TX2RTL8812AENF802.11a/b/g/n/ac RTL8812AENF Combo module

Realtek Semiconductor Corp.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jan 14, 2015
Application Purpose: Original Equipment
Date of Application: Jan 13, 2015
Equipment Note: 802.11a/b/g/n/ac RTL8812AENF Combo module
Frequency Range: 2402.00000000 - 2480.00000000
Company: Realtek Semiconductor Corp.
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Combo module User’s Manual Rev.0.1 24 Oct 2013 Realtek Semiconductor Corp. No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Tel.: +886-3-578-0211. Fax: +886-3-577-6047 www.realtek.com.tw RTL8812AENF RTL8812AENF Combo module User Manual Single-Chip 802.11b/g/n/ac 1T1R WLAN Controller ii Track ID: JATR-3375-16 Rev. 0.1 COPYRIGHT ©2012 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of Realtek Semiconductor Corp. DISCLAIMER Realtek provides this document „as is‟, without warranty of any kind. Realtek may make improvements and/or changes in this document or in the product described in this document at any time. This document could include technical inaccuracies or typographical errors. TRADEMARKS Realtek is a trademark of Realtek Semiconductor Corporation. Other names mentioned in this document are trademarks/registered trademarks of their respective owners. USING THIS DOCUMENT This document is intended for the software engineer‟s reference and provides detailed programming information. Though every effort has been made to ensure that this document is current and accurate, more information may have become available subsequent to the production of this guide. REVISION HISTORY Revision Release Date Summary 0.1 2013/10/24 Preliminary release. RTL8812AENF Combo module User Manual Single-Chip 802.11b/g/n/ac 1T1R WLAN Controller iii Track ID: JATR-3375-16 Rev. 0.1 Table of Contents 1. GENERAL DESCRIPTION................................................................................................................................................ 1 2. PRODUCT SPECIFICATIONS.......................................................................................................................................... 3 2.1. ENVIRONMENTAL ............................................................................................................................................................. 3 2.1.1. Operating ............................................................................................................................................................... 3 2.1.2. Storage.................................................................................................................................................................... 3 2.2. FUNCTIONAL SPECIFICATIONS .......................................................................................................................................... 3 2.3. WARNING......................................................................................................................................................................... 5 3.5.1 Federal Communication Commission Interference Statement ...................................................................................... 5 3.5.2 Industry Canada Statement .......................................................................................................................................... 6 3.5.3 NCC警語 ................................................................................................................................................................... 10 List of Tables TABLE 2. FUNCTIONAL SPECIFICATIONS ......................................................................................................................................... 3 RTL8812AENF Combo module User Manual Single-Chip 802.11b/g/n/ac 1T1R WLAN Controller 1 Track ID: JATR-3375-16 Rev. 0.1 1. General Description The Realtek RTL8812AE is a highly integrated single-chip 802.11b/g/n/ac 2T2R WLAN PCI Express network interface controller, and RTL8761AU is a integrated Bluetooth 2.1/3/0/4.0 USB interface controller. It combines a WLAN MAC, a 2T2R capable WLAN baseband, BT Protocol Stack (LM, LL, and LE), BT Baseband, modem, and WLAN/BT RF in a single module. The RTL8812AE with RTL8761AU provide a complete solution for a high throughput performance integrated wireless LAN and Bluetooth device. The RTL8812AE WLAN baseband implements Orthogonal Frequency Division Multiplexing (OFDM) with 1 transmit and 1 receive path and is compatible with the 802.11ac specification. Features include one spatial stream transmission, short guard interval (GI) of 400ns, spatial spreading, and transmission over 20MHz , 40MHz and 80MHz channel bandwidth. For legacy compatibility, Direct Sequence Spread Spectrum (DSSS), Complementary Code Keying (CCK) and OFDM baseband processing are included to support all 802.11b and 802.11g data rates. Differential phase shift keying modulation schemes, DBPSK and DQPSK with data scrambling capability, are available, and CCK provides support for legacy data rates, with long or short preamble. The high-speed FFT/IFFT paths, combined with BPSK, QPSK, 16QAM, 64QAM and 256-QAM modulation of the individual subcarriers and rate compatible punctured convolutional coding with coding rate of 1/2, 2/3, 3/4, and 5/6, provide up to 866.6Mbps for 802.11ac OFDM. A RTL8812AE built-in enhanced signal detector, adaptive frequency domain equalizer, and a soft-decision Viterbi decoder help to alleviate multi-path effects and mutual interference in the reception of multiple streams. Robust interference detection and suppression are provided to protect against Bluetooth, cordless phone, and microwave oven interference. Efficient IQ-imbalance, DC offset, phase noise, frequency offset, and timing offset compensations are provided for the radio frequency front-end. Selectable digital transmit and receive FIR filters are provided to meet transmit spectrum mask requirements and to reject adjacent channel interference, respectively. The RTL8812AE WLAN Controller supports fast receiver Automatic Gain Control (AGC) with synchronous and asynchronous control loops among antennas, antenna diversity functions, and adaptive…

Text truncated - open the document above for the full version.

Cover Letter(s)

Realtek Semiconductor Corp. No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Tel: 886-3-5780211 / Fax: 886-3-5776598 DoC Attestation Letter Date: 2014/4/2 We Realtek Semiconductor Corp., as the grantee of this project (FCC ID: TX2RTL8812AENF / Brand Name: REALTEK / Model No.: RTL8812AENF), would like to declare that the composite portion categorized as computer peripheral has been authorized under the Declaration of Conformity procedures (Sporton report No.: FD422118, FCC Test Firm Registration No.: 187376). The final product shall consequently comply with the FCC rule applied for DoC Procedure. Regards, Note: The registered grantee contact is not available, Judy Hsu is signing for grantee contact. He/She can be reached at email: [email protected]. FCC Grantee contact person information. Applicant’s company name : Realtek Semiconductor Corp. Applicant’s company address : No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Signature : Signed for Dana Liaw Name and Job Title : Dana Liaw / Project Manager E-Mail : [email protected] Tel. : 886-3-5780211

Cover Letter(s)

Realtek Semiconductor Corp. No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Tel: 886-3-5780211 / Fax: 886-3-5776598 Power of Attorney Date: 2014/4/2 Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Sporton International Inc. Address : No.8, Lane 724, Bo-ai St., Jhubei City, HsinChu County 302, Taiwan, R.O.C. Name : Leo Huang Job Title : Manager e-mail : [email protected] I am therefore responsible for the contents of the application. Brand name and model type of the specified radio equipment: REALTEK / RTL8812AENF FCC ID: TX2RTL8812AENF Product name: 802.11a/b/g/n/ac RTL8812AENF Combo module Note: The registered grantee contact is not available, Judy Hsu is signing for grantee contact. He/She can be reached at email: [email protected]. FCC Grantee contact person information. Applicant’s company name : Realtek Semiconductor Corp. Applicant’s company address : No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Signature : Signed for Dana Liaw Name and Job Title : Dana Liaw / Project Manager E-Mail : [email protected] Tel. : 886-3-5780211

Cover Letter(s)

Realtek Semiconductor Corp. No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Tel: 886-3-5780211 / Fax: 886-3-5776598 Restricted band Declaration Letter Date: 2014/4/2 FCC ID：TX2RTL8812AENF We, the undersigned, attest that this device does not support operation in the 5600 - 5650 MHz Band. The firmware on the device restricts the operation in this frequency band and does not utilize the channels in this band. Note: The registered grantee contact is not available, Judy Hsu is signing for grantee contact. He/She can be reached at email: [email protected]. FCC Grantee contact person information. Applicant’s company name : Realtek Semiconductor Corp. Applicant’s company address : No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Signature : Signed for Dana Liaw Name and Job Title : Dana Liaw / Project Manager E-Mail : [email protected] Tel. : 886-3-5780211

Cover Letter(s)

Realtek Semiconductor Corp. No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Tel: 886-3-5780211 / Fax: 886-3-5776598 Ad Hoc Mode Function Declaration Date: 2014/4/2 FCC ID：TX2RTL8812AENF To whom it may concern: We, Realtek Semiconductor Corp., declare that the EUT (Model Name: RTL8812AENF) doesn’t have Ad Hoc function on “non-US/ Canada frequencies” and/or “on DFS frequencies”. In non-associated mode, that software and associated drivers will not initiate any transmission on DFS frequencies. This includes transmissions for beacon ad-hoc peer-to-peer modes. Sincerely, Note: The registered grantee contact is not available, Judy Hsu is signing for grantee contact. He/She can be reached at email: [email protected]. FCC Grantee contact person information. Applicant’s company name : Realtek Semiconductor Corp. Applicant’s company address : No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Signature : Signed for Dana Liaw Name and Job Title : Dana Liaw / Project Manager E-Mail : [email protected] Tel. : 886-3-5780211

Cover Letter(s)

Realtek Semiconductor Corp. No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Tel: 886-3-5780211 / Fax: 886-3-5776598 Confidential Letter Date: 2014/4/2 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Confidentiality Request for FCC ID：TX2RTL8812AENF Gentlemen: The form 731 and application have been electronically submitted and any attachments will be up loaded to your web site to be used in obtaining a grant of certification. Short-term Pursuant to DA 04-1705 of the Commission’s pubic notice, we request short-term confidential treatment for the following information until 180 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: 1. External Photos 2. Internal Photos 3. Test Setup photos 4. User’s Manual Permanent Realtek Semiconductor Corp. requests that the material in the following files be withheld from public disclosure in accordance with Section 0.457 of the Commission’s Rules, 47 C.F.R. 0.459, following grant of the application. 1. Block Diagram 2. Circuit Diagram 3. Operational Description Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Note: The registered grantee contact is not available, Judy Hsu is signing for grantee contact. He/She can be reached at email: [email protected]. Sincerely, Applicant’s company name : Realtek Semiconductor Corp. Applicant’s company address : No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Signature : Signed for Dana Liaw Name and Job Title : Dana Liaw / Project Manager E-Mail : [email protected] Tel. : 886-3-5780211

Cover Letter(s)

Page No. : 23 Module Approval Request Letter Subject: Module Approval Date: 2015/1/13 FCC ID: TX2RTL8812AENF Dear Reviewer, We, Sporton International Inc., are authorized by Realtek Semiconductor Corp. to have their state-of-the-art 802.11a/b/g/n/ac RTL8812AENF Combo module approved under module approval authorization. The application of this module is specified to mobile host equipment. The requirements regulated in CFR47 Part 15.212 have been fulfilled and clearly explained below. 1. The requirement of RF shielding: The shielding of the radio portion can be demonstrated in exhibition External Photo. 2. The requirement of buffered inputs: Buffered data inputs stage has been integrated in chip RTL8812AE. 3. The requirement of power supply regulation: The part number of the power regulator is RTL8812AE. 4. The requirements of section 15.203 and 15.204(C): The requirements of antenna connector and spurious emission have been fulfilled. Please reference the exhibition Test Report. 5. The requirement of stand-alone test configuration: Please reference exhibition Test Configuration Photo for the stand-alone test configuration. 6. The requirement of labeling: The instruction on the labeling rule of the end product has been stated in the users manual of this module. Please also see the exhibition Label Sample. 7. The requirement of compliance on specific rule or operating requirements: The required FCC rule has been fulfilled and all the instructions for maintaining compliance has been clearly stated in the Users Manual. 8. The requirement of RF exposure: Please refer exhibition RF Exposure for the compliance of MPE RF exposure rule. Please do not hesitate to contact me for any questions of this request letter. Thank you. Company name : Sporton International Inc. Company Address : No.8, Lane 724, Bo-ai St., Jhubei City, Hsinchu County 302, Taiwan, R.O.C. Signature : Name : Leo Huang Job Title : Manager

External Photos

Report No.:422118 SPORTON International Inc. PAGE NUMBER : 1 OF 3 TEL : 886-3-327-3456 ISSUED DATE : Jan. 13, 2015 FAX : 886-3-327-0973 Photographs of EUT Report No.:422118 SPORTON International Inc. PAGE NUMBER : 2 OF 3 TEL : 886-3-327-3456 ISSUED DATE : Jan. 13, 2015 FAX : 886-3-327-0973 Report No.:422118 SPORTON International Inc. PAGE NUMBER : 3 OF 3 TEL : 886-3-327-3456 ISSUED DATE : Jan. 13, 2015 FAX : 886-3-327-0973

ID Label/Location Info

Realtek 802.11a/b/g/n/ac RTL8812AENF Combo module Label description Label location Label sample FCC/IC/CE Equality Ratio: 300% Equality Ratio: 100% 802.11a/b/g/n/ac RTL8812AENF Combo module Model: RTL8812AENF FCC ID: TX2RTL8812AENF IC: 6317A-RTL8812AENF Input：DC3.3V 1A 20mm 14mm LABEL HERE

Internal Photos

Report No.:422118 SPORTON International Inc. PAGE NUMBER : 1 OF 2 TEL : 886-3-327-3456 ISSUED DATE : Jan. 13, 2015 FAX : 886-3-327-0973 Photographs of EUT Report No.:422118 SPORTON International Inc. PAGE NUMBER : 2 OF 2 TEL : 886-3-327-3456 ISSUED DATE : Jan. 13, 2015 FAX : 886-3-327-0973

RF Exposure Info

Report No.: FR422118 FCC ID: TX2RTL8812AENF Page No. : B1 of B4 Appendix B. Maximum Permissible Exposure Report No.: FR422118 FCC ID: TX2RTL8812AENF Page No. : B2 of B4 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Report No.: FR422118 FCC ID: TX2RTL8812AENF Page No. : B3 of B4 1.3. Calculated Result and Limit Exposure Environment: General Population / Uncontrolled Exposure For 5GHz UNII Band: Antenna Type : PIFA Antenna Conducted Power for IEEE 802.11ac VHT20 : 20.77dBm The maximum combined Average Output Power Distance (m) Directional Gain (dBi) Antenna Gain (numeric) (dBm) (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 0.2 8.01 6.3246 20.7715 119.4387 0.150358 1 Complies Note: For 5GHz ISM Band: Antenna Type : PIFA Antenna Conducted Power for IEEE 802.11ac VHT40: 20.97dBm The maximum combined Average Output Power Distance (m) Directional Gain Antenna Gain (numeric) (dBm) (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 0.2 8.01 6.3246 20.9653 124.8908 0.157221 1 Complies Note: For 2.4GHz Band: For WLAN Antenna Type : PIFA Antenna Conducted Power for IEEE 802.11n 20: 20.95 dBm The maximum combined Average Output Power Distance (m) Directional Gain (dBi) Antenna Gain (numeric) (dBm) (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 0.2 6.51 4.4774 20.9504 124.4630 0.110923 1 Complies Note: Report No.: FR422118 FCC ID: TX2RTL8812AENF Page No. : B4 of B4 For Bluetooth Antenna Type : PIFA Antenna Max Conducted Power for Bluetooth ER (GFSK) 1Mbps : 3.32 dBm Average Output Power Distance (m) Antenna Gain (dBi) Antenna Gain (numeric) (dBm) (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 0.2 3.50 2.2387 3.3200 2.1478 0.000957 1 Complies Max Conducted Power for Bluetooth 4.0 : 3.24 dBm Average Output Power Distance (m) Antenna Gain (dBi) Antenna Gain (numeric) (dBm) (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 0.2 3.50 2.2387 3.2400 2.1086 0.000940 1 Complies CONCULSION: Both of the WLAN 2.4GHz Band and Bluetooth can transmit simultaneously, the formula of calculatedthe MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.110923 / 1 + 0.000957 / 1 = 0.11188, which is less than “1”. This confirmed that the device comply with FCC 1.1310 MPE limit. Both of the WLAN 5GHz Band and Bluetooth can transmit simultaneously, the formula of calculatedthe MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.157221 / 1 + 0.000957 / 1 = 0.158178, which is less than “1”. This confirmed that the device comply with FCC 1.1310 MPE limit.

Test Report

SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: Rev. 01 FCC RADIO TEST REPORT Applicant’s company Realtek Semiconductor Corp. Applicant Address No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan FCC ID TX2RTL8812AENF Manufacturer’s company Realtek Semiconductor Corp. Manufacturer Address No. 2,Innovation Road II, Hsinchu Science Park, Hsinchu 300,Taiwan Product Name 802.11a/b/g/n/ac RTL8812AENF Combo module Brand Name REALTEK Model No. RTL8812AENF Test Rule Part(s) 47 CFR FCC Part 15 Subpart C § 15.247 Test Freq. Range 2400 ~ 2483.5MHz / 5725 ~ 5850MHz Received Date Mar. 07, 2014 Final Test Date Nov. 28, 2014 Submission Type Original Equipment Statement Test result included is only for the IEEE 802.11n, IEEE 802.11b/g and IEEE 802.11a/ac of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.10-2013, 47 CFR FCC Part 15 Subpart C, KDB 558074 D01 v03r02, KDB 662911 D01 v02r01, KDB644545 D01 v01r02. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR422118AA Report Format Version: Rev. 01 Page No. : i of ii FCC ID: TX2RTL8812AENF Issued Date : Jan. 13, 2015 Table of Contents 1. CERTIFICATE OF COMPLIANCE ......................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT .......................................................................................................................... 2 3. GENERAL INFORMATION .................................................................................................................................. 3 3.1. Product Details....................................................................................................................................................................................3 3.2. Accessories .........................................................................................................................................................................................5 3.3. Table for Filed Antenna.......................................................................................................................................................................6 3.4. Table for Carrier Frequencies .............................................................................................................................................................8 3.5. Table for Test Modes ...........................................................................................................................................................................9 3.6. Table for Testing Locations................................................................................................................................................................13 3.7. Table for Supporting Units .................................................................................................................................................................14 3.8. Table for Parameters of Test Software Setting ...................................................................................................................................15 3.9. EUT Operation during Test .................................................................................................................................................................17 3.10. Duty Cycle ........................................................................................................................................................................................17 3.11. Test Configurations ...........................................................................................................................................................................18 4. TEST RESULT ................................................................................................................................................... 22 4.1. AC Power Line Conducted Emissions Measurement.........................................................................................................................22 4.2. Maximum Conducted Output Power Measurement .........................................................................................................................26 4.3. Power Spectral Density Measurement ..............................................................................................................................................30 4.4. 6dB Spectrum Bandwidth Measurement ..........................................................................................................................................45 4.5. Radiated Emissions Measurement ....................................................................................................................................................61 4.6. Emissions Measurement ....................................................................................................................................................................95 4.7. Antenna Requirements ...................................................................................................................................................................131 5. LIST OF MEASURING EQUIPMENTS ................................................................................................................. 132 6. MEASUREMENT UNCERTAINTY......................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Report No.: FR422118 FCC ID: TX2RTL8812AENF Page No. : C1 of C5 Appendix C. Radiated Emission Co-location Report Report No.: FR422118 FCC ID: TX2RTL8812AENF Page No. : C2 of C5 1. Results of Radiated Emissions for Co-located Temperature 26°C Humidity 68% Test Engineer Lucas Huang / Andy Tsai Configurations 2.4G WLAN + Bluetooth Horizontal Report No.: FR422118 FCC ID: TX2RTL8812AENF Page No. : C3 of C5 Vertial Report No.: FR422118 FCC ID: TX2RTL8812AENF Page No. : C4 of C5 Temperature 26°C Humidity 68% Test Engineer Lucas Huang / Andy Tsai Configurations 5G WLAN + Bluetooth Horizontal Report No.: FR422118 FCC ID: TX2RTL8812AENF Page No. : C5 of C5 Vertial

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Dana Liaw(Project Manager)

[email protected]886-3-5780211Fax: 886-3-5776598

Test Firm

Sporton International Inc.Alex Chen

[email protected]886-3-327-3456Fax: 886-3-327-0973

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
3	15C	2.40 GHz - 2.48 GHz	2.00 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Single Modular Approval. Power listed is maximum combined conducted output power. This module is restricted to installation in products for indoor use only in mobile and fixed applications. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 3.5dBi and 5dBi in 2.4GHz and 5GHz band, respectively. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This device has 20MHz and 40MHz bandwidth modes.
