VAV1000105USB HID dongle

Made for iPhone 3GS, iPhone 3G, iPhone, iPod touch (1st and 2nd generation), and iPad iWavit Quick Start Guide* TM * This manual is available in other languages at www.iwavit.com/Manuals.html Contents Plug-and-Play iWavit USB Dongle IR Lightbar on a magnetic base iWavit Attachment for iPhone, iPad & iPod touch Metal mounting plates Setup Step 1: Plug the iWavit™ attachment into your iPod touch, iPhone or iPad. Step 2: Go to the App Store on your iPhone and download a Wavit app. You are now ready to control infrared (IR) devices such as TV’s and Blu-ray players with your iWavit-enabled Universal IR Remote Control! Step 3: If you purchased the iWavit USB dongle and IR Lightbar, connect the cable from the Lightbar into the jack on the USB dongle. Step 4. Option A: Insert the iWavit USB Dongle into the PC or Mac that you wish to control. Step 4. Option B: Insert the USB dongle & IR Lightbar into any USB adaptor (sold separately). The dongle will now act like a wireless IR Extender. Use up to 16 in different rooms of your house if desired. B A Step 5: Place the IR Lightbar between yourself and the screen you will be viewing. For example, fasten the included metal pads with tape to your TV or the back of your PC lid or a table. This will make it easy to attach/detach the Lightbar’s magnetic mount. Now start your iWavit app and point to your screen. TV IR Lightbar YOU Position yourself in front of the Lightbar. The pointing-range is 3ft to 25ft. Do not stand closer than 3ft to the Lightbar! 3D Tracking The iWavit 3D tracking system is based on infrared (IR) light being emitted from the Lightbar. This is used by the iWavit attachment to track its own absolute pointing direction, roll angle and distance from the Lightbar. This does mean that care should be taken to avoid placing bright exposed lights near the Lightbar which could confuse the tracking system. This includes bare light bulbs and candles. Lamp shades are generally OK. When using the iWavit as a PC laser pointer, it should be noted that pointing stability varies with how steady the user’s hand is. The iWavit has a built-in dynamic anti-shake feature which greatly improves pointing stability. Nevertheless, it is good practice to lean you hand against a surface when pointing. This could be your knee, armrest on a chair, or the side of you body. Anti-shake Your iPhone has just become the Ultimate Remote Control. You can now control almost any IR device and PC/Mac/Linux or set-top box. You can even control a Windows 7 PC with voice commands (using Windows Speech Recognition). The iWavit includes patented 3D position & orientation tracking technology which allows you to simply point at the TV screen to move the cursor. Where you point is where the cursor goes! Note that no installation of software is required on the PC/Mac. The iWavit dongle is plug-and-play. You can choose from a growing number of iWavit iPhone apps that transform the iPhone into different virtual remotes, including : Getting started  3D Direct-Pointing PC Mouse  Wireless USB keyboard  Universal IR Learning Remote  Wireless PC Microphone  Business Presenter  PC Media Center Remote  IR & RF Remote for Mac  Multi-touch Trackpad ...and many more virtual remotes The iWavit Apps ThinkOptics is continually building new iWavit remote control apps which you can download from the App Store. Here are two must-have apps. Tabula Rasa & Wavit Flow Tabula Rasa is a Remote Control Editor app that allows you to create your own Virtual Remote Controls and functions and share them online with the rest of the world, if desired. You can learn IR codes or search our database of IR codes. You can also control the PC. Tabula Rasa is the "Blank Slate“ on which you can create your own master-piece remote control. The Wavit Flow app is the "One Remote To Rule Them All, and In The Darkness Bind Them". Swipe your finger across the screen to quickly thumb through cover-flow art of all your different Wavit remotes, or select ALL REMOTES to browse through all the Wavit Remotes that are currently available on the App store. iWavit On-The-Go The iWavit kit comes in a clear Executive Carrying Case. After you unpack it, you can reverse the inside paper cover (and optionally tear off the back flap). Now, when you transport your iWavit attachment, USB dongle & Lightbar, you can quickly set up by leaving the IR Lightbar inside the Case while threading the Lightbar cable out the side of the box and connecting it to the USB dongle. The Lightbar should be visible through the front window of the case. Caution: Changes or modifications not expressly approved by ThinkOptics could void the user’s authority to operate the equipment The iWavit Attachment and USB Dongle have been certified to comply with part 15C of the FCC Rules for Low Power Communications devices. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. iWavit™ Attachment and USB Dongle Model#: VAV1000105 VAV1000106 Tested to Comply with FCC Standards FOR HOME AND OFFICE USE © ThinkOptics, Inc. All rights reserved. Patents 11/187387, 11/187405, 11/187435. Assembled in South Korea. Designed by ThinkOptics in California, USA. Wavit and iWavit are trademarks of ThinkOptics, Inc. “Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. iPhone and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. iPad is a trademark of Apple Inc. App Store is a service mark of Apple Inc. www.thinkoptics.com Go to http://www.iwavit.com for a full product description…

Text truncated - open the document above for the full version.

Attestation for FCC Declaration of Conformity FCC ID: VAV1000105 Data: Aug. 5, 2010 Please be notified that we,the undersigned, ThinkOptics,Inc declares that the product which bears the above FCC ID is also compliant with the FCC requirements for Doc, The test report number supporting the DoC is SZ100819B01-EF .Testing in regards to this report was done by Compliance Certification Services Inc, located at No.81-1,Lane 210,Bade 2 nd RD.,Lujhu Township Taoyuan County,Taiwan which has been accredited in accordance to all of the requirements of 47CFR2.948(d)and(e)of the FCC rules and KDB349827 Sincerely,

Label Location

FCC Label for iWavit USB Dongle iWavit™ USB HID Dongle Tested to Comply with FCC StandardsFCC ID: VAV1000105 FOR HOME AND OFFICE USE ~30 mm ~13 mm

Atnenna location

RF Exposure Statement 1. Standard Applicable According to 1.1307 (b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a portable device. 2. Measurement Result: This is a portable device and the max average output power is -3.03 dBm (0.4977mW). The antenna gain of the device is 0dBi The EIRP of the devi ce is -3.03+0= -3.03dBm=0.4977mW Lower than the low threshold 60/f GHz = (24.37 mW),. The SAR/MPE measurement is not necessary.

FCC ID: VAV1000105 NS Technology Co., Ltd. Report No. NSE-F10075120 Page 1 of 44 FCC TEST REPORT for ThinkOptics,Inc Remote Conttoller Model Number: USB HID dongle Prepared for : ThinkOptics,Inc Address : 5568 Del Oro Dr.,San Jose,CA 94124,USA Prepared By : NS Technology Co., Ltd. Address : Chenwu Industrial Zone, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-85935656 Fax: +86-769-85991080 Report Number : NSE-F10075120 Date of Test : Jul. 5~Jul. 20, 2010 Date of Report : Jul. 23, 2010 Test Lab Cert 2951.01 FCC ID: VAV1000105 NS Technology Co., Ltd. Report No. NSE-F10075120 Page 2 of 44 TABLE OF CONTENTS Test Report Declaration Page 1. GENERAL PRODUCT INFORMATION .......................................................................... 4 1.1. Product Function ..........................................................................................................................4 1.2. Description of Device (EUT) .......................................................................................................4 1.3. Difference between Model Numbers ...........................................................................................4 1.4. Independent Operation Modes .....................................................................................................4 1.5. Test Supporting System ...............................................................................................................4 2. TEST SITES........................................................................................................................... 5 2.1. Test Facilities ...............................................................................................................................5 2.2. List of Test and Measurement Instruments ..................................................................................6 3. TEST SET-UP AND OPERATION MODES ..................................................................... 7 3.1. Principle of Configuration Selection............................................................................................7 3.2. Block Diagram of Test Set-up......................................................................................................7 3.3. Test Operation Mode and Test Software......................................................................................7 3.4. Special Accessories and Auxiliary Equipment ............................................................................7 3.5. Countermeasures to Achieve EMC Compliance..........................................................................7 4. TEST SUMMARY................................................................................................................. 8 5. EMISSION TEST RESULTS............................................................................................... 9 5.1. Conducted Emission at The Mains Terminals Test......................................................................9 5.2. Radiated Emission......................................................................................................................12 5.3. Conducted emission test data .....................................................................................................28 5.4. 6dB Bandwidth ..........................................................................................................................30 5.5. Power Spectral Density Test ......................................................................................................32 5.6. Output Power Test......................................................................................................................34 5.7. Band Edge ..................................................................................................................................35 5.8. ANTENNA REQUIREMENT ................................................................................................... 44 FCC ID: VAV1000105 NS Technology Co., Ltd. Report No. NSE-F10075120 Page 3 of 44 NS Technology Co., Ltd. Applicant: Address: ThinkOptics,Inc 5568 Del Oro Dr.,San Jose,CA 94124,USA Manufacturer: Address: Unisen Limited No. YuanJiangYuan market road,Changping Town,Donggguan City Guangdong,China E.U.T: Remote Conttoller Model Number: USB HID dongle Trade Name: ThinkOptics,Inc Operating Frequency: 2405~2480MHz Date of Receipt: Jun.28, 2010 Date of Test: Jul.5~Jul.20, 2010 Test Specification: FCC Part15C :2009 ANSI C63.4:2003 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Jul. 23, 2010 Tested by: Reviewed by: Approved by: Jade/ Engineer Iceman Hu / Supervisor Steven Lee / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products ,It is not permitted to be duplicated in extracts without written approval of NS Technology Co., Ltd. FCC ID: VAV1000105 NS Technology Co., Ltd. Report No. NSE-F10075120 Page 4 of 44 1. GENERAL PRODUCT INFORMATION 1.1. Product Function Details please refer to Technical Construction Form and User Manual. 1.2. Description of Device (EUT) E.U.T. : Remote Conttoller Model No. : USB HID dongle Operating Frequency : 2405~2480MHz Number of Channels : 16 Channels Type of Modulation : DSSS Antenna Type : Integral Antenna Gain : 0dBi System Input Voltage : DC 5V from PC input AC 120V/60Hz Temperature Range(Operating) : 0 ~+ 40°C I.R control line : Unshielded, Detachable, 1.0m 1.3. Difference between Model Numbers 1.4. Independent Operation Modes The basic operation modes are: 1.4.1 TX CH0 (2405MHz) 1.4.2. TX CH7 (2440MHz) 1.4.3. TX CH15 (2480MHz) 1.5. Test Supporting System 1.5.1. PC Model Number : 5P2PM2X Serial Number : D816CA00DC2 Manufacturer : DELL Adapter : M/N:DA90PE1-00 I/P:AC 100V~240V 50/60Hz O/P:DC 15V 2A DC Line:Unshielded, Undeta…

Text truncated - open the document above for the full version.

Set-up for conducted emission at the mains terminals test Set-up for radiated emission test (30MHz~1GHz) Set-up for radiated emission test（Above 1GHz）
