UG9UBHS-PH2BLUETOOTH STEREO HEADSET

Cautionary Notice _03Package Content _04Wearing the Headset _04Features _05Storing the Headset _06Turning the Headset On/Off _06Charging the Headset _07Pairing _08Connecting the Headset _09Multi Pairing _10Making Phone Calls _11Listening to Music _123D Sound _13IMOD display messages _14Troubleshooting _16Headset Specification _17Warranty Statement _19 Do not put the headset near a fire to avoid danger of explosion.Do not drop or apply excessive force to the headset. It may cause damage.In case of malfunction, do not attempt to repair. Please contact the nearest service center or the place of purchase immediately.If the headset gets wet, avoid any heat or electrical current, and contact the nearest service center or the place of purchase immediately.Keep out of children's reach.Do not use chemical products (example: Bleach) to clean the product.Do not use any unauthorized charging device.When storing the product for an extended period of time, store in a dry place and avoid extreme temperatures.In order to avoid any danger caused by radio interference, do not use the headset where its use is forbidden.Your battery and the mobile device may require recycling in accordance with the local laws. Please contact your local authorities for more information.Do not discard your battery or mobile device in the trash.If you use any medical device (pacemaker, hearing aids etc...), please consult your medical device manufacturer to make sure that the correct functioning of your medical device is not affected by RF energy emitted by the Bluetooth Headset. Your doctor may be able to assist you in obtaining this information.Our product satisfies Bluetooth Core Specification Version 2.0. Some Bluetooth devices may not be compatible with the headset. For further information about compatibility, please contact the concerned manufacturer, or our customer service center.Using the headset at full volume may damage your hearing.Strong static electricity may damage the product. Please use your caution when operating the headset.Modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 1.2.3.4.5.6.7.8.9. 10. 11. 12.13.14.15.16. 1. Manufacturers, retailers, agencies are not responsible for any bodily harm, intentional damages and damages caused by the user's lack of care.2. This user manual was written based on present product specification.3. All specification may be modified without prior notice. Table of Contents Cautionary NoticeCompany's Indemnification

801, Ssanglim Bldg, 151-11, Ssanglim-dong, Chung-gu Seoul, Korea 100-400 TEL No : +82-2-6320-0190 FAX No : +82-2-6320-0198 November 8, 2007 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : Ubixon Co., Ltd. FCC ID : UG9UBHS-PH2 Request for Confidentiality Gentlemen: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics (File name: [UG9UBHS-PH2] SCH.pdf), Parts list(File name: [UG9UBHS-PH2] PL.pdf), Block diagram (File name: [UG9UBHS-PH2] BLK.pdf), and Operational description (File name: [UG9UBHS-PH2] Op Des.pdf). The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Hyoung-ho Kim General Manager

Model No.: UBHS-PH2 FCC ID: UG9UBHS-PH2 Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 3 Model No.: UBHS-PH2 FCC ID: UG9UBHS-PH2 Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 3 Model No.: UBHS-PH2 FCC ID: UG9UBHS-PH2 Copyright ○ c 2007, LTA Co., Ltd. Page 3 of 3

FCC ID: UBHS-PH2 Copyright Ⓒ 2007, LTA Co., Ltd. SAMPLE LABEL & LOCATION Note: 1. Because The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual. UBHS-PH2 FCC ID: UG9UBHS-PH2 LUBIX Made in Korea

Model No.: UBHS-PH2 FCC ID: UG9UBHS-PH2 Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 3 Model No.: UBHS-PH2 FCC ID: UG9UBHS-PH2 Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 3 Model No.: UBHS-PH2 FCC ID: UG9UBHS-PH2 Copyright ○ c 2007, LTA Co., Ltd. Page 3 of 3

Ref. No.: LR500190711A Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 29 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: Nov. 02 ~ 08, 2007 Test Report S/N: LR500190711A Test Site : LTA CO., LTD. CERTIFICATION OF COMPLIANCE FCC ID. APPLICANT FCC Classification : FHSS Sequence Spread Spectrum (FHSS) Manufacturing Description : Bluetooth Stereo Headset Manufacturer List : Ubixon Co., Ltd. Model name : UBHS-PH2 Test Device Serial No.: : Identical prototype Rule Part(s) : FCC Part 15.247 Subpart C; ANSI C-63.4-2003 Frequency Range : 2402 ~ 2480MHz RF power Class : 2 (-6dBm ~ +4dBm) Data of issue : November 08, 2007 This test report is issued under the authority of: The test was supervised by: Dong –Min JUNG, Technical Manager Kyung-Taek LEE, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. This report must not be used by the applicant to claim product endorsement by any agency. NVLAP LAB Code.: 200723-0 UG9UBHS-PH2 Ubixon Co., Ltd. Ref. No.: LR500190711A Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 29 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TECHNICAL CHARACTERISTICS TEST ------------------------------------------------------- 3.2.1 CARRIER FREQUENCY SEPARATION ---------------------------------------------------- 3.2.2 NUMBER OF HOPPING FREQUENCIES -------------------------------------------------- 3.2.3 20 dB BANDWIDTH ---------------------------------------------------------------------------- 3.2.4 TIME OF OCCUPANCY (Dwell Time) ------------------------------------------------------- 3.2.5 TTANSMITTER OUTPUT POWER ---------------------------------------------------------- 3.2.6 BAND – EDGE ----------------------------------------------------------------------------------- 3.2.7 FIELD STRENGTH OF HARMONICS ------------------------------------------------------ 3.2.8 AC CONDUCTED EMISSIONS -------------------------------------------------------------- APPENDIX APPENDIX TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 8 11 13 15 17 22 25 28 Ref. No.: LR500190711A Copyright ○ c 2007, LTA Co., Ltd. Page 3 of 29 1. General information’s 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2008-09-30 ECT accredited Lab. RRL KOREA KR0049 2009-06-20 EMC accredited Lab. FCC U.S.A 610755 2008-03-28 FCC filing VCCI JAPAN R2133, C2307 2008-06-22 VCCI registration IC CANADA IC5799 2008-04-23 IC filing Ref. No.: LR500190711A Copyright ○ c 2007, LTA Co., Ltd. Page 4 of 29 2. Information’s about test item 2-1 Applicant & Manufacturer Company name : Ubixon Co., Ltd. Address : 801, Ssanglim Bldg, 151-11, Ssanglim-dong, Chung-gu Seoul, Korea 100-400 Tel / Fax : +82-2-6320-0190 / +82-2-6320-0198 2-2 Equipment Under Test (EUT) Trade name : Bluetooth Stereo Headset FCC ID : UG9UBHS-PH2 Model name : UBHS-PH2 Serial number : Identical prototype Date of receipt : November 2, 2007 EUT condition : Pre-production, not damaged Antenna type : PCB Pattern antenna Max. Gain: 0.65dBi Frequency Range : 2402 ~ 2480MHz RF output power Range : -6dBm~+4dBm (Class 2) Number of channels : 79 Channel spacing : 1MHz Channel Access Protocol : Frequency Hopping Type of Modulation : GFSK Power Source : 3.7V (Li-Polymer Rechargeable) (Recharging – by USB Cable) 2-3 Tested frequency LOW MID HIGH Frequency (MHz) 2402 2441 2480 2-4 Ancillary Equipment – Bluetooth Equipment Model No. Serial No. Manufacturer earphone N/A N/A N/A - - - - 2-5 Ancillary Equipment – Bluetooth + Charging mode Equipment Model No. Serial No. Manufacturer PC dx2200Microtower CNG6500RX9 HP Monitor VS11353 E060T4021/1-1 View Sonic Keyboard SK-8115 641-OEWW DELL Mouse MO56UO 510022473 DELL Print Deskjet 600K SG7631B1XX HP earphone N/A N/A N/A - - - - Ref. No.: LR500190711A Copyright ○ c 2007, LTA Co., Ltd. Page 5 of 29 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) 15.247(a) Carrier Frequency Separation > 25 kHz C 15.247(a) Number of Hopping Frequencies > 75 hops C 15.247(a) 20 dB Bandwidth - C 15.247 Dwell Time < 0.4 seconds C 15.247(b) Transmitter Output Power < 1Watt C 15.247(d) Conducted Spurious emission > 20 dBc C 15.247(d) Band Edge > 20 dBc Conducted C 15.249 / 15.209 Field Strength of Harmonics < 54 dBuV (at 3m) C 15.109 Field Strength - Radiated C 15.207 /15.107 AC Conducted Emissions EN 55022 Line Conducted C 15.203 Antenna requirement - - C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: The data in this test report are traceable to the national or international standards. The sample was tested according to the following specification: FCC Parts 15.247; ANSI C-63.4-2003 Æ Antenna Requirement The Ubixon co.,ltd. UBHS-PH1 unit complies with the requirement of §15.203. The antenna is PCB Pattern antenna. Ref. No.: LR500190711A Copyright ○ c 2007, LTA Co., Ltd. Page 6 of 29 3.2 Transmitter requirements 3.2.1 Carrier Frequency Separation Proc…
