8.2 Function menu Click in Main Menu to enter function menu 8.3 Widget 8.4 Operation background Click to look into background operation situation. 9.Battery management and charging A.Before first operation, the unit should be recharged for 5~6 hours to make sure the battery is fully charged. B.Connect the Power adapter to the device; the battery icon on desktop displays as[ ], and green bar is rolling, which means the device is charging. Don't unplug the charger in charging. After fully charged, the battery icon on desktop displays as[ ], and the green bar stops rolling. Note: Lithium battery doesn’t need to recharge after power fully runs out. 10.3 IP address setting and connecting: two ways A. Auto Obtain IP address: System default is IP address auto obtaining, click the target network name, input password if it is required to, click “KW” network as picture below to pop up Password Input Window; input right password, and click it; after through KW network's verification, system will auto obtain IP address from KW network, as shown in figure below: 10.2 WIFI setting and WIFI network Click ”Scan”, system will search WIFI network automatically, and display signal strength. B. Manually Obtain IP address: Place a check mark in “Advanced”, and select “Static” in“IP setting”; click “connect” and the setting will be effective. Disclaimer: We try to ensure its correctness and integrity manual, but it is hard to avoid any mistake and omission. Please take material object as the standard. Our company is derelict of duty for mistake and omission that may exist. of the User's Manual 7 891011 11.WIFI setup 11.1 Turn on WIFI Click to enter setup menu, select “On” in Wi-Fi option, as shown in figure below: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 10.Operation Guide for Bluetooth: 1.Enter into the Setting Menu, find out Bluetooth, turn it on (move the button of “OFF” to right side “ON”). 2.Click the “SEARCH FOR DEVICES” on the right-top side of the window, waiting for a few seconds, then the scanned Bluetooth Devices will be listed, click the proper device. 3.Click “Pair”, after pairing, then the files can be transferred by Bluetooth. 12.Technical Specifications Panel Size: Panel Resolution: Touch Panel Type: CPU: Operating System: RAM: Flash: External Storage: Built-in Speaker: WIFI: G-sensor: Power Input: Battery: Product Size: Device Weight: 8 inch Widescreen 1280x768 Pixels 5-point Capacitive Touch Panel ARM Cortex A9 Dual-core, Frequency 1.5GHz max, 512K L2 Cache Google Android 4.2 1G 8G Nand Flash Micro SD Card (Max 32GB) USB OTG(a. connect to PC for data transfer; b. Connect to USB Stick via the USB Host Cable.) Stereo Speaker 8ohm x 1 (1W) IEEE 802.11b/g/n 3(X/Y/Z )Axis AC 110~240V 50/60Hz; DC 5V/2.0A Model No. of Power adapter: PA010B-05020EU Lithium Polymer Battery 5000mAh 3.7V Model No. of Power adapter: BP4362157 213x138.5x11.2mm(L x W x H) Approx. 490g This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The portable device is designed to meet the requirements for exposure to radio waves established by the Federal Communications Commission (USA). These requirements set a SAR limit of 1.6 W/kg averaged over one gram of tissue. The highest SAR value reported under. this standard during product certification for use when properly worn on the body is 0.550 W/kg. 1. Accessory list Power adapter-----------------------------------------------1 pc User’s manual-----------------------------------------------1 pc USB cable----------------------------------------------------1 pc USB Host Converter Adapter Cable ---------------------1 pc 2. Mainframe introduction 3. Interface introduction Micro SD: insert Micro SD card; MIC: can do record and chat on line by third-party software; Earphone: connect to earphone to output stereo; USB OTG: a, connect to PC to transfer data; b, connect to USB flash drive , HDD or others through USB Host Cable, (External power is needed.); c, connect to USB power adapter or PC to charge the device; HDMI: HD output; can connect …

Text truncated - open the document above for the full version.

Qingyuan Gadmei Electronics Technology Co., Ltd. Statement We, Qingyuan Gadmei Electronics Technology Co., Ltd. certify the product: Tablet,Tablet PC,Android Tablet PC And Model No.: E8-3D, F8-3D, N8-3D, 3D-M8, TL803D, DP3D8, X81-8G3D, MiTraveler 3D-8, T8004 we provided the label of model：E8-3D for this FCC certification. The labels for the rest of models are same to the label of model：E8-3D we provided Only the model No. is different. By: ______Victor _Huang________ (Signature 1 ) (Print name) Title: ______Manager_ On behalf of: Qingyuan Gadmei Electronics Technology Co., Ltd._____ (Company Name) Telephone: _______+86 (0)763 3699 999___________________

Qingyuan Gadmei Electronics Technology Co., Ltd. Request for Confidentiality Date: 2013-4-22 Subject: Confidentiality Request for: FCC ID: VHH-E8-3DTL803D Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operational Description/Theory of Operation Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ Qingyuan Gadmei Electronics Technology Co., Ltd. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify PHOENIX in the event information regarding the product or the product is made available to the public. PHOENIX will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Victor Huang (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate

Qingyuan Gadmei Electronics Technology Co., Ltd. Statement We, the under signed, Qingyuan Gadmei Electronics Technology Co., Ltd. declared that, our product : Tablet, Tablet PC, Android Tablet PC, model No.: E8-3D, F8-3D, N8-3D, 3D-M8, TL803D, DP3D8, X81-8G3D, MiTraveler 3D-8, T8004 have been tested by SGS IECC Limited Located in Units 303-305, 3/F., 31 Lok Yip Road, On Lok Tsuen, Fanling, N.T., Hong Kong . Regards It is in compliance with conducted and radiated emission limits of FCC Rules Part 15B. Signature: Printed signature: Victor Huang On behalf of Qingyuan Gadmei Electronics Technology Co., Ltd. Date :2013-4-14

Qingyuan Gadmei Electronics Technology Co., Ltd. Statement We, Qingyuan Gadmei Electronics Technology Co., Ltd. declare that this EUT (FCC ID: VHH-E8-3DTL803D) doesn’t have ad Hoc Mode function on “non-US/Canada frequencies“. In addition, the frequency selection feature is disabled by firmware for devices marketed to the US/ Canada. For DTS part of this device, only channels 1-11 will be used in North America. Country code selection is disabled. Should you have any questions or comments regarding this matter, Please have my best attention. Sincerely yours, Signature: Printed signature: Victor Huang On behalf of Qingyuan Gadmei Electronics Technology Co., Ltd. Date :2013-4-14

1 Photographs - EUT Constructional Details Test model No.: E8-3D Adapter:

Label size：5CM*2.5CM FCC ID: VHH-E8-3DTL803D（size：2.8CM*0.3CM）

1 Photographs - EUT Constructional Details Test model No.: E8-3D Adapter:

SGS-CSTC Standards Technical Services Ltd. No. 1 W orkshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEM130300099602 Page: 1 of 75 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1 Cover page FCC REPORT Application No: SZEM1303000996RF Applicant: Qingyuan Gadmei Electronics Technology Co., Ltd. Manufacturer: Qingyuan Gadmei Electronics Technology Co., Ltd. Factory: Qingyuan Gadmei Electronics Technology Co., Ltd. Product Name: Tablet, Tablet PC, Android Tablet PC Model No.(EUT): E8-3D Add Model No.: F8-3D, N8-3D, 3D-M8, TL803D, DP3D8, X81-8G3D, MiTraveler 3D-8, T8004 Trade Mark: GADMEI FCC ID: VHH-E8-3DTL803D Standards: 47 CFR Part 15, Subpart C (2011) Date of Receipt: 2013-03-08 Date of Test: 2013-03-13 to 2013-03-30 Date of Issue: 2013-04-07 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM130300099602 Page: 2 of 75 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10 (2009) PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10 (2009) PASS Conducted Peak Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(1) ANSI C63.10 (2009) PASS 20dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Carrier Frequencies Separation 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Hopping Channel Number 47 CFR Part 15, Subpart C Section 15.247 (b) ANSI C63.10 (2009) PASS Dwell Time 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Pseudorandom Frequency Hopping Sequence 47 CFR Part 15, Subpart C Section 15.247(b)(4)&TCB Exclusion List (7 July 2002) ANSI C63.10 (2009) PASS Band-edge for RF Conducted Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2009) PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2009) PASS Radiated Spurious emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2009) PASS Band Edge (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2009) PASS Remark: Model No.: E8-3D, F8-3D, N8-3D, 3D-M8, TL803D, DP3D8, X81-8G3D, MiTraveler 3D-8, T8004 Only the model E8-3D was tested, since the circuit design, PCB layout, electrical components used, internal wiring and functions were identical for the above models, with difference being model No., color, plastic e…

Text truncated - open the document above for the full version.

1 Photographs - EUT Test Setup (Test model No.: E8-3D) 1.1 Conducted Emission 1.2 Radiated Emission
