Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Nov 29, 2011
Application Purpose: Original Equipment
Date of Application: Nov 29, 2011
Equipment Note: 444-2213
Frequency Range: 5500.00000000 - 5700.00000000
Company: Summit Semiconductor LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2213 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC SUMMIT SEMICONDUCTOR LLC Model No.: 444-2213 FCC ID: UA9400 USER MANUAL Issue Date: 27 October, 2011 Revision: 1.0 Revision History Rev. No. History Issue Date Remarks 1.0 Draft Release 27 October, 2011 Pending FCC Grant SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2213 2 of 11 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC COPYRIGHT 2010 SUMMIT SEMICONDUCTOR LLC ALL RIGHTS RESERVED THE MATERIAL CONTAINED IN THIS DOCUMENT IS PROTECTED BY COPYRIGHT LAWS OF THE UNITED STATES OF AMERICA AND OTHER COUNTRIES. IT MAY NOT BE REPRODUCED OR DISTRIBUTED IN ANY FORM BY ANY MEANS, ALTERED IN ANY FASHION, OR STORED IN A DATA BASE OR RETRIEVAL SYSTEM, WITHOUT EXPRESS WRITTEN PERMISSION OF SUMMIT SEMICONDUCTOR LLC. SUMMIT SEMICONDUCTOR CANNOT BE RESPONSIBLE FOR UNAUTHORIZED USE OF EQUIPMENT AND WILL NOT MAKE ALLOWANCE OR CREDIT FOR UNAUTHORIZED USE OR ACCESS SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2213 3 of 11 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC Table of contents 1.0 Regulatory Statement ............................................................4 1.1 FCC Certification.........................................................4 2.0 Introduction........................................................................5 3.0 Installation and Test procedure.................................................8 3.1 Boot 3.2 Setting frequency channel, data rate and transmit power 3.3 Stop Transmitting 4.0 System Requirements...........................................................13 SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2213 4 of 11 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC 1.0 Regulatory Statement The United States Federal Communication Commission has established certain rules governing the use of electronic equipment. 1.1 FCC Certification This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This device has been tested and found to comply with the limits for a CLASS B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation. This equipment generates, uses, and radiates radio frequency energy and if not installed and used in accordance with the instruction guide, may cause harmful interference to radio communications. CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This radio is compliant with FCC RF Exposure requirements for mobile devices. Users are cautioned to maintain 20 cm from the transmitter to ensure compliance. CAUTION: The operation of this radio in the 5.15-5.25 GHz frequency band is restricted to indoor use only. SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2213 5 of 11 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC 2.0 Introduction: The 444-2213 Wireless Audio Client device is a production ready module designed for active speakers in Summit Semiconductor’s wireless audio technology. The module mounts to the top interior wall of a typical speaker. The module includes a patented, low cost, high gain quad diversity PCB antenna integrated in the module to provide superior wireless performance without external antennas. A 40 pin interface provides, I2S digital audio outputs, power, I2C and GPIO signals for control of the amplifier and power supply. FRONT SIDE SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2213 6 of 11 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC BACK SIDE CAUTION: DO NOT TRY TO REPLACE THE ANTENNAS SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2213 7 of 11 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC 3.0 Installation and Test Procedure A host interface board is used to provide the necessary regulated power supply to the 444-2213 Wireless Audio Client device . The set up is as shown in the picture below. 7 5 6 4 2 1 3 SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2213 8 of 11 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC 3.1 Boot: . Download Summit Semiconductor’s Hood_BIST_156 software onto your computer. Connect Mikkalo (interface board) to 444-2213 Wireless Audio Client device as shown in the picture. Connect a 3.3V DC supply to Mikkalo (interface board) from a variable or a fixed source. Connect the RS232 interface from J4 of the interface board to the serial cable. Connect the serial cable to the computer’s COM port. Press the reset button for the DUT to boot. Your screen should look as below. 1 Wireless Audio Client device 2 Integrated Antenna 3 RF Can 4 Mikkalo(Interface Board) 5 Reset Button 6 Power Input 3.3V 7 RS232 interface SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2213 9 of 11 22867 NW Bennett St., Suite 200 www.summits…

Text truncated - open the document above for the full version.

Cover Letter(s)

Northwest EMC TCB Compliance Opinion Rev. 12/08/09 FOCU0116 Information about the Applicant Grantee (Company Name) Summit Semiconductor LLC FCC Contact Person James Svoboda Address 22867 NW Bennett St, Suite 200 City, State, Zip Hillsboro, OR 97124 Job Number FOCU0115 Model 444-2213 FCC ID UA9400 Agent Approval Type Original Modular Approval Equipment Class NII Unlicensed National Information Infrastructure DTS Digital Transmission System Rule Part 15C (15.407, 15.247) Overview Summit Semiconductor LLC is seeking modular approval for their model 444-2213. This device is a wireless audio client device operating under FCC part 15.247 and 15.407. The model 444- 2213 wireless audio client device is a turnkey solution that enables customers to start volume production of high performance Digital Wireless Audio Speakers. The model 444-2213 radio module is designed to be integrated into an audio speaker providing high fidelity audio. It is an 802.11a compliant radio operating in the UNII band as a client device. Confidentiality requested for allowed files. Request is properly addressed and referenced. A letter listing the applicable modular requirements was submitted. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature 11/18/2011 Dave Tolman, TCB Committee

Cover Letter(s)

SUMMIT SEMICONDUCTOR LLC 22867 NW Bennett Street, Suite 200 Hillsboro, OR 97124 USA Phone: 503 615-7700 • Fax: 503 615-4232 http://www.summitsemi.com Request for Confidentiality October 27, 2011 Federal Communications Commission Authorization and Evaluation Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Summit Semiconductor Certification Application FCC ID: UA9400 To Whom It May Concern: A portion of the data contained in this application is to be considered a trade secret and not to be made routinely available to the public. If such information were to be made public, it might be used to the disadvantage of Summit Semiconductor LLC (the applicant) in the market place. Therefore, pursuant to 47 CFR 0.459 and 47 CFR 0.457(d) of the FCC Rules, we request that the information listed below be withheld from public inspection: Schematics Frequency Block Diagrams Operational Description Thank you for your attention to this matter. Sincerely, James Svoboda Engineering Manager

Cover Letter(s)

NORTHWEST EMC, INC. 22975 NW Evergreen Parkway, Suite 400 Hillsboro, OR 97124 November 30, 2011 RE: FCC ID: UA9400 Dear Application Examiner: We completed an upload and issued a grant of equipment authorization for FCC ID UA9400. The application was assessed as a Full Modular Approval, but the Limited Modular Approval type was initially selected in error (on Form 731). This has now been corrected to reflect Single Modular Approval. An updated cover letter and modular approval letter have been uploaded (reflecting “full modular approval” instead of just “modular approval”) and should supersede the cover letter and modular approval letter that were originally submitted. Best regards, Northwest EMC, Inc.

Cover Letter(s)

SUMMIT SEMICONDUCTOR LLC 22867 NW Bennett Street, Suite 200 Hillsboro, OR 97124 USA Phone: 503 615-7700 • Fax: 503 615-4232 http://www.summitsemi.com 27 October, 2011 Federal Communications Commission Authorization and Evaluation Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Application Examiner: Summit Semiconductor LLC has designed and built a digital wireless audio client device. Summit Semiconductor requests FCC Equipment and Authorization branch to grant an original certification of a full modular approval for our wireless audio client device, Model No.: 444- 2213, FCC ID: UA9400. The 444-2213 digital wireless audio client device is a turnkey solution that enables customers to start volume production of high performance Digital Wireless Audio speakers. The 444-2213 is designed to be integrated into an audio speaker providing high fidelity audio. It is an IEEE 802.11a compliant radio operating in UNII band and operates in accordance with the client mode as stated in the FCC 06-96. The digital wireless audio client device works as part of a system along with Summit Semiconductor’s master module with Model No.: 444-2203, FCC ID: UA9100. The master module is typically installed in a DVR, Blu-ray player or a gaming console and transmits digital audio wirelessly to the client device which is typically installed in an audio speaker. The 444- 2213 is not compatible with any other device other than Summit Semiconductor’s Master Module. The 444-2213 digital wireless audio client device was tested at NWEMC’s Oregon facility for rule parts 15.247 and 15.407. The device was also tested for all the requirements necessary to certify it as a modular transmitter. The test set up photos and the technical test report has all the details about the performance and results of the device. The following test reports are being submitted as part of the requirements and in support of the filing for original certification. • Report FOCU0115 - 15.247 • Report FOCU0115.1 - 15.407 • Report FOCU00115.4 – MPE Report Please address any correspondence regarding this filing to my attention at the following address. Summit Semiconductor LLC 22867 NW Bennett St., Suite 200 Hillsboro, OR 97124 Ph: 503 615-7734 Sincerely, James Svoboda Engineering Manager

Cover Letter(s)

SUMMIT SEMICONDUCTOR LLC 22867 NW Bennett Street, Suite 200 Hillsboro, OR 97124 USA Phone: 503 615-7700 • Fax: 503 615-4232 http://www.summitsemi.com October 27, 2011 Federal Communications Commission Authorization and Evaluation Branch 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for unlicensed Modular Transmitter Approval. Dear Application Examiner: Summit Semiconductor LLC hereby requests FCC Equipment Authorization and Evaluation branch to approve Summit Semiconductor’s Model 444-2213 Audio Wireless Client Module, FCC ID- UA9400 as having a full modular approval. The 444-2213 Audio Wireless Client Module is a production ready module designed for audio speakers in Summit Semiconductor’s high definition wireless audio solution. The module is designed to be mounted to the interior of the speaker cabinet. This letter addresses the information required by points one through eight of 47 CFR 15.212. 1. “The modular transmitter must have its own RF shielding .” The radio section of the module is enclosed within a RF shield. The RF shield is solder mounted to exposed grounding of the circuit board. The point of contact between the shield and the board has multiple ground contacts. The internal photos exhibit has pictures of the wireless client device with and without the shield. The shield suppresses spurious radiations as per FCC requirements. 2. “The modular transmitter must have buffered modulation/data inputs.” The 444-2213 has buffered data inputs from an on-chip embedded processor. The purpose of this is to transmit control and status information back to the master device. This method insures compliance with Part 15 requirements under conditions of excessive data rates or over modulation. 3. “The modular transmitter must have its own power supply regulation .” The 444-2213 digital wireless client device receives power from an external +3.3 VDC supply via an industry standard power supply jack. The 3.3 volt DC is regulated to 1.5 and 2.8 volts VDC as well as it uses the 3.3 VDC directly. In order to comply with the requirement that all voltages be regulated, we have included an over voltage detection circuit which ceases RF transmission when the input voltage exceeds 3.6 VDC. Also, the technical report exhibit contains AC power line conducted emissions data taken with the EUT powered from a linear power supply that contains no EMC suppression components. 4. “The modular transmitter antenna must comply with the antenna and transmission system requirements of section 15.203, and 15.204(c).” The modular device complies with all FCC antenna requirements. The modular device is designed in such a way that the antenna is integrated with the modular device. As per the FCC 15.203 requirement, this can be considered as permanently attached and doesn’t give the user any option to replace it. A list of usable antennas is not provided since the user manual clearly instructs the user that the modular device is compatible with only the integrated antennas. Please see the internal exhibit photos for further details. The antenna report also provides a description as to how the modular device complies with the de facto EIRP limit. 5. “The modular transmitter must be tested in a stand-alone configuration .” As described in the technical report exhibit and the test set up photos of the test report included in the filing for FCC equipment authorization, the 444-2213 digital wireless client device module was tested as a stand- alone device. The 444-2213 is designed with an industry standard 40 pin multi pin flex cable and it is greater than 10 cm from the host device. 6. “The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying the FCC identification number.” A FCC ID and model number is labeled on every modular device. FCC ID label and location exhibit has a photograph which shows the exact location of the label. Since the FCC ID number will not be visible when the module is installed inside the audio speaker, another label with the same FCC ID will be applied to the exterior of the speaker. 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT complies with all specific rules such as modulation scheme, modulation type, bandwidth, antenna requirements, power supply regulation, and suppression of spurious emissions and so on. A detailed user manual is provided with every EUT which instructs the user to maintain compliance as per the requirements of the Commission. The manual also cautions the user not to make any changes or modifications not approved by the party responsible for compliance. Please see the operating description exhibit for further details to understand how the EUT complies with specific rules and operating requirements as per FCC. 8. “The modular transmitter must comply with any applicable RF exposure requirements in its final configuration.” The EUT is compliant with all applicable RF exposure requirements and EUT is operated in a manner that ensures the public is not exposed to radio frequency in excess of Federal Communication Commission’s guidelines. Please see the RF exposure exhibit. Best Regards James Svoboda Engineering Manager

Cover Letter(s)

1. Does this device meet the requirements for operation in the 5400 – 5725 MHz band specified in KDB 443999? Yes, Section 3.2 of the user manual lists the available channels and states, "This device will not operate in 5600 MHz - 5650 MHz band". Furthermore, this is a client device with no radar detection and no ad-hoc capability. It meets the 15.202 definition of a client device. 2. Is this an indoor device, outdoor device, or multi-use device? A multi-use device can operate in both indoor and outdoor configurations; such device will have to meet all the requirements for outdoor device. Per the grant notes, operation in the 5150 - 5250 MHz band is restricted to indoor use only. Therefore outdoor use outside of that band is not restricted. As a client device with no radar detection capability, it meets the requirements for outdoor use per KDB 443999. 3. Verify that the 5600 – 5650 MHz band is notched. The test report should include 20 dB BW plots for the 5600 and 5650 MHz band edges and an attestation statement that the device does not transmit in the notched band. See measurements below Band edge Compliance for 5580 MHz Value Limit Result ‐35.6dBc ≤ ‐20dBc Pass Band edge Compliance for 5660 MHz Value Limit Result ‐36.4dBc ≤ ‐20dBc Pass 4. Verify that this application contains a complete User’s Manual and/or Professional Installers Manual. If the manual is not complete, upload an updated User’s Manual exhibit. The User Manual that was uploaded with the filing is complete. 5. Verify that this device meets the uniform channel spreading requirements on the remaining (non- notched) channels once the device is in operation. The device meets the 15.202 definition of a client device. Channel spreading is determined by the master device. 6. Explain how this device meets the Software Configuration Control requirements of KDB 594280 including country code selection – see draft KDB at (https://fjallfoss.fcc.gov/eas/comments/GetPublishedDocument.html?id=205&tn=511416 ). If there is any user permitted configuration control, please explain what controls are provided to the user and if any will take the device out of compliance; also explain what prevents the end user from downloading and operating non-US software. UA9400 meets the software configuration control requirements of KDB 594280 including the country code selection as per the below information. No user configuration controls are provided to a third party that modifies the operating parameters of frequency range, modulation type or maximum transmit power. The software is not designed or expected to be modified by any party including the manufacturer. Only the grantee can modify the software. No user accessible software will be made available. The software that controls the radio and the processor functionality are independent. Software updates are sent only to update the processor functionality. Hence the software updates will not include anything that will manipulate with the radio functionality. Country code selection is not included in this device (UA9400) since it is a client device. Country code selection is included only in a master device. 7. Additional questions for outdoor and multi-use devices: Submit a Letter Exhibit identify the specific expertise and the training required by the professional installers for installing these types of devices. As specified by the grant notes and applicant cover letter, this module is for OEM installation only. It is not professionally installed. 8. Explain how this device can meet the 30 MHz frequency separation from TDWR (i.e.: Manually blocking frequencies by the professional installer, device notches 5470 -5680 MHz, etc.) The device meets the 15.202 definition of a client device. It has no radar detection or ad-hoc capability. The TDWR requirement is for devices with radar detection capability such as master devices. KDB 443999 specifies that the TDWR requirement is only for master devices with radar detection and with DFS capability. It states, "In the interim, the Commission will now allow certification of wireless master devices with radar detection function and with DFS capability, if they meet the following conditions:" 9. Does the manual for the installers and operators contain the information on how to register the device with the voluntary industry data base if operating within 35 km of any TDWR site location? The device meets the 15.202 definition of a client device. It has no radar detection or ad-hoc capability. The TDWR requirement is for devices with radar detection capability such as master devices. KDB 443999 specifies that the TDWR requirement is only for master devices with radar detection ans with DFS capability. It states, "In the interim, the Commission will now allow certification of wireless master devices with radar detection function and with DFS capability, if they meet the following conditions:"

External Photos

ID Label/Location Info

SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2196H 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC SUMMIT SEMICONDUCTOR LLC Model No.: 444-2213 FCC ID: UA9400 FCC ID and LOCATION SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2196H 2 of 2 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC FCC ID AND LOCATION

ID Label/Location Info

Example of label that will appear on outside of host device Contains: FCC ID: UA9400 IC: 9129A-400

Internal Photos

Operational Description

RF Exposure Info

Summit Semiconductor LLC Ice Axe – Slave Module Model 444-2213 Report No. FOCU0115.4 Report Prepared By www.nwemc.com 1-888-EMI-CERT © 2011 Northwest EMC, Inc 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Certificate of Evaluation Summit Semiconductor LLC Model: Ice Axe- Slave Module (Model 444-2213) Emissions Test Description Specification Test Method Pass/Fail Maximum Permissible Exposure FCC 2.1091:2011 OET Bulletin 65, Supplement C Ed 01-01 Pass Modifications made to the product See the Modifications section of this report Approved By: Donald Facteau, IS Manager This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. Northwest EMC Revision History Revision 05/05/03 Revision Number Description Date Page Number 00 Accreditations and Authorizations FCC Accredited by NVLAP for performance of FCC radio, digital, and ISM device testing. Our Open Area Test Sites, certification chambers, and conducted measurement facilities have been fully described in reports filed with the FCC and accepted by the FCC in letters maintained in our files. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by the FCC as a Telecommunications Certification Body (TCB). This allows Northwest EMC to certify transmitters to FCC specifications in accordance with 47 CFR 2.960 and 2.962. NVLAP Northwest EMC, Inc. is accredited under the National Voluntary Laboratory Accreditation Program (NVLAP) for satisfactory compliance with the requirements of ISO/IEC 17025 for Testing Laboratories. NVLAP is administered by the National Institute of Standards and Technology (NIST), an agency of the U.S. Commerce Department. The NVLAP accreditation encompasses Electromagnetic Compatibility Testing in accordance with the European Union EMC Directive 2004/108/EC, and ANSI C63.4. Additionally, Northwest EMC is accredited by NVLAP to perform radio testing in accordance with the European Union R&TTE Directive 1999/5/EEC, the requirements of FCC, and the RSS radio standards for Industry Canada. Industry Canada Accredited by NVLAP for performance of Industry Canada RSS and ICES testing. Our Open Area Test Sites and certification chambers comply with RSS-Gen, Issue 2 and have been filed with Industry Canada and accepted. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by NIST and recognized by Industry Canada as a Certification Body (CB) per the APEC Mutual Recognition Arrangement (MRA). This allows Northwest EMC to certify transmitters to Industry Canada technical requirements. (Site Filing Numbers - Hillsboro: 2834D-1, 2834D-2, Sultan: 2834C-1, Irvine: 2834B-1, 2834B-2, Brooklyn Park: 2834E-1) CAB Designated by NIST and validated by the European Commission as a Conformity Assessment Body (CAB) to conduct tests and approve products to the EMC directive and transmitters to the R&TTE directive, as described in the U.S. - EU Mutual Recognition Agreement. Australia/New Zealand The National Association of Testing Authorities (NATA), Australia has been appointed by the ACA as an accreditation body to accredit test laboratories and competent bodies for EMC standards. Accredited test reports or assessments by competent bodies must carry the NATA logo. Test reports made by an overseas laboratory that has been accredited for the relevant standards by an overseas accreditation body that has a Mutual Recognition Agreement (MRA) with NATA are also accepted as technical grounds for product conformity. The report should be endorsed with the respective logo of the accreditation body (NVLAP). Accreditations and Authorizations VCCI Accepted as an Associate Member to the VCCI, Acceptance No. 564. Conduct…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Ken N Boehlke(Engineering Manager)

[email protected]503-615-7727Fax: 503-615-4232

Test Firm

Northwest EMC, Inc.Greg Kiemel

[email protected]503-844-4066Fax: 503-844-3826

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
3	15E	5.50 GHz - 5.70 GHz	12.20 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Output power is conducted. Client device per section 15.202 definition. Operation of this device in the 5150 MHz to 5250 MHz range is restricted to indoor use only. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operating conditions for satisfying RF exposure compliance.
