UA9600444-2224

Summit Semiconductor LLC

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jul 08, 2013
Application Purpose: Original Equipment
Date of Application: Jul 08, 2013
Equipment Note: 444-2224
Frequency Range: 5745.00000000 - 5825.00000000
Company: Summit Semiconductor LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

SUMMIT SEMICONDUCTOR LLC 22867 NW Bennett Street, Suite 200 Hillsboro, OR 97124 USA Phone: 503 615‐7700 • Fax: 503 615‐4232 http://www.summitsemi.com Model 444‐2224(Athena 4X) User Manual 1 Table of Contents 2 User Manual Regulatory Statements ............................................................................................. 2 2.1 FCC / IC Identification Numbers .............................................................................................. 2 2.2 FCC/ IC Compliance Statement ............................................................................................... 2 2.3 FCC Changes Warning ............................................................................................................. 2 2.4 FCC / IC Information To The User ........................................................................................... 2 2.5 FCC Labeling ............................................................................................................................ 3 2.6 FCC / IC Antenna usage ........................................................................................................... 3 2.7 Mobile Exposure ...................................................................................................................... 3 2.8 FCC Modular approval configuration control ......................................................................... 3 2.9 FCC / IC Indoor Usage .............................................................................................................. 3 2.10 FCC Interim Solution to DFS band interference with Weather Radar .................................... 4 3 OEM Installation Instructions ........................................................................................................ 4 3.1 Mounting hardware ................................................................................................................ 4 4 OEM Operating Environment ......................................................................................................... 4 5 OEM Operating Instructions ........................................................................................................... 4 6 Compliance with country code requirements.......................................................................................5 SUMMIT SEMICONDUCTOR LLC 22867 NW Bennett Street, Suite 200 Hillsboro, OR 97124 USA Phone: 503 615‐7700 • Fax: 503 615‐4232 http://www.summitsemi.com 2 User Manual Regulatory Statements The United States Federal Communication Commission has established certain rules governing the use of electronic equipment, including the following required guidelines. 2.1 FCC / IC Identification Numbers United States FCC ID: UA9600 Industry Canada IC: 9129A‐600 2.2 FCC/ IC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. 2.3 FCC Changes Warning Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 2.4 FCC / IC Information to the user Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment can generate and radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. SUMMIT SEMICONDUCTOR LLC 22867 NW Bennett Street, Suite 200 Hillsboro, OR 97124 USA Phone: 503 615‐7700 • Fax: 503 615‐4232 http://www.summitsemi.com —Consult the dealer or an experienced radio/TV technician for help. Users should also be cautioned to take note that high-power radars are allocated as primary users (meaning they have priority) of the bands 5250-5350 MHz, 5500-5700 MHz, and these radars could cause interference and/or damage to WLAN devices. 2.5 FCC Labeling While the FCC user ID is placed on the slave device circuit board, compliant labeling shall also be placed on the end product housing exterior. 2.6 FCC / IC Antenna usage Antennas are required to be permanently attached or of non-standard connection method to prevent the end user from altering the installation’s performance. The installer shall be responsible for this. . CAUTION: DO NOT TRY TO REPLACE THE ANTENNAS 2.7 Mobile Exposure The user is cautioned to maintain 20cm (8 inch) spacing from the product to ensure compliance with FCC requirements. 2.8 FCC Modular approval configuration control Control of the end product into which the module will be installed must be maintained such that full compliance of the end product is always ensured. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. It is the responsibility of the OEM or module level customer to inst…

Text truncated - open the document above for the full version.

Attestation Statements

SUMMIT SEMICONDUCTOR LLC 22867 NW Bennett Street, Suite 200 Hillsboro, OR 97124 USA Phone: 503 615-7700 • Fax: 503 615-4232 http://www.summitsemi.com 25 June, 2013 Federal Communications Commission Authorization and Evaluation Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Application Examiner: We attest to the following the Athena4x product (model number 444-2224): • Per FCC KDB 443999 D01 v01 and RSS 210 Annex 9, this device will not transmit in the 5600 - 5650 MHz band. The device will not initiate any transmission without initiation by a master, and no compatible masters operate in that band. All compatible masters will support FCC KDB 443999 and RSS 210. • Per FCC KDB 848637, the device is a client device with no radar detection capability. The client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master. This includes restriction on transmissions for beacons and support for ad-hoc peer-to-peer modes. • Per FCC KDB 594280 D01 v01r02, the device complies with the requirements for software configuration control. The device meets the definition of FCC 15.202 client device and does not have the ability to be configured by end users or professional installers to operate outside the authorized bands • Per FCC 15.407(c), the device will automatically discontinue transmission in case of either absence of information to transmit or operational failure. Sincerely, James Svoboda Engineering Manager Summit Semiconductor LLC 22867 NW Bennett St., Suite 200 Hillsboro, OR 97124 Ph: 503 615-7734

Cover Letter(s)

WTD 13.4.9 FCC Compliance Opinion FOCU0141 Information about the Applicant Grantee (Company Name) Summit Semiconductor FCC Contact Person James Svoboda Address 22867 NW Bennett St, Suite 200 City, State, Zip Hillsboro, OR 97124 Job Number FOCU0141 Model 444-2224 FCC ID UA9600 Agent NA Approval Type Original Equipment Class DTS Digital Transmission System NII Unlicensed National Information Infrastructure Rule Part 15.247, 15.407 Overview The 444-2224 digital wireless audio client device is a turnkey solution that enables customers to start volume production of high performance Digital Wireless Audio speakers. The 444-2224 is designed to be integrated into an audio speaker providing high fidelity audio. It is an IEEE 802.11a compliant radio operating in UNII band and operates in accordance with the client mode as stated in the FCC 06-96. The digital wireless audio client device works as part of a system along with Summit Semiconductor’s master module with Model No.: 444-2216, FCC ID: UA9500. The master module is typically installed in a DVR, Blu-ray player or a gaming console and transmits digital audio wirelessly to the client device which is typically installed in an audio speaker. The 444-2224 is not compatible with any other device other than Summit Semiconductor’s Master Module. Confidentiality requested for allowed files. Request is properly addressed and referenced. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature Dave Tolman, TCB Committee 7/2/2013

Cover Letter(s)

SUMMIT SEMICONDUCTOR LLC 22867 NW Bennett Street, Suite 200 Hillsboro, OR 97124 USA Phone: 503 615-7700 • Fax: 503 615-4232 http://www.summitsemi.com 9 May, 2013 Federal Communications Commission Authorization and Evaluation Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Application Examiner: Summit Semiconductor LLC has designed and built a digital wireless audio client device. Summit Semiconductor requests FCC Equipment and Authorization branch to grant an original certification of a full modular approval for our wireless audio client device, Model No.: 444- 2224, FCC ID: UA9600. The 444-2224 digital wireless audio client device is a turnkey solution that enables customers to start volume production of high performance Digital Wireless Audio speakers. The 444-2224 is designed to be integrated into an audio speaker providing high fidelity audio. It is an IEEE 802.11a compliant radio operating in UNII band and operates in accordance with the client mode as stated in the FCC 06-96. The digital wireless audio client device works as part of a system along with Summit Semiconductor’s master module with Model No.: 444-2216, FCC ID: UA9500. The master module is typically installed in a DVR, Blu-ray player or a gaming console and transmits digital audio wirelessly to the client device which is typically installed in an audio speaker. The 444- 2224 is not compatible with any other device other than Summit Semiconductor’s Master Module. The 444-2224 digital wireless audio client device was tested at NWEMC’s Oregon facility for rule parts 15.247 and 15.407. The device was also tested for all the requirements necessary to certify it as a modular transmitter. The test set up photos and the technical test report has all the details about the performance and results of the device. The test reports are being submitted as part of the requirements and in support of the filing for original certification. Please address any correspondence regarding this filing to my attention at the following address. Summit Semiconductor LLC 22867 NW Bennett St., Suite 200 Hillsboro, OR 97124 Ph: 503 615-7734 Sincerely, James Svoboda Engineering Manager

Cover Letter(s)

SUMMIT SEMICONDUCTOR LLC 22867 NW Bennett Street, Suite 200 Hillsboro, OR 97124 USA Phone: 503 615-7700 • Fax: 503 615-4232 http://www.summitsemi.com May 9, 2013 Federal Communications Commission Authorization and Evaluation Branch 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for unlicensed Modular Transmitter Approval. Dear Application Examiner: Summit Semiconductor LLC hereby requests FCC Equipment Authorization and Evaluation branch to approve Summit Semiconductor’s Model 444-2224 Audio Wireless Client Module, FCC ID- UA9600 as having a full modular approval. The 444-2224 Audio Wireless Client Module is a production ready module designed for audio speakers in Summit Semiconductor’s high definition wireless audio solution. The module is designed to be mounted to the interior of the speaker cabinet. This letter addresses the information required by points one through eight of 47 CFR 15.212. 1. “The modular transmitter must have its own RF shielding .” The radio section of the module is enclosed within a RF shield. The RF shield is solder mounted to the exposed grounding of the circuit board. The point of contact between the shield and the board has multiple ground contacts. The internal photos exhibit has pictures of the wireless client device with and without the shield. The shield suppresses spurious radiations as per FCC requirements. 2. “The modular transmitter must have buffered modulation/data inputs.” The 444-2224 has buffered data inputs from an on-chip embedded processor. The purpose of this is to transmit control and status information back to the master device. This method insures compliance with Part 15 requirements under conditions of excessive data rates or over modulation. 3. “The modular transmitter must have its own power supply regulation .” The 444-2224 digital wireless client device receives power from an external +3.3 VDC supply via an industry standard power supply jack. The 3.3 volt DC is regulated to 1.2 and 2.8 volts VDC as well as it uses the 3.3 VDC directly. In order to comply with the requirement that all voltages be regulated, we have included an over voltage detection circuit which ceases RF transmission when the input voltage exceeds 3.6 VDC. Also, the technical report exhibit contains AC power line conducted emissions data taken with the EUT powered from a linear power supply that contains no EMC suppression components. 4. “The modular transmitter antenna must comply with the antenna and transmission system requirements of section 15.203, and 15.204(c).” The modular device complies with all FCC antenna requirements. The modular device is designed in such a way that the antenna is integrated with the modular device. As per the FCC 15.203 requirement, this can be considered as permanently attached and doesn’t give the user any option to replace it. A list of usable antennas is not provided since the user manual clearly instructs the user that the modular device is compatible with only the integrated antennas. Please see the internal exhibit photos for further details. The antenna report also provides a description as to how the modular device complies with the de facto EIRP limit. 5. “The modular transmitter must be tested in a stand-alone configuration .” As described in the technical report exhibit and the test set up photos of the test report included in the filing for FCC equipment authorization, the 444-2224 digital wireless client device module was tested as a stand- alone device. The 444-2224 is designed with an industry standard 40 pin multi pin flex cable and it is greater than 10 cm from the host device. 6. “The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying the FCC identification number.” A FCC ID and model number is labeled on every modular device. FCC ID label and location exhibit has a photograph which shows the exact location of the label. Since the FCC ID number will not be visible when the module is installed inside the audio speaker, another label with the same FCC ID will be applied to the exterior of the speaker. 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT complies with all specific rules such as modulation scheme, modulation type, bandwidth, antenna requirements, power supply regulation, and suppression of spurious emissions and so on. A detailed user manual is provided with every EUT which instructs the user to maintain compliance as per the requirements of the Commission. The manual also cautions the user not to make any changes or modifications not approved by the party responsible for compliance. Please see the operating description exhibit for further details to understand how the EUT complies with specific rules and operating requirements as per FCC. 8. “The modular transmitter must comply with any applicable RF exposure requirements in its final configuration.” The EUT is compliant with all applicable RF exposure requirements and EUT is operated in a manner that ensures the public is not exposed to radio frequency in excess of Federal Communication Commission’s guidelines. Please see the RF exposure exhibit. Best Regards James Svoboda Engineering Manager

Cover Letter(s)

SUMMIT SEMICONDUCTOR LLC 22867 NW Bennett Street, Suite 200 Hillsboro, OR 97124 USA Phone: 503 615-7700 • Fax: 503 615-4232 http://www.summitsemi.com Request for Confidentiality 9 May, 2013 Federal Communications Commission Authorization and Evaluation Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Summit Semiconductor Certification Application FCC ID: UA9600 To Whom It May Concern: A portion of the data contained in this application is to be considered a trade secret and not to be made routinely available to the public. If such information were to be made public, it might be used to the disadvantage of Summit Semiconductor LLC (the applicant) in the market place. Therefore, pursuant to 47 CFR 0.459 and 47 CFR 0.457(d) of the FCC Rules, we request that the information listed below be withheld from public inspection: Schematics Frequency Block Diagrams Operational Description Thank you for your attention to this matter. Sincerely, James Svoboda Engineering Manager

External Photos

ID Label/Location Info

Internal Photos

Operational Description

SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2224 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC SUMMIT SEMICONDUCTOR LLC Model No.: 444-2224 FCCID: UA9600 ANTENNA INFORMATION SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2224 2 of 5 22867 NW Bennett St., Suite 200 www.summitsemi.com The 444-2224 Digital Wireless Audio Client Device includes a low-cost, integrated quad diversity Inverted F - PCB antenna, meaning no unsightly external antennas or tuning of RF application circuits are required. This ensures unique coupling between the antenna and the intentional radiator. The user manual clearly cautions the user not to try to replace the antennas and the modular device is compatible with only the integrated antennas. Hence a list of usable antennas is not furnished to the user. Also, there are no specific controls available to the user that changes the performance of the antenna. The maximum gain for the wireless audio client device at 5500 and is 4.0dBi. Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2224 3 of 5 22867 NW Bennett St., Suite 200 www.summitsemi.com Antenna 2 Antenna 1 Antenna 3 Antenna 4 Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2224 4 of 5 22867 NW Bennett St., Suite 200 www.summitsemi.com NORTHWEST EMC EUT: Ice axe antenna _ Riddle BoardWork Order: FOCU0113 Serial Number: A1 ModDate : Customer: Summit SemiconductorTemperature: 23.4 °C Atte nde es: Ponna ppa PasuraHumidity: 41% Proje ct: NoneBarometric Pres.: 1019.3 mb Tested by: Rod PeloquinPower: N/AJob Site: EV01 TEST SPECIFICATIONS Test Method TEST PARAMETERS Ante nna He ight(s) (m)Te st Dista nce (m) 3 COMMENTS EUT OPERATING MODES DEVIATIONS FROM TEST STANDARD Run # Configuration # Re sults Signature 0.00 270.00 180.00 90.00 Frequency5500.00 Absolute Gain of Reference Antenna (dBi)10.30 Reference Antenna Relative Gain Max (dBuV/m)99.70 AUT Relative Gain Max (dBuV/m)93.40 Difference (Reference Antenna - AUT) (dB)6.30 AUT Setup Loss (dB)0.00 Ma x imum Absolute Ga in of AUT (dBi)4.00 Average ABS Gain (dBi)-3.87 Correction Factor (Convert From Relative to Absolute Gain) (dB)89.40 Measurement Antenna Polarity Horizontal Antenna Under Test (AUT) Polarity Horizontal ABSOLUTE GAIN DATA SHEET 5 1 None +10dBm output, 6dB attenuator at the end of NWEMC feed cable 08/17/11 0.00 270.0 0 180.0 0 90.00 -45.0 -35.0 -25.0 -15.0 -5.0 5.0 Absolute Ga in of AUT 90° 270° 180° 0° Antenna Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC SUMMIT SEMICONDUCTOR LLC AUDIO WIRELESS CLIENT DEVICE Model No. 444-2224 5 of 5 22867 NW Bennett St., Suite 200 www.summitsemi.com Hillsboro, OR 97124 TEL (503) 615 7734 FAX: (503) 615 4432 © 2010 Summit Semiconductor LLC

RF Exposure Info

Summit Semiconductor LLC 444-2224 Report No. FOCU0141.6 Report Prepared By Northwest EMC Inc. NORTHWEST EMC – (888) 364-2378 – www.nwemc.com California – Minnesota – Oregon – New York – Washington 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Certificate of Evaluation Date of Evaluation: May 16, 2013 Summit Semiconductor LLC Model: 444-2224 Emissions Description of Evaluation Specification Evaluation Method Pass/Fail Maximum Permissible Exposure FCC 2.1091:2013 OET Bulletin 65, Supplement C Ed 01-01 Pass Approved By: Don Facteau, IS Manager NVLAP Lab Code: 200630-0 This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. Report No. FOCU0141.62/9 REV 2012.08.02 REVISION HISTORY Revision Number Description Date Page Number 00 None Barometric Pressure The recorded barometric pressure has been normalized to sea level. Report No. FOCU0141.63/9 REV 2012.05.24 ACCREDITATIONS AND AUTHORIZATIONS United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC Guide 65 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea KCC / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Hong Kong OFTA – Recognized by OFTA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. Russia GOST – Accredited by Certinform VNIINMASH, CERTINFO, SAMTES, and Federal CHEC to perform EMC and Hygienic testing for Information Technology products to GOST standards. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ Report No. FOCU0141.64/9 REV 2013.02.26 LOCATIONS Oregon Labs EV01-12 22975 NW Evergreen Pkwy Hillsboro, OR 97124 (503) 844-4066 California Labs OC01-13 41 Tesla Irvine, CA 92618 (949) 861-8918 New York Labs NY01-04 4939 Jordan Rd. Elbridge, NY 13060 (315) 685-0796 Minnesota Labs MN01-08 9349 W Broadway Ave. Brooklyn Park, MN 55445 (763) 425-2281 Washington Labs NC01-05,SU02,SU07 19201 120 th Ave. NE Bothell, WA 98011 (425) 984-6600 VCCI A-0108 A-0029 A-0109 A-0110 Industry Canada 2834D-1, 2834D-2 2834B-1, 2834B-2, 2834B-3 2834E-1 2834C-1 NVLAP NVLAP Lab Code: 200630-0 NVLAP Lab Code: 200676-0 NVLAP Lab Code: 200761-0 NVLAP Lab Code: 200881-0 NVLAP Lab Code: 200629-0 Report No. FOCU0141.65/9 Product Description Revision 09/01/11 Client and Equipment Under Test (EUT) Information Company Name: Summit Semiconductor Address: 22867 NW Bennett St, Suite 200 City, State, Zip: Hillsboro, OR 97124 Test Requested By: Ponnappa Pasura Model: 444-2224 Date of Evaluation: May 15, 2013 Information Provided by the Party Requesting the Test Functional Description of the EUT (Equipment Under Test): The EUT is a digital wireless audio client device which utilizes a UNII radio module. Objective: To demonstrate compliance with FCC requirements for RF exposure for 2.1091 mobile devices Report No. FOCU0141.66/9 WD.12.29.11 Maximum Permissible Exposure (MPE) OVERVIEW Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. ANSI C95.1-1992 specifies a minimum separation distance of 20 cm for performing reliable field measurements to determine adherence to MPE limits. If the minimum separation distance between a transmitter and nearby persons is more than 20 cm under normal operating conditions, compliance with MPE limits may be determined at such distance from the transmitter. When applicable, operation instructions and prominent warning labels may be used to alert the exposed persons to maintain a specified distance from the transmitter or to limit their exposure durations and usage conditions to ensure compliance. If the use of warning labels on a transmitter is not effective or desirable, the alternative of performing SAR evaluation with the device at its closest range to persons under normal operating conditions may be used. The field strength and power density limits adopted by the FCC are based on whole-body averaged exposure and the assumption of RF field levels relate most accurately to estimating whole-body averaged SAR. This means some local values of exposures exceeding the stated field strength and power density limits may not necessarily imply non-compliance if the spatial average of spatially averaged RF fi…

Text truncated - open the document above for the full version.

Test Report

DFS PORTION OF FCC CFR47 PART 15 SUBPART E DFS PORTION OF INDUSTRY CANADA RSS-210 ISSUE 8 CERTIFICATION TEST REPORT FOR DIGITAL WIRELESS AUDIO CLIENT DEVICE (ATHENA 4X and ATHENA UFL) MODEL NUMBER: 444-2224 and 444-2225 FCC ID: UA9600 AND UA9700 IC: 9129A-600 and 9129A-700 REPORT NUMBER: 13U15005-4 ISSUE DATE: JUNE 28, 2013 Prepared for SUMMIT SEMICONDUCTOR LLC 22867 NW BENNETT ST. SUITE 200 HILLSBORO, OREGON 97124, U.S.A. Prepared by UL VERIFICATION SERVICES INC. 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 66…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Ken N Boehlke(Engineering Manager)

[email protected]503-615-7727Fax: 503-615-4232

Test Firm

Northwest EMC, Inc.Greg Kiemel

[email protected]503-844-4066Fax: 503-844-3826

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	5.75 GHz - 5.83 GHz	20.10 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Output power is conducted. Client device per section 15.202 definition. Operation of this device in the 5150 MHz to 5250 MHz range is restricted to indoor use only. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operating conditions for satisfying RF exposure compliance.
