U28FUBTE01Hearing Aid Module

INSTRUCTIONS FOR USE BTE Contents Instrument View BTE 5 Turning your instrument ON and OFF 6 Standby 8 Putting on your instrument 9 Left/Right ear marking 10 Push-button 12 Programs (Optional) 14 Volume Control 16 Changing batteries 18 Tamper-resistant battery door (Optional) 20 Telecoil (Optional) 21 Auto Phone (Optional) 22 DAI (Direct Audio Input) 24 Daily care of your hearing instrument 26 Using your hearing instrument 33 Common problems and their solutions 40 International Warranty 44 Warnings Yellow Pages Important Notice Please familiarise yourself with the entire contents of this booklet before using your hearing instruments. It contains instructions and important information about the use and handling of your hearing instruments and batteries. Congratulations We at Oticon would like to take this opportunity to congratulate you on selecting the most advanced Hearing Instrument on the market today. These instructions will help you get the most out of the instrument and ensure their continued high performance. Carefully follow these instructions when using and maintaining them. Instrument View BTE Microphone Openings Push-button Earmould Battery door Sound Hook Plastic tube Sound outlet Ventilation opening 5 Turning your instrument ON and OFF Turn ON your hearing instrument by closing the battery door completely with the battery in place. When the battery door is closed the instrument will start up by playing a jingle. This indicates that the battery is working and the instrument is operating. Turn OFF your hearing instrument by opening the battery door slightly until a click is felt. To preserve the battery, make sure your hearing instrument is switched off when you are not wearing it. ON Click Click 6 7 OFF Standby Push the button for a minimum of 3 seconds to set the instrument in standby mode. To reactivate the instrument, push the button shortly again. Use the standby function if you need to silence the instru- ment while you have the instrument on. Push 3 sec Note: pushing either side of the button will set the instrument on standby. A B 8 9 Putting on your instrument Place the tip of the earmould in your ear canal, twisting slightly, making sure that the top part of the earmould (A) is pushed behind and under the fold (B) of your ear. Gently pull down your earlope and press the earmould in the direction of the ear canal. With the earmould positioned correctly in your ear, place the hearing instrument behind your ear by lifting its lower part and sliding it over the top of your ear. Left/Right ear marking Hearing instruments are fitted to the uniqueness of each ear, which means if you have two instruments then your left hearing instrument is programmed differently from your right. That is why it is important to distinguish between the left hearing instrument and the right. In order to easily identify whether it is left ear or right ear instrument, colour markings may be applied inside the battery door. A blue dot marks the LEFT instrument A red dot marks the RIGHT instrument 10 12 13 LeftRight Program shift: Press shortly to change program Volume control: Press shortly to adjust the volume Both volume control and Program shift: Press shortly to adjust the volume and press long (about 2 seconds) to shift program. Push-button Your hearing instrument has an ergonomic designed push- button for volume adjustment and switching between different programs. The push-button can be pressed and activated on either the upper part (UP) or the lower part (DOWN). UP DOWN The push-button on your hearing instrument can be programmed to one of 3 functionalities. Binaural Interchangeable enabled To be filled out by your Hearing Care Professional! Below you can see a description of the programs available in your hearing instrument. Prg. 1: __________________________________ Prg. 2: __________________________________ Prg. 3: __________________________________ Prg. 4: __________________________________ Using 2 instruments For ease of use, the push-button can be programmed to change to the equivalent program in the other instrument also, by using the wireless communication between the instruments. This is referred as binaural interchange. You may ask your Hearing Care Professional about the set-up of your instrument. Your hearing instrument can have up to 4 different programs. When switching between the different programs, your hearing instrument will beep. The number of beeps will indicate which program you are using. One beep, when you switch to program 1 Two beeps, when you switch to program 2 Three beeps, when you switch to program 3 Four beeps, when you switch to program 4 e ee eee eeee 14 15 Programs (Optional) 16 17 A volume control may be activated The volume control allows you to adjust the volume in specific listening situations to the level you feel comfortable with. To increase volume, click the upper part of the push-button. To decrease volune, click the lower part of the push-button. When max. and min. levels are reached, this is indicated by 2 beeps. When the hearing instrument is turned on, it starts up at a preferred volume level. When adjusting the volume control to the preferred level, this is indicated by a beep. Volume Control (Optional) Using 2 instruments For ease of use, the push-button can be programmed to adjust the volume in the other instrument equivalently, by using the wireless communication between the instruments. This is referred as binaural interchange. You may ask your Hearing Care Professional about the set-up of your instrument. Volume Control (Optional) 18 19 Changing batteries Your hearing instrument battery size is 312 A worn out battery should be removed immediately. When the battery power is low, you will hear 2 beeps. This pre-warning starts when the battery has only a few hours of operation left. The pre-warning will be repeated with moderate intervals to indi- cate it is time to change the battery. If the battery runs out the instrument turns off. When th…

Text truncated - open the document above for the full version.

48 49 Waste from electronic equipment must be handled according to local regulations. 0543 ID: U28FUBTE01 IC: 1350B-FUBTE01 The hearing instrument contains a module with: The device complies with Part 15 of the FCC rules and RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. this device may not cause harmful interference 2. this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications made to the equipment not expressly approved by Oticon may void the FCC’s authorization to operate the equipment. Oticon A/S 9, Kongebakken DK-2765 Smørum www.hear-it.org www.oticon.com

CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-4458-02-06b/06 Date: 2007-02-26 Page 1 of 25 Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: IC 3463A-1 TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number DAT-P-176/94-D1 Independent ETSI compliance test house ETSI Accredited Bluetooth ® Test Facility (BQTF) Test report no. : 2-4458-02-06b/06 Applicant : Oticon S/A Type : BTE / RITE Test Standard : FCC Part 15.247, 15.223 RSS-210 Issue 6 FCC ID : U28FUBTE01 Certification No. IC : 1350B-FUBTE01 The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Cetecom ICT is under license CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-4458-02-06b/06 Date: 2007-02-26 Page 2 of 25 Table of contents 1. ADMINISTRATIVE DATA ...................................................................................................................................... 3 1.1. ADMINISTRATIVE DATA OF THE TEST FACILITY..................................................................................................... 3 1.1.1 Identification of the testing laboratory ......................................................................................................... 3 1.1.2 Organizational items..................................................................................................................................... 3 1.1.3 Applicant ́s details ........................................................................................................................................ 4 1.2 ADMINISTRATIVE DATA OF MANUFACTURER / MEMBER........................................................................................ 4 1.3 DESCRIPTION OF THE EQUIPMENT UNDER TEST (EUT) .......................................................................................... 5 1.3.1 EUT: Type, S/N etc. ...................................................................................................................................... 5 1.4 TEST SETUP........................................................................................................................................................... 6 1.5 TEST SPECIFICATIONS............................................................................................................................................ 6 2 STATEMENT OF COMPLIANCE .......................................................................................................................... 7 2.1 SUMMARY OF MEASUREMENT RESULTS................................................................................................................ 7 2.1.1 CFR 47 Part 15 Radio frequency devices ..................................................................................................... 7 3 MEASUREMENTS AND RESULTS ....................................................................................................................... 8 4 FCC PART 15 SUBPART C...................................................................................................................................... 9 4.1 Timing of the transmitter .................................................................................................................................. 9 4.2 Field strength of the fundamental § 15.209 (a) / 15.223............................................................................ 10 4.3 Field strength of the harmonics and the spurious § 15.209 (a) / 15.223 ...................................................... 12 4.4 Plots of measurements .................................................................................................................................... 13 4.5 Receiver spurious emission (radiated)............................................................................................................ 15 4.6 Conducted Limits ............................................................................................................................................ 17 5 USED TESTEQUIPMENT...................................................................................................................................... 18 6 ANNEX B: PHOTOGRAPHS OF TEST SITE ..................................................................................................... 21 7 ANNEX C: EXTERNAL PHOTOGRAPHS OF THE EQUIPMENT ................................................................ 23 8 ANNEX D: INTERNAL PHOTOGRAPHS OF THE EQUIPMENT.................................................................. 24 ANNEX 1: TECHNICAL PRODUCT DESCRIPTION CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-4458-02-06b/06 Date: 2007-02-26 Page 3 of 25 1. Administrative data 1.1. Administrative data of the test facility 1.1.1 Identification of the testing laboratory Company name: Cetecom ICT Services GmbH Address: Untertürkheimerstr. 6-10 D-66117 Saarbruecken Germany Laboratory accreditation: DAR-Registration No. DAT-P-176/94-D1 Bluetooth Qualification Test Facility (BQTF) Responsible for testing laboratory: Harro Ames Phone: +49 681 598 0 Fax: +49 681 598 9075 email: [email protected] ........................................................................................... Responsible for testing (Stefan Bös) 1.1.2 Organizational items Reference No.: 2-4458-02-06b/06 Order No.: Receipt of EUT: 2007-02-13 Date(s) of test: 2007-02-13 to 2007-02-14 Date of report: 2007-02-26 Number of report pages: 25 Number of diagram pages (annex): ---------------------------------------…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-4458-02-06b/06 Date: 2007-02-26 Page 21 of 25 6 Annex B: Photographs of Test site Photo 1: Radiated Emissions CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-4458-02-06b/06 Date: 2007-02-26 Page 22 of 25 Photo 2: Radiated Emissions
