Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
RE116_GE_Siren_Instructions.doc Page 1 of 4 2/20/20 12 www.ResolutionProducts.com Wireless Security Solutions RE116 Siren, GE ® -Simon XT Compatible Features • Remote Wireless Siren • For operation with Simon XT • Responds to wireless alarm signal from panel • Panel supervises Siren & Siren (optionally) supervi ses Panel • Backup power on CR123A battery • Cover tamper • Unparalleled wireless range • Low Battery indication • 3x4x1.25 inches Key Instructions • Requires either Resolution RE920 or RE922 Alarm Com municator Cards, which send wireless alarm signal. • Engage Battery by removing pink isolator tab. Battery “+” faces to right, away from tamper spring . • Mode 1: Panel supervises Siren & Siren supervises Panel Set switches Press ENROLL switch on Simon Communicator board. Put Panel in Enroll Mode. Press & Release Siren Tamper to enroll Siren in Pan el. • Alternate Mode 2: Panel supervises Siren & Siren D OES NOT supervise Panel Set switches Put Panel in Enroll Mode. Press & Release Siren Tamper to enroll Siren in Pan el. • Put Siren switches in RUN Mode: 1 2 1 2 1 2 RE116_GE_Siren_Instructions.doc Page 2 of 4 2/20/20 12 www.ResolutionProducts.com Operation • Alarm Siren follows panel alarm pattern. • Supervision Siren sends supervisory signals to panel IF: Siren has AC power. AND (if siren is set to supervise panel...) Siren has heard signal from panel in previous 60 mi nutes. • Tamper When battery cover is opened. Tamper Switch F unction Switches Yellow LED • ON if AC present. • Flashes on hearing from Panel. R ed LED • On if AC Present. • Flashes short ON when AC lost. • Flashes evenly ON/OFF in Enroll. Battery “+” B attery isolator tab. Bemove. RE116_GE_Siren_Instructions.doc Page 3 of 4 2/20/20 12 www.ResolutionProducts.com Specifications Device Behavior: Siren Supervision acts like a Door /Window Battery & Tamper Supervisory Time 64-68 minutes Alarm Patterns: Follows panel Siren ON/OFF Directly Shortest ON pulse: 250 ms Shortest OFF Pulse: 250 ms Alarm Sound Intensity 85dB, minimum, at 1m Receiver: Dual antenna diversity Transmitter> Dual antenna Dirersity Electrical Connection: US 2-prong Electrical outlet blades Mounting hardware: Secure with outlet plate mountin g screw Terminal wire capacity: 16 Gauge Replacement Battery: CR123A 1550 mAH Temperature Range: 0F to 120F Housing dimensions: 3x4x1.25 inches Specifications subject to change without notice. RE116_GE_Siren_Instructions.doc Page 4 of 4 2/20/20 12 www.ResolutionProducts.com Notices “GE”, “Honeywell”, and “DSC” are trademarks owned b y General Electric Company, Honeywell International Inc., and Tyco Safety Products Canada LTD, respectively. Resolution Products, Inc. products will function wi th one of either GE, DSC or Honeywell systems. However, no Resolution product is produced by, endo rsed by, nor is officially associated with GE, Honeywell or DSC. Resolution recommends verifying proper enrollment and operation, per control panel installation instructions, at installation. Warranty Resolution Products, Inc. will replace products tha t are defective in their first year. FCC Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference that may b e received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the Resolution Products, Inc. could void the user's authority to operate this equipment. FCC ID: U5X-RE116 IC Notice This device complies with Industry Canada license-e xempt RSS standard(s). Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, includ ing interference that may cause undesired operation of the device. Cet appareil est conforme avec d’Industrie Canada R SS standard exempts de licence. Son fonctionnement est soumis aux deux conditions suiva ntes: 1. Ce dispositif ne peut causer des interférences, et 2. Ce dispositif doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement du disposi tif. IC: 8310A-RE116
February 22, 2012 RE: Confidentiality Request for U5X-RE116/8310A-RE116 To Whom It May Concern: Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality RequestedExhibit Short Term PermanentBlock Diagrams Short TermExternal Photos Short Term Permanent* 1 Internal Photos Short Term PermanentOperation Description/Theory of Operation Short Term PermanentParts List & Placement/BOM Short Term PermanentTune-Up Procedure Short Term PermanentSchematics Short TermTest Setup Photos Short Term Permanent*User’s Manual *Note: ______(Insert Explanation as Necessary)______ Resolution Products, Inc. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By:__________________________ Paul Saldin, Vice President (Signature/Title 3 )(Print name) 2 - Please refer to http://atcb.com/publicdocs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.
Exhibit A RE116 External Photos
Exhibit B RE116 ID Label Photo
Exhibit C RE116 Internal Photos
Engineering Solutions & Electromagnetic Compatibility Services FCC 15.231 Test Data for Model: 56-0042-01 WIRELESS SIREN 319.5 MHz (RTL barcode: 020232) for Resolution Engineering RTL Project Number 2011177 Test Engineer: Jon Wilson This report may not be reproduced, except in full, without the full written approval of Rhein Tech Laboratories, Inc. and Resolution Engineering. Test results relate only to the item tested. These tests are accredited and meet the requirements of ISO/IEC 17025 as verified by ANSI-ASQ National Accreditation Board/ACLASS. Refer to certificate and scope of accreditation AT-1445. Rhein Tech Laboratories, Inc. Client: Resolution Engineering 360 Herndon Parkway Model: 56-0042-01 WIRELESS SIREN 433.9 MHz Suite 1400 FCC ID: N/A Herndon, VA 20170 Standards: FCC Part 2, 15 http://www.rheintech.com Report #: 2011177 2 of 12 Description of testing presented in this test report The data and limits presented in this report are for peak emissions limiting per 15.231(b)(2) which references 15.35(b), and peak limiting for restricted bands per 15.209(e) which again references 15.35(b)(2), as procured by Resolution Engineering. No average data is presented in this report. Radiated Emissions Test Data – FCC Limits / 3m Distance Mode: Antenna - DIP 1 On Emission Frequency (MHz) Test Detector Antenna Polarity (H/V) Analyzer Reading (dBuV) Site Correction Factor (dB/m) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Pass/ Fail 319.510 Peak H 63.2 26.4 89.6 95.9 -6.3 Pass 639.020 Peak H 69.6 -5.2 64.4 75.9 -11.5 Pass 958.520 Peak V 53.7 -1.8 51.9 75.9 -24.0 Pass 1278.025 Peak H 66.1 3.0 69.1 74.0 -4.9 Pass 1597.535 Peak H 54.4 6.7 61.1 74.0 -12.9 Pass 1917.045 Peak H 48.6 11.7 60.3 75.9 -15.6 Pass 2236.661 Peak H 49.5 -8.3 41.2 74.0 -32.8 Pass 2556.184 Peak H 48.8 -9.1 39.7 75.9 -36.2 Pass 2875.707 Peak V 59.9 -8.0 51.9 74.0 -22.1 Pass 3195.230 Peak H 49.0 -6.8 42.2 75.9 -33.7 Pass Mode: Antenna - DIP 2 On Emission Frequency (MHz) Test Detector Antenna Polarity (H/V) Analyzer Reading (dBuV) Site Correction Factor (dB/m) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Pass/ Fail 319.505 Peak H 64.6 26.4 91.0 95.9 -4.9 Pass 639.015 Peak H 71.8 -5.2 66.6 75.9 -9.3 Pass 958.525 Peak H 60.3 -1.8 58.5 75.9 -17.4 Pass 1278.008 Peak V 67.6 3.0 70.6 74.0 -3.4 Pass 1597.533 Peak V 55.0 6.7 61.7 74.0 -12.3 Pass 1917.027 Peak V 48.3 11.7 60.0 75.9 -15.9 Pass 2236.661 Peak H 48.3 -8.3 40.0 74.0 -34.0 Pass 2556.184 Peak V 44.7 -9.1 35.6 75.9 -40.3 Pass 2875.707 Peak H 50.1 -8.0 42.1 74.0 -31.9 Pass 3195.230 Peak H 47.9 -6.8 41.1 75.9 -34.8 Pass Rhein Tech Laboratories, Inc. Client: Resolution Engineering 360 Herndon Parkway Model: 56-0042-01 WIRELESS SIREN 433.9 MHz Suite 1400 FCC ID: N/A Herndon, VA 20170 Standards: FCC Part 2, 15 http://www.rheintech.com Report #: 2011177 3 of 12 Test Procedure Radiated emissions of the harmonics were tested at three meters. The EUT was tested in the three orthogonal planes with the receive antenna in both polarities. The emissions were maximized per ANSI C63.4:2003 8.3.1.2; that is, the measurement antenna height was varied between 1 and 4 m, and the EUT was rotated through 360° on a rotating turntable until the maximum emissions were found. Both horizontal and vertical measurement antenna polarizations were used. A resolution bandwidth of 100 kHz was used for frequencies less than 1000 MHz, and a resolution bandwidth of 1 MHz was used for frequencies greater than or equal to 1000 MHz. The video bandwidth was set to a value at least three times greater than the resolution bandwidth. EUT Disposition The EUT was adapted to continuously transmit for testing purposes. Radiated Emissions Test Equipment Part Manufacturer Model Serial Number RTL Bar Code Calibration Due Date Amplifier (20 MHz-2 GHz) Rhein Tech Laboratories, Inc. PR-1040 900905 900905 4/10/12 Bilog Periodic Antenna (25 MHz-2 GHz) Schaffner Chase CBL6112 2099 900791 12/12/12 EMI Receiver RF Section (9 KHz-6.5 GHz) Hewlett Packard 85462A 3325A00159 900913 6/8/12 RF Filter Section (100 KHz-6.5 GHz) Hewlett Packard 85460A 3330A00107 900914 6/8/12 Amplifier (1 GHz–26.0 GHz) Rhein Tech Laboratories, Inc. PR-1042 N/A 901364 7/14/12 Horn Antenna (2.0-4.0 GHz) EMCO 3161-02 9804-1044 900772 6/13/12 Emissions Testing Software Rhein Tech Laboratories, Inc. Automated Emission Tester Rev. 14.0.2 N/A N/A Test Personnel: Jon Wilson November 10, 2011 Test Engineer Signature Date of Test Rhein Tech Laboratories, Inc. Client: Resolution Engineering 360 Herndon Parkway Model: 56-0042-01 WIRELESS SIREN 433.9 MHz Suite 1400 FCC ID: N/A Herndon, VA 20170 Standards: FCC Part 2, 15 http://www.rheintech.com Report #: 2011177 4 of 12 Conducted Line Emissions Test Data – FCC Limits DIP 2 On - Phase DIP 2 On - Neutral Rhein Tech Laboratories, Inc. 15.107, Class B Phase Line 100.0K 1.0M 10.0M 100.0M Frequency MHz 0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 100.0 Amplitude dBuV 08:50:52 AM, Wednesday, November 09, 2011 Project # - 2011177 Mode - 115vac, 60Hz Model Number - Wireless Siren Company - Resolution Engineering C ISPR B _QP C ISPR B _A V C _Line_1 Line_1_qp Final_L1_A vg Rhein Tech Laboratories, Inc. 15.107, Class B Neutral Line 100.0K 1.0M 10.0M 100.0M Frequency MHz 0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 100.0 Amplitude dBuV 08:52:05 AM, Wednesday, November 09, 2011 C:\Tile4\RTL Conducted Emissions\SA3 SR2 Blue Cable Class B.TIL Project # - 2011177 Mode - 115vac, 60Hz Model Number - Wireless Siren Company - Resolution Engineering C ISPR B A vg C ISPR B QP N eutral Scan Line_2_qp Final_L2_A vg Rhein Tech Laboratories, Inc. Client: Resolution Engineering 360 Herndon Parkway Model: 56-0042-01 WIRELESS SIREN 433.9 MHz Suite 1400 FCC ID: N/A Herndon, VA 20170 Standards: FCC Part 2, 15 http://www.rheintech.com Report #: 2011177 5 of 12 Standby Mode - Neutral Standby Mode - Phase Rhein Tech Laboratories, Inc. 15.107, Class B Neutral Line 100.0K 1.0M 10.0M 100.0M Frequency MHz 0 10.0 20.0 30.0 40.0 50.0 60.0 70.0…
Text truncated - open the document above for the full version.
Resolution Products, Inc. Wireless Siren Transceiver FCC ID: U5X-RE116 Certification Test Report February 22, 2012 U5X-RE116 Resolution Products, Inc.2/22/12Page 1 of 9 Test Report 226 Locust Street, Suite 4 Hudson, WI 54016 Contents 1. Introduction.................................................................................................................................................................4 2. Statement of Compliance............................................................................................................................................4 2.1. FCC Part 2 §2.907................................................................................................................................................4 2.2. FCC Part 2 §2.911................................................................................................................................................4 2.3. FCC Part 2 §2.913................................................................................................................................................4 2.4. FCC Part 2 §2.915................................................................................................................................................4 2.5. FCC Part 2 §2.925................................................................................................................................................4 2.6. FCC Part 2 §2.943, 2.945....................................................................................................................................5 2.7. FCC Part 2 §2.947................................................................................................................................................5 2.8. FCC Part 2 §2.948................................................................................................................................................5 2.9. FCC Part 2 §2.1033..............................................................................................................................................5 3. Discussion of Laboratory Measurements and Rules Compliance...............................................................................6 3.1. FCC Part 15 §15.231(a)(1)..................................................................................................................................6 3.2. FCC Part 15 §15.231(a)(3)..................................................................................................................................6 3.3. FCC Part 15 §15.231(a)(4)..................................................................................................................................7 3.4. FCC Part 15 §15.231(a)(5)..................................................................................................................................7 3.5. FCC Part 15 §15.231(b).......................................................................................................................................7 3.5.1. Raw Field Strength Limits............................................................................................................................7 3.5.2. Duty Cycle Correction Factor and Resulting Limits.....................................................................................7 3.5.3. Measured Radiated Field Strength Data.......................................................................................................8 3.6. FCC Part 15 §15.231(c).......................................................................................................................................8 3.7. FCC Part 15 §15.207............................................................................................................................................9 U5X-RE116 Resolution Products, Inc.2/22/12Page 2 of 9 Test Report 226 Locust Street, Suite 4 Hudson, WI 54016 U5X-RE116 Resolution Products, Inc.2/22/12Page 3 of 9 Test Report 226 Locust Street, Suite 4 Hudson, WI 54016 1.Introduction The RE116 is a wireless siren transceiver for use in a wireless security system. The unit is powered by a US standard wall power socket of 120VAC and has a backup power supply consisting of a single CR123A 3V battery. The device enclosure measures 3.25 x 2.125 x 4.5” and weighs approximately 5.9 ounces. The device contains a very loud piezoelectric siren for the purpose of increasing the volume of a security system alarm, and relaying the alarm sounder to farther reaches of a home where the alarm may not be otherwise heard. A wireless receiver controlled by a microprocessor inside the device, checks for alarm transmission packets from a transmitter connected to a security system. There is also a tamper switch on the unit. If an alarm packet is received, or the device is tampered with, the device will sound an alarm. In the absence of tamper switch activations and alarm transmissions, the device sends a set of three supervision transmissions packets, once per hour, to the security system. Certification is requested under FCC Rules, Part 15, Subpart C, Paragraph 15.231. 2.Statement of Compliance Specific sections of FCC Rules Part 2 that require information or listing are given below. 2.1.FCC Part 2 §2.907 This is an application for certification of original equipment 2.2.FCC Part 2 §2.911 a)This application has been filed electronically using form 731. b) All required information has been supplied in this application and its attachments. c)This application has been electronically signed by an officer of Resolution Products, Inc. d) The technical test data has been signed by the agency performing the testing. e)Signature supplied in appropriate block on form 731. f)Processing fee has been paid. g) Signatures have been supplied electronically. 2.3.FCC Part 2 §2.913 a)This application has been filed electronically. b) Appropriate fees have been filed electronically. c)Equipment samples shall be supplied as requested…
Text truncated - open the document above for the full version.
U5X-RE116 8310A-RE116 Test Setup Photos
360 Herndon Parkway · Herndon, Virginia · United States
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15.231 | 319.51 MHz - 319.51 MHz | - |

Wireless Alarm Panel
Equipment Class
DSR - Part 15 Remote Control/Security Device Transceiver
Glass Break Sensor
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
Glass Break Sensor
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
Glass Break Sensor
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
Wireless Siren
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
