VG5RW80G2.4GHz WIRELESS LAN MODULE

RuggedCom Inc. I 30 Whitmore Road, Woodbridge, Ontario, Canada, L4L 7Z4 I www.RuggedCom.com Tel: (905) 856-5288 I Fax: (905) 856-1995 I Toll Free: (888) 264-0006 Dear FCC/TCB representative, We request “Limited Modular Approval” (LMA) for our proprietary 802.11b/g card, which will be installed exclusively by us, the Grantee, in products which we will design and manufacture. This device is a complete RF transmitter, i.e., it has its own reference oscillator (e.g., VCO), antenna, etc. The only connectors to the module, are power supply and modulation/data inputs. Compliance with FCC RF Exposure requirements is passing and is calculated in accordance with the test report, with sufficient margin. We are aware that the end device into which an authorized module is installed is not required to obtain a new authorization for the module, however this does not preclude the possibility that some other form of authorization or testing may be required for the device (e.g., a WLAN into which an authorized module is installed must still be authorized as a PC peripheral, subject to the appropriate equipment authorization). The modular transmitter does not have its own RF shielding. However, the module does not rely upon the shielding provided by the device into which it is installed in order for all modular transmitter emissions to comply with Part 15 emissions limits. Coupling between the RF circuitry of the module and any wires or circuits in the device into which the module is installed that may result in non-compliant operation, will be verified on a end-product basis. The modular transmitter has buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The modular transmitter must have its own power supply regulation. This is intended to ensure that the module will comply with Part 15 requirements regardless of the design of the power supplying circuitry in the device into which the module is installed. The modular transmitter complies with the antenna requirements of Section 15.203 and 15.204(c). The antenna employs a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The antenna to be used with the module is included with the test report. Any additional antennas will result in a Class II permissive change. The modular transmitter was tested in a stand-alone configuration, i.e., the module was not inside another device during testing. This shows that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. The transmitter module is DC powered, and is exempt from 15.207 testing. The DC power lines and data input/output lines connected to the module do not contain ferrites,. The length of these lines was extended to 10 centimeters. No accessories, peripherals, or support equipment connected was required, as the modular transmitter can operate in a stand-alone condition. The modular transmitter will be labeled with its own FCC ID number, and, if the FCC ID is not visible when the RuggedCom Inc. I 30 Whitmore Road, Woodbridge, Ontario, Canada, L4L 7Z4 I www.RuggedCom.com Tel: (905) 856-5288 I Fax: (905) 856-1995 I Toll Free: (888) 264-0006 module is installed inside another device, then the outside of the device into which the module is installed will also display a label referring to the enclosed module. This exterior label of such products will use wording such as the following: “Contains Transmitter Module FCC ID: VG5RW80G”. Included in our application is an example of this label. Internal documentation regarding the use of this module explains this requirement. As this module will be for use exclusively by the Grantee, we attest that we will retain control of this labeling and ensure this requirement is met on the end use product. The modular transmitter complies with all the specific rules or operating requirements applicable to this transmitter and we attest that we will provide adequate instructions along with the module to explain any such requirements that need to met when this modular transmitter is incorporated into another device. A copy of these internal instructions are included in the application for equipment authorization. The modular transmitter complies with any applicable RF exposure requirements, as per the test report. The end device manual will provide specific installation and operating instructions for users, installers and other interested parties to ensure compliance, such as that ‘a minimum distance of 20cm between the antenna and any person is to maintained during operation’. As the shielding requirement is not met, we request a limited modular approval. We, the grantee attest that we will retain control over the final installation of the device, such that compliance of the end product is assured. We recognize that an operating condition on the grant of equipment authorization for the module will state that the module is only approved for use when installed in devices produced by us, “RuggedCom”, the Grantee. Control of the end product(s), into which the module will be installed, will be maintained by verification of the end product(s), such that full compliance of the end product is always ensured. I the undersigned attest that I am an authorized representative of RuggedCom and attest to the above. Phil Levy, P.Eng. S/W Engineering Manager August 24 th , 2007

RuggedCom Inc. I 30 Whitmore Road, Woodbridge, Ontario, Canada, L4L 7Z4 I www.RuggedCom.com Tel: (905) 856-5288 I Fax: (905) 856-1995 I Toll Free: (888) 264-0006 Dear FCC/TCB representative, Request of Confidentiality: VG5RW80G Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying as outlined below: • Schematics (File name:CONF VG5RW80G_Schem.pdf) • Block Diagram (File name: CONF VG5RW80G_BlkDia.pdf) • Operating Description (File name: CONF VG5RW80G_OpDes.pdf) • Parts List (File name: CONF VG5RW80G_PartsLst.pdf) • User manual (Filename: CONF VG5RW80G_UsrMan.pdf) o Note: The user manual for this module is not normally available to the end user. As a limited module approval device, the user manual for this module is strictly available to specially trained staff under the employ of the Grantee. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Phil Levy, P.Eng. S/W Engineering Manager August 24 th , 2007

© Global EMC Inc. VG5RW80G Page 1 of 2 Figure 1 – Top Side © Global EMC Inc. VG5RW80G Page 2 of 2 Figure 2 – Reverse Side

© Global EMC Inc. VG5RW80G Page 1 of 2 Figure 1 – Top Side © Global EMC Inc. VG5RW80G Page 2 of 2 Figure 2 – Reverse Side

LAB REGISTRATION #6844A-1 FCC REGISTRATION #612361 Page 1 of 49 Report issue date: 8/31/2007 GEMC File #:GEMC790060-Rev1 © Global EMC Inc. This test report shall not be reproduced except in full, without written approval of Global EMC Inc. This report is based on GEMC Template “FCC 15 247 Rev2.” Global EMC Inc. Labs EMC & RF Test Report As per RSS 210 Issue 7:2007 & FCC Part 15 Subpart C:2006 Unlicensed Intentional Radiators on the RW80G – WiFi Module Scott Drysdale, Narte Certified Technician EMC Lab Manager Global EMC Inc. 180 Brodie Dr, Unit 2 Richmond Hill, ON L4B 3K8 Canada Ph: (905) 883-3919 Testing produced for See Appendix A for full customer & EUT details . Client RuggedCom Product RW80G – WiFi Module Standard(s) RSS 210 Issue 7:2007/ FCC Part 15 Subpart C 15:2006 Page 2 of 49 Report issue date: 8/31/2007 GEMC File #: GEMC-790060 Rev 1 © Global EMC Inc. This test report shall not be reproduced except in full, without written approval of Global EMC Inc. Table of Contents Table of Contents ...................................................................................................................2 Report Scope ..........................................................................................................................3 Summary ................................................................................................................................4 Test Results Summary .......................................................................................................5 Justifications, Descriptions, or Deviations.........................................................................6 Applicable Standards, Specifications and Methods...........................................................7 Sample calculation(s).........................................................................................................8 Document Revision Status .................................................................................................8 Definitions and Acronyms .....................................................................................................9 Testing Facility ....................................................................................................................10 Calibrations and Accreditations .......................................................................................10 Testing Environmental Conditions and Dates .................................................................11 Detailed Test Results Section ..............................................................................................12 Spurious Radiated Emissions...........................................................................................13 6 dB Bandwidth of Digitally Modulated Systems ...........................................................26 Maximum Peak Envelope Conducted Power ..................................................................29 Spurious Conducted Emissions........................................................................................32 Power Spectral Density....................................................................................................38 Maximum Permissible Exposure .....................................................................................41 Appendix A – EUT Summary..............................................................................................43 Appendix B – EUT and Test Setup Photographs.................................................................44 Client RuggedCom Product RW80G – WiFi Module Standard(s) RSS 210 Issue 7:2007/ FCC Part 15 Subpart C 15:2006 Page 3 of 49 Report issue date: 8/31/2007 GEMC File #: GEMC-790060 Rev 1 © Global EMC Inc. This test report shall not be reproduced except in full, without written approval of Global EMC Inc. Report Scope This report addresses the EMC verification testing and test results of the <EUT>, herein referred to as EUT (Equipment Under Test) performed at Global EMC Labs. The EUT was tested for compliance against the following standards: RSS 210 Issue 7:2007 / FCC Part 15 Subpart C 15:2006 Test procedures, results, justifications, and engineering considerations, if any, follow later in this report. The results contained in this report relate only to the item(s) tested. This report does not imply product endorsement by A2LA or any other accreditation agency, any government, or Global EMC Inc. Opinions/interpretations expressed in this report, if any, are outside the scope of Global EMC Inc accreditation. Any opinions expressed do not necessarily reflect the opinions of Global EMC Inc, unless otherwise stated. Client RuggedCom Product RW80G – WiFi Module Standard(s) RSS 210 Issue 7:2007/ FCC Part 15 Subpart C 15:2006 Page 4 of 49 Report issue date: 8/31/2007 GEMC File #: GEMC-790060 Rev 1 © Global EMC Inc. This test report shall not be reproduced except in full, without written approval of Global EMC Inc. Summary The results contained in this report relate only to the item(s) tested. EUT FCC Certification #, FCC ID: VG5-RW80G EUT Industry Canada Certification #, IC: 4997A-VG5RW80G EUT Passed all tests performed. Yes (see test results summary) Tests conducted by Scott Drysdale Client RuggedCom Product RW80G – WiFi Module Standard(s) RSS 210 Issue 7:2007/ FCC Part 15 Subpart C 15:2006 Page 5 of 49 Report issue date: 8/31/2007 GEMC File #: GEMC-790060 Rev 1 © Global EMC Inc. This test report shall not be reproduced except in full, without written approval of Global EMC Inc. Test Results Summary Standard/Method Description Class/Limit Result FCC 15.203 Antenna Requirement Unique Pass See Justification FCC 15.205 RSS 210 (Table 1) Restricted Bands for intentional operation None within chart Pass See description FCC 15.207 Power line conducted emissions QuasiPeak Average Pass See Justification FCC 15.209 RSS-210 (Table 2) Spurious Radiated emissions QuasiPeak Average Pass FCC 15.247(a)2 RSS-210 A8.2(a) 6 …

Text truncated - open the document above for the full version.

Figure 1 - Radiated Emissions Setup © Global EMC Inc. VG5RW80G Page 1 of 5 Figure 2 - Radiated Emissions Setup © Global EMC Inc. VG5RW80G Page 2 of 5 Figure 3 – Radiated Emissions Setup © Global EMC Inc. VG5RW80G Page 3 of 5 Figure 4 – Power Measurement Setup © Global EMC Inc. VG5RW80G Page 4 of 5 Figure 5 – Antenna Conducted Emissions Setup © Global EMC Inc. VG5RW80G Page 5 of 5
