U5MSPP-R200Thermal Mobile Printer

User's Manual Mobile Printer http://www.samsungminiprinters.com Rev. 1.00 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. CAUTION : Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Information to the user Rev. 1.00 Safety Precautions In using the present appliance, please keep the following safety regulations in order to prevent any hazard or material damage. WARNING Violating following instructions can cause serious injury or death. Do not bend the cable by force or leave it under any heavy object. A damaged cable can cause a fire. Do not plug in or unplug with your hands wet. You can be electrocuted. Keep the plastic bag out of children’s reach. If not, a child may put the bag on his head. Do not pull the cable to unplug. This can damage the cable, which is the origin of a fire or a breakdown of the printer. You must use only the supplied adapter. It is dangerous to use other adapters. Do not plug several products in one multi-outlet. This can provoke over-heating and a fire. If the plug is wet or dirty, dry or wipe it before usage. If the plug does not fit perfectly with the outlet, do not plug in. Be sure to use only standardized multi-outlets. PROHIBIT PROHIBIT PROHIBIT PROHIBIT PROHIBIT ONLY SUPPLIED ADAPTER PROHIBIT Rev. 1.00 CAUTION Violating following instructions can cause slight wound or damage the appliance. Do not use the printer when it is out of order. This can cause a fire or an electrocution. Switch off and unplug the printer before calling your dealer. Do not let water or other foreign objects in the printer. If this happened, switch off and unplug the printer before calling your dealer. Use only approved accessories and do not try to disassemble, repair or remodel it for yourself. Call your dealer when you need these services. Do not touch the blade of auto cutter. Install the printer on the stable surface. If the printer falls down, it can be broken and you can hurt yourself. Keep the desiccant out of children’s reach. If not, they may eat it. If you observe a strange smoke, odor or noise from the printer, unplug it before taking following measures. Switch off the printer and unplug the set from the mains. After the disappearance of the smoke, call your dealer to repair it. TO UNPLUG PROHIBIT DISASSEMBLING PROHIBITED PROHIBIT PROHIBIT TO UNPLUG PRINTER PRINTER PRINTER PRINTER DEALER PRINTER Rev. 1.00 All rights reserved. No part of this publication may reproduced, stored in a retrieval, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of BIXOLON. No patent liability is assumed with respect to the use of the information contained herein. While every precaution has been taken in the preparation of this book, BIXOLON assumed no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Neither BIXOLON nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of : accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with BIXOLON s operating and maintenance instructions. BIXOLON shall not be liable against any damages or problems arising from the use of any options or ant consumable products other than those designated as Original Samsung products or Samsung Approved products by BIXOLON. Notice The contents of this manual are subject to change without notice. Copyright 2007 BIXOLON CO., LTD WARNING The connection of a non-shielded printer interface cable to this printer will invalidate the EMC standards of this device. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. Waste Electrical and Electric Equipment (WEEE) This marking shown on the product or its literature, indicates that is should not be disposed with other household wastes at the end of its working life, To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal. Label Material * Rating Label: PP * Other Labels: PET Rev. 1.00 Introduction The SPP-…

Text truncated - open the document above for the full version.

BIXOLON Co.,Ltd. Date: MAR , 14, 2007 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize CTK Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CTK Co., Ltd. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CTK Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely, __________________________ Chi young, Ahn R&D / Assistant Manager

A-5F , Digital Empire Bldg,980-3, Yeongtong-Dong, Yeongtong-Gu,Suwon,Gyeonggi-Do, Korea Tel No : +82-31-218-5555 Fax No : +82-31-218-5589 Mar 15 , 2007 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : BIXOLON CO.,LTD. FCC ID : U5MSPP-R200 Request for Confidentiality Gentlemen: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics, Parts list, Block diagram and Operational description. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, __________________________ Chi young,Ahn R&D / Assistant Manager

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com FCC ID: U5MSPP-R200 Page 1 of 2 EUT External Photographs CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com FCC ID: U5MSPP-R200 Page 2 of 2

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com FCC ID: QZCGBH-M100 Page 1 of 1 FCC ID label and Location BIXOLON Co., Ltd. FCC ID: U5MSPP-R200 M/N: BIXOLON Co., Ltd. / Korea This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, Including interference that may cause undesired operation. Made in Korea Label

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com FCC ID: U5MSPP-R200 Page 1 of 3 EUT Internal Photographs CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com FCC ID: U5MSPP-R200 Page 2 of 3 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com FCC ID: U5MSPP-R200 Page 3 of 3

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: 2007020038 Date: March 16, 2007 Page 1 of 36 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) TEST REPORT For FCC Test Report No. : 2007020038 Date of Issue : March 16, 2007 FCC ID : U5MSPP-R200 Model/Type No. : SPP-u200vwxyz Kind of Product : Thermal mobile printer Applicant : BIXOLON Co., Ltd. Applicant Address : A-5F, Digital Empire Bldg., 980-3 Yeongtong-Dong, Yeongtong-Gu, Suwon, Gyeonggi Korea Manufacturer : BIXOLON Co., Ltd. Manufacturer Address : A-5F, Digital Empire Bldg., 980-3 Yeongtong-Dong, Yeongtong-Gu, Suwon, Gyeonggi Korea Contact Person : Chi young Ahn / Assitant Manager Telephone : +82-31-218-5555 Received Date : Febarury 22, 2007 Test period : Start : Febarury 01, 2007 End : March 15, 2007 Test Results : In Compliance Not in Compliance The test results presented in this report relate only to the object tested. CTK Co., Ltd. is accredited by Korea Laboratory Accreditation Scheme (KOLAS) which signed the International Laboratory Accreditation Cooperation (ILAC) Mutual Recognition Arrangement (MRA) for the above test item(s) and test method(s). Tested by Reviewed by Eun-Won, Lee Test Engineer Young-Joon, Park Technical Manager Date: March 16, 2007 Date: March 16, 2007 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: 2007020038 Date: March 16, 2007 Page 2 of 36 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) REPORT REVISION HISTORY Date Revision Page No March 16, 2007 Issued (2007020038) All This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. will constitute fraud and shall nullify the document. CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: 2007020038 Date: March 16, 2007 Page 3 of 36 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) TABLE OF CONTENTS REPORT REVISION HISTORY ..........................................................................................2 1.0General Product Description ...............................................................................4 1.1Tested Frequency .............................................................................................4 1.2Model Differences .............................................................................................5 1.3Device Modifications .........................................................................................5 1.4Peripheral Devices ............................................................................................5 1.5Calibration Details of Equipment Used for Measurement .........................................6 1.6Test Facility......................................................................................................6 1.7Laboratory Accreditations and Listings .................................................................6 2.0Summary of tests .............................................................................................7 2.1Transmitter Requirements ..................................................................................8 2.1.1Carrier Frequency Separation .......................................................................8 2.1.2Number of Hopping Frequencies ................................................................. 10 2.1.320 dB bandwidth ...................................................................................... 12 2.1.4Time of Occupancy (Dwell Time) ................................................................. 14 2.1.5Maximum peak Conducted Output Power...................................................... 18 2.1.6Band-edge............................................................................................... 21 2.1.7Field Strength of Emissions ........................................................................ 30 2.1.8AC Conducted Emissions............................................................................ 33 APPENDIX A – Test Equipment Used For Tests ................................................................ 36 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: 2007020038 Date: March 16, 2007 Page 4 of 36 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) 1.0 General Product Description Equipment model name : SPP-u200vwxyz Serial number : Prototype EUT condition : Pre-production, not damaged Antenna type : Chip antenna Gain 1.77dBi Frequency Range : 2402 ~ 2480 MHz RF output power Range : -6 dBm ~ +4 dBm (Class 2) RF power : 2.83 dBm - Conducted Number of channels : 79 Channel Spacing : 1 MHz Channel Access Protocol : Frequency Hopping Type of Modulation : GFSK Power Source : Internal Lithium-ion Battery(rechargeable battery) - 3.7 Vdc 1.1 Tested Frequency LOW MID HIGH Frequency (MHz) 2402 2441 2480 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: 2007020038 Date: March 16, 2007 Page 5 of 36 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 SubpartC(Rev.2) 1.2 Model Differences In the mod…

Text truncated - open the document above for the full version.

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com FCC ID: U5MSPP-R200 Page 1 of 2 Test Setup Photos and Configuration Conducted Voltage Emissions CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com FCC ID: U5MSPP-R200 Page 2 of 2 Radiated Electric Field Emissions
