RF209S Summary Manual Link: Charge the receiver then press and hold "SET" button for 3 seconds, wait for the link instruction after the orange light flashes slowly. Mode select: 1 Receiver setting way, press the "SET" to charge, then enter into model setting, gently click the "SET" into switcher mode, press and hold "SET" to confirm . 2 Transmitter setting way , please carry out in [Linkage setting]- [Receiver output] under the normal communication state of transmitter and receiver .After setting, return to the superior menu and save the setting (the receiver light color would be changed). MODE LED Action Status WORK PurpleNeverPWM normal work mode Green Never W.BUS normal work mode Blue Never PPM normal work mode Red Never No signal Slow flash Low voltage Orange Slow flash Linking SET Purple Slow flashPWM mode Green Slow flash W.BUS mode Blue Slow flash PPM mode PPM/PWM/W.BUS/W.BUS2 CH1~7:PWM PPM/W.BUS Signal Positive Negative USB port Link key Status light External voltage inspect port Red line to the positive pole 1Ω resistor to the negative Parameter performance Type: RF209S Band: 2.4GHz Voltage: 3.5V-13V Current: 95mA Application: Helicopter, Airplane, multicopter,Vehicle, Ship, Robot. Resolution: 4096 PWM: 9channels W.BUS: Compatible W.BUS2: Remote sensor input Two-way transmission: Support Lost-control protection: Support Online upgrading: Support Relay flight: Support 180/270°servo: Support Receiver port setting: Support External voltage detection: DC 0~96V Dimension: 47x14x25mm Weight: 12g Shenzhen WFLY Technology Development Co., Ltd www.wflysz.com FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment . This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with minimum distance 20cm between the radiator &you body.
QA-FR-170-B Shen Zhen WFLY Technology Development Co., Ltd. ADD: C2 Building, 4th Floor, Xiangli Industrial Park,Hepinghaoye Road, Fuyong Street, Bao'an District,Shenzhen China TEL: +86-755-26581815 FAX:+86-755-26581821 E-mail: [email protected] FCC Authorization Date: 2020-02-27 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We , Shen Zhen WFLY Technology Development Co., Ltd. , Hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Client’s signature Cheng Ji General Manager
QA-F R-172-A Shen Zhen WFLY Technology Development Co., Ltd. Add: :C2 Building, 4th Floor, Xiangli Industrial Park,Hepinghaoye Road, Fuyong Street, Bao'an District,Shenzhen China Tel: +86-755-26581815 FAX:+86-755-26581821 Email: [email protected] FCC Confidential Authorization Date: 202 0-02-27 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: TZVRF209S In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Shen Zhen WFLY Technology Development Co., Ltd. hereby requests long-term confidential treatment of information accompanying this application as outlined below: Block Diagra m Sch emati cs O peration Descriptio n As well as short-term (secrecy cycle: 45 days) confidential treatment of information accompanying this application as outlined below: Internal Ph otos User’ s Manu al Ex ternal Phot os Test Set -up Phot os Th e above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature Cheng Ji General Manager
Shen Zhen WFLY Technology Development Co., Ltd. Add: C2 Building, 4th Floor, Xiangli Industrial Park,Hepinghaoye Road, Fuyong Street, Bao'an District,Shenzhen China Tel: +86-755-26581815 FAX:+86-755-26581821 Email: [email protected] DECLARATION OF SIMILARITY Date: 2020-02-27 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 D ear Sir or Madam: We, Shen Zhen WFLY Technology Development Co., Ltd., hereby declare that the product: Wireless digital model remote control receiver, FCC ID: TZVRF209S. model: RF207S,RF206S,RF204W,RF201S are electrically identical with the model: RF209S which was tested by BACL with the same electromagnetic emissions and electromagnetic compatibility characteristics. A description of the differences between those models and that are declared similar are as follows: They are the same product, and just the different model name, the rest are the same. Please contact me should there be need for any additional clarification or information. Best Regards, Signature: Cheng Ji General Manager
EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS
:
EXHIBIT C - EUT INTERNAL PHOTOGRAPHS
Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG191220009-00 Page 9 of 41 FCC §15.247 (i) & §1.1310 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart 15.247(i)and subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. Calculation formula: Prediction of power density at the distance of the applicable MPE limit S = PG/4R² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); Calculated Data: Frequency (MHz) Antenna Gain Conducted output power including Tune-up Tolerance Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric)(dBm)(mW) 2402-2470 2 1.58 1979.43 20.00 0.03 1.0 Result: The device meet FCC MPE at 20 cm distance
FCC PART 15.247 TEST REPORT For Shenzhen WFLY Technology Development Co.,Ltd. C2 Building, 4th Floor, Xiangli Industrial Park, Hepinghaoye Road, Fuyong Street, Bao'an District,Shenzhen City,Guangdong Province,China FCC ID: TZVRF209S Report Type: Original Report Product Name: Wireless digital model remote control receiver Re port Number: RDG191220009-00 Re port Date: 2020-03-04 Reviewed By: Ivan Cao Assistant manager Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.69 Pulongcun, Puxinhu Industry Area, Tangxia, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG191220009-00 Page 2 of 41 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 4 TEST METHODOLOGY .................................................................................................................................................. 4 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 TEST FACILITY ............................................................................................................................................................. 5 DECLARATIONS ............................................................................................................................................................ 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 6 EUT EXERCISE SOFTWARE .......................................................................................................................................... 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 7 LOCAL SUPPORT EQUIPMENT LIST AND DETAILS ........................................................................................................ 7 SUPPORT CABLE LIST AND DETAILS ............................................................................................................................ 7 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 7 SUMMARY OF TEST RESULTS ............................................................................................................................... 8 FCC §15.247 (i) & §1.1310 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) ......................................... 9 APPLICABLE STANDARD .............................................................................................................................................. 9 FCC §15.203 - ANTENNA REQUIREMENT ........................................................................................................... 10 APPLICABLE STANDARD ............................................................................................................................................ 10 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 10 FCC §15.209, §15.205 & §15.247(d) - SPURIOUS EMISSIONS ............................................................................. 11 APPLICABLE STANDARD ............................................................................................................................................ 11 EUT SETUP ................................................................................................................................................................ 11 EMI TEST RECEIVER & SPECTRUM ANALYZER SETUP .............................................................................................. 12 TEST PROCEDURE ...................................................................................................................................................... 12 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 12 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 13 TEST DATA ................................................................................................................................................................ 13 FCC §15.247(a) (1) - CHANNEL SEPARATION TEST ......................................................................................... 19 APPLICABLE STANDARD ............................................................................................................................................ 19 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 19 TEST PROCEDURE ...................................................................................................................................................... 19 TEST DATA ...........................................................................…
