UXZEDR-APBluetooth Access Point

1 111 2 222 ■ ■■■ Table of Contents Table of ContentsTable of ContentsTable of Contents 1. EDR-AP KEY FEATURES 2. PART CHECKLIST 3. PRODUCT DESCRIPTION 4. SPECIFICATION 5. CONTROLS AND FUNCTIONS [BUTTON/LED/REAR PANEL] 6. EDR-AP INSTALLATION 7. CAUTION 8. ETHERNET NETWORK CONNECTION 3 333 ■ ■■■ EDR EDREDREDR- ---AP Key Features AP Key FeaturesAP Key FeaturesAP Key Features
EDR-AP supports Bluetooth PAN / DUN / OPP Gateway.
EDR-AP provides a built-in web server for convenien t configuration.
EDR-AP support private leased lines, ADSL/VDSL mode ms using PPPoE and cable modems (DHCP). ■ ■■■ Part Checklist Part ChecklistPart ChecklistPart Checklist Please check and make sure that you have the follow ing package contents. I IIItem temtemtem Q QQQ’ ’’’ty tytyty Use UseUseUse EDR-AP Body 1 EDR-AP main body User Manual 1 User guide that explains features, functions and implementation examples Antenna 1 Bluetooth Antenna Power Adaptor 1 EDR-AP power supply device LAN Cable(1.5m) 1 Cable that connects EDR-AP and I nternet Modem 4 444 ■ ■■■ Product Description Product DescriptionProduct DescriptionProduct Description Please check and make sure that you have all the fo llowing package contents. 5 555 ■ ■■■ Specification Specification Specification Specification Name Name Name Name Description DescriptionDescriptionDescription Output Power 15 ~ 20 dBm Rx Sensitivity 85 dBm Channel 79 CH Antenna 2.4GHz Band 1/2λSleeve Dipole Antenna Frequency 2402 ~ 2480 MHz Modulation FSK, QPSK Adaptor 5V 1A Max Current 560mA Operating Temperature -20°C~55°C 6 666 ■ ■■■ Controls and Functions Controls and FunctionsControls and FunctionsControls and Functions ▌ ▌▌▌ Button ButtonButtonButton Name NameNameName Description DescriptionDescriptionDescription Button If you press any two buttons on the unit, the LED ( Green) blinks and EDR-AP goes to discoverable and pairable mode. 7 777 ▌ ▌▌▌ LEDs LEDsLEDsLEDs Name NameNameName Color ColorColorColor Status StatusStatusStatus Description DescriptionDescriptionDescription ON Power is ON and Bluetooth is normal state mode BLINK Other device is connected and new device is under p airable mode STATUS Green OFF Power is OFF or Bluetooth is abnormal state mod e ON TCP/IP communication is able mode BLINK TCP/IP communication is disable mode WAN Green OFF No connection with the Ethernet * When EDR-AP restarts, every LED blinks several ti mes 8 888 ▌ ▌▌▌ Rear Panel Rear PanelRear PanelRear Panel (From the left to the right side) Name NameNameName Description DescriptionDescriptionDescription RESET Press this button for more than three seconds to re store the original factory default setting of EDR-AP (Reboot: press between 1~3 seconds) 5V1A Connect the Power Adaptor WAN Connect to private leased line, ADSL/VDSL modem, ca ble model using LAN cable (UTP Cable) 9 999 ■ ■■■ EDR EDREDREDR- ---AP Installation AP InstallationAP InstallationAP Installation Please check the port location of the rear panel an d then follow the steps below to install the BS-P10 0 properly. ▌ ▌▌▌ Ethernet Network Connection Ethernet Network ConnectionEthernet Network ConnectionEthernet Network Connection Let ’ s check the network cable connection to use the int ernet service. Modem 10 101010 ① Pull out the cable from the Ethernet (LAN) port of modem and connect it to the WAN port at the EDR-AP ’ s rear panel. ② Connect the power adaptor to the “ POWER ” port at the EDR-AP rear panel. ③ Connect antenna provided to antenna connecting jack at the side of body. When you connect antenna, twi st it on carefully and lastly push it strongly. 11 111111 ■ ■■■ CAUTION CAUTIONCAUTIONCAUTION
Use only the power adaptor supplied. Using other po wer adaptors may cause the voice quality to deteriorate and malfunction.
Install EDR-AP far from wireless LAN/microwave abou t 1m. If installed close may cause j amming.
Use only the antenna provided. The data of this device could be lost When the stat ic electricity occurs in antenna portion 12 121212 ■ ■■■ Configuration using Configuration using Configuration using Configuration using Web Interface Web InterfaceWeb InterfaceWeb Interface You can use Web Interface with web browser in order to s et the EDR-AP configuration. You can access the Web Interface by IP address or Bluetooth connection (PAN) . For the access by Bluetooth connection, connect wi th PAN of EDR-AP and access with Gateway address assigned from the PC. ▌ ▌▌▌ Checking device Checking deviceChecking deviceChecking device’ ’’’s IP address s IP addresss IP addresss IP address In case of you don’t know the IP address, you can ch eck the current EDR-AP IP address by configuring IP ad dress of user’s PC. ① Click [Start] from the bottom menu bar, then choose [Settings]. ② S elect [Control Panel] to view a new window, and the n choose [Network connections]. ③ Right click on [Local Area Connection]. If there ar e more than one Local Area Connections, choose the one that is currently in use. ④ Choose [Properties] when a new window appears. ⑤ Click [IP Address] tab and then check the [Obtain a n IP address automatically] box. If the box is alre ady checked, you don ’ t need to change anything. ⑥ Click [Ok]. You don ’ t need to restart your computer in Windows XP. 13 131313 Access to the Web Page: http://EDR EDREDREDR- ---AP APAPAP’ ’’’s sss Address AddressAddressAddress:1001/index.html or http://default defaultdefaultdefault Gateway GatewayGatewayGateway’ ’’’s sss Address AddressAddressAddress:1001/index.html You can set the functions below through Web Page. Name NameNameName Detailed Name Detailed NameDetailed NameDetailed Name Description DescriptionDescriptionDescription System Status You can check the status of EDR-AP System Information Technical Specification You can check the information about firmware, softw are, hardware of EDR- AP Network You can configure the network environment for the i nternet use. (Choose the network among Static IP, DHCP, ADSL(PPP oE)) Bluetooth You can set the environment for the Blueto…

Text truncated - open the document above for the full version.

CPU CPUCPUCPU S3C4510B01 S3C4510B01S3C4510B01S3C4510B01- ---QE80 QE80QE80QE80 2MByte Nor Flash 2MByte Nor Flash2MByte Nor Flash2MByte Nor Flash JS28F160C3BD70 JS28F160C3BD70JS28F160C3BD70JS28F160C3BD70 4MByte SDRAM 4MByte SDRAM4MByte SDRAM4MByte SDRAM M12L64322A M12L64322AM12L64322AM12L64322A- ---7T(G) 7T(G)7T(G)7T(G) Ethernet Switching Ethernet SwitchingEthernet SwitchingEthernet Switching IP175 LF IP175 LFIP175 LFIP175 LF USB Host Chip USB Host ChipUSB Host ChipUSB Host Chip ISP1160BM/01+118 ISP1160BM/01+118ISP1160BM/01+118ISP1160BM/01+118 BlueTooth BlueToothBlueToothBlueTooth Module ModuleModuleModule BTM BTMBTMBTM- ---221 221221221 M MMM I III I III 5V/1A 5V/1A5V/1A5V/1A Vout VoutVoutVout 3.3V 3.3V3.3V3.3V DATA BUS DATA BUSDATA BUSDATA BUS A AAA D DDD D DDD R RRR E EEE S SSS S SSSB BBBU UUU S SSS Rayson Bluetooth ® Module Class1 BC04-ext Module BTM-220 Features Outline Block Diagram ■ Bluetooth Ver. 2.0 compliant ■ Transmit Power up to +18dBm(class1) ■ Low current consumption: Hold, Sniff, Park, Deep sleep mode ■ 2.7V to 3.6V operation ■ Full Bluetooth Data rate over UART and USB ■ Support up to 7 ACL links and 3 SCO links ■ Enhanced Data Rate(EDR) compliant with Ver.0.9 of specification for both 2Mbps and 3Mbps modulation modes ■ Interface: USB, UART&PCM( for voice codec) ■ HCI or SPP firmware is available ■ Mini outline: 28.2 X 15.0 X 2.8 mm Application ● Laptop and Desktop PCs ● Access point ● Domestics and Industrial applications ● Personal Digital Assistants(PDA) ● Serial Adapter ● GPS, POS, Barcode Reader ● Digital camera, Printer& Cellular phone ● Cordless handset

Clipcomm, Inc. E.S.T Bldg, 229-15 Nonhyeon-dong, Gangnam-gu, Seoul 135-830, South Korea TEL: +82-2-541-9081, FAX: +82-2-541-9085 http://www.clipcomm.co.kr Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD21046 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission's Rules (47 C.F.R) and Section §552(b)(4) of the Freedom of Information Act, Clipcomm, Inc. requests confidentiality for the following products: FCC ID Number Product Title / Model UXZEDR-AP Bluetooth Access Point/BS-L100 For the product stated above, we request that the following information be held confidential: 1) Schematic diagrams 2) Bill of materials (Part List) No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain Clipcomm, Inc. trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our products. This material is not customarily available to the general public and we request that it be withheld from public inspection. Sincerely, Tae-Yoon Lee / Engineer

SK TECH CO., LTD. Page 1 of 2 SKTFCE-070118-010 FCC ID :UXZEDR-AP External Photographs of EUT SK TECH CO., LTD. Page 2 of 2 SKTFCE-070118-010 FCC ID :UXZEDR-AP

SK TECH CO., LTD. Page 1 of 1 SKTFCE-070118-010 FCC ID :UXZEDR-AP FCC ID Sample Label & Location Information LABELLING REQUIREMENTS PER ∫∫∫∫2.928 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase.

SK TECH CO., LTD. Page 1 of 1 SKTFCE-070118-010 FCC ID : UXZEDR-AP FCC ID Label Sample

SK TECH CO., LTD. Page 1 of 5 SKTFCE-070118-010 FCC ID :UXZEDR-AP Internal Photographs of EUT <Internal> SK TECH CO., LTD. Page 2 of 5 SKTFCE-070118-010 FCC ID :UXZEDR-AP <Mainboard Front/ BS-L100> SK TECH CO., LTD. Page 3 of 5 SKTFCE-070118-010 FCC ID :UXZEDR-AP <Mainboard Rear/ BS-L100> SK TECH CO., LTD. Page 4 of 5 SKTFCE-070118-010 FCC ID :UXZEDR-AP <Adaptor Front> SK TECH CO., LTD. Page 5 of 5 SKTFCE-070118-010 FCC ID :UXZEDR-AP <Adaptor Rear>

DOC. NO C-050501 REV. NO 0 Issued Date 2005-05-06 ANTENNA SPECIFICATION PAGE 1/10 Product Name Product NameProduct Name Product Name : : : : 2.4GHz Band 1/2λSleeve Dipole Antenna M M M Model odelodel odel Name NameName Name: : : : CW CWCW CWP PP P- -- -2400 24002400 2400D DD D- -- -SMA SMASMA SMA(V) (V)(V) (V) Contents 1. Descriptions 2. Application 3. Antenna Shape 4. Electrical Performance 5. Mechanical Performance 6. Environmental Performance 7. Attachment Release Written Checked Checked Approved Sign. J.R.Park Date 2005-05-06 CHINWOOTECH A4(210×297) Model CWP-2400D- SMA(V) Docu-NO C-050501 Code NO Rev-NO 0 Customer ANTENNA SPECIFICATION PAGE 2/10 1. 1. 1. 1. Description DescriptionDescription Descriptions ss s This 2400MHz Band 1/2wavelength Sleeve Dipole Antenna designed in the PCB, consisting of the 1/2 wavelength whip elements at the front plane and a 1/4 wavelength conductive matching sleeve having 50 ohm feed to connector at the back, for wireless communcation unit. 2. 2. 2. 2. Application Application Application Application □ Hand Held ▣ Fixed □ Mobile □ Out Door ▣ In Door □ Others 3. 3. 3. 3. A AA Antenna Shap ntenna Shapntenna Shap ntenna Shape ee e See attached 4. 4. 4. 4. Electrical Performance Electrical Performance Electrical Performance Electrical Performance 4.1 4.14.1 4.1 Frequency Range Frequency RangeFrequency Range Frequency Range 2400 MHz ~ 2480 MHz 4.2 4.24.2 4.2 Impedance ImpedanceImpedance Impedance Nominal Value 50 Ohm 4.3 4.34.3 4.3 V.S.W.R V.S.W.R V.S.W.R V.S.W.R Less than 1 : 2.0 4.4 4.44.4 4.4 Antenna Antenna Antenna Antenna Radiation Pattern Radiation PatternRadiation Pattern Radiation Pattern Omni-Directional 4.5 4.54.5 4.5 Antenna Antenna Antenna Antenna Polarization PolarizationPolarization Polarization Vertical CHINWOOTECH A4(210×297) Model CWP-2400D- SMA(V) Docu-NO C-050501 Code NO Rev-NO 0 Customer ANTENNA SPECIFICATION PAGE 3/10 4. 4.4. 4.6 66 6 Antenna Gain ( dBi ) Antenna Gain ( dBi ) Antenna Gain ( dBi ) Antenna Gain ( dBi ) 2.0 dB 5. 5. 5. 5. Mechanical Performance Mechanical PerformanceMechanical Performance Mechanical Performance 5.1 5.15.1 5.1 Element Element Element Element Material Cu Insulator FR-4 / 0.8T Electrical Length 1/2 Wavelength 5.2 5.25.2 5.2 Connector Connector Connector Connector Type SMA-male Finish Ni-plating 5.3 5.35.3 5.3 Base Base Base Base Type 90 deg. Angled insert molding Material ABS Finish Dark-Blue 5.4 5.45.4 5.4 Sleeve Sleeve Sleeve Sleeve Material ABS Finish Dark-Blue 5.5 5.55.5 5.5 Antenna total length Antenna total length Antenna total length Antenna total length See Attached 5.6 5.65.6 5.6 Antenna Weight Antenna Weight Antenna Weight Antenna Weight 7.5 gram CHINWOOTECH A4(210×297) Model CWP-2400D- SMA(V) Docu-NO C-050501 Code NO Rev-NO 0 Customer ANTENNA SPECIFICATION PAGE 4/10 6. 6. 6. 6. Environmental Resistance Environmental Resistance Environmental Resistance Environmental Resistance Performance PerformancePerformance Performance 6. 6.6. 6.1 11 1 Operating Temperature Operating TemperatureOperating Temperature Operating Temperature – 30°C ~ 70°C 6 66 6.2 .2.2 .2 Storage Temperature Storage TemperatureStorage Temperature Storage Temperature – 40°C ~ 80°C 6. 6.6. 6.3 33 3 Humidity HumidityHumidity Humidity 95% RH / 50°C 6.4 Sleeve 6.4 Sleeve 6.4 Sleeve 6.4 Sleeve Tensile strength Tensile strengthTensile strength Tensile strength Minimum Value : F = 5 Kgf Demands : No visual change and the fitting and mold shall be unchanged mechanically during the test. The antenna shall satisfy the electrical data. . 6. 6.6. 6.5 55 5 Drop DropDrop Drop Height : 0.7 m Angle : 45° Set Weight : 200 g Demands : No visual change and the fitting and mold shall be unchanged mechanically during the test. The antenna shall satisfy the electrical data. CHINWOOTECH A4(210×297) Model CWP-2400D- SMA(V) Docu-NO C-050501 Code NO Rev-NO 0 Customer ANTENNA SPECIFICATION PAGE 5/10 7 77 7. . . . Attached AttachedAttached Attached 1. Antenna Specifications Drawing 2. Antenna Performance Data -. V.S.W.R -. Impedance -.Radiation Pattern / Gain CHINWOOTECH A4(210×297) Model CWP-2400D- SMA(V) Docu-NO C-050501 Code NO Rev-NO 0 Customer ANTENNA SPECIFICATION PAGE 6/10 [Attached] 1. Antenna Specifications Drawing Antenna Specifications DrawingAntenna Specifications Drawing Antenna Specifications Drawing CHINWOOTECH 이하 CHINWOOTECH A4(210×297) Model CWP-2400D- SMA(V) Docu-NO C-050501 Code NO Rev-NO 0 Customer ANTENNA SPECIFICATION PAGE 7/10 2. Antenna Antenna Antenna Antenna Performance Data Performance DataPerformance Data Performance Data Test Equipment : HP Test Equipment : HPTest Equipment : HP Test Equipment : HP- -- -8753ES 8753ES8753ES 8753ES SET (PCB ver.) : BS SET (PCB ver.) : BS SET (PCB ver.) : BS SET (PCB ver.) : BS- -- -T100V v4.D T100V v4.DT100V v4.D T100V v4.D - -- -. Impedance . Impedance . Impedance . Impedance CHINWOOTECH A4(210×297) Model CWP-2400D- SMA(V) Docu-NO C-050501 Code NO Rev-NO 0 Customer ANTENNA SPECIFICATION PAGE 8/10 - -- -. V.S.W.R . V.S.W.R. V.S.W.R . V.S.W.R CHINWOOTECH A4(210×297) Model CWP-2400D- SMA(V) Docu-NO C-050501 Code NO Rev-NO 0 Customer ANTENNA SPECIFICATION PAGE 9/10 - -- -. RADIATION PATTERN / GAIN . RADIATION PATTERN / GAIN. RADIATION PATTERN / GAIN . RADIATION PATTERN / GAIN H H H H- -- -PLANE PLANE PLANE PLANE CHINWOOTECH A4(210×297) Model CWP-2400D- SMA(V) Docu-NO C-050501 Code NO Rev-NO 0 Customer ANTENNA SPECIFICATION PAGE 10/10 E E E E- -- -PLANE PLANEPLANE PLANE CHINWOOTECH A4(210×297)

Operational Description This product, BS-L100, is a Bluetooth device. The product operates in 2400 to 2483.5 MHz band. The channel is represented by a pseudo-random hopping sequence through the 79 channels. The channel is divided into time slots, with a nominal slot length of 625μs, where each slot corresponds to different RF hop frequencies. The nominal hop rate is 1600 hops/s. The control signals and data in the Bluetooth Chipset are modulated and processed and then pass the PA in it. They will be transmitted from ANT through the BALUN FILTER to another Bluetooth device. The RF signal from other Bluetooth devices is received via ANT. And they go through internal BALUN FILTER into the chip. They are magnified by internal LNA in the chip. The power settings and crystal trim are stored in internal flash. The product is powered from a Adaptor and uses a sleeve dipole antenna. No external ground is required.

SK TECH CO., LTD. Page 1 of 15 SKTFCE-070118-010 FCC ID :UXZEDR-AP FCC-Certificate of Compliance Test Report No.: SKTFCE-070118-010 NVLAP CODE : 200220-0 Applicant: Clipcomm, Inc. Applicant Address: E.S.T Bldg, 229-15, Nonhyeon-dong, Gangnam-gu, Seoul 135-830, South Korea Manufacturer : Clipcomm, Inc. Manufacturer Address: E.S.T Bldg, 229-15, Nonhyeon-dong, Gangnam-gu, Seoul 135-830, South Korea Product: Bluetooth Access Point FCC ID: UXZEDR-AP Model No.: BS-L100 Receipt No.: SKTEU06-0754 Date of Issue: Jan. 18, 2007 Date of receipt: Dec. 04, 2006 Brand/Trade Name: ANYCOM EDR-AP Testing location: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Standards: ANSI C63.4 / 2003 Rule Parts: FCC part 15 Subpart B, CISPR 22 Equipment Class : Class B Digital Device Peripheral Test Result: The above mentioned product has been tested and passed. Prepared by: S.Y.Ye Tested by:H.S.Yeom/Engineer Approved by: D.H.Kang /Manager& Chief Engineer Signature Date Signature Date Signature Date Other Aspects : Abbreviations : · OK, Pass = passed · Fail = failed · N/A = not applicable ☞ •This test report is not permitted to copy partly without our permission. •This test result is dependent on only equipment to be used. •This test result is based on a single evaluation of one sample of the above mentioned. •This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government. • We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. •This test report is the accredited testing items by Korea Laboratory Accreditation Scheme, which signed the ILAC-MRA. NVLAP Lab. Code: 200220-0 SK TECH CO., LTD. Page 2 of 15 SKTFCE-070118-010 FCC ID :UXZEDR-AP 》》 Contents 《《 Contents 2 List of Tables 2 List of Figures 2 1. General 3 2. Test Site 3 2.1 Location 3 2.2 List of Test and Measurement Instruments 4 2.3 Test Date 4 2.4 Test Environment 4 3. Description of the tested samples 5 3.1 Rating and Physical Characteristics 5 3.2 Submitted Documents 5 4. Measurement Conditions 6 4.1 Modes of Operation 6 4.2 List of Peripherals 6 4.3 Type of Used cables 7 4.4 Test Setup 8 4.5 Uncertainty 9 5. EMISSION Test 10 5.1 Conducted Emissions 10 5.2 Radiated Emissions 14 》List of Tables Table 1 List of test and measurement Equipment 4 Table 2 Test Data, Conducted Disturbance 11 Table 3 Test Data, Radiated Emissions 15 》List of Figures Figure 1 Spectral Diagram, LINE-PE 12 Figure 2 Spectral Diagram, NEUTRAL-PE 13 SK TECH CO., LTD. Page 3 of 15 SKTFCE-070118-010 FCC ID :UXZEDR-AP 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by SK TECH Co., Ltd. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site SK TECH Co., Ltd. 2.1 Location 820-2, Wolmoon Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea The test site is in compliance with ISO/IEC 17025 for general requirements for the competence of testing and calibration laboratories. This laboratory is recognized as a Conformity Assessment Body(CAB) for CAB’s, Designation Number: KR0007 by FCC, is accredited by NVLAP for NVLAP Lab. Code : 200220-0 and DATech for DAR-Registration No.:DAT-P-076/97-01 and KOLAS for Accreditation No.: KT191. SK TECH CO., LTD. Page 4 of 15 SKTFCE-070118-010 FCC ID :UXZEDR-AP 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment z Conducted Disturbance Kind of Equipment Type S/N Calibrated until EMI Receiver ESHS10 835871/002 09.2007 Artificial Mains Network ESH2-Z5 834549/011 07.2007 z Radiated Disturbance Kind of Equipment Type S/N Calibrated until EMI Receiver ESIB40 100277 02.2007 Amplifier 8447F 3113A0515307.2007 Trilog-Broadband Antenna VULB9168 9168-230 07.2007 Antenna Turntable Driver 5907 91X518 N/A Antenna Turntable controller 5906 91X519 N/A 2.3 Test Date Date of Application : Dec. 04, 2006 Date of Test : Jan. 13, 2007 ~ Jan. 18, 2007 2.4 Test Environment See each test item’s description. SK TECH CO., LTD. Page 5 of 15 SKTFCE-070118-010 FCC ID :UXZEDR-AP 3. Description of the tested samples The EUT is a Bluetooth Access Point. 3.1 Rating and Physical Characteristics Name Description Output Power 15 ~ 20 dBm Rx Sensitivity 85 dBm Channel 79CH Antenna 2.4GHz Band 1/2 λ Sleeve Dipole Antenna Frequency 2402 ~ 2480 MHz Modulation FSK, QPSK Adaptor 5V 1A Max Current 560mA Operating Temperature -20°C ~ 55°C 3.2 Submitted Documents N/A SK TECH CO., LTD. Page 6 of 15 SKTFCE-070118-010 FCC ID :UXZEDR-AP 4. Measurement Conditions The rating of adaptor is DC 5V, 1A at output and AC100~240V, 50/60Hz, 0.3A at input. 4.1 Modes of Operation The EUT was connected to pc by RJ45 cable. The data file stored in pc was downloaded to the note pc via wireless communication. 4.2 List of Peripherals Equipment Manufacturer Model Name Serial No. Keyboard (PS2) YET FOUNDATE LTD. SK-1688 C0509035926 Mouse(USB) SUZHOU LOGITECH ELECTRONIC CO., LTD. M-BJ58 HCA54718469 LCD Monitor LG 1510TFT Rev B 304KG04862 PC Samsung Electronics DM-V50 371F97BA100133V Note PC LG IBM PC 2681 FX-P2816 Adaptor (For Note PC) ASTEC ELECTRONICS CO., LTD 08K8202 11S08K8202Z1Z 6LR38F053 Bluetooth USB Adaptor J communications Co., ltd.BA10006 N/A AC/DC ADAPTOR Seung Bo Elecom Co., Ltd.SP0507A SB0610000944 SK TECH CO., LTD. Page 7 of 15 SKTFCE-070118-010 FCC ID :UXZEDR-AP 4.3 Type of Used Cables Equipment Manufacturer M/N S/N Cables &connectors EUT (RJ cable for PC) N/A N/A N/A 1.5m unshielded RJ cable EUT (Power cable for Adaptor) N/A N/A N/A 1.8m unshielded Power cable EUT (SMA Connector cable for Antenna) N/A N/A N/A - PC(PS/2 cable for Keyboard) …

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 2 SKTFCE-070118-010 FCC ID :UXZEDR-AP Test set up photos Photograph 1: Setup for Conducted Emissions SK TECH CO., LTD. Page 2 of 2 SKTFCE-070118-010 FCC ID :UXZEDR-AP Photograph 2: Setup for Radiated Emissions
