Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
User’s Manual V1.0 1 Navi R122g Quick Setup Guide V1.0 User’s Manual V1.0 2 Table of Contents CHAPTER 1 HARDWARE CONNECTION............................................................... 4 1.1 Router Mode Hardware connection and application....................... 4 1.2 AP Mode Hardware connection and application ............................. 4 1.3 Client Mode Hardware connection and application ........................ 4 CHAPTER 2 ROUTER MODE QUICK SETUP .......................................................... 5 2.1 ROUTER MODE QUICK SETUP INSTRUCTION........................................................ 5 2.1.1 WAN Setup .................................................................................... 7 2.1.1.1 WAN Type – Static IP................................................................. 7 2.1.1.2 WAN Type – Dynamic IP ............................................................ 8 2.1.1.3 WAN Type – PPPoE .................................................................... 8 2.1.1.4 WAN Type – PPTP ...................................................................... 9 2.1.2 LAN Setup ................................................................................... 10 2.1.3 Wireless Setup ............................................................................ 10 2.1.4 Time Server Setup....................................................................... 11 2.1.5 Password Setup .......................................................................... 12 2.1.6 USB Disk Management Setup ...................................................... 13 2.1.7 User Account Management Setup ................................................ 13 2.1.8 Firewall Setup ............................................................................. 14 2.1.9 QoS Configuration Setup ............................................................. 15 2.1.10 FTP Server Setup......................................................................... 16 2.1.11 Web Camera Server Setup........................................................... 17 2.1.12 Printer Server Setup.................................................................... 17 2.1.13 Samba Server Setup .................................................................... 18 2.1.14 Audio Server Setup ..................................................................... 18 2.1.15 Quick Setup Finish....................................................................... 19 CHAPTER 3 AP MODE QUICK SETUP................................................................. 19 3.1 AP MODE QUICK SETUP INSTRUCTION........................................................ 19 3.1.1 LAN Setup ................................................................................... 21 3.1.2 Wireless Setup........................................................................... 22 3.1.3 Time Server Setup....................................................................... 22 3.1.4 Password Setup .......................................................................... 23 3.1.5 USB Disk Management Setup ...................................................... 24 3.1.6 User Account Management Setup ................................................ 24 3.1.7 FTP Server Setup......................................................................... 25 3.1.8 Web Camera Server Setup........................................................... 26 User’s Manual V1.0 3 3.1.9 Printer Server Setup.................................................................... 26 3.1.10 Samba Server Setup .................................................................... 27 3.1.11 Audio Server Setup ..................................................................... 27 3.1.12 Quick Setup Finish....................................................................... 27 CHAPTER 4 CLIENT MODE QUICK SETUP ......................................................... 28 4.1 C LIENT MODE QUICK SETUP INSTRUCTION.................................................. 28 4.1.1 Site Survey Setup........................................................................ 30 4.1.2 Wireless Setup ............................................................................ 31 4.1.3 Time Server Setup....................................................................... 32 4.1.4 Password Setup .......................................................................... 32 4.1.5 USB Disk Management Setup ...................................................... 33 4.1.6 User Account Management Setup ................................................ 34 4.1.7 FTP Server Setup......................................................................... 34 4.1.8 Web Camera Server Setup........................................................... 35 4.1.9 MFP Server Setup ........................................................................ 35 4.1.10 Samba Server Setup .................................................................... 36 4.1.11 Audio Server Setup ..................................................................... 37 4.1.12 Quick Setup Finish....................................................................... 37 User’s Manual V1.0 4 Chapter 1 Hardware Connection 1.1 Router Mode Hardware connection and application When Mini Router switches to Router Mode, there will be each WAN and LAN port exist. 1.2 AP Mode Hardware connection and application When Mini Router switches to AP Mode, it supports 2 LAN ports as Bridge. 1.3 Client Mode Hardware connection and application When Mini Router switches to Client Mode, Mini Router will be a Wireless Adapter, and users can plug cable to each 2 LAN ports and then connect Internet via Wireless. User’s Manual V1.0 5 Chapter 2 Router Mode Quick Setup 2.1 Router Mode Quick Setup Instruction Please open a Microsoft Internet Explorer, and enter http://192.168.1.1 (Default Gateway) into browser’s blank, then you will see the configuration page below. Please click on Admin…
Text truncated - open the document above for the full version.
Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Pictures External Photos Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd.
Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Pictures External Photos Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd.
Size: mm
Size: mm
Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Internal Photos Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd.
Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Internal Photos Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd.
MPE Prediction FCC Rule: 15.247(b)(5) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See §1.1307(b)(1) of this Chapter. LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average time (minutes) (A)Limits For Occupational / Control Exposures 30-300 61.4 0.613 1.0 6 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 30-300 27.5 0.073 0.2 30 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 PG S = -------------- 4πR² where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 15.08 (dBm) Maximum peak output power at antenna input terminal: 32.2106 (mW) Antenna gain(maximal): 0 (dBi) Prediction distance: 20 (cm) Prediction frequency: 2437 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1.0 (mW/cm²) Power density at prediction frequency: 0.0064079 (mW/cm²) The manual instruct the user to install and operate the device in a minimum distance of 20 cm between antenna and the users body.
MPE Prediction FCC Rule: 15.247(b)(5) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See §1.1307(b)(1) of this Chapter. LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average time (minutes) (A)Limits For Occupational / Control Exposures 30-300 61.4 0.613 1.0 6 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 30-300 27.5 0.073 0.2 30 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 PG S = -------------- 4πR² where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 15.08 (dBm) Maximum peak output power at antenna input terminal: 32.2106 (mW) Antenna gain(maximal): 0 (dBi) Prediction distance: 20 (cm) Prediction frequency: 2437 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1.0 (mW/cm²) Power density at prediction frequency: 0.0064079 (mW/cm²) The manual instruct the user to install and operate the device in a minimum distance of 20 cm between antenna and the users body.
of Applicant:E-Top Network Technology Inc. Address:No.28, Gongye 2nd Rd., Tainan City 70095, Taiwan, R.O.C. Tested and Prepared by ETS DR. GENZ TAIWAN PS CO., LTD FCC Registration No.: 930600 Industry Canada filed test laboratory Reg. No. IC 5679 A2LA Cert.No.: 2300.01 PTCRB Accredited Type Certification Test House FCC ID: U6AMR122G 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E-mail: [email protected] Report number: W6M20703-7925-C-1 FCC TESTREPORT for MFP Server Router Model No.: MR122g Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr.Genz Taiwan PS Co., Ltd. 2 of 30 TABLE OF CONTENTS 1GENERAL INFORMATION ................................................................................................... 3 1.1 NOTES................................................................................................................................... 3 1.2 T ESTING LABORATORY......................................................................................................... 4 1.2.1Location ....................................................................................................................... 4 1.2.2Details of accreditation status ..................................................................................... 4 1.3 DETAILS OF APPROVAL HOLDER............................................................................................ 4 1.4 APPLICATION DETAILS.......................................................................................................... 5 1.5 GENERAL INFORMATION OF TEST ITEM................................................................................. 5 1.6 T EST STANDARDS.................................................................................................................. 6 2TECHNICAL TEST .................................................................................................................. 7 2.1 SUMMARY OF TEST RESULTS................................................................................................. 7 2.2 TEST ENVIRONMENT.............................................................................................................. 7 2.3 TESTEQUIPMENT LIST.......................................................................................................... 8 2.4 GENERAL TESTPROCEDURE............................................................................................... 10 3TEST RESULTS (ENCLOSURE).......................................................................................... 12 3.1 P EAKOUTPUT POWER (TRANSMITTER) ............................................................................... 13 3.2 EQUIVALENT ISOTROPIC RADIATED POWER......................................................................... 15 3.2.1Transmitter................................................................................................................. 15 3.3 RF EXPOSURE COMPLIANCE REQUIREMENTS..................................................................... 15 3.4 T RANSMITTER RADIATEDEMISSIONS IN RESTRICTED BANDS............................................. 16 3.5 SPURIOUSEMISSIONS(TX) .................................................................................................. 17 3.6 MINIMUM 6 DBBANDWIDTH.............................................................................................. 22 3.7 P EAKPOWER SPECTRAL DENSITY....................................................................................... 23 3.8 R ADIATEDEMISSION FROM DIGITALPARTANDRECEIVER L.O. ........................................ 24 3.9 P OWER LINE CONDUCTED EMISSION.................................................................................. 28 A PPENDIX....................................................................................................................................... 30 Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr.Genz Taiwan PS Co., Ltd. 3 of 30 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has Passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the ETS DR. GENZ TAIWAN PS CO., LTD. Specific Conditions: Usage of the hereunder tested device in combination with other integrated or external antennas requires at least additional output power measurements, spurious emission measurements, conducted emission measurements (AC supply lines) and radio frequency exposure evaluations for each individual configuration performed, for certification by FCC. The test sample is able to work according IEEE 802.11 b/g. This report is related to FCC Part 15 C (DSSS and OFDM device). Tester: April 18, 2007 Jay Chaing Date ETS-Lab. Name Signature Technical responsibility for area of testing: April 18, 2007 Steven Chuang Date ETS Name Signature Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr.Genz Taiwan PS Co., Ltd. 4 of 30 1.2 Testing laboratory 1.2.1 Location OATS No.5-1, Shuang Sing Village, LiShuei Rd., Wanli Township, Taipei County 207, Taiwan (R.O.C.) Company ET…
Text truncated - open the document above for the full version.
of Applicant:E-Top Network Technology Inc. Address:No.28, Gongye 2nd Rd., Tainan City 70095, Taiwan, R.O.C. Tested and Prepared by ETS DR. GENZ TAIWAN PS CO., LTD FCC Registration No.: 930600 Industry Canada filed test laboratory Reg. No. IC 5679 A2LA Cert.No.: 2300.01 PTCRB Accredited Type Certification Test House FCC ID: U6AMR122G 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E-mail: [email protected] Report number: W6M20703-7925-C-1 FCC TESTREPORT for MFP Server Router Model No.: MR122g Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr.Genz Taiwan PS Co., Ltd. 2 of 30 TABLE OF CONTENTS 1GENERAL INFORMATION ................................................................................................... 3 1.1 NOTES................................................................................................................................... 3 1.2 T ESTING LABORATORY......................................................................................................... 4 1.2.1Location ....................................................................................................................... 4 1.2.2Details of accreditation status ..................................................................................... 4 1.3 DETAILS OF APPROVAL HOLDER............................................................................................ 4 1.4 APPLICATION DETAILS.......................................................................................................... 5 1.5 GENERAL INFORMATION OF TEST ITEM................................................................................. 5 1.6 T EST STANDARDS.................................................................................................................. 6 2TECHNICAL TEST .................................................................................................................. 7 2.1 SUMMARY OF TEST RESULTS................................................................................................. 7 2.2 TEST ENVIRONMENT.............................................................................................................. 7 2.3 TESTEQUIPMENT LIST.......................................................................................................... 8 2.4 GENERAL TESTPROCEDURE............................................................................................... 10 3TEST RESULTS (ENCLOSURE).......................................................................................... 12 3.1 P EAKOUTPUT POWER (TRANSMITTER) ............................................................................... 13 3.2 EQUIVALENT ISOTROPIC RADIATED POWER......................................................................... 15 3.2.1Transmitter................................................................................................................. 15 3.3 RF EXPOSURE COMPLIANCE REQUIREMENTS..................................................................... 15 3.4 T RANSMITTER RADIATEDEMISSIONS IN RESTRICTED BANDS............................................. 16 3.5 SPURIOUSEMISSIONS(TX) .................................................................................................. 17 3.6 MINIMUM 6 DBBANDWIDTH.............................................................................................. 22 3.7 P EAKPOWER SPECTRAL DENSITY....................................................................................... 23 3.8 R ADIATEDEMISSION FROM DIGITALPARTANDRECEIVER L.O. ........................................ 24 3.9 P OWER LINE CONDUCTED EMISSION.................................................................................. 28 A PPENDIX....................................................................................................................................... 30 Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr.Genz Taiwan PS Co., Ltd. 3 of 30 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has Passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the ETS DR. GENZ TAIWAN PS CO., LTD. Specific Conditions: Usage of the hereunder tested device in combination with other integrated or external antennas requires at least additional output power measurements, spurious emission measurements, conducted emission measurements (AC supply lines) and radio frequency exposure evaluations for each individual configuration performed, for certification by FCC. The test sample is able to work according IEEE 802.11 b/g. This report is related to FCC Part 15 C (DSSS and OFDM device). Tester: April 18, 2007 Jay Chaing Date ETS-Lab. Name Signature Technical responsibility for area of testing: April 18, 2007 Steven Chuang Date ETS Name Signature Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr.Genz Taiwan PS Co., Ltd. 4 of 30 1.2 Testing laboratory 1.2.1 Location OATS No.5-1, Shuang Sing Village, LiShuei Rd., Wanli Township, Taipei County 207, Taiwan (R.O.C.) Company ET…
Text truncated - open the document above for the full version.
Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Set Up Photo of Radiated Emission Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Set Up Photo of Conducted Emission Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd.
Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Set Up Photo of Radiated Emission Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd. Set Up Photo of Conducted Emission Registration number: W6M20703-7925-C-1 FCC ID: U6AMR122G ETS Dr. Genz Taiwan PS Co., Ltd.
6F., No. 58, Lane 188, Ruey Kuang Road, Neihu · Taipei · Taiwan
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.41 GHz - 2.46 GHz | 32.21 mW |
