HP Roar Travel BT Speaker Model No.: SR7450 Input: 5V 2A Product No.: M1F95AA Output: 5V 2A Spare Part No.: 829156-001 FCC ID: VF6HPSR7450 IC: 11241A-HPSR7450

 Report No.: C150625B01 1/6 Internal Photos of EUT  Report No.: C150625B01 Page 2/5  Report No.: C150625B01 Page 3/5 RF Module Antenna  Report No.: C150625B01 Page 4/5  Report No.: C150625B01 Page 5/5  Report No.: C150625B01 Page 6/5

SR7450 operation schematic diagram explanation Frequency Range 2402 – 2480 MHz Modulation Techniques FHSS Number of Channels 79 Channels Antenna Specification PCB Antenna with 2.12 dBi gain (Max) Hardware Version 0730 Software Version 0730 Instruction 1. After the Bluetooth module CSR BC5-MM is matched with the Bluetooth device, CSR BC5-MM is a Bluetooth v2.1+EDR lower power Bluetooth modular, integrated 26MHz Crystal, the Bluetooth module accepts the Bluetooth audio signal VOL+/VOL- to enter the ALC5676 DSP Audio signal into the audio signal processing, the output of the output through the ALC1006. ACL5676 DSP integrated 11.2896MHz Crystal; 2. when the analog audio signal, model Bluetooth will cut off the Bluetooth module to receive audio signal, signal VOL+/VOL- and then enter the ALC5676 DSP into the audio signal processing, through the ALC1006 amplifier output audio signal 3. USB power supply BQ24295 through 5V to the battery charging, the battery to the tooth blue (3.3V) and power amplifier power supply. USB port only used as charge for the sample, cannot exchange data with PC; 4. At the same time Battery though BQ24295 output POWER USB DC5V 1A; Manufacturing tolerance Bluetooth GFSK (Average) Channel Channel 00 Channel 39 Channel 78 Target (dBm) 2.0 1.0 -1.0 Tolerance ±(dB) 1.0 1.0 1.0 8DPSK (Average) Channel Channel 00 Channel 39 Channel 78 Target (dBm) 0.0 -1.0 -2.0 Tolerance ±(dB) 1.0 1.0 1.0 π/4DQPSK (Average) Channel Channel 00 Channel 39 Channel 78 Target (dBm) 1.0 -1.0 -2.0 Tolerance ±(dB) 1.0 1.0 1.0

FCC RF Exposure FCC ID: VF6HPSR7450 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Portable Device Refer Standard: KDB 447498 D01 General RF Exposure Guidance v05r02 FCC Part 2 §2.1093 Evaluation method According to KDB447498 D01 General RF Exposure Guidance v05r01Section 4.3.1 Standalone SAR test exclusion considerations:“ Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. Conducted Power Results Bluetooth Mode Channel Frequency (MHz) Average Conducted Output Power (dBm) GFSK 00 2402 2.89 39 2441 1.16 78 2480 -1.39 8DPSK 00 2402 1.02 39 2441 -0.92 78 2480 -2.53 π/4DQPSK 00 2402 0.88 39 2441 -1.59 78 2480 -2.72 Manufacturing tolerance Bluetooth GFSK (Average) Channel Channel 00 Channel 39 Channel 78 Target (dBm) 2.0 1.0 -1.0 Tolerance ±(dB) 1.0 1.0 1.0 8DPSK (Average) Channel Channel 00 Channel 39 Channel 78 Target (dBm) 0.0 -1.0 -2.0 Tolerance ±(dB) 1.0 1.0 1.0 π/4DQPSK (Average) Channel Channel 00 Channel 39 Channel 78 Target (dBm) 1.0 -1.0 -2.0 Tolerance ±(dB) 1.0 1.0 1.0 Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT* 2.450 5 3.0 1.9953 0.6<3.0 Yes BT*-BT including BLE (lower power BT) Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v05r02. .......................End of Report.........................
