UQORC-09Remote Controller

RC-09 User Manual Mode Name : RC-09 Battery : AAA*2 Frequency : 433.92MHz Device Keys Setting Keys Active Keys FCC Caution : To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example - use only shielded interface cables when connecting to computer or peripheral devices). This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that ma y cause undesired operation. ID Setting 1. Take one battery out from remote controller, press any key then reload battery. 2. The red LED indicator at front panel lights up for 5 seconds. 3. Within 5 seconds, enter a set of 4 numbers to finishes digital ID setup Note: There are 10000 combination of digital ID code range from 0000 to 9999. User may change it when desire. Please note that the digital ID code must correspond to the chosen light, wall and power switch’s ID enable for controller to control them. ID check 1. Press and hold key. 2. Pressand count the number of times red LED indicator blinks, which represent the first digit of the code. Repeat step with,andto check for other digits. Note: The factory default code of the remote controller is “0000”. User need to change the code correspond to light switch’s digital ID or power plug ID to enable the RC-06 Smart Remote Controller to control them. Lighting Control Note: Please make sure the chosen light, wall or power switch’s digital ID code is consistent with RC-09’s digital ID code. 1. Select the control Zone of or 2. Press device key from tothen release, red LED indicator will light up and within 5 seconds, press or to send command, red LED indicator will blink once. 3. If user changed mind after select a set of device but want to control another set of device, within 5 seconds of pressing the first set of device key, press second device key from toand release, backlight will blink twice to indicate the change of control, then pressorto activate the command. Home Appliances Control 1. Select one of the home appliances device 2. Press active key then release to control the home appliance. + - or Setting Keys Learn+Devices Key : going to device Learning Mode Set+No.1 or 2 or 3 or 4: check the RC-09’s ID Learn+MACRO : going to MACRO edit mode Set+Off : clear the memory MACRO+No. 0~9 : MACRO Active

Registration number: W6M20610-7509-C-1 FCC ID: QUORC-09 ETS Dr. Genz Taiwan PS Co., Ltd. External Photos Registration number: W6M20610-7509-C-1 FCC ID: QUORC-09 ETS Dr. Genz Taiwan PS Co., Ltd. Black Registration number: W6M20610-7509-C-1 FCC ID: QUORC-09 ETS Dr. Genz Taiwan PS Co., Ltd. Registration number: W6M20610-7509-C-1 FCC ID: QUORC-09 ETS Dr. Genz Taiwan PS Co., Ltd. Red Registration number: W6M20610-7509-C-1 FCC ID: QUORC-09 ETS Dr. Genz Taiwan PS Co., Ltd.

Remote Control Model number: RC-09 FCC ID: UQORC-09 Label Size: 80×20 mm Model: RC-09 FCC ID:UQORC-09 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: Made in Taiwan (1)This device may not cause harmful interference, and (2)This device must accept any interference received,including interference that may cause undesired operation. TECHCity Technology Co., Ltd.

ETS Dr.Genz Taiwan PS Co., Ltd. FCC Registration No.: 930600 A2LA Cert.No.: 2300.01 PTCRB Accredited Type Certification Test House TEST - REPORT FCC RULES PART 15 / SUBPART C FCC ID: UQORC-09 Test report no.: W6M20610-7509-C-1 FCC ETS DR. GENZ TAIWAN PS CO., LTD 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. PHONE 886-2-66068877 FAX 886-2-66068879 Registration number: W6M20610-7509-C-1 FCC ID: UQORC-09 ETS Dr. Genz Taiwan PS Co., Ltd. Page 1 of 20 TABLE OF CONTENTS 1 G ENERAL INFORMATION 2 1.1 NOTES 2 1.2 TESTING LABORATORY 3 1.2.1 Location 3 1.2.2 Details of accreditation status 3 1.3 D ETAILS OF APPROVAL HOLDER 3 1.4 A PPLICATION DETAILS 4 1.5 T EST ITEM 4 1.6 TEST STANDARDS 5 2 T ECHNICAL TEST 5 2.1 S UMMARY OF TEST RESULTS 5 2.2 T EST ENVIRONMENT 5 2.3 T EST EQUIPMENT UTILIZED 6 2.4 GENERAL TEST PROCEDURE 8 3 TEST RESULTS (ENCLOSURE) 9 3.1 TRANSMISSION REQUIREMENTS 10 3.1.1 Limit of Transmission Time 10 3.1.2 Active Time 10 3.2 O UTPUT POWER (FIELD STRENGTH) 11 3.3 OUT OF BAND RADIATED EMISSIONS 12 3.4 TRANSMITTER RADIATED EMISSIONS IN RESTRICTED BANDS 13 3.5 SPURIOUS EMISSION RADIATED, TRANSMITTER 14 3.6 CHANNEL BANDWIDTH 16 3.7 ANTENNA REQUIREMENT 17 3.8 DUTY CYCLE 18 3.9 CONDUCTED MEASUREMENT AT (AC) POWER LINE 19 A PPENDIX 20 Registration number: W6M20610-7509-C-1 FCC ID: UQORC-09 ETS Dr. Genz Taiwan PS Co., Ltd. Page 2 of 20 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has Passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the ETS DR. GENZ TAIWAN PS CO., LTD Tester: Nov 15, 2006 Jay Chaing Date ETS-Lab. Name Signature Technical responsibility for area of testing: Nov 15, 2006 Steven Chuang Date ETS Name Signature Registration number: W6M20610-7509-C-1 FCC ID: UQORC-09 ETS Dr. Genz Taiwan PS Co., Ltd. Page 3 of 20 1.2 Testing laboratory 1.2.1 Location OATS No.5-1, Shuang Sing Village, LiShuei Rd., Wanli Township, Taipei County 207, Taiwan (R.O.C.) Company ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD. NEIHU, TAIPEI 114, TAIWAN R.O.C. Tel : 886-2-66068877 Fax : 886-2-66068879 1.2.2 Details of accreditation status Accredited testing laboratory A2LA-registration number: 2300.01 FCC filed test laboratory Reg. No. 930600 Industry Canada filed test laboratory Reg. No. IC 5679 PTCRB Accredited Type Certification Test House Town: ./. Country: ./. Telephone: ./. Fax: ./. 1.3 Details of approval holder Name : TECHCity Technology Co., Ltd. Street : 4F, No.4, Alley 1, Szu Wei Lane, Chung Cheng Rd., Hsin Tien, Town : Taipei Hsien, Country : Taiwan, R.O.C. Telephone : +886-2-2219-4201 Fax : +886-2-8667-1977 Registration number: W6M20610-7509-C-1 FCC ID: UQORC-09 ETS Dr. Genz Taiwan PS Co., Ltd. Page 4 of 20 1.4 Application details Date of receipt of application : Oct 25, 2006 Date of receipt of test item : Oct 26, 2006 Date of test : from Oct 26, 2006 to Nov 14, 2006 1.5 Test item Description of test item : Remote Controllor Type identification : RC-09 Brand name : ./. Serial number : Test sample without serial number Transmitting frequency : 433.92 MHz Operation mode : simplex Voltage supply : 3 VDC ( 1.5 x battery ) (If the device is using battery, please check if the device is tested under fresh battery condition.) Highest clock frequency : 433.92 MHz Antenna type : wire antenna Photos : see Appendix Manufacturer (if applicable) Name : ./. Street : ./. Town : ./. Country : ./. Additional information : ./. Registration number: W6M20610-7509-C-1 FCC ID: UQORC-09 ETS Dr. Genz Taiwan PS Co., Ltd. Page 5 of 20 1.6 Test standards Technical standard : FCC RULES PART 15 / SUBPART B § 15.109/ SUBPART C § 15.203, § 15.209, § 15.231 (a) 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course : of the tests performed. or The deviations as specified in 2.5 were ascertained in the course of the tests … performed. 2.2 Test environment Temperature : 23 o C Relative humidity content : 20 ... 75 % Air pressure : 86 ... 103 kPa Details of power supply : 3 VDC ( 1.5 x battery ) Registration number: W6M20610-7509-C-1 FCC ID: UQORC-09 ETS Dr. Genz Taiwan PS Co., Ltd. Page 6 of 20 2.3 Test equipment utilized No. Test equipment Type Serial No. Manufacturer Cal. Date Next Cal. Date ETSTW-CE 001 EMI TEST RECEIVER ESHS10 842121/013 R&S 2006/10/16 2007/10/15 ETSTW-CE 002 PREREULATOR MODE DC POWER SUPPLY None None Function Test ETSTW-CE 003 AC POWER SOURCE APS-9102 D161137 GW Function Test ETSTW-CE 004 ZWEILEITER-V- NETZNACHBILDUNG TWO- LINE V-NETWORK ESH3-Z5 840731/011 R&S 2006/10/16 2007/10/15 ETSTW-CE 005 Line-Impedance Stabilisation Network NNBM 8126D 137 Schwarzbeck 2006/10/16 2007/10/15 ETSTW-CE 006 IMPULS-BEGRENZER PULSE LIMITER ESH3-Z2 100226 R&S In House Certificate ETSTW-CE 008 ABSORBING CLAMP MDS 21 3469 ABSORPTIONS- MESSWANDLER- ZANGE 2005/10/24 2007/10/23 ETSTW-CE 009 TEMP.&HUMIDITY CHAMBER GTH-225-40-1P-UMAA0305-009 GIANT FORCE 2006/8/17 2007/8/16 ETSTW-CE 012 Dual-Phase-V-Network NNB-2/16Z 03/10201 Telemeter 2006/6/13 2007/6/12 ETSTW-RE 002 Function Generator 33220A MY430…
