VPX-8200-26ABase Station

Digital Radios 260-668107-001 StarMAX™ 6000 SERIES MOBILE BASE STATIONS USER MANUAL StarMAX™ 6000 Series Mobile Base Stations User Manual Rel. 4.1.1 (GA Preliminary Draft) iiHarris Stratex Networks StarMAX™ 6000 Series Mobile Base Stations User Manual 260-668107-001 October 2009 This manual incorporates features and functions provided with the StarMAX™ 6000 Series, Release 4.1.1. (GA Preliminary Draft). Copyright © 2009 by Harris Stratex Networks, Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Harris Stratex Networks Inc. To request permission, contact [email protected] . Warranty Harris Stratex Networks makes no representation or warranties with respect to the contents hereof and specifically disclaims any implied warranties or merchantability or fitness for any particular purpose. Further, Harris Stratex Networks reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Harris Stratex Networks to notify any person of such revision or changes. Safety Recommendations The following safety recommendations must be considered to avoid injuries to persons and/or damage to the equipment: 1.Installation and Service Personnel: Installation and service must be carried out by authorized personnel who have the technical training and experience necessary to be aware of any hazardous operations during installation and service, and of measures to avoid any danger to themselves, to any other personnel, and to the equipment. 2.Access to the Equipment: Access to the equipment in use must be restricted to service personnel only. 3.Safety Norms: Local safety regulations must be used if mandatory. Safety instructions in this document should be used in addition to the local safety regulations. In the case of conflict between safety instructions stated in this manual and those indicated in local regulations, mandatory local norms will prevail. 4.Service Personnel Skill: Service personnel must have received adequate technical training on telecommunications and in particular on the equipment this manual refers to. Trademarks All trademarks are the property of their respective owners. 260-668107-001 October 2009iii StarMAX™ 6000 Series Mobile Base Stations User Manual Contact Information Sales and Sales Support: For sales information, contact one of the Harris Stratex Networks headquarters, or find your regional sales office at http://www.harrisstratex.com/contact. Customer Service: For customer service, contact one of the regional Technical Help Desks listed below. Or you can contact your local Harris Stratex Networks office. Contact information is available on our website at: www.harrisstratex.com/support/customer/. Corporate Headquarters North Carolina, USA International Headquarters Singapore Harris Stratex Networks, Inc. Research Triangle Park 637 Davis Drive Morrisville, North Carolina 27560 United States Phone: + 1 919-767-3230 Fax: + 1 919-767-3233 Toll Free for Sales Inquiries: + 1 888-HSTX-NOW (888-478-9669) Harris Stratex Networks (S) Pte. Ltd. 17, Changi Business Park Central 1 Honeywell Building, #04-01 Singapore 486073 Phone: +65 6496 0900 Fax: + 65 6496 0999 Sales Inquiries: +1-321-674-4252 Americas Technical Help Desk EMEA Technical Help DeskAsia Pacific Technical Help Desk Harris Stratex Networks 120 Rose Orchard Way San Jose, CA 95134 U.S.A. Harris Stratex Networks 4 Bell Drive Hamilton International Technology Park Blantyre, Glasgow, Scotland G72 0FB United Kingdom Harris Stratex Networks Bldg 10, Units A&B Philexcel Industrial Park M. Roxas Hi-way Clark Freeport Zone Philippines 2023 Phone:+1 210 561 7400 Toll-free in US: +1 800 227 8332 Fax:+1 408 944 1683 Phone:+44 1698 714 073 Fax:+44 1698 717 204 Phone:+63 45 599 5192 Fax:+63 45 599 5196 [email protected] [email protected]@hstx.com ivHarris Stratex Networks FCC Notices 1.The StarMAX Base Station must be professionally installed and maintained. 2. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential environment is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. 3. Notes specific to the 2.496 – 2.69GHz band: •The StarMAX Base Station (radio model 8200-26, range 2.583-2.690) is compliant with FCC CFR47, Part 27. •To ensure compliance with the FCC RF exposure requirements, a minimum distance of 3.72 meters must be maintained between the base station antenna and any persons whilst the unit is operational. This calculation is based on the maximum conducted power and maximum antenna gain. •The 2.6GHz Base Station has been tested and certified for use with an XPOL antenna with a maximum gain of 18dBi and Omni antennas with a maximum gain of 13dBi. 4. Notes specific to the 3.65 – 3.675GHz band: •The StarMAX 3.6GHz Base Station complies with FCC CFR47, Part 90, Subpart Z •For FCC CFR47, Part 90, Subpart Z, StarMAX operation is restricted to the 25MHz band 3.65GHz – 3.675GHz. •To ensure compliance with the FCC RF exposure requirements, a minimum distance of 25cm must be maintained between the base station antenna and any persons whilst the unit is operational at 5MHz and 34cm for 10MHz operation. This calculation is based on the EIRP limits within Part 90, Subpart Z. •The…

Text truncated - open the document above for the full version.

30 November, 2009 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality for VPX-8200-26A Harris Stratex Networks requests according to FCC 47 CFR 0.459 that the following items are held permanently confidential and from public view: Block diagrams All schematic diagrams Parts list Tune-up information Operational description These items contain proprietary information that represents considerable investment on the part of Harris Stratex Networks. Public disclosure of this information would be damaging for Harris Stratex due to the competitive nature of our industry. Ruth French Product Compliance Manager

December, 2009. FCC application VPX-8200-26A StarMAX 8200 External photographs – Six sides Photograph 1 December, 2009. FCC application VPX-8200-26A Photograph 2 December, 2009. FCC application VPX-8200-26A Photograph 3 December, 2009. FCC application VPX-8200-26A Photograph 4 December, 2009. FCC application VPX-8200-26A Photograph 5 December, 2009. FCC application VPX-8200-26A Photograph 6

StarMAX 8200 Base Station Label Location

December, 2009. FCC application VPX-8200-26A StarMAX 8200-26 Internal Photographs December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A

MPE CALCULATION REPORT FROM RFI GLOBAL SERVICES LTD Evaluation of: Harris Stratex Networks StarMAX 8200-25 and StarMAX 8200-26 Base Stations To: FCC OET Bulletin 65 Report Serial No: RFI/REGA2/TP75361D01C This Test Plan Is Issued Under The Authority Of Nick Hooper, Head of Inspection Written By: John Bellairs Checked By: Report Copy No: PDF01 Issue Date: 18 December 2009 This report may be reproduced in full. Partial reproduction may only be made with the written consent of RFI Global Services Ltd. This report is produced on the basis of our understanding of the information supplied. If our understanding of the information supplied is incorrect, this may affect the response given. In the event that our understanding of the matter is incorrect, you should not place any reliance up on it until you have advised the correct nature of the problem and we have been able to reconsider the matter. This report is issued in Portable Document Format (PDF) and may only be copied in full. RFI GLOBAL SERVICES LTD MPE CALCULATION REPORT S.No. RFI/REGA2/TP75361D01C Page: 2 of 8 Issue Date: 18 December 2009 For: Harris Stratex Networks Product: StarMax 2.5 to 2.7GHz WiMax™ BS This page has been left intentionally blank. RFI GLOBAL SERVICES LTD MPE CALCULATION REPORT S.No. RFI/REGA2/TP75361D01C Page 3 of 8 Issue Date: 18 December 2009 For: Harris Stratex Networks Product: StarMax 2.5 to 2.7GHz WiMax™ BS Table of Contents 1. Client Information........................................................................................................... 4 2. Equipment Under Evaluation......................................................................................... 5 3. Applicable FCC Rule Parts: ........................................................................................... 6 4. MPE Calculation for the StarMAX 8200-25 and StarMAX 8200-26 BS ......................... 6 5. Conclusion...................................................................................................................... 8 RFI GLOBAL SERVICES LTD MPE CALCULATION REPORT S.No. RFI/REGA2/TP75361D01C Page: 4 of 8 Issue Date: 18 December 2009 For: Harris Stratex Networks Product: StarMax 2.5 to 2.7GHz WiMax™ BS 1. Client Information Company Name: Harris Stratex Networks Address: 4 Bell Drive Hamilton International Technology Park Blantyre G72 0FB, Scotland Contact Name: Ms R French RFI GLOBAL SERVICES LTD MPE CALCULATION REPORT S.No. RFI/REGA2/TP75361D01C Page 5 of 8 Issue Date: 18 December 2009 For: Harris Stratex Networks Product: StarMax 2.5 to 2.7GHz WiMax™ BS 2. Equipment Under Evaluation The following information has been supplied by the client: 2.1. Identification of Equipment Under Evaluation Brand Name: Harris Stratex StarMAX Model Name or Number: StarMAX 8200-25; FCC ID: VPX-8200-25A StarMAX 8200-26; FCC ID: VPX-8200-26A Equipment Category: WiMax™ Base Station Serial Number: No specific equipment Frequency of Operation: 2.496 – 2.690GHz. Transmitting Power: +36dBm standard (+40dBm high power on request) Antenna Gain +18.0dBi maximum Channel Bandwidth: 5 and 10MHz Duplex Method TDD Max. TDD TX Duty Cycle 74% 2.2. Description of EUT The equipment under evaluation is the Harris Stratex StarMAX 8200-25 and StarMAX 8200-26 base stations. This evaluation covers operation at 2.5 - 2.7GHz. The StarMAX 8200-25 and StarMAX 8200-26 base stations can utilise single or two antenna operation and is intended to be used in fixed outdoor installations. . RFI GLOBAL SERVICES LTD MPE CALCULATION REPORT S.No. RFI/REGA2/TP75361D01C Page: 6 of 8 Issue Date: 18 December 2009 For: Harris Stratex Networks Product: StarMax 2.5 to 2.7GHz WiMax™ BS 3. Applicable FCC Rule Parts: Part 27.52. Licensees and manufacturers are subject to the radio frequency radiation exposure requirements specified in sections 1.1307(b), 2.1091, and 2.1093. Part 1.1310. Radiofrequency radiation exposure limits. Part 27.50(h)(1).Main, booster and base stations. (i) The maximum EIRP of a main, booster or base station shall not exceed 33 dBW + 10log(X/Y) dBW, where X is the actual channel width in MHz and Y is either 6 MHz if prior to transition or the station is in the MBS following transition or 5.5 MHz if the station is in the LBS and UBS following transition, except as provided in paragraph (h)(1)(ii) of this section. (ii) If a main or booster station sectorizes or otherwise uses one or more transmitting antennas with a non-omnidirectional horizontal plane radiation pattern, the maximum EIRP in dBW in a given direction shall be determined by the following formula: EIRP = 33 dBW + 10 log(X/Y) dBW + 10 log(360/beamwidth) dBW, where X is the actual channel width in MHz, Y is either (i) 6 MHz if prior to transition or the station is in the MBS following transition or (ii) 5.5 MHz if the station is in the LBS and UBS following transition, and beamwidth is the total horizontal plane beamwidth of the individual transmitting antenna for the station or any sector measured at the half-power points. . 4. MPE Calculation for the StarMAX 8200-25 and StarMAX 8200-26 BS Maximum antenna gain specified is 18.0dBi Maximum transmitter power specified is 40dBm (10W) For 2 transmitters @ 40dBm and 74% TDD duty cycle: P = 10 x 2 x 0.74 = 14.8W 4.1 Calculation for 2.5 – 2.7GHz. From FCC Rule Part 1.1310 table 1 (b) - Limits for General Population/ Uncontrolled Exposure: S = 1.0 mW/cm 2 The MPE calculation as given in FCC OET Bulletin 65, page 19 is used to calculate the safe operating distance for the user. S = EIRP/4 π R 2 RFI GLOBAL SERVICES LTD MPE CALCULATION REPORT S.No. RFI/REGA2/TP75361D01C Page 7 of 8 Issue Date: 18 December 2009 For: Harris Stratex Networks Product: StarMax 2.5 to 2.7GHz WiMax™ BS Where S = Power density EIRP = Effective Isotropic Radiated Power (EIRP = P x G) P = Conducted Transmitter Power G = Antenna Gain (relative to an isotropic radiator) R = distance to the centre of radiation of the antenna Values for StarMax 6000 BS : P = 14.8W G = 18.0dBi (63.1) S …

Text truncated - open the document above for the full version.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: StarMAX 8200-26 To: FCC Part 27: 2008 Subpart C Test Report Serial No: RFI/RPT2/RP75353JD07B Supersedes Test Report Serial No: RFI/RPT1/RP75353JD07A This Test Report Is Issued Under The Authority Of Brian Watson, Operations Director: Checked By: Nigel Davison Signature: Date of Issue: 18 December 2009 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI/RPT2/RP75353JD07B ISSUE DATE: 18 DECEMBER 2009 Page 2 of 122 RFI Global Services Ltd This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI/RPT2/RP75353JD07B ISSUE DATE: 18 DECEMBER 2009 RFI Global Services Ltd Page 3 of 122 Table of Contents 1. Customer Information .................................................................................................................. 4 2. Summary of Testing ..................................................................................................................... 5 3. Equipment Under Test (EUT) ....................................................................................................... 7 4. Operation and Monitoring of the EUT during Testing ............................................................. 12 5. Measurements, Examinations and Derived Results ................................................................ 13 6. Measurement Uncertainty ........................................................................................................ 120 Appendix 1. Test Equipment Used .............................................................................................. 121 TEST REPORT SERIAL NO: RFI/RPT2/RP75353JD07B ISSUE DATE: 18 DECEMBER 2009 Page 4 of 122 RFI Global Services Ltd 1. Customer Information Company Name: Harris Stratex Networks Address: 4 Bell Drive Hamilton International Technology Park Blantyre, Lanarkshire Scotland G72 0FB TEST REPORT SERIAL NO: RFI/RPT2/RP75353JD07B ISSUE DATE: 18 DECEMBER 2009 RFI Global Services Ltd Page 5 of 122 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR27 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2008: Part 27 Subpart C (Miscellaneous Wireless Communication Services) Site Registration: FCC: 209735 Location of Testing: RFI Global Services Ltd, Wade Road, Basingstoke, Hampshire, RG24 8AH, England Test Dates: 16 October 2009 to 27 November 2009 2.2. Summary of Test Results FCC Reference (47CFR) Measurement Port Type Result FCC Part 15.107 Idle Mode AC Conducted Spurious Emissions AC Mains FCC Part 15.109 Idle Mode Radiated Spurious Emissions Enclosure FCC Part 15.207 Transmitter AC Conducted Spurious Emissions AC Mains FCC Part 2.1046 FCC Part 27.50 Transmitter Carrier Output Power Antenna Terminals FCC Part 27.50 Transmitter Equivalent Isotropic Radiated Power (EIRP) Enclosure FCC Part 2.1049 Transmitter Occupied Bandwidth Antenna Terminals FCC Part 27.53 26 dB Bandwidth Antenna Terminals FCC Part 2.1055 FCC Part 27.54 Transmitter Frequency Stability (Temperature Variation) Antenna Terminals FCC Part 2.1055 FCC Part 27.54 Transmitter Frequency Stability (Voltage Variation) Antenna Terminals FCC Part 2.1051 FCC Part 27.53 Transmitter Conducted Emissions Antenna Terminals FCC Part 2.1051 FCC Part 27.53 Transmitter Band Edge Conducted Emissions Antenna Terminals FCC Part 2.1051 FCC Part 27.53 Transmitter Radiated Spurious Emissions Enclosure FCC Part 2.1051 FCC Part 27.53 Transmitter Band Edge Radiated Emissions Enclosure Key to Results = Complied = Did not comply TEST REPORT SERIAL NO: RFI/RPT2/RP75353JD07B ISSUE DATE: 18 DECEMBER 2009 Page 6 of 122 RFI Global Services Ltd 2.3. Methods and Procedures Reference: ANSI/TIA-603-C-2004 Title: Land Mobile Communications Equipment, Measurements and performance Standards Reference: ANSI C63.4 (2003) Title: American National Standard Methods of Measurement of Electromagnetic Emissions from Low Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: RFI/RPT2/RP75353JD07B ISSUE DATE: 18 DECEMBER 2009 RFI Global Services Ltd Page 7 of 122 3. Equipment Under Test (EUT) 3.1. Identification of Equipment Under Test (EUT) Description: Base Station – Outdoor Unit Brand Name: Harris Stratex Networks Product: StarMAX 8200-26 Model Name or Number: 8200-26-10-01 Serial Number: T00000104P0929T Unit Code: AX01101T26350200000-100 REV.B Hardware Version: Carrier board : 0 ODU 2 hardware type: DPD-CDRS-CPRI-1-WiMax Software Version: Carrier board : 3.6.3 ODU 2 software version: 6328 ODU 2 software build: 3263 FCC ID Number: VPX-8200-26A Description: Base Station – Indoor Unit Brand Name: Harris Stratex Networks Product: StarMAX 6100 OEM Code: 6112-00-00-001 Serial Number: MLI18180801817 Hardware Version: StarMAX Chassis: PTZ6010BA0A0 ACB Board: 402-0008-045 Software Version: System software version: 4.1.1.1 Kernel: 4.1.1.1 Application: 4.1.1.1 Description: Omnidirectional antenna Brand Name: Doradus Antenna Code: OMNI Frequency Range: 2.6 GHz Polarity: Vertical Gain: 13.0 dBi TEST REPORT SERIAL NO: RFI/RPT2/RP75353JD07B ISSUE DATE: 18 DECEMBER 2009 Page 8 of 122 RFI Global Services Ltd Description: Sectorised antenna Brand Name: PCTEL Model Name or Number: SP2327-18XP60NUF Frequency Range: 2.3 – 2.7 GHz 3 dB Beamwidth: 60º Gain: 18 dBi Serial Number: 460148 Description: Fibre optic cab…

Text truncated - open the document above for the full version.

December, 2009. FCC application VPX-8200-26A StarMAX 8200 Set-up photographs AC conducted photographs December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A Bench set-up December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A EIRP photos December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A RSE photos December, 2009. FCC application VPX-8200-26A December, 2009. FCC application VPX-8200-26A
