Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: UZZBT500 Project No. : 1301C323 Equipment : BT500 Bluetooth Speaker Model : BNA-G0001 Applicant : Beautiful Enterprise Co., Ltd. Address : 26th Floor, Beautiful Group Tower, 77 Connaught Road Central, Hong Kong According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna TEST RESULTS EUT： BT500 Bluetooth Speaker Model Name ： BNA-G0001 Temperature： 24 °C Relative Humidity： 60 % Pressure： 1016 hPa Test Voltage ： DC 3.7V Test Mode ： CH00/ CH39 /CH78 -1Mbps Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -1.72 0.6730 3.56 2.2699 0.000304 1 Complies -1.72 0.6730 2.75 1.8836 0.000252 1 Complies -1.72 0.6730 2.19 1.6558 0.000222 1 Complies Neutron Engineering Inc. EUT： BT500 Bluetooth Speaker Model Name ： BNA-G0001 Temperature： 24 °C Relative Humidity： 60 % Pressure： 1016 hPa Test Voltage ： DC 3.7V Test Mode ： CH00/ CH39 /CH78 -3Mbps Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm2) Limit of Power Density (S) (mW/cm2) Te s t Result -1.72 0.6730 2.79 1.9011 0.000255 1 Complies -1.72 0.6730 1.88 1.5417 0.000207 1 Complies -1.72 0.6730 1.18 1.3122 0.000176 1 Complies

Neutron Engineering Inc. Report No.: NEI-FICP-1-1301C323 Page 1 of 109 FCC/IC Radio Test Report FCC ID: UZZBT500 IC: 7633A-BT500 This report concerns (check one) : Original Grant Class II Change Issued Date : Feb. 08, 2013 Project No. : 1301C323 Equipment : BT500 Bluetooth Speaker Model Name BNA-G0001 Applicant : Beautiful Enterprise Co., Ltd. Address : 26th Floor, Beautiful Group Tower, 77 Connaught Road Central, Hong Kong Manufacturer : Beautiful Enterprise Co., Ltd. Address : 26th Floor, Beautiful Group Tower, 77 Connaught Road Central, Hong Kong Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Feb. 01, 2013 Date of Test: Feb. 01, 2013 ~ Feb. 07, 2013 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FICP-1-1301C323 Page 2 of 109 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FICP-1-1301C323 Page 3 of 109 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 10 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.5 DESCRIPTION OF SUPPORT UNITS 12 4 . EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 13 4.1.3 TEST PROCEDURE 14 4.1.4 DEVIATION FROM TEST STANDARD 14 4.1.5 TEST SETUP 14 4.1.6 EUT OPERATING CONDITIONS 14 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 19 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BELOW 30MHZ) 23 4.2.8 TEST RESULTS (BETWEEN30 – 1000 MHZ) 24 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 37 5 . NUMBER OF HOPPING CHANNEL 61 5.1 APPLIED PROCEDURES / LIMIT 61 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 61 5.1.2 TEST PROCEDURE 61 5.1.3 DEVIATION FROM STANDARD 61 5.1.4 TEST SETUP 61 5.1.5 EUT OPERATION CONDITIONS 61 5.1.6 TEST RESULTS 62 6 . AVERAGE TIME OF OCCUPANCY 64 Neutron Engineering Inc. Report No.: NEI-FICP-1-1301C323 Page 4 of 109 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 64 6.1.1 MEASUREMENT INSTRUMENTS LIST 64 6.1.2 TEST PROCEDURE 64 6.1.3 DEVIATION FROM STANDARD 64 6.1.4 TEST SETUP 65 6.1.5 EUT OPERATION CONDITIONS 65 6.1.6 TEST RESULTS 66 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 78 7.1 APPLIED PROCEDURES / LIMIT 78 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 78 7.1.2 TEST PROCEDURE 78 7.1.3 DEVIATION FROM STANDARD 78 7.1.4 TEST SETUP 78 7.1.5 EUT OPERATION CONDITIONS 78 7.1.6 TEST RESULTS 79 8 . BANDWIDTH TEST 83 8.1 APPLIED PROCEDURES / LIMIT 83 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 83 8.1.2 TEST PROCEDURE 83 8.1.3 DEVIATION FROM STANDARD 83 8.1.4 TEST SETUP 83 8.1.5 EUT OPERATION CONDITIONS 83 8.1.6 TEST RESULTS 84 9 . PEAK OUTPUT POWER TEST 88 9.1 APPLIED PROCEDURES / LIMIT 88 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 88 9.1.2 TEST PROCEDURE 88 9.1.3 DEVIATION FROM STANDARD 88 9.1.4 TEST SETUP 88 9.1.5 EUT OPERATION CONDITIONS 88 9.1.6 TEST RESULTS 89 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 93 10.1 APPLIED PROCEDURES / LIMIT 93 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 93 10.1.2 TEST PROCEDURE 93 10.1.3 DEVIATION FROM STANDARD 93 10.1.4 TEST SETUP 93 10.1.5 EUT OPERATION CONDITIONS 93 10.1.6 TEST RESULTS 94 11 . EUT TEST PHOTO 106 Neutron Engineering Inc. Report No.: NEI-FICP-1-1301C323 Page 5 of 109 1. CERTIFICATION Equipment : BT500 Bluetooth Speaker Brand Name : NOOK Model Name BNA-G0001 Applicant : Beautiful Enterprise Co., Ltd. Factory : Shenzhen Synchron Electronics Co., Ltd. Address : No. 9 Mei Li Road, Xia Mei Lin, Fu Tian Area, Shenzhen, Guangdong, China Date of Test : Feb. 01, 2013 ~ Feb. 07, 2013 Test Item : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2009 FCC Public Notice DA 00-705, March 30, 2000. Canada RSS-210:2010 RSS-GEN Issue 3, Dec 2010 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FICP…
