model Name: RTL8723BS) doesn’t have Ad Hoc function on “non-US/Canada frequencies”. Regards, Note: The registered grantee contact is not available, Judy Hsu is signing for grantee contact. He/She can be reached at email: [email protected]. FCC Grantee contact person information. Applicant’s company name : Realtek Semiconductor Corp. Applicant’s company address : No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Signature : Signed for Dana Liaw Name and Job Title : Dana Liaw / Project Manager E-Mail : [email protected] Tel. : 886-3-5780211

Cover Letter(s)

Page No. : 23 Module Approval Request Letter Subject: Module Approval Date: 2014/4/24 FCC ID: TX2-RTL8723BS Dear Reviewer, We, Sporton International Inc., are authorized by Realtek Semiconductor Corp. to have their state-of-the-art 802.11b/g/n RTL8723BS Combo module approved under module approval authorization. The application of this module is specified to mobile host equipment. The requirements regulated in Public Notice DA00-1407 have been fulfilled and clearly explained below. 1. The requirement of RF shielding: The shielding of the radio portion can be demonstrated in exhibition External Photo. 2. The requirement of buffered inputs: Buffered data inputs stage has been integrated in chip RTL8723BS. 3. The requirement of power supply regulation: The power regulator has been integrated in chip RTL8723BS. 4. The requirements of section 15.203 and 15.204(C): The requirements of antenna connector and spurious emission have been fulfilled. Please reference the exhibition Test Report. 5. The requirement of stand-alone test configuration: Please reference exhibition Test Configuration Photo for the stand-alone test configuration. 6. The requirement of labeling: The instruction on the labeling rule of the end product has been stated in the users manual of this module. Please also see the exhibition Label Sample. 7. The requirement of compliance on specific rule or operating requirements: The required FCC rule has been fulfilled and all the instructions for maintaining compliance has been clearly stated in the Users Manual. 8. The requirement of RF exposure: Please refer exhibition RF Exposure for the compliance of MPE RF exposure rule. Please do not hesitate to contact me for any questions of this request letter. Thank you. Company name : Sporton International Inc. Company Address : No.8, Lane 724, Bo-ai St., Jhubei City, Hsinchu County 302, Taiwan, R.O.C. Signature : Name : Leo Huang Job Title : Manager

Cover Letter(s)

Page No. : 2 Realtek Semiconductor Corp. No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Tel: 886-3-5780211 / Fax: 886-3-5776598 Power of Attorney Date: 2014/4/7 Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Sporton International Inc. Address : No.8, Lane 724, Bo-ai St., Jhubei City, HsinChu County 302, Taiwan, R.O.C. Name : Leo Huang Job Title : Manager e-mail : [email protected] I am therefore responsible for the contents of the application. Brand name and model type of the specified radio equipment: REALTEK / RTL8723BS FCC ID: TX2-RTL8723BS Product name: 802.11b/g/n RTL8723BS Combo module Note: The registered grantee contact is not available, Judy Hsu is signing for grantee contact. He/She can be reached at email: [email protected]. FCC Grantee contact person information. Applicant’s company name : Realtek Semiconductor Corp. Applicant’s company address : No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Signature : Signed for Dana Liaw Name and Job Title : Dana Liaw / Project Manager E-Mail : [email protected] Tel. : 886-3-5780211

External Photos

Report No.: 431858 SPORTON International Inc. PAGE NUMBER : 1 OF 4 TEL : 886-3-327-3456 ISSUED DATE : Apr. 23, 2014 FAX : 886-3-327-0973 Photographs of EUT EUT1&EUT2 Report No.: 431858 SPORTON International Inc. PAGE NUMBER : 2 OF 4 TEL : 886-3-327-3456 ISSUED DATE : Apr. 23, 2014 FAX : 886-3-327-0973 EUT3 Report No.: 431858 SPORTON International Inc. PAGE NUMBER : 3 OF 4 TEL : 886-3-327-3456 ISSUED DATE : Apr. 23, 2014 FAX : 886-3-327-0973 Antenna Report No.: 431858 SPORTON International Inc. PAGE NUMBER : 4 OF 4 TEL : 886-3-327-3456 ISSUED DATE : Apr. 23, 2014 FAX : 886-3-327-0973

ID Label/Location Info

Realtek 802.11b/g/n RTL8723BS Combo module Label description Label location Label sample Japan/NCC Equality Ratio: 300% Equality Ratio: 100% 1.Pantone：White ground and black work 2.Material：特多龍 3. Telec Logo : 5 * 5mm FCC/IC/CE Equality Ratio: 300% Equality Ratio: 100% 802.11b/g/n RTL8723BS Combo module Model: RTL8723BS Input：DC3.3V350mA 11m 11m LABEL HERE Made in Taiwan 802.11b/g/n RTL8723BS Combo module Model: RTL8723BS FCC ID: TX2-RTL8723BS IC: 6317A-RTL8723BS Input：DC3.3V350mA 1mm 11m

Internal Photos

Report No.: 431858 SPORTON International Inc. PAGE NUMBER : 1 OF 3 TEL : 886-3-327-3456 ISSUED DATE : Apr. 23, 2014 FAX : 886-3-327-0973 Photographs of EUT EUT1&EUT2 Report No.: 431858 SPORTON International Inc. PAGE NUMBER : 2 OF 3 TEL : 886-3-327-3456 ISSUED DATE : Apr. 23, 2014 FAX : 886-3-327-0973 EUT3 Report No.: 431858 SPORTON International Inc. PAGE NUMBER : 3 OF 3 TEL : 886-3-327-3456 ISSUED DATE : Apr. 23, 2014 FAX : 886-3-327-0973

Parts List/Tune Up Info

Report No.: FR431858 Page No. : D1 of D14 Appendix D. Antenna List Report No.: FR431858 Page No. : D2 of D14 Table for Filed Antenna No. Brand Ant. Type Con. Type Peak Gain (dBi) Model No. 1 LYNwave PIFA IPEX MHF4 TX1: 3.5 TX1: ALA110-222050-300011 2 FVC PIFA IPEX TX1: 1.58 TX2: 1.75 K05007012102 3 FVC PIFA IPEX TX1: 2.7 TX2: 2.19 K05007013402 4 FVC PIFA IPEX TX1: 1.51 TX2: 2.04 K05007012803 5 FVC PIFA IPEX TX1: 2.53 TX2: 2.28 K05007015501 6 FVC PIFA IPEX TX1: 2.85 TX2: 1.59 K05007014501 7 FVC PIFA IPEX TX1: 3.00 TX2: 1.52 K05007014201 8 FVC PIFA IPEX TX1: 1.85 TX2: 1.94 TX1: K05007014901 TX2: K05007015001 9 ACON PIFA IPEX TX1: -0.57 TX2: -1.61 TX1: APP6P-700900 TX2: APP6P-700900 10 JEM PIFA IPEX TX1: 2.23 TX2: 2.21 1510-0122-0022(IA-120073) 11 WGT PIFA IPEX TX1: 3.2 TX2 :2.76 TX1: SKX51WMPB01+C TX2: SKX51WMPB02+C 12 Yageo PIFA IPEX TX1: 0.24 TX2: 0.59 TX1: ANTA0ZP08021WLAN1 TX2: ANTA0ZP08021WLAN2 13 WGT PIFA IPEX TX1: 1.79 TX2: 0.66 TX1: SK 81WMPB01+A TX2: SK 81WMPB02+A 14 WGT PIFA IPEX TX1: 1.36 TX2: 2.88 SKW2UWMPB01+A 15 WGT PIFA IPEX TX1: 1.85 TX2: 3.14 SKW31WMPB01+A 16 WGT PIFA IPEX TX1: -1.84 TX2: -2.93 TX1: SKM11WMPB03+A TX2: SKM11WMPB02+D 17 WGT PIFA IPEX TX1: 2.46 TX2: 2.91 SKC45WMPB03+B 18 WGT PIFA IPEX TX1: 1.25 TX2: 3.17 SKW24WMPB01+B Report No.: FR431858 Page No. : D3 of D14 19 WGT PIFA IPEX TX1: 0.76 TX2: 0.09 TX1: SK555WMPB01+B TX2: SK555WMPB02+B 20 ACON PIFA IPEX TX1: 1.94 TX2: 1.40 TX1: DQ60APP6P81 TX2: DQ60APP6P80 21 HONGLIN PIFA IPEX TX1: -0.50 TX2: -0.19 TX1: DQ602352300 TX2: DQ602352200 22 Amphenol PIFA IPEX TX1: 1.82 TX2: 2.64 TX1: DC330016100 TX2: DC330016110 23 Amphenol PIFA IPEX TX1: -0.35 TX2: 0.59 TX1: DC330016180 TX2: DC330016190 24 Luxshare-ICT PIFA IPEX TX1: -0.07 TX2: 0.32 TX1: DC330015Z80 TX2: DC330015Z90 25 Luxshare-ICT PIFA IPEX TX1: -1.45 TX2: -0.37 TX1: DC330015Z00 TX2: DC330015Z10 26 Amphenol PIFA IPEX TX1: 1.64 TX2: 1.47 TX1: DC330016160 TX2: DC330016170 27 Luxshare-ICT PIFA IPEX TX1: -0.38 TX2: -0.60 TX1: DC330015Z60 TX2: DC330015Z70 28 Amphenol PIFA IPEX TX1: 1.67 TX2: 2.26 TX1: DC3300161A0 TX2: DC3300161B0 29 Luxshare-ICT PIFA IPEX TX1: 1.1 TX2: 0.1 TX1: DC330015ZA0 TX2: DC330015ZB0 30 Amphenol PIFA IPEX TX1: -0.22 TX2: -1.73 TX1: DC330016200 TX2: DC330016210 31 Amphenol PIFA IPEX TX1: -2.62 TX2: -0.70 TX1: DC330016220 TX2: DC330016230 32 Luxshare-ICT PIFA IPEX TX1: -0.94 TX2: -1.11 TX1: DC330016020 TX2: DC330016030 33 Luxshare-ICT PIFA IPEX TX1: -4.49 TX2: -1.68 TX1: DC330016000 TX2: DC330016010 34 Amphenol PIFA IPEX TX1: -0.46 TX2: -0.98 TX1: DC330016260 TX2: DC330016270 35 Luxshare-ICT PIFA IPEX TX1: -0.43 TX2: 0.84 TX1: DC330016060 TX2: DC330016070 36 HIGH-TEK PIFA IPEX TX1: -0.69 TX2: -0.61 TX1: DC33001C100 TX2: DC33001C100 37 JESS-LINK PIFA IPEX TX1: -1.90 TX2: -0.98 TX1: DC33001AX00 TX2: DC33001AX00 Report No.: FR431858 Page No. : D4 of D14 38 YAGEO PIFA IPEX TX1: -0.27 TX2: -0.88 TX1: 25.90AH8.021 TX2: 25.90AH7.021 39 ACON PIFA IPEX TX1: 0.96 TX2: 1.33 TX1: ATP6P-700000 TX2: ATP6P-700001 40 ACON PIFA IPEX TX1: 1.92 TX2: 2.20 TX1: APP6P-700853 TX2: APP6P-700854 41 ACON PIFA IPEX TX1: 1.20 TX2: 0.11 APP6P-700931 42 WNC PIFA IPEX TX1: 0.24 TX2: -0.58 TX1: 25.90AH8.001 TX2: 25.90AH7.001 43 ACON PIFA IPEX TX1: -0.84 TX2: -1.60 APP6P-700932 44 WNC PIFA IPEX TX1: 0.20 TX2: -0.60 81EAAS15.G01 (DC33001EK00) 45 Luxshared PIFA IPEX TX1: -0.77 L01RF035-DT-R 46 TE PIFA IPEX TX1: -0.63 TX2: -1.69 TX1: 25.90AC4.011 TX2: 25.90AC3.011 47 WNC PIFA IPEX TX1: 1.19 TX2: -0.14 TX1: 25.90AC4.001 TX2: 25.90AC3.001 48 WGT PIFA IPEX TX1: 1.05 TX2: -0.41 TX1: SK110WMPB01+A TX2: SK110WMPB02+A 49 WGT PIFA IPEX TX1: -1.61 TX2: -2.84 TX1: SKW23WMPB01+A TX2: SKW23WMPB02+A 50 WGT PIFA IPEX TX1: -0.66 TX2: 0.78 TX1: SK547WMPB01+A TX2: SK549WMPB02+A 51 WGT PIFA IPEX TX1: -0.93 TX2: 0.20 TX1: SK740WMPB01+A TX2: SK740WMPB02+A 52 WGT PIFA IPEX TX1: 3.03 TX2: 0.55 TX1: SK840WMPB01+B_SN TX2: SK840WMPB01+B_SN Report No.: FR431858 Page No. : D5 of D14 53 WNC PIFA IPEX TX1: -0.26 TX2: -0.67 TX1: 81EAAS15.G02 TX2: 81EAAS15.G02 54 WNC PIFA IPEX TX1: 0.89 TX2: 0.14 DC33001EK40 (81EAAS15.G05) 55 WNC PIFA IPEX TX1: -0.06 TX2: 0.25 TX1: 81.EL415.G28.X01 TX2: 81.EL415.G29.X01 56 TONGDA PIFA IPEX TX1: -0.57 TX2: 0.14 TX1: T-543-900100-12 TX2: T-543-900100-12 57 TONGDA PIFA IPEX TX1: -1.96 TX2: 0.11 TX1: DC33001F300 / T-543-900100-02 TX2: DC33001F300 / T-543-900100-02 58 TONGDA PIFA IPEX TX1: -0.37 TX2: 0.39 TX1: T-543-900100-01 TX2: T-543-90 0100-01 59 WGT PIFA IPEX TX1: 0.46 TX2: -0.79 TX1: SKCZTWMPB01+A TX2: SKCZTWMPB02+A 60 WGT PIFA IPEX TX1: 1.48 TX2: 1.15 TX1: SK670WMPB01+A TX2: SK670WMPB02+A 61 INPAQ PIFA IPEX TX1: -3.66 TX2: -1.78 TX1: WAPLB02082 TX2: WAPLB01046 62 SmartApproach PIFA IPEX TX1: -4.42 TX2: -4.71 TX1: SEECZA0001 TX2: SEECZA0002 63 WNC PIFA IPEX TX1: 0.26 TX2: -0.65 TX1: 81EAAS15.G13 TX2: 81EAAS15.G14 64 WNC PIFA IPEX TX1: 0.01 TX2: -0.36 TX1: 81EAAS15.G09 TX2: 81EAAS15.G10 65 ACON PIFA IPEX TX1: 1.84 TX2: 1.05 TX1: APP6P-700917 TX2: APP6P-700918 66 ACON PIFA IPEX TX1: 0.17 TX2: -1.20 TX1: APP6P-700915 TX2: APP6P-700916 67 JEM PIFA IPEX TX1: 2.13 TX2: 2.04 TX1: IA 120278 TX2: IA 120279 68 JEM PIFA IPEX TX1: 2.06 TX2: 2.77 IA-120007 69 JEM PIFA IPEX TX1: 1.60 TX2: 2.93 IA-120007 70 WGT PIFA IPEX TX1: 0.76 TX2: 0.46 TX1: SK94SWMPB01+B TX2: SK94SWMPB01+B 71 WGT PIFA IPEX TX1: 1.32 TX2: 1.86 TX1: SK94TWMPB01+B TX2: SK94TWMPB01+B Report No.: FR431858 Page No. : D6 of D14 72 WGT PIFA IPEX TX1: -0.03 TX2: -0.13 TX1: SK50SWMPB01+A TX2: SK50SWMPB02+A 73 ACON PIFA IPEX TX1: 0.84 TX2: -0.27 TX1: APM8P-700072 TX2: APM8P-700073 74 ACON PIFA IPEX TX1: 0.76 TX2: -0.52 TX1: APP8P-700461 TX2: APP8P-700462 75 ACON PIFA IPEX TX1: 1.74 TX2: 1.01 TX1: APM8P-700070 TX2: APM8P-700071 76 ACON PIFA IPEX TX1: 2.92 TX2: 0.06 TX1: APP8P-700463 TX2: APP8P-700464 77 HongLin PIFA IPEX TX1: -0.8 TX2: 0.72 TX1: 260-24018 TX2: 260-24017 78 WNC PIFA IPEX TX1: -0.85 TX2: -0.51 TX1: DC33001CA20 (81.EK515.G52) TX2: DC33001CA30 (81.EK515.G53) 79 ACON PIFA IPEX TX1: 0.82 TX2: 2.07 TX1: APP8P-7004…

Text truncated - open the document above for the full version.

RF Exposure Info

Report No.: FR431858 FCC ID: TX2-RTL8723BS Page No. : B1 of B3 Appendix B. Maximum Permissible Exposure Report No.: FR431858 FCC ID: TX2-RTL8723BS Page No. : B2 of B3 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Report No.: FR431858 FCC ID: TX2-RTL8723BS Page No. : B3 of B3 1.3. Calculated Result and Limit For 2.4GHz function: Antenna Type : PIFA Antenna Conducted Power for IEEE 802.11b: 16.45 dBm Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 3.50 2.2387 16.4500 44.1570 0.019677 1 Complies For Bluetooth function: Antenna Type : PIFA Antenna Conducted Power for Bluetooth 4.0: 5.09 dBm Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 3.50 2.2387 5.0900 3.2285 0.001439 1 Complies CONCULSION: Both of the 2.4GHz WLAN function and Bluetooth function can transmit simultaneously, the formula of calculatedthe MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.019677 / 1 + 0.001439 / 1 =0.021116, which is less than “1”. This confirmed that the device comply with FCC 1.1310 MPE limit.

Test Report

SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: Rev. 01 FCC RADIO TEST REPORT Applicant’s company Realtek Semiconductor Corp. Applicant Address No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan FCC ID TX2-RTL8723BS Manufacturer’s company Realtek Semiconductor Corp. Manufacturer Address No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Product Name 802.11b/g/n RTL8723BS Combo module Brand Name REALTEK Model No. RTL8723BS Test Rule 47 CFR FCC Part 15 Subpart C § 15.247 Test Freq. Range 2400 ~ 2483.5MHz Received Date Mar. 17, 2014 Final Test Date Apr. 19, 2014 Submission Type Original Equipment Statement Test result included in this report is for the IEEE 802.11n and IEEE 802.11b/g of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.10-2009, 47 CFR FCC Part 15 Subpart C, KDB 558074 D01 v03r01. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR431858AA Report Format Version: Rev. 01 Page No. : i of ii FCC ID: TX2-RTL8723BS Issued Date : Apr. 24, 2014 Table of Contents 1. CERTIFICATE OF COMPLIANCE ......................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT .......................................................................................................................... 2 3. GENERAL INFORMATION .................................................................................................................................. 3 3.1. Product Details....................................................................................................................................................................................3 3.2. Accessories .........................................................................................................................................................................................4 3.3. Table for Filed Antenna.......................................................................................................................................................................5 3.4. Table for Carrier Frequencies .............................................................................................................................................................6 3.5. Table for Test Modes ...........................................................................................................................................................................6 3.6. Table for Testing Locations..................................................................................................................................................................7 3.7. Table for Supporting Units ...................................................................................................................................................................8 3.8. Table for Parameters of Test Software Setting .....................................................................................................................................9 3.9. EUT Operation during Test ...................................................................................................................................................................9 3.10. Duty Cycle ........................................................................................................................................................................................10 3.11. Test Configurations ...........................................................................................................................................................................12 4. TEST RESULT ................................................................................................................................................... 15 4.1. AC Power Line Conducted Emissions Measurement.........................................................................................................................15 4.2. Maximum Conducted Output Power Measurement .........................................................................................................................19 4.3. Power Spectral Density Measurement ..............................................................................................................................................22 4.4. 6dB Spectrum Bandwidth Measurement ..........................................................................................................................................28 4.5. Radiated Emissions Measurement ....................................................................................................................................................33 4.6. Emissions Measurement ....................................................................................................................................................................52 4.7. Antenna Requirements .....................................................................................................................................................................70 5. LIST OF MEASURING EQUIPMENTS ................................................................................................................... 71 6. MEASUREMENT UNCERTAINTY.......................................................................................................................... 73 APPENDIX A. TEST PHOTOS ..................................…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Dana Liaw(Project Manager)

[email protected]886-3-5780211Fax: 886-3-5776598

Test Firm

Sporton International Inc.Alex Chen

[email protected]886-3-327-3456Fax: 886-3-327-0973

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
3	15C	2.40 GHz - 2.48 GHz	3.20 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. This OEM module is approved for use in products operating as mobile transmitting device. The only antennas approved for use with this module are those documented in the filing, and must be installed in the manner specified therein. This device and its antenna(s) must operate with a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Grantee shall provide installation and operating instructions for satisfying RF exposure requirements to OEM integrators and installers. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This device supports 802.11n, 20MHz and 40MHz mode.
