VPX-3160-25AWiMAX Subscriber Station

STARMAX Rev.001 3100 Series Subscriber Station User Manual 260-668104-001 TM StarMAX™ 3100 Series Subscriber Station User Manual iiAVIAT NETWORKS StarMAX™ 3100 Series Subscriber Station User Manual 260-668104-001 MARCH 2010 This manual incorporates features and functions provided with the StarMAX™ 3100 Series, Release 4.1.1. Copyright © 2010 by Aviat Networks, Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Aviat Networks Inc. To request permission, contact [email protected]. Warranty Aviat Networks makes no representation or warranties with respect to the contents hereof and specifically disclaims any implied warranties or merchantability or fitness for any particular purpose. Further, Aviat Networks reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Aviat Networks to notify any person of such revision or changes. Safety Recommendations The following safety recommendations must be considered to avoid injuries to persons and/or damage to the equipment: 1.Installation and Service Personnel: Installation and service must be carried out by authorized personnel who have the technical training and experience necessary to be aware of any hazardous operations during installation and service, and of measures to avoid any danger to themselves, to any other personnel, and to the equipment. 2.Access to the Equipment: Access to the equipment in use must be restricted to service personnel only. 3.Safety Norms: Local safety regulations must be used if mandatory. Safety instructions in this document should be used in addition to the local safety regulations. In the case of conflict between safety instructions stated in this manual and those indicated in local regulations, mandatory local norms will prevail. 4.Service Personnel Skill: Service personnel must have received adequate technical training on telecommunications and in particular on the equipment this manual refers to. Trademarks All trademarks are the property of their respective owners. 260-668104-001 REV 01 MARCH 2010iii STARMAX™ 3100 SERIES SUBSCRIBER STATION USER MANUAL Contact Information Sales and Sales Support: For sales information, contact one of the Aviat Networks headquarters, or find your regional sales office at http:// www.aviatnetworks.com/contact-us/sales/. Customer Service: For customer service, contact one of the regional Technical Help Desks listed below. Or you can contact your local Aviat Networks office. Contact information is available on our website at: www.aviatnetworks.com/contact-us/locations-worldwide/. Corporate Headquarters North Carolina, USA International Headquarters Singapore Aviat Networks, Inc. Research Triangle Park 637 Davis Drive Morrisville, North Carolina 27560 United States Phone: + 1 919-767-3230 Fax: + 1 919-767-3233 Aviat Networks (S) Pte. Ltd. 17, Changi Business Park Central 1 Honeywell Building, #04-01 Singapore 486073 Phone: +65 6496 0900 Fax: + 65 6496 0999 Americas Technical Help Desk EMEA Technical Help DeskAsia Pacific Technical Help Desk Phone:+1 210 561 7400 Toll-free in Canada/US: +1 800 227 8332 Fax:+1 210 561 7399 Phone:+44 1698 714 073 Fax:+44 1698 717 204 Phone:+63 45 599 5192 Fax:+63 45 599 5196 [email protected] [email protected]@aviatnet.com ivAVIAT NETWORKS FCC Notices 1.The StarMAX Subscriber Station must be professionally installed and maintained. 2.This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. 3.Notes specific to the 3.65 - 3.675GHz band: • The StarMAX 3160-37 Subscriber Station complies with FCC CFR47, Part 90, Subpart Z. • For FCC CFR47, Part 90, Subpart Z, StarMAX operation is restricted to the 25MHz band 3.65GHz - 3.675GHz. • To ensure compliance with the FCC RF exposure requirements, a minimum distance of 25cm must be maintained between the subscriber station antenna and any persons whilst the unit is operational at 5MHz and 34cm for 10MHz operation. This calculation is based on the EIRP limits within Part 90, Subpart Z. • The 3160-37 Subscriber Station has been tested and certified to FCC CFR47, Part 90, Subpart Z with an integral antenna with a gain of 14dBi. • FCC CFR47, Part 90, Subpart Z, applies strict limitations on EIRP. 5MHz operation has an EIRP limit of 5W and 10MHz operation has an EIRP limit of 10W. The StarMAX Subcriber Station is not field programmable so the power is set during production. Model 3160-37-14-05 should be used for all installations within the United States. 4.Notes specific to the 2.496 - 2.69GHz band: • The 3160-25 Subscriber Station has been tested and certified to FCC CFR47, Part 27 with an integral antenna with a gain of 12dBi. • To ensure compliance with the FCC exposure requirements, a minimum distance of 34cm must be maintained between the subscriber station antenna and any persons whilst the unit is operational. 260-668104-001 REV 01 MARCH 2010v STARMAX™ 3100 SERIES SUBSCRIBER STATION USER MANUAL WARNING Making adjustments and/or modifications to this equipment that are not in accordance with the provisions of this instruction manual or other supple- mentary documentation may result in personal injury or damage to the equipment, and may void the equipment warranty. AVERTISSEMENT Tout réglage ou modification faits à cet équipement hors du cadre édicté par ce guide d’utilisation ou par toute autre documentation supplémentaire pourraient causer des blessures ou endommager l’équipement et peut entraîner l’annulation de sa garantie. WARNUNG Die an diesen Geräten gemachte Einstellungen und/oder Änderungen, welche nicht gemäß dieser Bedienungsanleitung, oder gemäß anderen zusätzlichen Anleitungen, ausg…

Text truncated - open the document above for the full version.

16 March, 2010 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality for VPX-3160-25A Aviat Networks requests according to FCC 47 CFR 0.459 that the following items are held permanently confidential and from public view: Block diagrams All schematic diagrams Parts list Tune-up information Operational description These items contain proprietary information that represents considerable investment on the part of Aviat Networks. Public disclosure of this information would be damaging for Aviat Networks due to the competitive nature of our industry. Ruth French Product Compliance Manager

StarMAX 3160 External photographs – Six sides Photograph 1 Photograph 2 Photograph 3 Photograph 4 Photograph 5 Photograph 6

Labels for VPX-3160-25A 3160-25 Compliance Label: Compliance label location on the unit: 25A Compliance label location on the unit: Product label for the 3160-25: Product label location:

March, 2010. FCC application VPX-3160-25A StarMAX 3160-25 Internal Photographs March, 2010. FCC application VPX-3160-25A March, 2010. FCC application VPX-3160-25A March, 2010. FCC application VPX-3160-25A

MPE CALCULATION REPORT FROM RFI GLOBAL SERVICES LTD Evaluation of: Harris Stratex Networks StarMax 3160 Series 2.5 to 2.7GHz WiMax™ SS To: FCC OET Bulletin 65 Report Serial No: RFI/REGA3/TP75361D01E This Test Plan Is Issued Under The Authority Of Nick Hooper, Head of Inspection Written By: John Bellairs Checked By: Tony Henriques Report Copy No: PDF01 Issue Date: 01 April 2010 This report may be reproduced in full. Partial reproduction may only be made with the written consent of RFI Global Services Ltd. This report is produced on the basis of our understanding of the information supplied. If our understanding of the information supplied is incorrect, this may affect the response given. In the event that our understanding of the matter is incorrect, you should not place any reliance up on it until you have advised the correct nature of the problem and we have been able to reconsider the matter. This report is issued in Portable Document Format (PDF) and may only be copied in full. RFI GLOBAL SERVICES LTD MPE CALCULATION REPORT S.No. RFI/REGA3/TP75361D01E Page: 2 of 8 Issue Date: 01 April 2010 For: Harris Stratex Networks Product: StarMax 3160 Series 2.5 to 2.7GHz WiMax™ SS This page has been left intentionally blank. RFI GLOBAL SERVICES LTD MPE CALCULATION REPORT S.No. RFI/REGA3/TP75361D01E Page 3 of 8 Issue Date: 01 April 2010 For: Harris Stratex Networks Product: StarMax 3160 Series 2.5 to 2.7GHz WiMax™ SS Table of Contents 1. Client Information........................................................................................................... 4 2. Equipment Under Evaluation......................................................................................... 5 3. Applicable FCC Rule Parts: ........................................................................................... 6 4. MPE Calculation for the StarMax 3160 SS .................................................................... 6 5. Conclusion...................................................................................................................... 7 RFI GLOBAL SERVICES LTD MPE CALCULATION REPORT S.No. RFI/REGA3/TP75361D01E Page: 4 of 8 Issue Date: 01 April 2010 For: Harris Stratex Networks Product: StarMax 3160 Series 2.5 to 2.7GHz WiMax™ SS 1. Client Information Company Name: Harris Stratex Networks Address: 4 Bell Drive Hamilton International Technology Park Blantyre G72 0FB, Scotland Contact Name: Ms R French RFI GLOBAL SERVICES LTD MPE CALCULATION REPORT S.No. RFI/REGA3/TP75361D01E Page 5 of 8 Issue Date: 01 April 2010 For: Harris Stratex Networks Product: StarMax 3160 Series 2.5 to 2.7GHz WiMax™ SS 2. Equipment Under Evaluation The following information has been supplied by the client: 2.1. Identification of Equipment Under Evaluation Brand Name: Harris Stratex Networks. Model Name or Number: StarMax 3160 Series FCC ID: VPX-3160-25A Equipment Category: WiMax™ Subscriber Station Serial Number: No specific equipment Frequency of Operation: 2.5 – 2.7GHz. Transmitting Power: +28dBm Antenna Gain +12dBi maximum Channel Bandwidth: 5 and 10MHz Duplex Method TDD Max. TDD TX Duty Cycle 74% 2.2. Description of EUT The equipment under evaluation is the Harris Stratex StarMax 3160 Series WiMax™ SS. This evaluation covers operation at 2.5 - 2.7GHz. The StarMax WiMax™ 3160 SS can utilises single antenna operation and is intended to be used in fixed outdoor installations. Antenna gain details have been supplied by Harris Stratex. RFI GLOBAL SERVICES LTD MPE CALCULATION REPORT S.No. RFI/REGA3/TP75361D01E Page: 6 of 8 Issue Date: 01 April 2010 For: Harris Stratex Networks Product: StarMax 3160 Series 2.5 to 2.7GHz WiMax™ SS 3. Applicable FCC Rule Parts: Part 27.52. Licensees and manufacturers are subject to the radio frequency radiation exposure requirements specified in sections 1.1307(b), 2.1091, and 2.1093. Part 1.1310. Radiofrequency radiation exposure limits. Part 27.50(h)(1).Main, booster and base stations. (i) The maximum EIRP of a main, booster or base station shall not exceed 33 dBW + 10log(X/Y) dBW, where X is the actual channel width in MHz and Y is either 6 MHz if prior to transition or the station is in the MBS following transition or 5.5 MHz if the station is in the LBS and UBS following transition, except as provided in paragraph (h)(1)(ii) of this section. (ii) If a main or booster station sectorizes or otherwise uses one or more transmitting antennas with a non-omnidirectional horizontal plane radiation pattern, the maximum EIRP in dBW in a given direction shall be determined by the following formula: EIRP = 33 dBW + 10 log(X/Y) dBW + 10 log(360/beamwidth) dBW, where X is the actual channel width in MHz, Y is either (i) 6 MHz if prior to transition or the station is in the MBS following transition or (ii) 5.5 MHz if the station is in the LBS and UBS following transition, and beamwidth is the total horizontal plane beamwidth of the individual transmitting antenna for the station or any sector measured at the half-power points. 4. MPE Calculation for the StarMax 3160 SS Maximum antenna gain specified is 12.0dBi Maximum transmitter power specified is 28dBm (0.63W) At 0.63W and 74% TDD duty cycle: P = 0.63 x 0.74 = 0.47 W 4.1 Calculation for 2.5 – 2.7GHz. From FCC Rule Part 1.1310 table 1 (b) - Limits for General Population/ Uncontrolled Exposure: S = 1.0 mW/cm 2 The MPE calculation as given in FCC OET Bulletin 65, page 19 is used to calculate the safe operating distance for the user. S = EIRP/4 π R 2 RFI GLOBAL SERVICES LTD MPE CALCULATION REPORT S.No. RFI/REGA3/TP75361D01E Page 7 of 8 Issue Date: 01 April 2010 For: Harris Stratex Networks Product: StarMax 3160 Series 2.5 to 2.7GHz WiMax™ SS Where S = Power density EIRP = Effective Isotropic Radiated Power (EIRP = P x G) P = Conducted Transmitter Power G = Antenna Gain (relative to an isotropic radiator) R = distance to the centre of radiation of the antenna Values for StarMax 3160 SS : P = 0.47W G = 12.0dBi (15.85) S = 1.0 mW/cm 2 S = EIRP/4 π R 2…

Text truncated - open the document above for the full version.

26 March, 2010 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Response to OET Correspondence Numbers 82741, 82742, 82744 Aviat Networks submits information in relation to the abovementioned correspondence numbers. The StarMAX 3160 Series is WiMAX Forum compliant terminal station (IEEE802.16-2005 standard based). The WiMAX Forum has created standard TDD system profiles where the DL:UL split ratios are specified. The DL:UL ratio range (in symbols, total amount of symbols in one 5ms air frame is 47) for 5MHz and 10MHz channel BW is between 35:12 and 26:21. The first 3 symbols in the UL are used for ranging and transmission of various feedback messages that are communicated with a relatively low duty cycle (every few 5ms frames) and minimum power on just few subchannels (3-10% of bandwidth) – so the terminal station TX duty cycle range is between 19% (9/47) and 38% (18/47). For particular applications the required DL:UL ratio could be very low and outside WiMAX Forum system profile values. Extreme DL:UL ratio supported by StarMAX 3160 Series is 11:36 which translates to 70% (33/47) TX duty cycle. Ruth French Product Compliance Manager

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: StarMAX 3160-25 Subscriber Station To: FCC Part 27: 2009 Subpart C Test Report Serial No: RFI-RPT-RP76313JD01A_V3.0 Version 3.0 supersedes all previous versions This Test Report Is Issued Under The Authority of Brian Watson, COO Payments and Consultancy: pp Checked By: R. Graham Signature: Date of Issue: 31 March 2010 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI-RPT-RP76313JD01A_V3.0 VERSION NO. 3.0 ISSUE DATE: 31 MARCH 2010 Page 2 of 73 RFI Global Services Ltd This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI-RPT-RP76313JD01A_V3.0 VERSION NO. 3.0 ISSUE DATE: 31 MARCH 2010 RFI Global Services Ltd Page 3 of 73 Table of Contents 1. Customer Information .................................................................................................................. 4 2. Summary of Testing ..................................................................................................................... 5 3. Equipment Under Test (EUT) ....................................................................................................... 6 4. Operation and Monitoring of the EUT during Testing ............................................................... 9 5. Measurements, Examinations and Derived Results ................................................................ 10 6. Measurement Uncertainty .......................................................................................................... 72 Appendix 1. Test Equipment Used ................................................................................................73 TEST REPORT SERIAL NO: RFI-RPT-RP76313JD01A_V3.0 VERSION NO. 3.0 ISSUE DATE: 31 MARCH 2010 Page 4 of 73 RFI Global Services Ltd 1. Customer Information Company Name: Aviat Networks Address: 4 Bell Drive Hamilton International Technology Park Blantyre Glasgow G72 0FB United Kingdom TEST REPORT SERIAL NO: RFI-RPT-RP76313JD01A_V3.0 VERSION NO. 3.0 ISSUE DATE: 31 MARCH 2010 RFI Global Services Ltd Page 5 of 73 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR27 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2009: Part 27 Subpart C (Miscellaneous Wireless Communication Services) Site Registration: FCC: 209735 Location of Testing: RFI Global Services Ltd, Wade Road, Basingstoke, Hampshire, RG24 8AH. Test Dates: 08 March 2010 to 18 March 2010 2.2. Summary of Test Results FCC Reference (47CFR) Measurement Result Part 15.107 Idle Mode AC Conducted Spurious Emissions Part 15.109 Idle Mode Radiated Spurious Emissions Part 15.207 Transmitter AC Conducted Spurious Emissions Parts 2.1046 & 27.50(h)(2) Transmitter Carrier Output Power Part 2.1049 Transmitter Occupied Bandwidth Parts 2.1055 & 27.54 Transmitter Frequency Stability (Temperature Variation) Parts 2.1055 & 27.54 Transmitter Frequency Stability (Voltage Variation) Parts 2.1051 & 27.53 Transmitter Conducted Emissions Parts 2.1051 & 27.53 Transmitter Band Edge Conducted Emissions Parts 2.1051 & 27.53 Transmitter Radiated Spurious Emissions Parts 2.1051 & 27.53 Transmitter Band Edge Radiated Emissions Key to Results = Complied = Did not comply 2.3. Methods and Procedures Reference: ANSI/TIA-603-C-2004 Title: Land Mobile Communications Equipment, Measurements and performance Standards Reference: ANSI C63.4 (2003) Title: American National Standard Methods of Measurement of Electromagnetic Emissions from Low Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: RFI-RPT-RP76313JD01A_V3.0 VERSION NO. 3.0 ISSUE DATE: 31 MARCH 2010 Page 6 of 73 RFI Global Services Ltd 3. Equipment Under Test (EUT) 3.1. Identification of Equipment Under Test (EUT) Description: WiMAX subscriber unit Brand Name: Aviat Networks Model Name or Number: 3160-25-12-05 Serial Number: TSS40340900031 MAC Address: 00:02:73:00:12:2F System Hardware Version: REV-B Software Kernal Version: 20091120 Software Application Version: 20091120 Build Revision: Trunk/14453 Boot Loader Version: 20091120 FCC ID Number: VPX-3160-25A 3.2. Description of EUT The equipment under test was a WiMAX subscriber unit. 3.3. Modifications Incorporated in the EUT No modifications were applied to the EUT during testing. TEST REPORT SERIAL NO: RFI-RPT-RP76313JD01A_V3.0 VERSION NO. 3.0 ISSUE DATE: 31 MARCH 2010 RFI Global Services Ltd Page 7 of 73 3.4. Additional Information Related to Testing Category of Equipment: User station Type of Radio Device: WiMAX Transceiver Modulation Type: QPSK 16QAM 64QAM Coding Scheme: 1/2 CTC 3/4 CTC 1/2 CTC 3/4 CTC 2/3 CTC 3/4 CTC 5/6 CTC Channel Spacing: 5 MHz and 10MHz Frequency Range: 2496MHz to 2690MHz Nominal 110.0 VAC Minimum 93.5 VAC Power Supply Requirement(s): Maximum 126.5 VAC Channel ID Channel Frequency (MHz) Bottom 2498.5 Middle 2600.0 5 MHz Transmit Channels Tested: Top 2687.5 Channel ID Channel Frequency (MHz) Bottom 2498.5 Middle 2600.0 5 MHz Receive Channels Tested: Top 2687.5 Channel ID Channel Frequency (MHz) Bottom 2501 Middle 2600 10 MHz Transmit Channels Tested: Top 2685 Channel ID Channel Frequency (MHz) Bottom 2501 Middle 2600 10 MHz Receive Channels Tested: Top 2685 TEST REPORT SERIAL NO: RFI-RPT-RP76313JD01A_V3.0 VERSION NO. 3.0 ISSUE DATE: 31 MARCH 2010 Page 8 of 73 RFI Global Services Ltd 3.5. Suppor…

Text truncated - open the document above for the full version.

18 March, 2010. FCC application VPX-3160-25A StarMAX 3160-25 Set-up Photographs AC Conducted and Radiated Testing 18 March, 2010. FCC application VPX-3160-25A 18 March, 2010. FCC application VPX-3160-25A 18 March, 2010. FCC application VPX-3160-25A
