TX2RTL8188CEBT802.11b/g/n RTL8188CE Combo miniCard

Realtek Semiconductor Corp.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Mar 22, 2010
Application Purpose: Original Equipment
Date of Application: Mar 22, 2010
Equipment Note: 802.11b/g/n RTL8188CE Combo miniCard
Frequency Range: 2422.00000000 - 2452.00000000
Company: Realtek Semiconductor Corp.
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

RTL8188CEBT Combo miniCard User’s Manual Rev. 1.0 03 Dec 2009 Realtek Semiconductor Corp. No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Tel.: +886-3-578-0211. Fax: +886-3-577-6047 www.realtek.com.tw RTL8188CEBT Combo mini-Card User Manual COPYRIGHT ©2009 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of Realtek Semiconductor Corp. DISCLAIMER Realtek provides this document “as is”, without warranty of any kind, neither expressed nor implied, including, but not limited to, the particular purpose. Realtek may make improvements and/or changes in this document or in the product described in this document at any time. This document could include technical inaccuracies or typographical errors. TRADEMARKS Realtek is a trademark of Realtek Semiconductor Corporation. Other names mentioned in this document are trademarks/registered trademarks of their respective owners. USING THIS DOCUMENT This document is intended for the software engineer’s reference and provides detailed programming information. Though every effort has been made to ensure that this document is current and accurate, more information may have become available subsequent to the production of this guide. In that event, please contact your Realtek representative for additional information that may help in the development process. ii Rev.1.0 RTL8188CEBT Combo mini-Card User Manual Table of Contents 1. GENERAL DESCRIPTION................................................................................................................................................1 1.1. RTL8188CE...................................................................................................................................................................1 1.2. BLUECORE4-ROM..........................................................................................................................................................1 2. FEATURES...........................................................................................................................................................................2 2.1. RTL8188CE...................................................................................................................................................................2 2.2. BLUECORE4 ....................................................................................................................................................................3 PRODUCT SPECIFICATIONS.................................................................................................................................................4 2.3. MINI PCI EXPRESS PIN ASSIGNMENT..............................................................................................................................4 2.4. MECHANICAL..................................................................................................................................................................5 2.5. ENVIRONMENTAL............................................................................................................................................................5 2.5.1. Operating...............................................................................................................................................................5 2.5.2. Storage....................................................................................................................................................................5 2.6. FUNCTIONAL SPECIFICATIONS.........................................................................................................................................5 2.7. WARNING........................................................................................................................................................................7 4.5.1 Federal Communication Commission Interference Statement......................................................................................7 4.5.2 Industry Canada Statement..........................................................................................................................................8 4.5.3 NCC警語....................................................................................................................................................................10 List of Tables TABLE 1. MINI PCI EXPRESS PIN ASSIGNMENT............................................................................................................................4 TABLE 2. FUNCTIONAL SPECIFICATIONS.......................................................................................................................................5 List of Figures FIGURE 1. RTL8188CE MINICARD APPLICATION DIAGRAM...................................................................錯誤! 尚未定義書籤。 FIGURE 2. RTL8188CE MINICARD MECHANICAL SPECIFICATION................................................................................................5 iii Rev.1.0 RTL8188CEBT Combo mini-Card User Manual 1 Rev.1.0 1. General Description 1.1. RTL8188CE The Realtek RTL8188CE is a highly integrated single-chip Wireless LAN (WLAN) controller compatible with the IEEE 802.11n specification. It combines a MAC, a 1T1R capable baseband, and RF in a single chip. The RTL8188CE provides a complete solution for a high-performance wireless client. The RTL8188CE baseband implements Multiple Input, Multiple Output (MIMO) Orthogonal Frequency Division Multiplexing (OFDM) with one transmit and one receive path (1T1R). Features include one spatial stream transmission, short Guard Interval (GI) of 400ns, spatial spreading, and support for both 20MHz and 40MHz channel bandwidth. For legacy compatibility, Direct Sequence Spread Spectrum (DSSS), Complementary Code K…

Text truncated - open the document above for the full version.

External Photos

SPORTON International Inc. PAGE NUMBER : A1 OF A4 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 09, 2010 FAX : 886-2-2696-2255 APPENDIX A. Photographs of EUT SPORTON International Inc. PAGE NUMBER : A2 OF A4 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 09, 2010 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A3 OF A4 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 09, 2010 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A4 OF A4 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 09, 2010 FAX : 886-2-2696-2255

ID Label/Location Info

Realtek RTL8188CEBT Label description Label location Label sample FCC/IC/NCC Equality Ratio: 300% Equality Ratio: 100% CE/Japan Equality Ratio: 300% Equality Ratio: 100% 802.11b/g/n RTL8188CE Combo miniCard RTL8188CEBT FCC ID: TX2RTL8188CEBT IC: 6317A-RTL8188CEBT Made in Taiwan 27mm 15mm Input: DC 3.3V 802.11b/g/n RTL8188CE Combo miniCard RTL8188CEBT Made in Taiwan 27mm 15mm Input: DC 3.3V LABEL HERE

Internal Photos

SPORTON International Inc. PAGE NUMBER : A1 OF A2 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 09, 2010 FAX : 886-2-2696-2255 APPENDIX A. Photographs of EUT SPORTON International Inc. PAGE NUMBER : A2 OF A2 TEL : 886-2-2696-2468 ISSUED DATE : Mar. 09, 2010 FAX : 886-2-2696-2255

Test Report

Report No.: 022402 Page No. : E1 of E6 Appendix E. Antenna List Report No.: 022402 Page No. : E2 of E6 Table for Filed Antenna No. Brand Ant. Type Con. Type Peak Gain (dBi) Model No. 1 WNC PIFA IPEX Main: 3.95 Aux.: 3.90 DQ661500301 2 WNC PIFA IPEX Main: -2.50 Aux.: -1.12 Main: 25.90970.021 Aux.: 25.90970.031 3 Smart Approach PIFA IPEX Main: 0.90 Aux.: 2.75 Main: SE-042C0-ECL30 Aux.: SE-042D0-ECL30 4 ACON PIFA IPEX Left: 1.89 Right: -2.13 Left: 25.90915.041 Right: 25.90915.051 5 WHAYU PIFA IPEX Main: -2.12 Aux.: -2.49 MSA-00005A 6 Quanta PIFA IPEX TX 1: 1.8 TX 2: -0.3 37LX6AATP00 7 Quanta PIFA IPEX TX 1: 0.3 TX 2: 1.7 37LX7AATP00 8 Quanta PIFA IPEX TX: 1.0 RX: 0.2 3ASP8AATP20 9 NISSEI PIFA IPEX TX: 1.80 RX: 0.54 TX: 3172509 RX: 3172467 10 Amphenol PIFA IPEX TX: 1.68 RX: 1.47 TX: LX0968-11-000-R RX: LX0970-11-000-R 11 FOXCONN PIFA IPEX TX: 1.10 RX: -0.40 TX: WDAN-L1ML3002-DF RX: WDAN-L1ML3001-DF 12 NISSEI PIFA IPEX TX: -0.61 RX: -0.83 TX: 3176674 RX: 3176658 13 FOXCONN PIFA IPEX TX: -0.88 RX: 1.16 TX: 024-01F0-2243 RX: 024-01F0-2242 14 NISSEI PIFA IPEX TX: 1.99 RX: 1.35 TX: 3172566 RX: 3172525 15 Amphenol PIFA IPEX TX: 1.57 RX: 1.61 TX: LX0983-11-000-R RX: LX0980-11-000-R 16 Hitachi PIFA IPEX TX: 1.54 RX: 1.82 TX: HMT14-AUX RX: HMT14-MAIN 17 FOXCONN PIFA IPEX TX: 1.43 RX: 1.71 TX: WDAN-L1WK1002-DF RX: WDAN-L1WK1001-DF Report No.: 022402 Page No. : E3 of E6 18 NISSEI PIFA IPEX TX: 1.26 RX: 1.88 TX: 3210002 RX: 3209970 19 ACON PIFA IPEX TX: -0.86 RX: -0.96 TX: APM6P-700034 RX: APM6P-700033 20 Amphenol PIFA IPEX TX: -1.60 RX: -1.85 TX: 14G152168131LV RX: 14G152168231LV 21 ACON PIFA IPEX TX: -0.23 RX: -1.32 TX: APM6P-700029 RX: APM6P-700027 22 TYCO PIFA IPEX TX: 1.52 RX: -2.39 TX: 2023944-1 RX: 2023940-1 23 ACON PIFA IPEX TX: -0.74 RX: -1.16 TX: APM6P-700030 RX: APM6P-700028 24 TYCO PIFA IPEX TX: -0.11 RX: -0.58 TX: 2023950-1 RX: 2023946-1 25 ACON PIFA IPEX TX: 1.27 RX: -1.21 TX: 25.90702.001 RX: 25.90700.001 26 ACON PIFA IPEX TX: 1.21 RX: 1.37 TX: 25.90802.001 RX: 25.90800.001 27 ACON PIFA IPEX TX: 1.04 RX: 1.17 TX: 25.90597.001 RX: 25.90598.001 28 Wistron NW PIFA IPEX TX: 0.59 RX: 1.94 TX: 25.90586.001 RX: 25.90587.001 29 ACON PIFA IPEX TX: -0.13 RX: -0.42 TX: 25.90654.001 RX: 25.90653.001 30 Wistron NW PIFA IPEX TX: 0.31 RX: -0.52 TX: 25.90650.001 RX: 25.90649.001 31 ACON PIFA IPEX TX: 0.64 RX: -0.39 TX: 25.90676.001 RX: 25.90675.001 32 Wistron NW PIFA IPEX TX: 1.32 RX: -1.53 TX: 25.90670.001 RX: 25.90669.001 33 Quanta PIFA IPEX TX: -0.40 RX: 0.10 TX: DQ6GC200200 RX: DQ6GC200100 34 Quanta PIFA IPEX TX: 0.7 RX: -1.3 TX: DQ6GC300200 RX: DQ6GC300100 35 ACON PIFA IPEX TX: 1.16 RX: -0.04 TX: 25.90930.001 RX: 25.90929.001 Report No.: 022402 Page No. : E4 of E6 36 Ethertronics PIFA IPEX TX: -0.59 RX: 0.60 TX: 25.90935.001 RX: 25.90934.001 37 Wistron NW PIFA IPEX TX: -0.93 RX: 0.87 TX: 25.90920.001 RX: 25.90919.001 38 ACON PIFA IPEX TX: -2.64 RX: -0.37 TX: C-1335-11-000-26 RX: C-1334-11-000-26 39 Wistron NW PIFA IPEX TX: 0.74 RX: 0.77 TX: 25.90980.001 RX: 25.90979.001 40 Quanta PIFA IPEX TX: -0.10 RX: -0.10 TX: QADCFL3_WLA RX: QADCFL3_WL_M 41 QUANTA PIFA IPEX TX: -1.40 RX.: -0.50 TX: QADCPS1_WL_A RX.: QADCPS1_WL_M 42 Hitachi PIFA IPEX Main: 0.58 Aux.: 1.12 HFT40 43 Hitachi PIFA IPEX Main: -1.65 Aux.: -0.92 HFT60 44 WNC PIFA IPEX Main: -1.10 Aux.: 1.76 Main: 81.EE215.002 Aux.: 81.EE215.001 45 WNC PIFA IPEX Main: 1.18 Aux. 1.75 WNC002 46 Tyco PIFA IPEX Main: 3.45 Aux: 2.41 MIMO: 1.04 TBN001 47 Tyco PIFA IPEX Main: -1.11 Aux.: -1.11 MIMO: -0.95 TBN003 48 Hitachi PIFA IPEX TX 1: 2.19 TX 2: -0.33 HBY07 49 Hitachi PIFA IPEX TX 1: 2.91 TX 2: 2.82 HBY051 50 Hitachi PIFA IPEX TX 1: 0.27 TX 2: 0.02 HBY052 51 Hitachi PIFA IPEX TX 1: 1.30 TX 2: 2.42 HBY061 52 Hitachi PIFA IPEX TX 1: -1.04 TX 2: -1.19 HBY062 Report No.: 022402 Page No. : E5 of E6 53 Hitachi PIFA IPEX TX 1: -1.74 TX 2: 1.16 HFT65 54 Hitachi PIFA IPEX Main: 0.87 Aux.: 1.94 HCT01 55 FOXCONN PIFA IPEX TX 1: -0.43 TX 2: -0.7 WDAN-TQ 56 Tyco PIFA IPEX -1.11 TBN005 & TBN006 57 WNC PIFA IPEX Main: 2.40 Aux.: 1.50 WNC004 58 WNC PIFA IPEX Main: 1.19 Aux.: 0.28 WNC001 59 WNC PIFA IPEX Main: 0.52 Aux.: 1.07 WNC003 60 WNC PIFA IPEX Main: -2.76 Aux.: -3.64 WNC005 61 WNC PIFA IPEX Main: 0.42 Aux.: 0.79 MIMO: 0.14 81.EJZ 62 WNC PIFA IPEX Main: 0.86 Aux.: -0.08 81.EJT 63 Tyco (20-D1130002D) PIFA IPEX TX1: -0.10 TX2: -0.92 TX 3: 0.56 TBN008 64 Tyco (20-D1130002D) PIFA IPEX TX: -0.10 RX: -0.92 TBN008 65 Tyco PIFA IPEX Main: 0.28 Aux.: -0.83 TBN004 66 TYCO PIFA IPEX TX 1: 1.98 TX 2: 1.97 TX 3: -0.88 TBN007 67 Hitachi PIFA IPEX -0.80 HFS23 68 Hitachi PIFA IPEX 0.64 HFS40 69 TYCO (20238740-1) PIFA IPEX TX 1: 0.47 TX 2: 0.06 TX 3: 1.65 TBN008 70 TYCO (2023750-1) PIFA IPEX TX 1: 0.47 TX 2: 0.06 TBN008 Report No.: 022402 Page No. : E6 of E6 71 TYCO (2023772-1) PIFA IPEX TX 1: -2.60 TX 2: -0.26 TX 3: -0.91 TBN008 72 TYCO (2023770-1) PIFA IPEX TX 1: -2.60 TX 2: -0.26 TBN008 73 Smart Approach PIFA IPEX TX 1: 2.37 TX 2: 1.59 03-FR021-016 74 WNC PIFA IPEX Main: 2.71 Aux.: 1.75 MIMO: 2.57 Main: 81.EEO15.001 Aux.: 81.EEO15.002 MIMO: 81.EEO15.003 75 WNC PIFA IPEX Main: 2.23 Aux.: 1.18 Main: 81.EHD15.003 Aux.: 81.EHD15.002 76 WNC PIFA IPEX TX1: 2.37 TX2.: -0.77 TX1: 81.EHD15.004 TX2.: 81.EHD15.005 77 WNC PIFA IPEX Main: -1.51 Aux.: -0.49 Main: 81.EHD15.004 Aux.: 81.EHD15.006 78 WNC PIFA IPEX Main: -1.51 Aux.: -1.10 Main: 81.EHD15.004 Aux.: 81.EHD15.007 79 WNC PIFA IPEX TX1: 1.86 TX2: 1.19 TX1: 81.EHD15.G09 TX2: 81.EHD15.G10 80 Foxconn PIFA IPEX Main: -0.28 Aux.: -1.24 Main: WDAN-M1WC1001-DF Aux.: WDAN-M1MM1001-DF 81 Amphenol KAE PIFA IPEX Main: 2.49 Aux.: 0.58 MIMO: 0.65 Main: SS-03-03-099 Aux.: SS-03-03-100 MIMO: SS-03-03-101 82 Foxconn PIFA IPEX Main: -0.28 Aux.: -0.14 Main: WDAN-M1WC1001-DF Aux.: WDAN-M1BN1001-DF 83 Foxconn PIFA IPEX 0.68 WDAN-M1NY1001-DF 84 Foxconn PIFA IPEX TX1: 0.54 TX2: -1.40 TX1: WDAN-M1PB1001-DF TX2: WDAN-M1PB1002-DF 85 Foxconn PIFA IPEX Main: 2.18 Aux.: 1.11 Main: WDAN-M1SN1002-DF Aux.: WDAN-M1SN1001-DF 86 Foxconn PIFA IPEX Main: 1.31 Aux.: 0.54 MIMO…

Text truncated - open the document above for the full version.

Test Report

Report No.: FR022402 FCC ID: TX2RTL8188CEBT Page No. : D1 of D3 Appendix D. Co-location Report No.: FR022402 FCC ID: TX2RTL8188CEBT Page No. : D2 of D3 1. Results of Radiated Emissions for Co-located Temperature 23°C Humidity 56% Test Engineer Howar Sung Configurations 2.4GHz Bluetooth + 2.4GHz WLAN Horizontal Report No.: FR022402 FCC ID: TX2RTL8188CEBT Page No. : D3 of D3 Vertial

Test Report

SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: 01 FCC RADIO TEST REPORT Applicant’s company Realtek Semiconductor Corp. Applicant Address No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan FCC ID TX2RTL8188CEBT Manufacturer’s company Realtek Semiconductor Corp. Manufacturer Address No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Product Name 802.11b/g/n RTL8188CE Combo miniCard Brand Name Realtek Model Name RTL8188CEBT Test Rule 47 CFR FCC Part 15 Subpart C § 15.247 Test Freq. Range 2400 ~ 2483.5MHz Received Date Feb. 24, 2010 Final Test Date Mar. 17, 2010 Submission Type Original Equipment Statement Test result included in this report is for the IEEE 802.11n and IEEE 802.11b/g part of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR022402AA Report Format Version: 01 Page No. : iof ii FCC ID: TX2RTL8188CEBT Issued Date : Mar. 18, 2010 Table of Contents 1. CERTIFICATE OF COMPLIANCE ......................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT .......................................................................................................................... 2 3. GENERAL INFORMATION .................................................................................................................................. 3 3.1. Product Details....................................................................................................................................................................................3 3.2. Accessories .........................................................................................................................................................................................5 3.3. Table for Filed Antenna.......................................................................................................................................................................5 3.4. Table for Carrier Frequencies .............................................................................................................................................................5 3.5. Table for Test Modes ...........................................................................................................................................................................6 3.6. Table for Testing Locations..................................................................................................................................................................6 3.7. Table for Supporting Units ...................................................................................................................................................................7 3.8. Table for Parameters of Test Software Setting .....................................................................................................................................7 3.9. Test Configurations .............................................................................................................................................................................8 4. TEST RESULT ................................................................................................................................................... 12 4.1. AC Power Line Conducted Emissions Measurement.........................................................................................................................12 4.2. Maximum Conducted Output Power Measurement .........................................................................................................................16 4.3. Power Spectral Density Measurement ..............................................................................................................................................22 4.4. 6dB Spectrum Bandwidth Measurement ..........................................................................................................................................28 4.5. Radiated Emissions Measurement ....................................................................................................................................................34 4.6. Band Edge Emissions Measurement .................................................................................................................................................64 4.7. Antenna Requirements .....................................................................................................................................................................73 5. LIST OF MEASURING EQUIPMENTS ................................................................................................................... 74 6. TEST LOCATION.............................................................................................................................................. 75 7. TAF CERTIFICATE OF ACCREDITATION ............................................................................................................. 76 APPENDIX A. PHOTOGRAPHS OF EUT.......................................................................................................... A1 ~ A6 APPENDIX B. TEST PHOTOS.......................................................................................................................... B1 ~ B6 APPENDIX C. MAXIMUM PERMISSIBLE EXPOSURE..........…

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: FR022402 FCC ID: TX2RTL8188CEBT Page No. : 1 of 6 Appendix B. Test Photos Report No.: FR022402 FCC ID: TX2RTL8188CEBT Page No. : 2 of 6 1. Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW Report No.: FR022402 FCC ID: TX2RTL8188CEBT Page No. : 3 of 6 2. Photographs of Radiated Emissions Test Configuration 9kHz ~30MHz FRONT VIEW REAR VIEW Report No.: FR022402 FCC ID: TX2RTL8188CEBT Page No. : 4 of 6 30MHz~1GHz FRONT VIEW REAR VIEW Report No.: FR022402 FCC ID: TX2RTL8188CEBT Page No. : 5 of 6 SIDE VIEW Report No.: FR022402 FCC ID: TX2RTL8188CEBT Page No. : 6 of 6 Above 1GHz FRONT VIEW REAR VIEW
