Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
1 E-TOP 11n Broadband Router Wireless Broadband Router BR486n User Manual 2 Table of Contents CE Statement of Conformity ................................................................................................................ 7 Notice ..................................................................................................................................................... 8 Chapter 1 Introduction ................................................................................................................. 9 1.1 Overview ...................................................................................................................... 9 1.2 Features ..................................................................................................................... 10 1.3 Specifications ............................................................................................................ 11 1.3.1 Views of Product Appearance......................................................................... 13 1.3.2 LED Indicator Status Description ................................................................... 14 1.4 System Requirements .............................................................................................. 15 1.5 WAN Network Plug and Play.................................................................................... 15 1.6 Get Your IP Automatically & Manually .................................................................... 15 1.6.1 Network Testing................................................................................................ 18 1.6.2 Testing with Internet Browser ......................................................................... 18 1.6.2.1 Testing with DOS (Windows XP Platform)......................................................... 19 Chapter 2 Hardware Installation................................................................................................ 21 2.1 Diagram of Connecting Hardware to 11N Broadband router ............................... 21 2.1.1 Hardware Connection and Application for Router Mode ............................. 21 2.1.2 Hardware Connection and Application for AP Mode .................................... 22 2.1.3 Hardware Connection and Application for Wi-Fi AP Mode .......................... 22 Chapter 3 One Button Setup...................................................................................................... 24 3.1 One Button Setup configuration for Router Mode ................................................ 24 3.2 One Button Setup configuration for AP Mode ....................................................... 26 3.3 One Button Setup configuration for WiFi AP Mode............................................... 28 Chapter 4 Basic Setup................................................................................................................ 32 4.1 Router Mode .............................................................................................................. 33 4.2 AP Mode ..................................................................................................................... 36 4.3 WiFi AP Mode ............................................................................................................ 38 Chapter 5 Advanced Configuration for Router Mode ............................................................. 41 5.1 IP Configuration ........................................................................................................ 41 5.1.1 WAN ................................................................................................................... 41 5.1.1.1 WAN Interface– Ethernet Port............................................................................. 41 5.1.1.2 WAN Interface– Wireless.................................................................................... 42 5.1.1.3 WAN Access Type – Static IP.............................................................................. 43 5.1.1.4 WAN Access Type – Dynamic IP........................................................................ 45 5.1.1.5 WAN Access Type – PPPoE................................................................................ 47 5.1.1.6 WAN Access Type – PPTP.................................................................................. 50 3 5.1.1.7 WAN Access Type – L2TP................................................................................... 52 5.1.2 LAN Interface Setup ......................................................................................... 54 5.1.3 Dynamic DNS Setting....................................................................................... 55 5.2 Wireless Setup .......................................................................................................... 57 5.2.1 Wireless Basic Settings................................................................................... 57 5.2.2 Wireless Advanced Settings ........................................................................... 62 5.2.3 Wireless Security Setup .................................................................................. 63 5.2.4 Wireless Access Control ................................................................................. 65 5.2.5 WDS Settings .................................................................................................... 67 5.2.6 WPS ................................................................................................................... 71 5.3 NAT .............................................................................................................................76 5.3.1 Visual Server..................................................................................................... 76 5.3.2 Visual DMZ ........................................................................................................ 78 5.4 Firewall ......................…
Text truncated - open the document above for the full version.
101 Click Multiple APs to set up 4 different SSIDs to deploy a shared WLAN. Users can add or limit the properties for each SSID, increasing the flexibility and efficiency of the network. (1.)Enable: check it for enable or not. (2.)Band: select the frequency from the drop down list. (3.)SSID: please enter different SSID in each class. (4.)Data Rate: please select the data transmission rate. (5.)Access: defined the access type. a. LAN+WAN: the client can access to the Internet and connect to 11N Mobile Router’s GUI to setup. b. WAN: the client can only access to the Internet. (6.)Active Client List: display the properties of the client which is connecting successfully. (7.)Apply Changes: Please click Apply Changes to initiate or click Reset to cancel. 4. Network Type Κ Please select “Infrastructure” or “Ad hoc.” The default is “Infrastructure.” The selection is disabled when wireless mode is selected to AP. 5. SSID Κ Please input your wireless network name. Default is “11N_Mini_Router”. 6. Channel Width Please select “20MHZ” or “40MHZ” channel width to change the transmission channels. 102 7. ControlSideband Setting the Sideband "Upper" or "Lower.” 8. Channel Number Please select your wireless network channel. There are Auto, 2~11. 9. Broadcast SSID Enable or disable the SSID broadcast function. Disable this feature can provide more security of your WLAN. 10. Data Rate Rate at which data can be communicated (bps); auto, 1M, 2M, 5.5M, 11M, 6M, 9M, 12M, 18M, 24M, 36M, 48M or 54M to be selected from the drop-down list. 11. Associated Clients Check the WiFi ISP connectors and the connecting status. 12. Enable Mac Clone (Single Ethernet Client) Copy the MAC Address for identity of some ISPs. 13. Enable Universal Repeater Mode (Acting as AP and Client simultaneously) EnableUniversal Repeater Mode, 11N Broadband Router will act as a wireless AP and AP client at the same time, and able to link to another AP.. It uses AP client function to connect to a Root AP (any AP) and uses AP function to service all wireless stations within its coverage. All the stations within the coverage of 11N Broadband Router can be bridged to the Root AP. It can help user to extend the coverage of wireless network. How to Enable URM (Universal Repeater Mode) User could enable URM in wireless basic setting page as shown in following figures. Step 1. Get back to menu “Network Config” and write down the SSID, channel and security. 103 Step 2. Setting the same SSID, channel and security you got form “Network Config” and Click on Apply Changes to save the setting Note: The DHCP server should be disabled under menu “LAN Interface Setup” and then the URM could be enabled. Step 3. Check the AP connectors and the Wireless connecting status. 104 ʳ 14. SSID of Extended Interface When mode is set to “AP” and Universal Repeater Mode is enabled, user should input SSID of another AP (the upper level device) in the field of SSID of Extended Interface. 15. Apply Changes & Reset Click on “Apply Changes” to save the setting data. Or you may click on “Reset” to clear all the input data. 6.2.2 Wireless Advanced Settings Please follow the instructions to configure the Wireless settings. 1. Fragment Threshold To identify the maximum length of packet, the overflow packet length wil be fragmentized. The allowed range is 256-2364, and default length is 2346 bytes. 2. RTS Threshold This value should remain at its default setting of 2347. The range is 0~2347. Should you encounter inconsistent data flow, only minor modifications are recommended. If a network packet is smaller than the present RTS threshold size, the RTS/CTS mechanism will not be 105 enabled. The router sends Request to Send (RTS) frames to a particular receiving station and negotiates the sending of a data frame. After receiving an RTS, the wireless station responds with a Clear to Send (CTS) frame to acknowledge the right to begin transmission. Fill the range from 0 to 2347 into this blank. 3. Beacon Interval Beacons are packets sent by an access point to synchronize a wireless network. Specify a beacon interval value. The allowed setting range is 20-1024 ms. 4. Preamble Type The preamble (also called “a header”) is a section of data at the head of a packet that contains information that wireless devices need when they send and receive packets. Short preambles improve throughput performance, but some wireless devices require long preambles. Select the suitable preamble as short or long preamble. 5. IAPP Inter Access Point Protocol. Allow seamless roaming between Access Points in your wireless network. Coupled with superior RF performance 6. Protection Select to enable the wireless protection or not. 7. Aggregation Data aggregation can reduce the amount of data routed through the network, and increasing throughput. 8. Short GI Enabling the Short Guard Interval increases the wireless transmission. 9. Apply Changes & Reset Click on “Apply Changes” to save the setting data. Or you may click on “Reset” to clear all the input data. 6.2.3 Wireless Security Setup 4 encryption types can be selected here, please follow the instructions below for each. 106 1. Encryption – WEP Enabling WEP can protect your data from eavesdroppers. If you do not need this feature, select “None” to skip the following setting. 11N Broadband Router supports both 64-bit and 128-bit encryption using the Wired Equivalent Privacy (WEP) algorithm. Select the type of encryption you want to use (64 or 128 bit) and configure one to four WEP Keys. The “1280bit” method is more secure than the “64-bit”. Use 802.1x Authentication Enable 802.1x Authentication so that a wireless node must be authenticated before it can gain access to other LAN resources. 107 Key Length: For 64bits WEP key, either 5 ASCII characters or 10 hexadecimal digitals leading by 0x can be entered. For 128bits WEP key, either 13 ASCII characters or 26 hexadecimal digits leading by 0x can be entered. Note: 128 bits WEP is most secure, but has more encrypti…
Text truncated - open the document above for the full version.
E-TOP Network Technology Inc. No . 82, Gongye 2nd Rd. , Tainan City 70955 , Taiwan , R.O.C. Date: 2011/3/30 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Mr. Alex Chiu / Director of Compliance Certification Services Inc. and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Mr. Alex Chiu / Director of Compliance Certification Services Inc. on our behalf shall have the same effect as acts of our own. In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, (Please type Name and Title of Person to Receive Grant/Certificate) (Please type Company Name) REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.
Compliance Certification Services Inc. Report No.:T110218401 Date of Issue: March 29, 2011 Page A1 Total Page: 7 Rev. 00 PHOTOGRAPHS OF EUT External Photo Compliance Certification Services Inc. Report No.:T110218401 Date of Issue: March 29, 2011 Page A2 Rev. 00 Compliance Certification Services Inc. Report No.:T110218401 Date of Issue: March 29, 2011 Page A3 Rev. 00 Compliance Certification Services Inc. Report No.:T110218401 Date of Issue: March 29, 2011 Page A4 Rev. 00
Diagram Label location Label location (49mmx29mm)
Compliance Certification Services Inc. Report No.:T110218401 Date of Issue: March 29, 2011 Page A5 Rev. 00 Internal Photo Compliance Certification Services Inc. Report No.:T110218401 Date of Issue: March 29, 2011 Page A6 Rev. 00 Compliance Certification Services Inc. Report No.:T110218401 Date of Issue: March 29, 2011 Page A7 Rev. 00
Date: Customer P/N S22-XY31225 APPROVAL SHEET Customers: 易通展科技股份有限公司 2011/3/17 Antenna 0 Yong-Shun P/N Production Description Version Approve ApproveApprove ApproveChief ChiefChief ChiefResponsible ResponsibleResponsible Responsible Jimmy JimmyJimmy JimmyFrank FrankFrank FrankHunter HunterHunter Hunter Approved By Customer Approved By CustomerApproved By Customer Approved By Customer YONG-SHUN Technology Co., LTD. 擁瞬科技有限公司 擁瞬科技有限公司擁瞬科技有限公司 擁瞬科技有限公司 Address: No.29, Xikun 1st St., Banqiao Dist., New Taipei City 220, Taiwan (R.O.C.) Tel: +886-2-26841827 Fax: +886-2-26835010 Xinxie Technology Co., LTD. (Shenzhen) 欣協科技有限公司 欣協科技有限公司欣協科技有限公司 欣協科技有限公司 (深圳廠 深圳廠深圳廠 深圳廠 ) Address: Nanbiantou Industrial Area, Dongfang Village, Songgang Town, Shenzhen City, China Tel:+86-755-27553831 Fax:+86-755-27092799 Approved By Yong-Shun Approved By Yong-ShunApproved By Yong-Shun Approved By Yong-Shun Table of Contents Item 1. Drawing 2. Test Report -Electrical test 3. Material Certifications -Cable 4. Packing -PE Bag -Carton Modification History: REV.Content 02011/3/17 Date PolarizationVertical Weight~11.1g Operating Temp -20°C+65°C Electrical Properties Mechanical Properties 2.4GHz 50Ω ≦2.0 Omni-directional Standard connector Frequency range Impedance V.S.W.R Radia tion Gain3dBi PC/PBT/TPEE Whip Electrical Test 2350MHz 2400MHz 2450MHz 2500MHz Antenna Efficiency CABLE SPECIFICATION 線材規格
Description of Operation The EUT is a N+ High Power Broadband Router - All Broadbands with IEEE 802.11b/g/n (2T2R) . And this device provided of transm itting s peed: IEEE 802.11b : 11, 5.5, 2, 1 Mbps IEEE 802.11g : 54, 48 ,36, 24, 18, 12, 9, 6 Mbps IEEE 802.11n HT20 : 65, 58.5, 52, 39, 26, 19.5, 13, 6.5 Mbps IEEE 802.11n HT40 : 135, 121.5, 108, 81, 54, 40.5, 27, 13.5 Mbps the device of RF carrier is CCK, DQPSK, DBPSK, 64QAM, 16QAM, QPSK and BPSK. The device adapts DSSS and OFDM m odulation. And the antennas were two dipole antennas and provided diversity function to im prove the receiving function. It allows your computer to connect to a wireless network and to s hare res ources , such as files or printers without being bound to the network wires . And this EUT Operation in 2.4GHz Direct Sequence Spread Spectrum (D.S.S.S) and Orthogonal Frequency division Multiplex (O.F.D.M) radio transmiss ion. In addition, its s tandard compliance ens ures that it can comm unicate with any 802.11b/g/n network. Frequency Range IEEE 802.11b/g, 802.11n HT20 (DTS Band):2412MHz~2462MHz IEEE 802.11n HT40 (DTS Band):2422MHz~2452MHz Channel Spacing IEEE 802.11b/g, 802.11n HT20/HT40: 5MHz Channel Number IEEE 802.11b/g, 802.11n HT20:11 Channels IEEE 802.11n HT40 :7 Channels
Report No.:T110218401-RP1 FCC ID:U6A-BR486N Date of Issue: March 29, 2011 Page 1 FCC 47 CFR PART 15 SUBPART C: 2009 AND ANSI C63.4: 2003 TEST REPORT For Wireless Broadband Router Model Number: BR486n Brand Name: ETOP Issued for E-TOP Network Technology Inc. No. 82, Gongye 2nd Rd., Tainan City 70955, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. Tainan Lab. No. 8, Jiu Ceng Ling, Jiaokeng Village,Sinhua Township, Tainan Hsien 712, Taiwan (R.O.C.) TEL: 886-6-580-2201 FAX: 886-6-580-2202 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. Ltd. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document Total Page: 139 Report No.:T110218401-RP1 FCC ID:U6A-BR486N Date of Issue: March 29, 2011 Page 2 REVISION HISTORY Rev. Issue Date Revisions Effect Page Revised By 00 March 29, 2011 Initial Issue ALL Daphne Liang Report No.:T110218401-RP1 FCC ID:U6A-BR486N Date of Issue: March 29, 2011 Page 3 TABLE OF CONTENTS 1. TEST REPORT CERTIFICATION ...................................................................................4 2. EUT DESCRIPTION ........................................................................................................5 2.1 DESCRIPTION OF EUT & POWER ........................................................................................ 5 3. DESCRIPTION OF TEST MODES ..................................................................................7 4. TEST METHODOLOGY ..................................................................................................8 5. FACILITIES AND ACCREDITATIONS............................................................................8 5.1 FACILITIES .............................................................................................................................. 8 5.2 EQUIPMENT............................................................................................................................ 8 5.3 LABORATORY ACCREDITATIONS LISTINGS ...................................................................... 8 5.4 TABLE OF ACCREDITATIONS AND LISTINGS ..................................................................... 9 6. CALIBRATION AND UNCERTAINTY.............................................................................10 6.1 MEASURING INSTRUMENT CALIBRATION.......................................................................... 10 6.2 MEASUREMENT UNCERTAINTY .......................................................................................... 10 7. SETUP OF EQUIPMENT UNDER TEST.........................................................................11 7.1 SETUP CONFIGURATION OF EUT........................................................................................ 11 7.2 SUPPORT EQUIPMENT ......................................................................................................... 12 7.2 SUPPORT EQUIPMENT ......................................................................................................... 12 7.3 EUT OPERATING CONDITION .............................................................................................. 13 8. APPLICABLE LIMITS AND TEST RESULTS.................................................................14 8.1 6DB BANDWIDTH ................................................................................................................... 14 8.2 MAXIMUM PEAK OUTPUT POWER....................................................................................... 29 8.3 AVERAGE POWER ................................................................................................................. 32 8.4 MAXIMUM PERMISSIBLE EXPOSURE.................................................................................. 35 8.5 POWER SPECTRAL DENSITY ............................................................................................... 37 8.6 CONDUCTED SPURIOUS EMISSION.................................................................................... 56 8.7 RADIATED EMISSIONS ..........................................................................................................85 8.8 POWERLINE CONDUCTED EMISSIONS .............................................................................. 131 9. ANTENNA REQUIREMENT ............................................................................................135 9.1 STANDARD APPLICABLE ...................................................................................................... 135 9.2 ANTENNA CONNECTED CONSTRUCTION .......................................................................... 135 APPENDIX 1 SETUP PHOTOS ..........................................................................................136 APPENDIX 2 PHOTOGRAPHS OF EUT...................................................................A1 Report No.:T110218401-RP1 FCC ID:U6A-BR486N Date of Issue: March 29, 2011 Page 4 1. TEST REPORT CERTIFICATION Applicant : E-TOP Network Technology Inc. Address : No. 82, Gongye 2nd Rd., Tainan City 70955, Taiwan, R.O.C. Equipment Under Test : Wireless Broadband Router Model Number : BR486n Brand Name : ETOP Date of Test : March 2, 2011 ~ March 23, 2011 APPLICABLE STANDARD STANDARD TEST RESULT FCC Part 15 Subpart C : 2009 AND ANSI C63.4 : 2003 No non-compliance noted Approved by: Reviewed by: Jeter Wu Eric Huang Assistant Manager Assistant Section Manager Report No.:T110218401-RP1 FCC ID:U6A-BR486N Date of Issue: March 29, 2011 Page 5 2. EUT DESCRIPTION 2.1 DESCRIPTION OF EUT & POWER Product Name Wireless Broadband Router Model Number BR486n Brand Name ETOP Frequency Range IEEE 802.11b/g,802.11n HT20 (DTS Band):2412MHz~2462MHz IEEE 802.11n HT40 (DTS Band):2422MHz~2452MHz Transmit Power IEEE 802.11b Mode : 16.36dBm (DTS Band) (43.24 mW) IEEE 802.11g Mode : 22.51dBm (DTS Band) (178.24 mW) IEEE 802.11n HT20 Mode …
Text truncated - open the document above for the full version.
Report No.:T110218401-RP1 FCC ID:U6A-BR486N Date of Issue: March 29, 2011 Page 101 Product Name Wireless Broadband Router Test Date 2011/3/23 Model BR486n Test By John Chen Test Mode IEEE 802.11g TX (CH High) TEMP& Humidity 24.8°C, 55% Vertical TX / IEEE 802.11g mode / CH HighMeasurement Distance at 3m Vertical polarity Freq. Reading AF Cable LossPre-ampFilterLevel Limit Margin Mark (MHz) (dBμV) (dB/m) (dB) (dB) (dB)(dBμV/m)(dBμV/m) (dB) (P/Q/A) * 1406.20 59.63 26.21 2.14 41.73 0.7747.02 74.00 -26.98 P * 1406.20 57.44 26.21 2.14 41.73 0.7744.83 54.00 -9.17 A * 4923.95 67.26 33.47 3.76 42.48 0.7362.74 74.00 -11.26 P * 4923.95 55.87 33.47 3.76 42.48 0.7351.35 54.00 -2.65 A N/A ------ ------------ ------ ------------ ------ ------ P N/A ------ ------------ ------ ------------ ------ ------ A REMARK: 1. AF: Antenna Factor, Cable: Cable Loss, Pre-Amp: Preamplifier gain, Filter: High Pass Filter Insertion Loss (3.5GHz) 2. Spectrum analyzer setting P(Peak): RBW=1MHz, VBW=1MHz, A(Average): RBW=1MHz, VBW=10Hz 3. The result basic equation calculation is as follow: Level = Reading + AF + Cable – Preamp + Filter – Dist, Margin = Level-Limit 4. The other emission levels were 20dB below the limit 5. The test limit distance is 3M limit. Report No.:T110218401-RP1 FCC ID:U6A-BR486N Date of Issue: March 29, 2011 Page 102 Product Name Wireless Broadband Router Test Date 2011/3/23 Model BR486n Test By John Chen Test Mode IEEE 802.11n HT20 TX (CH Low) TEMP& Humidity 24.8°C, 55% Horizontal TX / IEEE 802.11n HT20 mode / CH LowMeasurement Distance at 3m Horizontal polarity Freq. Reading AF Cable LossPre-ampFilterLevel Limit Margin Mark (MHz) (dBμV) (dB/m) (dB) (dB) (dB)(dBμV/m)(dBμV/m) (dB) (P/Q/A) * 1406.22 61.60 26.21 2.14 41.73 0.7748.99 74.00 -25.01 P * 1406.22 58.97 26.21 2.14 41.73 0.7746.36 54.00 -7.64 A * 4823.97 57.63 33.17 3.73 42.38 0.6952.84 74.00 -21.16 P * 4823.97 52.28 33.17 3.73 42.38 0.6947.49 54.00 -6.51 A N/A ------ ------ ------ ------ ------------ ------ ------ P N/A ------ ------ ------ ------ ------------ ------ ------ A REMARK: 1. AF: Antenna Factor, Cable: Cable Loss, Pre-Amp: Preamplifier gain, Filter: High Pass Filter Insertion Loss (3.5GHz) 2. Spectrum analyzer setting P(Peak): RBW=1MHz, VBW=1MHz, A(Average): RBW=1MHz, VBW=10Hz 3. The result basic equation calculation is as follow: Level = Reading + AF + Cable – Preamp + Filter – Dist, Margin = Level-Limit 4. The other emission levels were 20dB below the limit 5. The test limit distance is 3M limit. Report No.:T110218401-RP1 FCC ID:U6A-BR486N Date of Issue: March 29, 2011 Page 103 Product Name Wireless Broadband Router Test Date 2011/3/23 Model BR486n Test By John Chen Test Mode IEEE 802.11n HT20 TX (CH Low) TEMP& Humidity 24.8°C, 55% Vertical TX / IEEE 802.11n HT20 mode / CH LowMeasurement Distance at 3m Vertical polarity Freq. Reading AF Cable LossPre-ampFilterLevel Limit Margin Mark (MHz) (dBμV) (dB/m) (dB) (dB) (dB)(dBμV/m)(dBμV/m) (dB) (P/Q/A) * 1406.20 60.13 26.21 2.14 41.73 0.7747.52 74.00 -26.48 P * 1406.20 57.48 26.21 2.14 41.73 0.7744.87 54.00 -9.13 A * 4823.98 67.63 33.17 3.73 42.38 0.6962.84 74.00 -11.16 P * 4823.98 55.43 33.17 3.73 42.38 0.6950.64 54.00 -3.36 A N/A ------ ------ ------ ------ ------------ ------ ------ P N/A ------ ------ ------ ------ ------------ ------ ------ A REMARK: 1. AF: Antenna Factor, Cable: Cable Loss, Pre-Amp: Preamplifier gain, Filter: High Pass Filter Insertion Loss (3.5GHz) 2. Spectrum analyzer setting P(Peak): RBW=1MHz, VBW=1MHz, A(Average): RBW=1MHz, VBW=10Hz 3. The result basic equation calculation is as follow: Level = Reading + AF + Cable – Preamp + Filter – Dist, Margin = Level-Limit 4. The other emission levels were 20dB below the limit 5. The test limit distance is 3M limit. Report No.:T110218401-RP1 FCC ID:U6A-BR486N Date of Issue: March 29, 2011 Page 104 Product Name Wireless Broadband Router Test Date 2011/3/23 Model BR486n Test By John Chen Test Mode IEEE 802.11n HT20 TX (CH Middle) TEMP& Humidity 24.8°C, 55% Horizontal TX / IEEE 802.11n HT20 mode / CH MiddleMeasurement Distance at 3m Horizontal polarity Freq. Reading AF Cable LossPre-ampFilterLevel Limit Margin Mark (MHz) (dBμV) (dB/m) (dB) (dB) (dB)(dBμV/m)(dBμV/m) (dB) (P/Q/A) * 1406.17 61.36 26.21 2.14 41.73 0.7748.75 74.00 -25.25 P * 1406.17 58.14 26.21 2.14 41.73 0.7745.53 54.00 -8.47 A * 4873.95 56.95 33.32 3.74 42.43 0.7152.29 74.00 -21.71 P * 4873.95 50.17 33.32 3.74 42.43 0.7145.51 54.00 -8.49 A N/A ------ ------ ------ ------ ------------ ------ ------ P N/A ------ ------ ------ ------ ------------ ------ ------ A REMARK: 1. AF: Antenna Factor, Cable: Cable Loss, Pre-Amp: Preamplifier gain, Filter: High Pass Filter Insertion Loss (3.5GHz) 2. Spectrum analyzer setting P(Peak): RBW=1MHz, VBW=1MHz, A(Average): RBW=1MHz, VBW=10Hz 3. The result basic equation calculation is as follow: Level = Reading + AF + Cable – Preamp + Filter – Dist, Margin = Level-Limit 4. The other emission levels were 20dB below the limit 5. The test limit distance is 3M limit. Report No.:T110218401-RP1 FCC ID:U6A-BR486N Date of Issue: March 29, 2011 Page 105 Product Name Wireless Broadband Router Test Date 2011/3/23 Model BR486n Test By John Chen Test Mode IEEE 802.11n HT20 TX (CH Middle) TEMP& Humidity 24.8°C, 55% Vertical TX / IEEE 802.11n HT20 mode / CH MiddleMeasurement Distance at 3m Vertical polarity Freq. Readi…
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 2 | 15C | 2.42 GHz - 2.45 GHz | 159.00 mW |
