TXTGLM1652XXLaser Rangefinder

IMPORTANT: Read Before Using IMPORTANT : Lire avant usage IMPORTANTE: Leer antes de usar For English Version See page 8 Version française Voir page 40 Versión en español Ver la página 77 Call Toll Free for Consumer Information and Service Locations Pour obtenir des informations et les adresses de nos centres de service après-vente, appelez ce numéro gratuit Llame gratis para obtener información para el consumidor y ubicaciones de servicio Operating/Safety Instructions Consignes de sécurité/d’utilisation Instrucciones de funcionamiento y seguridad 1-877-BOSCH99 (1-877-267-2499) www.boschtools.com 0.0° 1/x 164 ' 6 " ⁄ GLM165-22 GLM165-27C -2- GLM165-22 (1) (2) (3) (4) (5) (6) (7) (8) (a)(d) (e) (f) (g) (9) 4'02" 8'05" 12'08" 164' 6" ⁄ 1/x (b) 4'02" 8' 05" 12' 08" 164 ' 6 " ⁄ -3- GLM165-27C 0.0° (1) (2) (3) (4) (5) (6) (7) (8) (a)(c) (d)( e) (f) (g) (h) (b) (9) 4'02" 8'05" 12'08" 164' 6" ⁄ 1/x 0.0° 4'02" 8' 05" 12' 08" 164 ' 6 " ⁄ -4- (10) (11) (12) (13) (14) (15) (16) GLM165- 22 36 01K 72S10 2 x 1.5V (AA) LASE R RADIATIO N. DO NOT STA RE INTO B EAM . CL ASS 2 LASE R PRODU CT . RAYONNEME NT LASE R. NE RE- GA RDEZ PAS DI - RECTEMENT DANS LE FAISC EAU . PR O- DU IT LAS ER DE CLAS SE 2. IEC 6 0825 -1 :2 01 4 < 1 mW , 63 5 nm 2 Robert Bo sch Too l Corp., Mo unt Pr ospect, IL Ma de in Ma laysia -5- X 1 1 C AB 1/x 1/x 1/x (i)(j)(k) (i)(j)(k) A GLM165-27C GLM165-22 -6- (17) (18) C (18) (17) -7- GL M 5 0 C P r o fes s i o n a l D (17) (18) (19) (20) (21) (22) -8- Read all instructions. Failure to follow all instructions listed below may result in hazardous radiation exposure, electric shock, fire and/or serious injury. The term “laser measure” in the warnings listed below refers to your battery-operated (cordless) laser mea- suring tool. SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE The following label is on your laser measure for your safety. ALWAYS BE AWARE of its location when using the laser measure. DO NOT direct the laser beam at persons or animals and do not stare into the laser beam yourself. This laser measure produces class 2 laser radia- tion and complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007. This can lead to persons being blinded. DO NOT stare directly at the laser beam or project the laser beam directly into the eyes of others. Seri- ous eye injury could result. DO NOT place the laser measure in a position that may cause anyone to stare into the laser beam inten- tionally or unintentionally. Serious eye injury could result. DO NOT operate the laser measure around children or allow children to operate the laser measure. Seri- ous eye injury could result. ALWAYS: Make sure that any bystanders in the vicin- ity of use are made aware of the dangers of looking directly into the laser measure. General Safety Rules LASER RADIATION. DO NOT STARE INTO BEAM. CLASS 2 LASER PRODUCT. RAYONNEMENT LASER. NE RE- GARDEZ PAS DI- RECTEMENT DANS LE FAISCEAU. PRO- DUIT LASER DE CLASSE 2. IEC 60825-1:2014 < 1 mW, 635 nm 2 -9- Never aim the beam at a workpiece with a reflective surface. Bright shiny reflective sheet steel or similar reflective surfaces are not recommended for laser use. Reflective surfaces could direct the beam back towards the operator. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. DO NOT use any optical tools such as, but not limited to, telescopes or transits to view the laser beam. Se- rious eye injury could result. DO NOT leave the laser measure “ON” unattended in any operation mode. ALWAYS turn the laser measure “OFF” when not in use. Leaving the laser measure “ON” increases the risk of someone inadvertently star- ing into the laser beam. DO NOT operate the laser measure in combustible areas such as in the presence of flammable liquids, gases or dust. Do not use the laser viewing glasses as safety gog- gles. The laser viewing glasses are used for improved visualization of the laser beam, but they do not protect against laser radiation. Do not use the laser viewing glasses as sun glasses or in traffic. The laser viewing glasses do not afford complete UV protection and reduce color perception. ALWAYS position the laser measure securely. Dam- age to the laser measure and/or serious injury to the user could result if the laser measure falls. Take care to recognize the accuracy and range of the laser measure. Measurement may not be accurate if used beyond the rated range of the laser measure. DO NOT remove or deface any warning or caution labels. Removing labels increases the risk of exposure to laser radiation. -10- Electrical safety Batteries can explode or leak, cause injury or fire. To reduce this risk, always follow all instructions and warnings on the battery label and package. DO NOT short any battery terminals. DO NOT charge alkaline batteries. DO NOT mix old and new batteries. Replace all of them at the same time with new batteries of the same brand and type. DO NOT mix battery chemistries. Dispose of or recycle batteries per local code. DO NOT dispose of batteries in fire. Keep batteries out of reach of children. Remove batteries if the device will not be used for several months. Maintenance DO NOT disassemble the laser measure. There are no user serviceable parts inside. Disassembling the laser will void all warranties on the product. Do not modify the product in any way. Modifying the laser measure may result in hazardous laser radiation expo- sure. ALWAYS remove the batteries when cleaning the la- ser light aperture to laser lens. DO NOT use this laser measure for any purpose other than those outlined in this manual. This could result in serious injury. ALWAYS use only the accessories that are recom- mended by the manufacturer of your laser measure. Use of accessories that have been designed for use with other laser measures could result in serious in- jury. Repair and servicing must alway…

Text truncated - open the document above for the full version.

are Trademarks of Robert Bosch GmbH, Germany Robert Bosch Tool Corporation 1800 W. Central Rd. Mount Prospect, IL 60056 Telephone +1 224 232- 2382 Fax +1 224 232-2984 [email protected] ch.com www.bosch.us To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: TXTGLM1652XX including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Gerard Pasciak Approvals Engineer Robert Bosch Tool Corporation Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 26 May 2020

are Trademarks of Robert Bosch GmbH, Germany Robert Bosch Tool Corporation 1800 W. Central Rd. Mount Prospect, IL 60056 Telephone +1 224 232- 2382 Fax +1 224 232-2984 [email protected] ch.com www.bosch.us Request for Permanent Confidentiality Company name: Robert Bosch Tool Corporation FCC ID: TXTGLM1652XX FCC Part 15 Certification FCC Part 15 Certification Ladies and gentlemen, in accordance with CFR 47 § 0.457 and CFR 47 § 0.459 Robert Bosch Tool Corporation hereby requests confidentiality of following attachments: (1) schematic diagrams, (2) detailed block diagrams, (3) detailed operational descriptions, (4) parts lists. These documents contain detailed system and equipment description and related information about the product which Robert Bosch Tool Corporation considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Robert Bosch Tool Corporation considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 26 May 2020 26 May 2020 Page 2 of 2 Yours sincerely Gerard Pasciak Approvals Engineer Robert Bosch Tool Corporation 1800 W. Central Road 60056 Mount Prospect, IL

08-External Photos page 1 FCC ID: TXTGLM1652XX IC: 909H-GLM1652XX HVIN: GLM165-27C Project No.: G0M-2002-8796 08-External Photos page 2 FCC ID: TXTGLM1652XX IC: 909H-GLM1652XX HVIN: GLM165-27C Project No.: G0M-2002-8796 08-External Photos page 3 FCC ID: TXTGLM1652XX IC: 909H-GLM1652XX HVIN: GLM165-27C Project No.: G0M-2002-8796 08-External Photos page 4 FCC ID: TXTGLM1652XX IC: 909H-GLM1652XX HVIN: GLM165-27C Project No.: G0M-2002-8796

FCC ID: TXTGLM1652XX IC: 909H-GLM1652XX HVIN GLM165-27C G0M‐2002‐8796

09-Internal Photos page 1 FCC ID: TXTGLM1652XX IC: 909H-GLM1652XX HVIN: GLM165-27C Project No.: G0M-2002-8796 09-Internal Photos page 2 FCC ID: TXTGLM1652XX IC: 909H-GLM1652XX HVIN: GLM165-27C Project No.: G0M-2002-8796 09-Internal Photos page 3 FCC ID: TXTGLM1652XX IC: 909H-GLM1652XX HVIN: GLM165-27C Project No.: G0M-2002-8796 09-Internal Photos page 4 FCC ID: TXTGLM1652XX IC: 909H-GLM1652XX HVIN: GLM165-27C Project No.: G0M-2002-8796 09-Internal Photos page 5 FCC ID: TXTGLM1652XX IC: 909H-GLM1652XX HVIN: GLM165-27C Project No.: G0M-2002-8796

Test Report No.: G0M-2002-8796-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 25 EMC TEST REPORT FCC 47 CFR Part 15B, ISED ICES-003 Issue 6 Report Reference No G0M-2002-8796-EF0115B-V01 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation DAkkS - Registration number : D-PL-12092-01-03 (ISED) ISED Testing Laboratory site: 3470A-2 DAkkS - Registration number : D-PL-12092-01-04 (FCC) FCC Filed Test Laboratory, Reg.-No.: 96970 Applicant Robert Bosch Tool Corporation Address 60056 Mount Prospect, IL USA Test Specification Standard(s) 47 CFR Part 15 Subpart B ISED ICES-003 Issue 6 ANSI C63.4:2014+A1:2017 Non-Standard Test Method None Equipment under Test (EUT): Product Description Laser Rangefinder Model(s) GLM165-27C Additional Model(s) None Brand Name(s) BOSCH Hardware Version(s) Main PCBA v0.1 (BOM 08.06.20); CF340 PCBA v11 (BOM 03.01.20) Software Version(s) MCU 0.3.1, Bluetooth 1.6.0 FCC-ID TXTGLM1652XX IC 909H-GLM1652XX Test Result PASSED Test Report No.: G0M-2002-8796-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 25 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EUT Equipment Under Test FCC Federal Communications Commission ISED Innovation, Science and Economic Development Canada T NOM Nominal operating temperature V NOM Nominal supply voltage Test Report No.: G0M-2002-8796-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 25 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2020-10-02 Initial Release Test Report No.: G0M-2002-8796-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 25 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Equipment Ports ............................................................................................................................................ 7 1.2 Equipment Photos - Internal .......................................................................................................................... 8 1.3 Equipment Photos - External ......................................................................................................................... 9 1.4 Support Equipment ...................................................................................................................................... 11 1.5 Operational Modes ...................................................................................................................................... 12 1.6 EUT Configuration ....................................................................................................................................... 12 1.7 Sample emission level calculation ............................................................................................................... 13 2 Result Summary ............................................................................................................................... 14 2.1 Test Conditions and Results - Radiated emissions acc. to ANSI C63.4 ...................................................... 15 Test Report No.: G0M-2002-8796-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 25 1 Equipment (Test Item) Under Test Description Laser Rangefinder Model GLM165-27C Additional Model(s) None Brand Name(s) BOSCH Serial Number(s) 024600048 Hardware Version(s) Main PCBA v0.1 (BOM 08.06.20); CF340 PCBA v11 (BOM 03.01.20) Software Version(s) MCU 0.3.1, Bluetooth 1.6.0 FCC-ID TXTGLM1652XX IC 909H-GLM1652XX Class Class B Equipment type Table top Highest internal frequency [MHz] 2480 Radio Module Type Bluetooth Module Model unspecified Manufacturer unspecified FCC-ID unspecified IC unspecified Supply Voltage V NOM 3.0 VDC (alkaline 2x1.5V(AA)) AC/DC-Adaptor none Manufacturer Robert Bosch Power Tools GmbH 70538 Stuttgart Germany Test Report No.: G0M-2002-8796-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 25 1.1 Equipment Ports Name Type Attributes Comment None Description: AC AC mains power input/output port DC DC power input/output port BAT DC power input port connected to external battery IO Input/Output port TP Telecommunication port NE Non-electrical port Test Report No.: G0M-2002-8796-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 25 1.2 Equipment Photos - Internal EUT PCB front EUT PCB back Test Report No.: G0M-2002-8796-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 25 1.3 Equipment Photos - External EUT FRONT EUT BACK Test Report No.: G0M-2002-8796-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 25 EUT Label Test Report No.: G0M-2002-8796-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 11 of 25 1.4 Support Equipment Product Type Device Manufacturer Model Comment AE Smartphone Samsung S4 for BTLE connection Description: AE Auxiliary Equipment SIM Simulator MON Monitoring Equipment CBL Connecting Cable Comment: Test Report No.: G0M-2002-8796-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 12 of 25 1.5 Operational Modes Mode # Description 1  Bluetooth LE and PRO360-function activated  BT LE connection to smartphone  maximum display brightness  continuous measurement 2  Bluetooth LE and PRO360-function activated  BT LE connection to smartphone  maximum display brightness  single measurement controlled by app (via smartphone) Comment: 1.6 EUT Configuration Configuration # Description 1 EUT is powered via 2x1.5V batteries (AA size)…

Text truncated - open the document above for the full version.

Test Report No.: G0M-2002-8796-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 97 RADIO REPORT FCC 47 CFR Part 15C ISED Canada RSS-247 Digital transmission systems operating within the 2400 – 2483.5 MHz band Report Reference No G0M-2002-8796-TFC247BL-V01 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation DAkkS - Registration number : D-PL-12092-01-03 (ISED) ISED Testing Laboratory site: 3470A-2 DAkkS - Registration number : D-PL-12092-01-04 (FCC) FCC Filed Test Laboratory, Reg.-No.: 96970 Applicant Robert Bosch Tool Corporation Address 60056 Mount Prospect, IL USA Test Specification 47 CFR Part 15C RSS-247, Issue 2, 2017-02 RSS-Gen, Issue 5, Amendment 1, 2019-03 Non-Standard Test Method None Equipment under Test (EUT): Product Description Laser Rangefinder Model(s) GLM165-27C Additional Model(s) None Brand Name(s) BOSCH Hardware Version(s) Main PCBA v0.1 (BOM 08.06.20); CF340 PCBA v11 (BOM 03.01.20) Software Version(s) MCU 0.3.1, Bluetooth 1.6.0 FCCID TXTGLM1652XX IC 909H-GLM1652XX Test Result PASSED Test Report No.: G0M-2002-8796-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 97 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2020-10-02 Initial Release Test Report No.: G0M-2002-8796-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 97 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EUT Equipment Under Test FCC Federal Communications Commission ISED Innovation, Science and Economic Development Canada N/A Not applicable RBW Resolution bandwidth RMS Root mean square T NOM Nominal temperature VBW Video bandwidth V NOM Nominal supply voltage Test Report No.: G0M-2002-8796-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 97 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Photos – Equipment External ........................................................................................................................ 7 1.2 Photos – Equipment Internal ......................................................................................................................... 9 1.3 Photos – Equipment Label .......................................................................................................................... 14 1.4 Photos – Test Setup .................................................................................................................................... 15 1.5 Support Equipment ...................................................................................................................................... 17 1.6 Test Modes ................................................................................................................................................. 18 1.7 Test Frequencies ......................................................................................................................................... 19 1.8 Sample emission level calculation ............................................................................................................... 20 2 Result Summary ............................................................................................................................... 21 3 Test Conditions and Results .......................................................................................................... 22 3.1 Test Conditions and Results - Occupied bandwidth .................................................................................... 22 3.2 Test Conditions and Results - 6 dB bandwidth ............................................................................................ 26 3.3 Test Conditions and Results - Maximum peak conducted output power ..................................................... 30 3.4 Test Conditions and Results - Power spectral density ................................................................................ 35 3.5 Test Conditions and Results - Band-edge compliance ................................................................................ 39 3.6 Test Conditions and Results - Conducted spurious emissions .................................................................... 42 3.7 Test Conditions and Results - Transmitter radiated emissions ................................................................... 46 3.8 Test Conditions and Results - Receiver radiated emissions ....................................................................... 49 ANNEX A Transmitter spurious emissions ....................................................................................................... 52 ANNEX B Receiver spurious emissions ........................................................................................................... 88 Test Report No.: G0M-2002-8796-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 97 1 Equipment (Test Item) Under Test Description Laser Rangefinder Model GLM165-27C Additional Model(s) None Brand Name(s) BOSCH Serial Number(s) 100191258 Test Sample ID 29603 (radiated measurements) 100191311 Test Sample ID 29604 (conducted measurements) Hardware Version(s) Main PCBA v0.1 (BOM 08.06.20); CF340 PCBA v11 (BOM 03.01.20) Software Version(s) MCU 0.3.1, Bluetooth 1.6.0 PMN GLM165-27C HVIN GLM165-27C FVIN 1.6.0 HMN N/A FCCID TXTGLM1652XX IC 909H-GLM1652XX Equipment type End Product Radio type Transceiver Assigned frequency bands 2400 MHz - 2483.5 MHz Radio technology Bluetooth LE 4.2 Modulation GFSK Number of antenna ports 1 Antenna Type Integrated antenna (2.4 GHz Inverted F PCB antenna according to Texas Instruments design SWRU120D) Model SWRU120D Manufacturer - Gain 3.3 dBi (decl…

Text truncated - open the document above for the full version.

Test Report No.: G0M-2002-8796-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 15 RF-EXPOSURE REPORT FCC 47 CFR Part 2.1093 ISED RSS-102 RF-Exposure evaluation of portable equipment Report Reference No G0M-2002-8796-TFC093PE-V01 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation DAkkS - Registration number : D-PL-12092-01-03 (ISED) ISED Testing Laboratory site: 3470A-2 DAkkS - Registration number : D-PL-12092-01-04 (FCC) FCC Filed Test Laboratory, Reg.-No.: 96970 Applicant Robert Bosch Tool Corporation Address 60056 Mount Prospect, IL USA Test Specification According to FCC/ISED rules Standard FCC 47 CFR 2.1093 ISED RSS-102 Issue 5 Non-Standard Test Method None Equipment under Test (EUT): Product Description Laser Rangefinder Model(s) GLM165-27C Additional Model(s) None Brand Name(s) BOSCH Hardware Version(s) Main PCBA v0.1 (BOM 08.06.20); CF340 PCBA v11 (BOM 03.01.20) Software Version(s) MCU 0.3.1, Bluetooth 1.6.0 FCCID TXTGLM1652XX IC 909H-GLM1652XX Test Result PASSED Test Report No.: G0M-2002-8796-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 15 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2020-10-02 Initial Release Test Report No.: G0M-2002-8796-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 15 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EIRP Equivalent Isotropic Radiated Power ERP Effective Radiated Power EUT Equipment Under Test LPE Low Power Exclusion N/A Not applicable Test Report No.: G0M-2002-8796-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 15 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Reference Documents ................................................................................................................................... 7 1.2 Standalone radiation sources ........................................................................................................................ 8 1.3 Concurrent Sources ...................................................................................................................................... 8 2 Result Summary ................................................................................................................................. 9 3 RF-Exposure classification ............................................................................................................ 10 4 RF-Exposure limits and exclusion thresholds ............................................................................ 11 4.1 SAR limits .................................................................................................................................................... 11 4.2 SAR standalone test exclusion threshold .................................................................................................... 11 4.3 SAR concurrent test exclusion threshold ..................................................................................................... 12 5 RF-Exposure Evaluation ................................................................................................................. 13 6 Single Source Evaluation Results - FCC ...................................................................................... 14 7 Single Source Evaluation Results - ISED ..................................................................................... 15 Test Report No.: G0M-2002-8796-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 15 1 Equipment (Test Item) Under Test Description Laser Rangefinder Model GLM165-27C Additional Model(s) None Brand Name(s) BOSCH Serial Number(s) 100191258 Test Sample ID 29603 (radiated measurements) 100191311 Test Sample ID 29604 (conducted measurements) Hardware Version(s) Main PCBA v0.1 (BOM 08.06.20); CF340 PCBA v11 (BOM 03.01.20) Software Version(s) MCU 0.3.1, Bluetooth 1.6.0 PMN GLM165-27C HVIN GLM165-27C FVIN 1.6.0 HMN N/A FCCID TXTGLM1652XX IC 909H-GLM1652XX Equipment type End Product Environment General public Use case Body worn Test Report No.: G0M-2002-8796-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 15 1.1 Reference Documents Document Type Document No. Issued by Date Test Report (FCC/ISED) – FCC 47 CFR 15.247 + ISED RSS-247 Issue 2 (February 2017) G0M-2002-8796- TFC247BL-V01 Eurofins Product Service GmbH 2020-10-02 Test Report No.: G0M-2002-8796-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 15 1.2 Standalone radiation sources Standalone radiation sources Mode Operating Frequency [MHz] Maximum conducted power [dBm] Maximum radiated power [dBm EIRP] Maximum duty cycle [%] Antenna distance to body [mm] Bluetooth Low Energy 2402 4.469 7.769 64 5.0 2440 4.708 8.008 64 5.0 2480 4.591 7.891 64 5.0 Comment: None. 1.3 Concurrent Sources No concurrent radiation sources. Test Report No.: G0M-2002-8796-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 15 2 Result Summary Standalone sources - FCC KDB 447498 Product Standard Reference Requirement Reference Method Mode Verdict KDB 447498 SAR Test Exclusion KDB 447498 4.3.1 Bluetooth Low Energy PASS Comment: None. Standalone sources - ISED RSS-102 Product Standard Reference Requirement Reference Method Mode Verdict ISED RSS-102 SAR Test Exclusion ISED RSS-102 2.5.1 Bluetooth Low Energy PASS Comment: None. Test Report No.: G0M-2002-8796-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 15 3 RF-Exposure classification RF-Exposure Categories Fixed…
