1 / 17 [GRAND MATE] Version: D07.1 at October 19 th , 2022 GM9K SERIES (INCLUDING GM9K1 / GM9K2 / GM9K3): GAS FIRED CONTROL SYSTEM USER MANUAL -FOR OEM USE ONLY FEATURES Fire or explosion hazard. Attempted disassembly or repair of controls can cause property damage, severe injury or death. Do not disassemble the gas valve; it contains no serviceable components. Read these instructions carefully. Failure to follow them could result in a fire or explosion causing property damage, personal injury, or loss of life. The product must be installed and operated according to all local regulations. A.BEFORE OPERATING verify that no gas is in the area around the appliance, including near the floor. WHAT TO DO IF YOU SMELL GAS: ■Do not light any appliance. ■Do not touch any electrical switch; do not use any phone in your building. ■Immediately call the gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. ■If you cannot reach the gas supplier, call the fire department. B.Use only your hand to push in or turn the gas control knobs. Never use tools. If a knob will not push in or turn by hand, don’t try to repair it, call a qualified service technician. Force or attempted repair may result in a fire or explosion. C.Do not use this control or any gas appliance if any part has been under water or in contact with water. Immediately call a qualified service technician to replace the control system and any gas control system which has been under water or in contact with water. D.These instructions are to be referenced as a user guide, and do not supersede appliance manufac- turer’s lighting instructions. APPLICATION GM9K series is an electronic ignition control module for gas appliances with pilot burners, ODS systems, remote function, second burner and extra AC/DC output. Control module is a combination of control board and power board. GENERAL NOTES Multiple Remote Control Solutions: ■GM9K1 for Unidirectional RF (434 MHz) ■GM9K2 for Bidirectional RF (434 MHz) (Support RevoHome SYS.) ■GM9K3 for Bluetooth This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Primary source(AC): An AC Main Adapter may be used instead of batteries. (AC source according to CSA and CE.) Secondary source(DC): ■4 x 1.5V “AA” Batteries. (quality alkaline recommended) ■AC to DC 6.5V 1.5A adapter. NOTE: ■Power board needed AC power to perform all functions, while AC power lost, power board function may lost simultaneously. ■Electronic ignition control system ■Ignition by supervised gas-fire pilot burner ■Support pilot flame sensing: •Ionization flame detection •Thermpcouple flame detection ■Max 9 hours idle auto shutdown ■Manual control and Remote control ■Flame height adjustment ■Flexible combination of AC/DC output to control FAN, LIGHT, AUX ■Second burner control ■Thermostat function H13 2 / 17 GM9K SERIES (INCLUDE GM9K1 / GM9K2 / GM9K3) USER MANUAL - FOR OEM USE ONLY H13 [GRAND MATE] Version: D07.1 at October 19 th , 2022 SYSTEM WIRING DIAGRAM NOTE: “The pilot valve flame power must be limited to 250 Thermal Watt” This is mandatory to avoid the test to the pilot valve as safety relevant valve. AC to DC 6.5V Adapter Second Burn er Valve Wires Load 3 Load 2 Load 1 CON3 CON2 CON1 Appliance Grou nd Power in GM9K Series System Wiring Diagram for Flame Ionization Sensor Load s definition please see co mb inatio n diagram S Pilot I Main Wires Batteries Pack (6V) Appliance Grou nd V1V2 Stepper Moto r Gas Valve ON/OFF/REMOTE SWITCH I O II AA/1 .5V AA/1 .5V AA/1 .5V AA/1 .5V External Learn Butto n V Second Burn er Valve AC Power Cord V1 = Pilot Valve V2 = Main Valve Internal Learn Button LPG / NAT Figure 1: GM9K Series system wiring diagram for ionization sensor External Learn Butto n Second Burn er Valve Wires Load 3 Load 2 Load 1 CON3 CON2 CON1 Appliance Grou nd Power in GM9K Series System Wiring Diagram for Thermocouple Sensor AC to DC 6.5V Ad apter Load s definition please see co mb inatio n diagram TC Module S I Pilot (Thermocouple, TC ) TC TC Module Wires Main Wires Batteries Pack (6V) Appliance Grou nd V1V2 Stepper Moto r Gas Valve ON/OFF/REMOTE SWITCH AA/1 .5V AA/1 .5V AA/1 .5V AA/1 .5V V Second Burn er Valve AC Power Cord I O II Optional V1 = Pilot Valve V2 = Main Valve Internal Learn Button LPG / NAT Figure 2: GM9K Series system wiring diagram for thermocouple sensor\ 3 / 17 GM9K SERIES (INCLUDE GM9K1 / GM9K2 / GM9K3) USER MANUAL - FOR OEM USE ONLY H13 [GRAND MATE] Version: D07.1 at October 19 th , 2022 ` CONTROL BOARD AND POWER BOARD CONNECTION DIAGRAM Bo ard to board wire Connection of wire to board(W to B) Connection of board to board(B to B) Label Size: 100 x 40 mm Label Size: 54 x 26 mm Label Size: 75 x 60 mm Figure 3: GM9K Series connection diagram of control board and power board 4 / 17 GM9K SERIES (INCLUDE GM9K1 / GM9K2 / GM9K3) USER MANUAL - FOR OEM USE ONLY H13 [GRAND MATE] Version: D07.1 at October 19 th , 2022 Table 1 and table 2 are optional features list of control board and power board. (●: Selected feature) NOTE: Default AC output definitions of power board as below, all AC output load definitions could modified by firmware for variety applications. CON3 = 4 PIN CON3 = 7 PIN CON3 CON2 CON1 JP1 CON3 CON2 CON1 JP1 5 / 17 GM9K SERIES (INCLUDE GM9K1 / GM9K2 / GM9K3) USER MANUAL - FOR OEM USE ONLY H13 [GRAND MATE] Version: D07.1 at October 19 th , 2022 TABLE 4a. TERMINALS DESCRIPTION 01 TABLE 4b. TERMINALS DESCRIPTION 02 N.C. = Not Connection N.A. = Not Available N.C. = Not Connection N.A. = Not Available CON3 CON2 CON1 JP1 CON3 CON2 CON1 JP1 6 / 17 GM9K SERIES (INCLUDE GM9K1 / GM9K2 / GM9K3) USER MANUAL - FOR OEM USE ONLY H13 [GRAND …
