U5X-RE934ZZwave Daughter Board

RE934Z Zwave Module Features •Connects to the Resolution Products RE6100 Security panel. •Adds Zwave Home Automation functionality. •Allows control of most Zwave devices through the online webpage or mobile app, through a Ethernet, WiFi, or cellular connection to home security system. Key Instructions •Insert the module in the the Resolution Products RE6100 Security panel. •Power up the Resolution Products RE6100 panel. •Use the online web page or mobile app to add, remove and control Zwave Home Automation devices! Specifications Panel Compatibility:Resolution Products RE6100 Current draw:0-20mA, normal operation. PCB dimensions:1.875 x 1.875 inches. Zwave RF Range:~80-100ft indoors, ~300ft line of site Zwave Mesh:Range greatly improved when used with large zwave home network (other devices act as repeaters to one another for network reliability). Specifications subject to change without notice. RE934Z Zwave Module User ManualPage 1 of 3 www.resolutionproducts.com OEM Installation Instructions 1.Open the Resolution Products RE6100 security panel. 2.Insert the RE934Z in the security panel as shown in the below picture. 3.Use the online web page or mobile app to start adding, removing and controlling all home automation devices. RE934Z Zwave Module User ManualPage 2 of 3 www.resolutionproducts.com FCC Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1.This device may not cause harmful interference. 2.This device must accept any interference that may be received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the Resolution Products, Inc. could void the user's authority to operate this equipment. FCC ID: U5X-RE934Z IC Notice This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1.This device may not cause interference, and 2.This device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme avec d’Industrie Canada RSS standard exempts de licence. Son fonctionnement est soumis aux deux conditions suivantes: 1.Ce dispositif ne peut causer des interférences, et 2.Ce dispositif doit accepter toute interférence, y compris les interferences qui peuvent causer un mauvais fonctionnement du dispositif. IC: 8310A-RE934Z Model: RE934Z RE934Z Zwave Module User ManualPage 3 of 3 www.resolutionproducts.com

December 15, 2014 RE: Confidentiality Request for U5X-RE934Z/8310A-RE934Z To Whom It May Concern: Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality RequestedExhibit Short Term PermanentBlock Diagrams Short TermExternal Photos Short Term Permanent* 1 Internal Photos Short Term PermanentOperation Description/Theory of Operation Short Term PermanentParts List & Placement/BOM Short Term PermanentTune-Up Procedure Short Term PermanentSchematics Short TermTest Setup Photos Short Term Permanent*User’s Manual *Note: ______(Insert Explanation as Necessary)______ Resolution Products, Inc. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Please refer to http://atcb.com/publicdocs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By:__________________________ Paul Saldin, Vice President (Signature/Title 3 )(Print name) 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

December 15, 2014 RE: U5X-RE934Z Request for Limited Modular Approval To Whom It May Concern: We hereby request Limited Modular Approval for U5X-RE934Z as described under 47 CFR 15.212(b). This device is usable on only one host device, and that fact has been stated in the manual. The following pages describe the compliance with this device with the requirements. Sincerely, Paul Saldin Vice President Resolution Products, Inc. Applicant/GranteeResolution Products, Inc FCC ID:U5X-RE934Z Section 15.212 Modular Transmitters Request for Modular ApprovalRequest for Limited Modular Approval RequirementsEUT ConditionsComply (Y/N) Single Modular Approval Requirements 1The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. Not required for LMAY 2The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. N/A - These inputs are not providedY 3The modular transmitter must have its own power supply regulation. Not required for LMAY 4The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The antenna is permanently attached to the board and is not removable. Y 5The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, Not required for LMA. As specified in 15.212(b), the manufacturer must only "demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used." We have done this by testing the device in the host with which it will be used. This is the ONLY host that may be used with this device. Y or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. FCC label shall be affixed to the top of the device so that it is visible when the module is installed in the host. Please see Internal Photos and ID Label Photos which show this. Y 7The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. We have provided instructions in the user manual. Y 8The modular transmitter must comply N/A - this device is not meant to be usedY with any applicable RF exposure requirements in its final configuration. near the body A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part…

Text truncated - open the document above for the full version.

Exhibit A RE934Z External Photos Photos of RE6100 panel with RE934Z module installed.

Exhibit B RE934Z ID Label Photos

Exhibit C RE934Z Internal Photos

Engineering Solutions & Electromagnetic Compatibility Services FCC Part 15.249 Test Data EUT: 908.42 MHz Panel Zwave Module 56-0064-00 RevB00 for Resolution Engineering, Inc. 1402 Heggen Street Hudson, WI 54016 Contact: Josh Gathje Testing Conducted By Rhein Tech Laboratories, Inc. 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 RTL Test Engineer: Dan Baltzell RTL Project/Report Number: 2014215 December 12, 2014 This report may not be reproduced, except in full, without the full written approval of Rhein Tech Laboratories, Inc. and Resolution Engineering. Test results relate only to the item tested. These tests are accredited and meet the requirements of ISO/IEC 17025 as verified by ANSI-ASQ National Accreditation Board/ACLASS. Refer to certificate and scope of accreditation AT-1445. Rhein Tech Laboratories, Inc. Client: Resolution Engineering 360 Herndon Parkway, Suite 1400 EUT: 56-0064-00 RevB00 Herndon, VA 20170 Standards: FCC Parts 2, 15 http://www.rheintech.com Report #: 2014215 2 of 11 Testing Represented in Report 15.249 The data and limits presented in this report are for radiated emissions per 15.249 which references 15.35(b), and peak limiting for restricted bands per 15.209(e), which again references 15.35(b)(2), as procured by Resolution Engineering. No average data is presented in this report. Data is also presented for spurious, non-harmonic radiated emissions per 15.209. 15.207 Unintentional digital emissions, mains conducted. The Equipment Under Test (EUT) was the 908.42 Panel Zwave Module 56-0064-00 RevB00 (RTL Bar Code 21545) with AC Adapter (RTL Bar Code 21548). 15.249 Radiated Emissions Test Data – FCC Limits/ 3m Distance Emission Frequency (MHz) Test Detector Analyzer Reading (dBuV Site Correction Factor (dB/m) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) 908.420 Peak 65.9 23.2 89.1 94.0 -4.9 1816.840 Peak 20.1 30.1 50.2 74.0 -23.8 2725.260 Peak 65.5 -9.1 56.4 74.0 -17.6 3633.680 Peak 55.1 -5.5 49.6 74.0 -24.4 4542.100 Peak 57.6 -1.4 56.2 74.0 -17.8 5450.520 Peak 52.5 -0.8 51.7 74.0 -22.3 6358.940 Peak 53.8 0.0 53.8 74.0 -20.2 7267.360 Peak 51.9 0.9 52.8 74.0 -21.2 8175.780 Peak 57.7 5.9 63.6 74.0 -10.4 9084.200 Peak 53.3 6.4 59.7 74.0 -14.3 FCC/IC Cross Reference FCC 15.249 RSS-210 Issue 8 A2.9 FCC 15.35(b) RSS-Gen Issue 4 8.1 FCC 15.205 RSS-Gen Issue 4 8.10 FCC 15.209 RSS-Gen Issue 4 8.9 Rhein Tech Laboratories, Inc. Client: Resolution Engineering 360 Herndon Parkway, Suite 1400 EUT: 56-0064-00 RevB00 Herndon, VA 20170 Standards: FCC Parts 2, 15 http://www.rheintech.com Report #: 2014215 3 of 11 15.209 Radiated Emissions Unintentional Test Data – FCC Limits/ 3m Distance Temperature: 38°F Humidity: 40% Emission Frequency (MHz) Test Detector Antenna Polarity (H/V) Antenna Height (m) Analyzer Reading (dBuV) Site Correction Factor (dB/m) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Pass/ Fail 69.596 Qp V 0 1.0 48.5 -25.1 23.4 40.0 -16.6 106.957 Qp V 0 1.0 53.4 -20.5 32.9 43.5 -10.6 115.081 Qp V 0 1.0 42.3 -20.1 22.2 43.5 -21.3 182.610 Qp H 0 1.0 30.3 -21.9 8.4 43.5 -35.1 906.529 Qp H 0 1.5 36.0 -5.8 30.2 46.0 -15.8 910.329 Qp H 0 1.5 32.8 -5.8 27.0 46.0 -19.0 913.690 Qp H 0 1.2 30.2 -5.9 24.3 46.0 -21.7 915.590 Qp H 0 1.0 30.6 -5.9 24.7 46.0 -21.3 Test Procedure Radiated fundamental and spurious emissions were tested at three meters. The EUT was tested in the three orthogonal planes with the receive antenna in both polarities. The emissions were maximized per ANSI C63.4:2003 8.3.1.2; that is, the measurement antenna height was varied between 1 and 4 m, and the EUT was rotated through 360° on a rotating turntable until the maximum emissions were found. Both horizontal and vertical measurement antenna polarizations were used. A resolution bandwidth of 100 kHz was used for frequencies less than 1000 MHz, and a resolution bandwidth of 1 MHz was used for frequencies greater than or equal to 1000 MHz. The video bandwidth was set to a value at least three times greater than the resolution bandwidth. EUT Disposition The EUT was adapted to continuously transmit for testing purposes. Rhein Tech Laboratories, Inc. Client: Resolution Engineering 360 Herndon Parkway, Suite 1400 EUT: 56-0064-00 RevB00 Herndon, VA 20170 Standards: FCC Parts 2, 15 http://www.rheintech.com Report #: 2014215 4 of 11 Radiated Emissions Test Equipment RTL Bar Code Manufacturer Model Part Serial Number Calibration Due Date 901581 Rohde & Schwarz FSU Spectrum Analyzer 1166.1660.50 11/13/15 900791 Chase CBL6111B Bilog antenna (30 MHz – 2000 MHz) N/A 6/11/17 900932 Hewlett Packard 8449B OPT H02 Preamplifier 1-26.5 GHz 3008A00505 9/5/15 900772 EMCO 3161-02 Horn Antenna (2.0-4.0 GHz) 9804-1044 4/20/15 900321 EMCO 3161-03 Horn Antenna (4.0-8.0 GHz) 9508-1020 4/20/17 900323 EMCO 3160-07 Horn Antenna (8.0-12.4 GHz) 9605-1054 4/20/17 900356 EMCO 3160-08 Horn Antenna (12.4-18.0 GHz) 9607-1044 4/20/17 901218 EMCO RA42-K-F-43_C Horn Antenna (18.0-26.5 GHz) 960281-003 4/20/17 N/A Rhein Tech Laboratories, Inc. Automated Emission Tester Emissions Testing Software Rev. 14.0.2 N/A 901592 Insulated Wire Inc. KPS-1503- 3600-KPR SMK RF Cables 20’ NA 9/3/15 901593 Insulated Wire Inc. KPS-1503-360- KPR SMK RF Cables 36” NA 9/3/15 900905 Rhein Tech Laboratories, Inc. PR-1040 Amplifier (20 MHz-2 GHz) 900905 9/5/15 Test Personnel: Dan Baltzell December 10-11, 2014 Test Engineer Signature Date Of Test Rhein Tech Laboratories, Inc. Client: Resolution Engineering 360 Herndon Parkway, Suite 1400 EUT: 56-0064-00 RevB00 Herndon, VA 20170 Standards: FCC Parts 2, 15 http://www.rheintech.com Report #: 2014215 5 of 11 15.207 Conducted Line Emissions Test Data – FCC Limits Phase Rhein Tech Laboratories, Inc. Client: Resolution Engineering 360 Herndon Parkway, Suite 1400 EUT: 56-0064-00 RevB00 Herndon, VA 20170 Standards: FCC Parts 2, 15 http://www.rheintech.com Report #: 2014215 6 of 11 Neutral Result: Pass Rhein Tech Laboratories, Inc. Client: Resolution Engineering 360 Herndon Parkway, Suite 1400 EUT: 56-0064-00 RevB00 Herndo…

Text truncated - open the document above for the full version.

Resolution Products, Inc. Zwave Daughter Board FCC ID: U5X-RE934Z Certification Test Report December 15, 2014 U5X-RE934Z Resolution Products, Inc.12/15/14Page 1 of 6 Test Report 1402 Heggen Street Hudson, WI 54016 Contents 1. Introduction.................................................................................................................................................................3 2. Statement of Compliance............................................................................................................................................3 2.1. FCC Part 2 §2.907................................................................................................................................................3 2.2. FCC Part 2 §2.911................................................................................................................................................3 2.3. FCC Part 2 §2.913................................................................................................................................................3 2.4. FCC Part 2 §2.915................................................................................................................................................3 2.5. FCC Part 2 §2.925................................................................................................................................................3 2.6. FCC Part 2 §2.943, 2.945....................................................................................................................................3 2.7. FCC Part 2 §2.947................................................................................................................................................3 2.8. FCC Part 2 §2.948................................................................................................................................................3 2.9. FCC Part 2 §2.1033..............................................................................................................................................4 3. Discussion of Laboratory Measurements and Rules Compliance...............................................................................5 3.1. FCC Part 15 §15.249............................................................................................................................................5 3.1.1. FCC Part 15 §15.249(a)................................................................................................................................5 3.1.1.1. Raw Field Strength Limits.....................................................................................................................5 3.1.1.2. Measured Radiated Field Strength Data................................................................................................5 3.1.2. FCC Part 15 §15.249(d)................................................................................................................................5 3.2. FCC Part 15 §15.207............................................................................................................................................5 3.2. FCC Part 15 §15.207............................................................................................................................................5 U5X-RE934Z Resolution Products, Inc.12/15/14Page 2 of 6 Test Report 1402 Heggen Street Hudson, WI 54016 1.Introduction This device is a transceiver for use in home automation applications. It controls other devices such as lights, thermostats, door locks, etc. This module mates with the Resolution Products RE6100 board to add Zwave (home automation) ability to that board. The device is powered by its RE6100 parent board with 3.3V. The device transmitter contains a Zensys ZM5202AU Zwave module centered at 908.42MHz. The device measures 1.8 x 1.8”. Certification is requested under FCC Rules, Part 15, Subpart C, Paragraph 15.231. 2.Statement of Compliance Specific sections of FCC Rules Part 2 that require information or listing are given below. 2.1.FCC Part 2 §2.907 This is an application for certification of original equipment 2.2.FCC Part 2 §2.911 a)This application has been filed electronically using form 731. b)All required information has been supplied in this application and its attachments. c)This application has been electronically signed by an officer of Resolution Products, Inc. d)The technical test data has been signed by the agency performing the testing. e)Signature supplied in appropriate block on form 731. f)Processing fee has been paid. g)Signatures have been supplied electronically. 2.3.FCC Part 2 §2.913 a)This application has been filed electronically. b)Appropriate fees have been filed electronically. c)Equipment samples shall be supplied as requested. 2.4.FCC Part 2 §2.915 We are requesting a grant of certification. This application shows compliance with the technical standards. 2.5.FCC Part 2 §2.925 A label shall be affixed to each piece of equipment, showing the FCC identifier. The label shall read “FCC ID: U5X- RE934Z”. See Exhibit B for a photograph showing the label and location on the device. 2.6.FCC Part 2 §2.943, 2.945 Sample production equipment shall be submitted to the FCC upon request. 2.7.FCC Part 2 §2.947 a)Measurement procedure follows ANSI C63.4: 2009. b)A description of utilized test equipment is contained in the report. 2.8.FCC Part 2 §2.948 Radiated measurements were taken at the following FCC-approved facility: Rhein Tech Laboratories, Inc. 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 USA Contact: Rick McMurray 703-689-0368 Photographs of the test site are shown in Exhibit J. 2.9.FCC Part 2 §2.1033 a)Form 731 has been filed electronically. b)The technical report, along with its exhibits, contains the information as follows: (1)full name and mailing address of the manufacturer of the device and the applicant for certification: Resolution Products, Inc. 1402 Heggen Street Hudson, WI …

Text truncated - open the document above for the full version.

U5X-RE934Z 8310A-RE934Z Test Setup Photos
