U5MIFJ-BBLUETOOTH INTERFACE

User’s Manual SRP-F310/312/313II Front Exit Thermal Printer IFJ-W, IFJ-Bi(Equipped Interface card) Rev. 1.00 http://www.bixolon.com SRP-F310/312/313II ■ Safety Precautions In using the present appliance, please keep the following safety regulations in order to prevent any hazard or material damage. WARNING Violating following instructions can cause serious injury or death. Do not bend the cable by force or leave it under any heavy object. • A damaged cable can cause a fire. Do not plug in or unplug with your hands wet. • You can be electrocuted. Keep the plastic bag out of children’s reach. • If not, a child may put the bag on his head. Do not pull the cable to unplug. • This can damage the cable, which is the origin of a fire or a breakdown of the printer. You must use only the supplied adapter. • It is dangerous to use other adapters. Do not plug several products in one multi-outlet. • This can provoke over-heating and a fire. • If the plug is wet or dirty, dry or wipe it before usage. • If the plug does not fit perfectly with the outlet, do not plug in. • Be sure to use only standardized multi-outlets. PROHIBITED PROHIBITED PROHIBITED PROHIBITED PROHIBITED ONLY SUPPLIED ADAPTER PROHIBITED Rev. 1.00 - 2 - SRP-F310/312/313II CAUTION Violating following instructions can cause slight wound or damage the appliance. Do not use the printer when it is out of order. This can cause a fire or an electrocution. • Switch off and unplug the printer before calling your dealer. Do not let water or other foreign objects in the printer. • If this happened, switch off and unplug the printer before calling your dealer. Use only approved accessories and do not try to disassemble, repair or remodel it for yourself. • Call your dealer when you need these services. • Do not touch the blade of auto cutter. Install the printer on the stable surface. • If the printer falls down, it can be broken and you can hurt yourself. Keep the desiccant out of children’s reach. • If not, they may eat it. If you observe a strange smoke, odor or noise from the printer, unplug it before taking following measures. • Switch off the printer and unplug the set from the mains. • After the disappearance of the smoke, call your dealer to repair it. TO UNPLUG PROHIBITED DISASSEMBLING PROHIBITED PROHIBITED PROHIBITED TO UNPLUG PRINTER PRINTER PRINTER PRINTER DEALER PRINTER Rev. 1.00 - 3 - SRP-F310/312/313II ■ Warning - U.S.A i) Class B Digital Device This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications, However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. ii) Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. iii) Cation: Exposure to Radio Frequency Radiation. To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm must be maintained between the antenna of this device and all persons. ■ Notice - Canada This Apparatus complies with class “B” limits for radio interference as specified in the Canadian department of communications radio interference regulations. Get appareil est conforme aux normes class “B” d’interference radio tel que specifier par ministre canadien des communications dans les reglements d’interference radio. ■ Caution Some semiconductor devices are easily damaged by static electricity. You should turn the printer “OFF”, before you connect or remove the cables on the rear side, in order to guard the printer against the static electricity. If the printer is damaged by the static electricity, you should turn the printer “OFF”. Rev. 1.00 - 4 - SRP-F310/312/313II ■ Waste Electrical and Electric Equipment ( WEEE) This marking shown on the product or its literature, indicates that is should not be disposed with other household wastes at the end of its working life, To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal. ■ Rating Label Symbol Information DC (Direct current) ■ Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. ■ Label Material * Control Label: PC * Other Labels: PET Rev. 1.00 - 5 - SRP-F310/312/313II ■ Introduction SRP-F310/312/313II series printers have been designed to be connected to various types of electronic devices such as ECR (Electronic Cash Register), POS (Point Of Sa…

Text truncated - open the document above for the full version.

7th-8th FL, MiraeAsset Venture Tower, 20, Pangyoyeok-ro 241beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Tel No : +82-31-218-5582 Fax No : +82-31-218-5589 ATTESTATION STATEMENT In re : BIXOLON Co., Ltd. FCC ID : U5MIFJ-B Date : March 13, 2015 15.247(a)(1) The hopping sequence is random. Each hopping channels is used equally on the average. The receiver input bandwidth matches the bandwidth of the transmitted signal. The receiver has the ability to shift frequencies in synchronization with the transmitted signals. Example of a 79 hopping sequence in data mode: 20 62 46 77 7 64 8 73 16 75 1 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information). 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. Sincerely, Young-taek Lee / Assistant Manager

Rev 11/20/07 7th-8th FL, MiraeAsset Venture Tower, 20, Pangyoyeok-ro 241beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Tel No : +82-31-218-5582 Fax No : +82-31-218-5589 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: U5MIFJ-B Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Parts List Operational description Block Diagram (U5MIFJ-B).pdf Schematics (U5MIFJ-B).pdf Part List (U5MIFJ-B).pdf Operational Description (U5MIFJ-B).pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name - - Sincerely, Jinseob Oh / CEO BIXOLON Co., Ltd.

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com EUT External Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Label and Location

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com EUT Internal Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Base Board CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Bluetooth Board CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Antenna

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Test Report No.: CTK-2015-00353 Date: 2015-03-16 Page 1 of 57 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) TEST REPORT For FCC FCC Standards : FCC 47CFR part 15 subpart C Test Report No. : CTK-2015-00353 Date of Issue : 2015-03-16 FCC ID : U5MIFJ-B Basic Model/Type No. : IFJ-B Kind of Product : BLUETOOTH INTERFACE Applicant : BIXOLON Co., Ltd. Applicant Address : 7th-8th FL, Miraeasset Venture Tower, 20, Pangyoyeok-ro 241beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Manufacturer : BIXOLON Co., Ltd. Manufacturer Address : 7th-8th FL, Miraeasset Venture Tower, 20, Pangyoyeok-ro 241beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Contact Person : Shin Ji Sung / Assistant Manager Telephone : +82–31-218-5582 Received Date : 2015-01-27 Test period : Start : 2015-02-03 End : 2015-02-26 Test Results : In Compliance Not in Compliance The test results presented in this report relate only to the object tested. Tested by Reviewed by Young-taek Lee Test Engineer Young-Joon, Park Technical Manager Date: 2015-03-16 Date: 2015-03-16 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Test Report No.: CTK-2015-00353 Date: 2015-03-16 Page 2 of 57 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) REPORT REVISION HISTORY Date Revision Page No 2015-03-16 Issued (CTK-2015-00353) All This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. will constitute fraud and shall nullify the document. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Test Report No.: CTK-2015-00353 Date: 2015-03-16 Page 3 of 57 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) TABLE OF CONTENTS REPORT REVISION HISTORY ........................................................................................... 2 1.0 General Product Description ................................................................................ 4 1.1 Tested Frequency ............................................................................................... 4 1.2 Tested Mode ...................................................................................................... 4 1.3 Model Differences .............................................................................................. 5 1.4 Device Modifications ........................................................................................... 5 1.5 Peripheral Devices ............................................................................................. 5 1.6 Calibration Details of Equipment Used for Measurement ......................................... 5 1.7 Test Facility ....................................................................................................... 5 1.8 Laboratory Accreditations and Listings .................................................................. 6 2.0 Summary of tests .............................................................................................. 7 2.1 Transmitter Requirements ................................................................................... 8 2.1.1 Carrier Frequency Separation ........................................................................ 8 2.1.2 Number of Hopping Frequencies .................................................................. 10 2.1.4 Time of Occupancy (Dwell Time) .................................................................. 19 2.1.5 Maximum peak Conducted Output Power ...................................................... 25 2.1.6 RF Conducted Emissions ............................................................................. 33 2.1.7 Other requirements Frequency Hopping Spread Spectrum System ................... 44 2.1.8 Field Strength of Emissions ......................................................................... 45 2.1.9 AC Conducted Emissions ............................................................................. 54 APPENDIX A – Test Equipment Used For Tests ................................................................. 57 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Test Report No.: CTK-2015-00353 Date: 2015-03-16 Page 4 of 57 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) 1.0 General Product Description Equipment model name IFJ-B Serial number Prototype EUT condition Pre-production, not damaged Antenna type Chip antenna Gain -0.28 dBi Frequency Range 2402 MHz - 2480 MHz RF power 8.74 dBm Peak Conducted (GFSK) 7.02 dBm Peak Conducted (π/4 DQPSK) 7.04 dBm Peak Conducted (8-DPSK) Type of Modulation Frequency Hopping Spread Spectrum Number of channels 79 Channel Spacing 1 MHz Channel Access Protocol Frequency Hopping Type of Modulation GFSK(1Mbps), DQPSK(2Mbps), 8-DPSK(3Mbps) Power Source DC 3.3 V 1.1 Tested Frequency LOW MID HIGH Frequency (MHz) 2402 2441 2480 1.2 Tested Mode - Pre-Scan has been conducted to determine the worst-case mode from all possible combinations between available modulations, data rates and antenna ports (if EUT with antenna diversity architecture). - Following channel(s) was (were) selected for the final test as listed below. Tested Ch Modulation Technology Modulation T…
