SUMMIT SEMICONDUCTOR LLC 22867 NW Bennett Street, Suite 200 Hillsboro, OR 97124 USA Phone: 503 615-7700 • Fax: 503 615-4232 http://www.summitsemi.com August 15, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia , Maryland 21046 To Whom it May Concern: We attest to the following:  Per FCC KDB 443999 D01 v01r02 and RSS 210 Annex 9, this device will not transmit in the 5600 - 5650 MHz band  Per FCC KDB 594280 D01 v02r01, the device complies with the requirements for software configuration control. The device does not have the ability to be configured by end users or professional installers to operate outside the authorized bands  Per FCC 15.407(c), the device will automatically discontinue transmission in case of either absence of information to transmit or operational failure. Kenneth A. Boehlke

SUMMIT SEMICONDUCTOR LLC 22867 NW Bennett St., Suite 200 Hillsboro, OR, 97124 USA Phone: 503 615-7700 Fax: 503 615-4232 http://www.summitsemi.com Request for Confidentiality July 2, 2014 Federal Communications Commission Authorization and Evaluation Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Summit Semiconductor LLC Certification Application FCC ID: UA9800 To Whom It May Concern: A portion of the data contained in this application is to be considered a trade secret and not to be made routinely available to the public. If such information were to be made public, it might be used to the disadvantage of Summit Semiconductor LLC (the applicant) in the market place. Therefore, pursuant to 47 CFR 0.459 and 47 CFR 0.457(d) of the FCC Rules, we request that the information listed below be withheld from public inspection: Schematics Frequency Block Diagrams Operational Description Thank you for your attention to this matter. Sincerely, Kenneth A Boehlke Principal Engineer

WTD 13.4.9 FCC Compliance Opinion FOCU0169 Information about the Applicant Grantee (Company Name) Summit Semiconductor LLC FCC Contact Person Kenneth A Boehlke Address 22867 NW Bennett St. Suite 200 City, State, Zip Hillsboro, OR 97124 Job Number FOCU0169 Model 444-2251 FCC ID UA9800 Agent Approval Type Original Equipment Class NII Unlicensed National Information Infrastructure Tx, DTS Digital Transmission System Rule Part 15.247, 15.407 Overview The model 444-2251 is an 802.11a compliant wireless master module, which allows a turnkey solution for volume production of wireless audio speakers. Summit Semiconductor is seeking single modular approval. Since this device is a master UNII modular device, KDB inquiries were necessary to get FCC approval for this application. The FCC PBA process was followed. Confidentiality requested for allowed files. Request is properly addressed and referenced. A letter listing the applicable modular requirements was submitted. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature Dave Tolman, TCB Committee 8/19/2014

SUMM 8 July, 20 Federal C Authoriz 7435 Oak Columbi Dear Ap p Summit S operates Equipme our wirel The 444 - volume p designed consoles, UNII ban The 444 - 15.247 an modular, report ha to verific IT SEMI C 014 Communicat zation and Ev kland Mills R a, MD 2104 plication Ex Semiconduc in the UNII ent and Auth less master m -2251 wirele production o d to be integr , set top box nd and opera -2251 wirele nd 15.407. T , DFS capabl ave all the de cation and no CONDUCT tions Comm valuation Br Road 6 aminer: ctor LLC has band includ horization bra module, Mod ess master m f high perfor rated into an xes and wirel ates in accord ess master m The device w le, and 21 ch etails about t ot DoC beca TOR LLC ission ranch s designed an ding the DFS anch to gran del No.: 444 module is a tu rmance digit audio sourc less hubs. It dance with t module was te was tested for hannel transm the performa use it is not C nd built a dig S frequencies nt an original 4-2251, FCC urnkey soluti tal wireless ce device suc is an IEEE 8 the master m ested at NW r all the requ mitter. The t ance and resu a PC periph gital wireles s. Summit Se l certification ID: UA980 ion that enab audio source ch as AVRs, 802.11a com mode as state WEMC’s Oreg uirements ne test set up ph ults of the de heral 22678 NW Suite 200 Hillsboro, O Phone: 503 Fax: 503 6 http://www ss master mo emiconducto n of modula 00. bles custome e devices. Th DVD playe mpliant radio ed in the FCC gon facility ecessary to c hotos and th evice. The d Bennett St. OR, 97124 3 615-7700 615-4232 w.summitsem odule that or requests F ar approval f ers to start he 444-2251 ers, TVs, gam o operating in C 06-96. for rule par t certify it as a e technical t device is subj mi.com FCC for 1 is ming n ts a test ject Please ad Summit S 22678 NW Hillsboro Phone: 5 Sincerel y Ken A B Principal ddress any co Semiconduc W Bennett S o, OR, 97124 03 615-7700 y, oehlke l Engineer orresponden ctor LLC St. Suite 200 4 0 nce regarding 0 g this filing t to my attentiion at the folllowing addrress.

SUMM 8 July, 20 Federal C Authoriz 7435 Oak Columbi Subject: Dear Ap p Summit branch to device, F letter add 1. “The the m groun multi devic requi 2. “The buffe gener data r affect under 3. “The wirel IT SEMI C 014 Communicat zation and Ev kland Mills R a, MD 2104 Request for plication Ex Semicondu c o approve S FCC ID-UA dresses the in modular tra module is en nding of the iple ground ce with and irements. modular tra ered data inp rated on boa rate control t the RF dat r conditions modular tra less master d CONDUCT tions Comm valuation Br Road 6 unlicense d M aminer: ctor LLC h ummit Semi A9800, modu nformation r ansmitter mu closed withi e circuit boa contacts. T without the ansmitter m puts that pas ard. Firmwa settings of t ta rate or typ of excessive ansmitter mu device receiv TOR LLC ission ranch Modular Tra ereby reque iconductor L ular approva required by p ust have its in a RF shie ard. The poi The internal e shield. The must have bu ss through an are will also the RF circu pe. This me e data rates o ust have its o ves power f C ansmitter Ap ests FCC Eq LLC Model al for a 21 points one th own RF shi eld. The RF nt of conta c photos exhi e shield sup uffered modu n embedded o not allow uitry. No ch ethod insure or over modu own power s from an exte pproval. quipment A 444-2251, d channel DF hrough eight ielding.” The shield is so ct between t ibit has pict ppresses spu ulation/data d processor. the end us e hange in inp es complianc dulation. supply regul ernal +3.3 V 22867 NW B Suite 200 Hillsboro, O Phone: 503 Fax: 503 6 http://www Authorization digital wirel FS enabled t of 47 CFR e transmitter older mounte the shield an tures of the urious radiat inputs.” T RF modula er to access put data or c ce with Part lation.” The VDC and ex Bennett St. OR, 97124 3 615-7700 • 615-4232 w.summitsem n and Evalu less audio m transmitter. 15.212. r radio secti ed to the exp nd the board e wireless m tions as per The 444-225 ation control RF modulat control signa t 15 requirem 444-2251 d xternal +1.2 mi.com uation master This on of posed d has master FCC 1 has ls are tion / al can ments digital VDC supply on the customer’s host controller board. The +3.3 VDC supply sources some circuitry directly and is also regulated to +2.8 VDC. The +1.2 VDC supply sources circuitry directly. In order to comply with the requirement that all voltages be regulated, we have included an over voltage detection circuit which ceases RF transmission when the radio input voltage exceeds its +10% threshold. 4. “The modular transmitter antenna must comply with the antenna and transmission system requirements of section 15.203, and 15.204(c).” The modular device complies with all FCC antenna requirements. The 444-2251 digital wireless master device is designed in such a way that the antenna is integrated with the modular device. As per the FCC 15.203 requirement, this can be considered as permanently attached and doesn’t give the user any option to replace it. A list of usable antennas is not provided since the user manual clearly instructs the user that the modular device is compatible with only the integrated antenna. The antenna report also provides a description as to how the modular device complies with the de facto EIRP limit. 5. “The modular transmitter must be tested in a stand-alone configuration.” As described in the technical report exhibit and the test set up photos of the test report included in the filing for FCC equipment authorization, the 444-2251 digital wireless master device module was tested as a standalone device. The device is designed with an industry standard multi pin connector and was tested in typical configuration which is greater than 10 cm in length from the host device. 6. “The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying the FCC identification number.” A FCC ID and model number is labeled on every modular device. FCC ID label and location exhibit has a photograph which shows the exact location of the label. Since the FCC ID number will not be visible when the module is installed inside the host audio source, another label with the same FCC ID will be applied to the exterior of the host/master enclosure. 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT complies with all specific rules such as modulation scheme, modulation type, bandwidth, antenna requirements, power supply regulation, and suppression of spurious emissions and so on. A detailed user manual is provided with every EUT which instructs the user to maintain compliance as per the requirements of the Commission. The manual also cautions the user not to make any changes or modifications not approved by the party responsible for compliance. Please see the operating description exhibit for further details to understand how the EUT complies with specific rules and operating requirements as per FCC. 8. “The modular transmitter must comply with any applicable RF exposure requirements in its final configuration.” The EUT is compliant with all applicable RF exposure requirements and EUT is operated in a manner that ensures the public is not exposed to radio frequency in excess of Federal Communication Commission’s guidelines. Please see the RF exposure exhibit. Best R Kenn e Princi Regards eth A Boehlk ipal Enginee ke er

20575 NW Von Neumann Dr. Suite 100 Beaverton, OR 97006 USA (503) 615-7700 summitsemi.com October 21, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern, This letter describes the compliance of master device FCC ID: UA9800 to the 594280 D01 Configuration Control v02r01 and 594280 D02 U‐NII Device Security v01r01 documents referred in KDB 594280. Software updates are provided to third party ODM/OEM partners and they may distribute them to end‐user or installer customers. These updates are in 128 bit encrypted binary machine code and are extremely difficult to disassemble for unauthorized modification. If the decoding of the encrypted code fails to decipher the binary machine code will not load and run on the radio device. Radio parameters can only be modified by third party ODM/OEM partners through the mechanism of country codes. No radio parameter can be modified directly and cause a violation of certification. No end‐user or installer can modify these country codes. The software distribution is worldwide and does not differ on a country by country basis. The country code portion of the software is not part of the software update distribution, and so software updates are not able to modify the country code. Before the country code documentation, visibility, and control method are available to the third party ODM/OEM the ODM/OEM must sign the included Attestation Letter. This letter dictates the responsibility of ODM/OEM to control the country code and what actions they must do to stay within compliance. This prevents improper loading of non‐US parameters in to the radio device. Master software cannot load on a client and client software cannot load on a master. Summit Semiconductor UA9800 is a master only device and cannot be configured as a client. Summit Semiconductor UA9601 is a client only device and cannot be configured as a master. No other modes; ad hoc, bridge, or mesh are permitted in either radio device. When the device is re‐started the default radio parameters are assigned identical to normal use radio parameters. Best Regards, Kenneth A. Boehlke Principal Engineer Summit Semiconductor [email protected] 20575 NW Von Neumann Dr. Suite 100 Beaverton, OR 97006 USA (503) 615-7700 summitsemi.com October 21, 2014 COMPANY NAME COMPANY ADDRESS Dear COMPANY REPRESENTATIVE The Federal Communications Commission (FCC) recently requested Summit Semiconductor, LLC. (Summit) to demonstrate compliance with the software configuration control and country code requirements specified in KDB 594280. Summit responded to this request by submitting a letter to the FCC stating the step by step procedure that Summit will follow to comply with the requirements of KDB 594280. This letter was accepted by the FCC and it can be accessed at the FCC’s website. One of the FCC requirements is that COMPANY NAME signs an attestation statement ensuring that any wireless module programmed to a specific country will only be used in products shipped to that country. This is to prevent modules programmed for a different country being mistakenly shipped to USA. Hence, Summit is requesting COMPANY NAME to follow the diagrammatically represented procedure below to fulfill the requirement stated in KDB 594280. A brief explanation follows the blocks diagram. 20575 NW Von Neumann Dr. Suite 100 Beaverton, OR 97006 USA (503) 615-7700 summitsemi.com The MFG data file and the DFS parameters file are loaded into the wireless module during Summit’s manufacturing process, and the country code in the MFG data file is by default set to USA. The modules are shipped to COMPANY NAME’s receiving department, at which time COMPANY NAME assigns a SKU number. Units that are designated to be shipped to USA are assigned a unique SKU number and units to be shipped to the rest of the world are assigned a different SKU number. Once the units are assigned a SKU number for USA, the MFG data file and DFS parameters file cannot be changed. For rest of the world, COMPANY NAME can follow the procedure illustrated in the block diagram above. By signing below COMPANY NAME agrees to Summit’s process illustrated above, which is necessary to demonstrate compliance with the software configuration control and country code requirements as stated in KDB 594280. Signature ________________________________ COMPANY REPRESENTATIVE TITLE COMPANY NAME COMPANY ADDRESS Date: ______________________

SUMMIT SEMICONDUCTOR LLCSUMMIT SWM 908 MASTER MODULE Model No. 444-2251 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC SUMMIT SEMICONDUCTOR LLC Model No.: 444-2251 FCC ID: UA9800 INTERNAL PHOTOS SUMMIT SEMICONDUCTOR LLC SUMMIT SWM 908 MASTER MODULE Model No. 444-2251 2 of 3 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC FRONT SIDE WITH RF SHIELDING (under labels) BACK SIDE MANUFACTURING TEST POINT PATCH ANTENNA (BACK SIDE) RF RADIO SHIELD SUMMIT SEMICONDUCTOR LLC SUMMIT SWM 908 MASTER MODULE Model No. 444-2251 3 of 3 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC FRONT SIDE WITHOUT RF SHIELDING PATCH ANTENNA WORKING RADIO MONITOR RADIO SWM 908 PROCESSOR TEMPORARY / TEST ANTENNA CONNECTOR

SUMM Model N www.su MIT SEMICO No. 444-2251 ummitsemi.com S ONDUCTOR L SUMMIT M FCC LLC © 2014 Sum T SEMI Model N FCC I C ID an mmit Semiconduc ICONDU No.: 444 ID: UA9 nd LOC S ctor LLC UCTOR 4-2251 9800 CATIO SUMMIT SW 22867 NW B H T FA R LLC ON WM 908 MAS ennett St., Suite 2 Hillsboro, OR 9712 TEL (503) 615 77 AX: (503) 615 44 STER MODU 00 24 34 32 LE SUMM Model N www.su FCC MIT SEMICO No. 444-2251 ummitsemi.com ID AND LO ONDUCTOR L OCATION LLC © 2014 Sum 2 of 2 mmit Semiconduc S ctor LLC SUMMIT SW 22867 NW B H T FA WM 908 MAS ennett St., Suite 2 Hillsboro, OR 9712 TEL (503) 615 77 AX: (503) 615 44 STER MODU 00 24 34 32 LE

SUMMIT SEMICONDUCTOR LLCSUMMIT SWM 908 MASTER MODULE Model No. 444-2251 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC SUMMIT SEMICONDUCTOR LLC Model No.: 444-2251 FCC ID: UA9800 INTERNAL PHOTOS SUMMIT SEMICONDUCTOR LLC SUMMIT SWM 908 MASTER MODULE Model No. 444-2251 2 of 3 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC FRONT SIDE WITH RF SHIELDING (under labels) BACK SIDE MANUFACTURING TEST POINT PATCH ANTENNA (BACK SIDE) RF RADIO SHIELD SUMMIT SEMICONDUCTOR LLC SUMMIT SWM 908 MASTER MODULE Model No. 444-2251 3 of 3 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC FRONT SIDE WITHOUT RF SHIELDING PATCH ANTENNA WORKING RADIO MONITOR RADIO SWM 908 PROCESSOR TEMPORARY / TEST ANTENNA CONNECTOR

SUMM Model N www.su MIT SEMICO No. 444-2251 ummitsemi.com S A ONDUCTOR L SUMMIT M ANTEN LLC © 2014 Su m T SEMI Model N FCC ID NNA I mmit Semiconduc ICONDU No.: 444 D.: UA9 INFOR SU 22867 ctor LLC UCTOR 4-2251 9800 RMAT UMMIT SWM 7 NW Bennett S Hillsboro, TEL (50 FAX: (50 R LLC TION M908 MODULE t. Suite 200 OR, 97124 03) 615-7700 03) 615 4232 E - SHERWOOD D SUMM Model N www.su The cost , tunin viola The and t Henc spec anten The dBi a comp MIT SEMICO No. 444-2251 ummitsemi.com 444-2251 , integrated ng of RF ap ating the F user man u the modula ce a list of cific contro nna. maximu m at 5500 MH plies with ONDUCTOR L Summit SW d PCB ante pplication CC requir e ual clearly c ar device i fusable ant ols availabl m gain for th Hz. From the EIRP l LLC © 2014 Su m WM908 m enna, mean circuits ar ement per cautions th s compatib tennas is n le to the us he Summit the test re limit SU mmit Semiconduc master mod ning no un re required 15.203 he user not ble with on not furnishe ser that cha t SWM908 port it is ev UMMIT SWM9 ctor LLC dule include sightly ext . This kee t to try to r nly the inte ed to the us anges the p 8 master m vident that 908 MASTER 22867 NW B H TEL FA es a patent ternal anten eps the user eplace the egrated ant ser. Also, t performanc module is ar t the antenn MODULE - SH Bennett St, Suite 20 Hillsboro, OR, 9712 L (503) 615-770 AX (503) 615-4232 ted, low- nnas or rs from antenna enna. there are n ce of the round 0.6 na HERWOOD 00 24 00 2 no

Summit Semiconductor LLC Model: 444-2251 Report No. FOCU0169.1 FCC 2.1091:2014 Maximum Permissible Exposure Level Report Prepared By Northwest EMC Inc. NORTHWEST EMC – (888) 364-2378 – www.nwemc.com California – Minnesota – Oregon – New York – Washington 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Certificate of Evaluation Date of Evaluation: July 10, 2014 Summit Semiconductor LLC Model: 444-2251 Emissions Description of Evaluation Specification Evaluation Method Pass/Fail Maximum Permissible Exposure FCC 2.1091:2014 KDB 447498 D01 General RF Exposure Guidance v05r02 Pass Approved By: Donald Facteau,IT Manager NVLAP Lab Code: 200630-0 This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. Report No. FOCU0169.12/9 REV 2012.05.24 REVISION HISTORY Revision Number Description Date Page Number 00 None Report No. FOCU0169.13/9 REV 2012.05.24 ACCREDITATIONS AND AUTHORIZATIONS United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC Guide 65 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea KCC / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Hong Kong OFTA – Recognized by OFTA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. Russia GOST – Accredited by Certinform VNIINMASH, CERTINFO, SAMTES, and Federal CHEC to perform EMC and Hygienic testing for Information Technology products to GOST standards. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ Report No. FOCU0169.14/9 REV 2013.01.07 LOCATIONS Oregon Labs EV01-12 22975 NW Evergreen Pkwy Hillsboro, OR 97124 (503) 844-4066 California Labs OC01-13 41 Tesla Irvine, CA 92618 (949) 861-8918 New York Labs WA01-04 4939 Jordan Rd. Elbridge, NY 13060 (315) 685-0796 Minnesota Labs MN01-08 9349 W Broadway Ave. Brooklyn Park, MN 55445 (763) 425-2281 Washington Labs NC01-05,SU02,SU07 19201 120 th Ave. NE Bothell, WA 98011 (425) 984-6600 VCCI A-0108 A-0029 A-0109 A-0110 Industry Canada 2834D-1, 2834D-2 2834B-1, 2834B-2, 2834B-3 2834E-1 2834C-1 Report No. FOCU0169.15/9 WTD 12.5.23 PRODUCT DESCRIPTION Client and Equipment Under Test (EUT) Information Company Name: Summit Semiconductor Address: 22867 NW Bennett St, Suite 200 City, State, Zip: Hillsboro, OR 97124 Test Requested By: Paul Price Model: 444-2251 Information Provided by the Party Requesting the Test Functional Description of the EUT (Equipment Under Test): The EUT is a digital wireless audio Master device which utilizes an 802.11a compliant radio module operating in the 5.2 GHz, 5.3 GHz, 5.6 GHz UNII bands and the 5.8 GHz 15.247 band. The device has a single antenna. Testing Objective: To demonstrate compliance with FCC requirements for RF exposure for 2.1091 mobile devices Report No. FOCU0169.16/9 WD.12.29.11 Maximum Permissible Exposure (MPE) OVERVIEW Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. ANSI C95.1-1992 specifies a minimum separation distance of 20 cm for performing reliable field measurements to determine adhere…
