U28AWRPAssistive listening device

InstructIons for use Amigo WRP 23 Important notice Please familiarise yourself with the entire contents of this booklet before using your Amigo Wireless Receiver Programmer (WRP). The booklet contains various statements, safety instructions and important information about the use and handling of the Amigo WRP. Content Introduction 5 Typical package content 6 Overview of the WRP 7 Preparing your Amigo system 8 Inserting the battery 8 Charging the battery 9 Selecting language and country 11 The Amigo receivers 12 Changing the pin orientation 13 Attaching the universal Amigo receivers to a hearing instrument 14 Using Amigo with the Sumo R7 receiver 15 Synchronising Amigo receivers 16 Accessing the Programming Menus 18 Overview of the menus of the R1/R2 19 Programming Amigo R1/R2 Receivers 20 Using the FM Channel Wizard (T20/21/WRP 24 45 WRP Special functions 26 LED/Display legend 27 Cleaning the T20/T21 28 Appendix A: Troubleshooting 29 Appendix B: Manufacturers’ warranty 30 Introduction Congratulations on your decision to take the next step in improving classroom FM. The Amigo product family is extremely versatile, making life easier for users in school settings. The Amigo transmitters and receivers can be used with virtually all Behind- the-Ear hearing instruments, as well as cochlear implants. 67 Typical package content Navigation buttons on the WRP SYNC acts as the “ENTER” button “C” acts as the “CLEAR/EXIT” button. ◄ exits a menu while saving. WRP Charger Earphones IFU LED status indicator ON/OFF/Mute 2.5 mm microphone jack High resolution LCD display Clear entered values (“C”) Synchronise receiver/enter 3.5 auxiliary audio input jack “MiniB” USB charge jack Overview of the WRP AA battery 89 Preparing your Amigo system Inserting battery Remove the battery lid on the back of the WRP and insert the rechargeable battery - remember to position the battery according to the markings (+/ -) on the label. Then replace the battery lid. The WRP can then be used to charge the battery that came in the package. Note: The positive and negative ends of the battery may appear similar, so doublecheck that the battery is positioned correctly. Charging the battery To charge the battery, plug in the charger as shown in the picture. The Amigo WRP uses one AA rechargeable NiMH battery, which must be charged for at least 14 hours before being used for the first time. The WRP offers failsafe charging, which prevents alkaline batteries being charged. Charging Error Check Battery! The display on the WRP will indicate when the unit is charging. Also, the LED will turn on and shine green. Note: With a typical user pattern it is recommended to replace rechargeable batteries once every year, because the battery capacity decreases each time it is charged. Battery charging 1011 Select language and country (first time only) Turn the WRP on by pressing and holding the On/Off button for two seconds. Press ▲ or ▼ to select language, and confirm by pressing the SYNC button. To select your country, use the ▲ or ▼ buttons, and confirm by pressing the SYNC button. Select Language English Francais Deutsch • • • Select Country United States Canada Germany • • • If you do not have time to charge the battery that came with the WRP, you can replace the battery with any of the following: • Special “silver-banded” rechargeable batteries (Only available through your Hearing Care Professional, these are the only batteries that can be recharged inside the transmitter.) • Standard, rechargeable NiMH batteries These cannot be recharged inside the transmitter, but must be charged in a separate charger. • Standard, non-rechargeable alkaline batteries Can be used in an emergency, i.e. if you don’t have time to charge your rechargeable batteries. Alkaline batteries cannot be recharged. Note: Always dispose of old batteries in approved battery disposal bins. For more information please consult your Hearing Care Professional. Note: Selecting a country will also select a predefined channel list, which contains all of the channels approved for use in that country. Warning: Only use channels legal in your country. 1213 LED status indicator 3-position mode switch Channel seek/toggle (R2 and R7 only) Note: Since Amigo receivers draw power from the hearing instrument battery, there is no reason to try to open the receiver casing. Never attempt to do this. Changing the pin orientation If the pins on the Amigo receiver do not match the holes on the audio shoe, they can be rotated in steps of 90°. Simply pull the tab on both sides of the receiver back simultaneously, move the pins and push the tab back in. Amigo receivers can be positioned with the LED facing to the front or the back. Note: To ensure optimal antenna performance, the Amigo receivers must be positioned with the LED facing either to the front or to the back. The Amigo Receivers Europin connector Europin rotation lock 1415 Attaching the universal Amigo receivers to a hearing instrument Amigo R1 and R2 receivers are attached to the hearing instrument via an audio shoe. First attach the receiver to the audio shoe. Then attach the audio shoe to the hearing instrument. SUMO DM with the dedicated, Amigo R7 receiver. Using Amigo with the Sumo receiver • Sumo detects the receiver and disables the telecoil if the receiver is on. • Operate the receiver from the hearing instrument 2 = FM only 1 = FM+Hearing instrument M = Hearing instrument only The use of the telecoil with the receiver attached requires that the receiver is set to the off position. Note: To obtain information about connecting your Amigo to Cochlear Implants, please consult your Hearing Care Professional. 1617 Synchronising Amigo receivers Connect the receiver to a hearing instrument, and turn it on. Check that the receiver switch is set to the correct mode, i.e. FM only or FM+HA mode. Off FM-only FM+HA Within a distance of approximately 50 cm, press the SYNC button. The LED on the transmitter will then blink three times, and the S…
