UK4JTBT2100Vehicle driving logs tracker

von-STD Manual Instruction Cautions For Safety We kindly recommend you to be fully aware of using a product ac curately and for safety of user. All liabilities by uncomplying cautions are not supposed to be responsible to man ufacturer. 1 This product into water or prolonged exposure to moisture can cause failu re resulting in no charge for broken A/S 1 . This product into water or prolonged exposure to moisture can cause failure resulting in no charge for broken A/S . 2. Do not disassemble or repair this product if the label seal is broken or damaged, free A/S will not be received. 3. Do not separate or equip OBD II module while driving vehicle or ignition off. – This causes to car accident and defective of it. 4. Please note that on the surface of the product carefully to avoid strong detergent or chemicals. 5. This product works under the proper temperature -30~+80°C.6. Do not impact the product. It’s the cause of product defecti ve. 7. Using other products rated vol tage is the cause of the crush . Rated voltage state must be sure to use the product. 8. After parking vehicle in a safe place, install OBD II module then drive. 9. When installing or removing product on the vehicle as the ve hicle peripheral device could be due to injury, Please be caref ul. 10. Incorrect installation of the product by the vehicle’s shoc k and vibration and can cause data loss, after the installation , please check it properly. 11. Products by shock or vibration of the vehicle is released from the car be cause it can cause data loss if the installation st atus checks 11. Products by shock or vibration of the vehicle is released from the car because it can cause data loss if the installation st atus checks on a regular basis. This produc t is equipped with a breakdown o f the car by the impact of accide nts, damage, of driving record , we are not responsible for missing. 12. Jastec Co.,Ltd provides cable, please use the original cabl e. This confidential information is not supposed to disclosed and misused to the third party 2 1. von-STD Descriptions 1.1 Overview V STD hil dii l t k d i dt ll t hil dii if ti f ECU(El t i C t lUit) V on- STD as ve hi c l e d r i v i ng l ogs t rac k er d es i gne d t o co ll ec t a ve hi c l e d r i v i ng i n f orma ti on f rom ECU(El ec t ron i c C on t ro l U n it) By OBD standard protocol communication and can be saved a drivi ng logs by connecting to PC. This confidential information is not supposed to disclosed and misused to the third party 3 1. von-STD Descriptions 1.2 Specifications In-vehicle Protocol ISO 9141-2, ISO 14230-4(KWP-2000), ISO15765-4(CAN) J1850(PVM/VPW) pro tocol supported, physical communication standard followed and high credibility being wit h vehicle DB. 32 bit main processor Boasting fast and stable performance ARMv7 Corte x-M3 CPU has adopted. Stability real-time operating system System,hardware,applications,databases,data communications and oth er resources efficiently and reliably manages the real-time operating system is used based on Tiny. USB communication USB Full-Speed (12Mbps) high data transmitter functi on supported. Low power consumption and saving Standby power consumption in driving conditions with low start-off when t he vehicle’s power- saving features built in to prevent battery discharge. Fi d t t Firmware and vehicle DB p ro g ram to communicate with a PC via USB connection to u pg rade is Fi rmware up d a t e suppor t pg pg easy and fast.. Mass storage space Large amounts of information and operating data in real time on a high-capa city memory and high data reliability by applying non-volatile memory can be saved. Data communication High-speed communications, the processor transfer, processing speed an dlargememorycapacity b bi i ft h hi l dii d dt i l ti d t ii i th b ycom bi n i ng f ea t ures suc h as ve hi c l e d r i v i ng recor d d a t a i nrea l ti me an d t om i n i m i ze th e error. Smart design Due to small and light for easy installation and occupies less space, it doe sn’t interfere with the operation easier you can determine. This confidential information is not supposed to disclosed and misused to the third party 4 1. von-STD Descriptions 13 Functions1 . 3 Functions Saving vehicle information.Collecting and saving driving logs information. Driving logs record Vehicle identification information / module certification / module seri al number information / driving data starting time and ending time / ignition On and Off time /Accumulated driving distance / module connection and disconnection time / driving information transmitting time / acceleration pedal or throttle valve open angle Module operating check and alarm Display [indicator] : power display lamp[POWER –blue] / status display la mp[STATUS -red] Driving information security Encoded saving data to not modify a driving recorded information. Dii if ti l d USB titt fd D r i v i ng i n f orma ti on up l oa d USB t ransm itt er pre f erre d . Power saving function Automatically power will be off when ignition off. Self diagnostic Su pp ortin g self dia g nostic function throu g hOBDIImoduleo p eratin g check ( Indicator ) . Self diagnostic pp g g g pg () Firmware upgrade support Supporting firmware upgrade This confidential information is not supposed to disclosed and misused to the third party 5 1. von-STD Descriptions 1.4 Specification Specification CPU 32 bi ARM 7 C M 3 External interface specification USB 1 1 ( 2 0 Cibl) CPU 32 bi t ARM v 7 C ortex- M 3 Memory 4 MB Internal Flash Memory LED Display LED USB USB 1 . 1 ( 2 . 0 C ompat ibl e ) VCP(Virtual COM Port) Supported Bluetooth (JTBT 1100 ) Bluetooth v2.0 Class 12.4GHz ISM bandF 2 400 2 483 5 MH Vehicle protocol CAN[Control Area Network]: ISO 11898 /ISO 9141-2 / ISO 14230 [KWP 2000] /SAE J1850 (PWM / VPW) Connector type SAE J1962 OBD-II 16Pin Standard Connector (JTBT 1100 ) F requency range: 2 , 400 ~ 2 , 483 . 5 MH z Data Rates: 1 Mbps Bluetooth ( JTBT 2100 ) Bluetooth v3.0 Class 22.4GHz ISM bandF 2 …

Text truncated - open the document above for the full version.

Date: October 4, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Lab Manager Charles. Kim (or Feel. Jeong) and of SGS Korea Co., Ltdand hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Charles. Kim (or Feel. Jeong) of SGS Korea Co., Ltdon our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a)comply with the relevant provisions of the certification program; b)make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c)make claims regarding certification only in respect of the scope for which certification has been granted; d)do not use our product certification in such a manner as to bring the Certification Division into disrepute andnot make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e)upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f)use certification only to indicate the products are certified as being in conformity with specified standards; g)endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h)ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i)keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j)take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k)document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Manager Jastec Co., Ltd.

Jastec Co., Ltd. Jastec B/D, 92-7, Kumgok-Dong, Boondang-Gu, Seongnam-Si, Kyunggi-Do Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) and 0.459 pertaining to confidential material. We, Jastec Co., Ltd.would like the following documents regarding this submission for FCC ID: We are also hereby request Short­Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04­1705. This provision will give Jastec Co., Ltd temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: UK4JTBT2100to be kept confidential. 1 Block Diagram 2 Operational Descriptions Permanent 3 Schematics 4 External Photos 5 Internal Photos 6 Test-Setup Photos Short-Term 7 User’s Manual The above material contains trade secrets or technical data, which would customarily be guarded fromcompetitors.We do not want these documents to be accessible to the general public. Sincerely, Manager Jastec Co., Ltd.

Model :JTBT2100 External photos of EUT Model :JTBT2100 Front view of EUT Rear view of EUT Model :JTBT2100 Top view of EUT Bottom view of EUT Model :JTBT2100 Side view of EUT

FCC Label 1.FCC Label Drawing 2.FCC Label Location Jastec Co., Ltd. Model : JTBT2100 FCC ID : UK4JTBT2100 This device complies with part 15 of the FCC Rules. Operation is subject to The following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Made in Korea

Model :JTBT2100 Internal photos of EUT Model :JTBT2100 Internal view of EUT Model :JTBT2100 Top view of PCB1 Bottom view of PCB1 Antenna Model :JTBT2100 Top view of PCB2 Bottom view of PCB2 Model :JTBT2100 Top view of PCB3 Bottom view of PCB3

Report Number: F690501/RF-RTL005027 Page: 2 of 47 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.kr.sgs.com/ee INDEX Table of Contents Page 1. General Information --------------------------------------------------------------------------------- 3 2. Transmitter Radiated Spurious Emissions and Conducted Spurious Emission ------ 8 3. 20㏈ Bandwidth ------------------------------------------------------------------------------------- 24 4. Maximum Peak Output Power ------------------------------------------------------------------- 29 5. Hopping Channel Separation --------------------------------------------------------------------- 31 6. Number of Hopping Frequency ------------------------------------------------------------------ 34 7. Time of Occupancy(Dwell Time) ----------------------------------------------------------------- 38 8. Antenna Requirement ------------------------------------------------------------------------------ 45 9. RF Exposure evaluation -------------------------------------------------------------------------- 46 Report Number: F690501/RF-RTL005027 Page: 3 of 47 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.kr.sgs.com/ee 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. - 413-15, Gomae-Dong Giheung-Gu, Yongin-Si, Gyeonggi-Do, South Korea. - Wireless Div. 2FL, 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea 435-040 www.kr.sgs.com/ee Telephone : +82 +31 428 5700 FAX : +82 +31 427 2371 1.2. Details of Applicant Applicant : JASTEC CO., LTD. Address : 92-7, Kumgok-dong, Boondang-gu, Seongnam-si, Gyeonggi-do, Korea Contact Person : Park, Chul-Hong Phone No. : +82 +70 7606 1694 1.3. Description of EUT Kind of Product Vehicle driving logs tracker Model Name JTBT2100 Serial Number N / A Power Supply DC 12 V(Vehicle Bettary) Frequency Range 2 402 ~ 2 480 ㎒ Modulation Technique GFSK, π/4DQPSK, 8DPSK Number of Channels 79 Antenna Type Chip Antenna Antenna Gain 2.41 ㏈i Report Number: F690501/RF-RTL005027 Page: 4 of 47 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.kr.sgs.com/ee 1.5. Information about the FHSS characteristics: 1.5.1. Pseudorandom Frequency Hopping Sequence The channel is represented by a pseudo-random hopping sequence hopping through the 79 RF channels. The hopping sequence is unique for the piconet and is determined by the Bluetooth device address of the master; the phase in the hopping sequence is determined by the Bluetooth clock of the master. The channel is divided into time slots where each slot corresponds to an RF hop frequency. Consecutive hops correspond to different RF hop frequencies. The nominal hop rate is 1 600 hops/s. 1.5.2. Equal Hopping Frequency Use All Bluetooth units participating in the piconet are time and hop-synchronized to the channel. 1.5.3. System Receiver Input Bandwidth Each channel bandwidth is 1㎒ Report Number: F690501/RF-RTL005027 Page: 5 of 47 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.kr.sgs.com/ee 1.6. Test Equipment List Equipment Manufacturer Model Serial Number Cal Due. Signal Generator R & S SMR40 100272 Jul. 15, 2012 Signal Generator Agilent 8648D 3847M00534 Apr. 01, 2012 Spectrum Analyzer R & S FSV30 100955 Apr. 01, 2012 Power Sensor R & S NRP-Z81 101341 Sep. 29, 2012 Bluetooth Tester TESCOM TC-3000C 3000C000296 Aug. 22, 2012 Low Pass Filter Minicircuits NLP-1200+ V9500401023-3 Aug. 22, 2012 High Pass Filter Wainwright WHKX3.0/18G-6SS 4 Sep. 14, 2012 High Pass Filter Wainwright WHNX7.5/26.5G-6SS 11 Sep. 15, 2012 DC power Supply Agilent U8002A MY48490027 Jan. 05, 2012 Preamplifier H.P. 8447D 1726A01265 Sep. 27, 2012 Preamplifier R & S SCU-18 10070 Aug. 09, 2012 Preamplifier SCHWARZBECK MESSELEKTRONIK JS44-18004000-35-8P1546891 Jul. 04, 2012 Test Receiver R & S ESU40 100075 Feb. 13, 2012 Bilog Antenna SCHWARZBECK MESSELEKTRONIK VULB9163 9163-437 Aug. 02, 2012 Horn Antenna R & S HF907 100208 Jun. 08, 2012 Horn Antenna SCHWARZBECK MESSELEKTRONIK BBHA9170 BBHA9170431 Mar. 17, 2012 Antenna Master INNCO MA4000-EP N/A N.C.R. Turn Table INNCO DT-3000S N/A N.C.R. Anechoic Chamber SY Corporation L × W × H (21.5 m × 13.0 m × 9.0 m) N/A N.C.R. Report Number: F690501/RF-RTL005027 Page: 6 of 47 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.kr.sgs.com/ee 1.7. Summary of Test Results The EUT has been tested according to the following specifications: APPLIED STANDARD:FCC Part15, RSS-210,RSS-Gen Section in FCC 15 Test Item Result 15.205(a) 15.209 15.247(d) Transmitter Radiated Spurious Emissions Conducted Spurious Emission Complied 15.109(a) Rec…

Text truncated - open the document above for the full version.

Test setup photo of EUT Photo of Spurious Emission Test
