VTV-T097Pathfinder Edge (Handheld Barcode Printer)

Report No.: 2630679R-SAUSV01S-A Page: 1 of 15 Appendix B. Highest Measurement Data Report No.: 2630679R-SAUSV01S-A Page: 2 of 15 Test Laboratory: DEKRA Date: 2026-05-28 8_WLAN2.4GHz_802.11b-1M_CH1_Right-side_5mm_Ant 2 Communication System: UID 10415-AAA, WLAN; Frequency: 2412.000 MHz Medium parameters used: f = 2412.000 MHz; Conductivity = 1.78 S/m; Permittivity = 40.5 Phantom section: Flat DASY Configuration: • Probe: EX3DV4 - SN7784; ConvF(6.9, 7.19, 6.96); Calibrated: 2026-04-21 • Sensor-Surface: 1.4 mm • Electronics: DAE4 Sn1791; Calibrated: 2026-04-22 • Phantom: ELI V8.0 (20deg probe tilt) • Measurement SW: V16.4.0.5005 Area Scan (80.0 mm x 100.0 mm ): Measurement grid: 10.0 mm x 10.0 mm SAR (1 g) = 1.03 W/kg; SAR (10 g) = 0.461 W/kg Zoom Scan (30.0 mm x 30.0 mm x 30.0 mm ): Measurement grid: 5.0 mm x 5.0 mm x 1.5 mm Power Drift = 0.08 dB SAR(1 g) = 1.09 W/kg; SAR(10 g) = 0.470 W/kg Smallest distance from peaks to all points 3 dB below = 9.0 Ratio of SAR at M2 to SAR at M1 = 79.9 Report No.: 2630679R-SAUSV01S-A Page: 3 of 15 Test Laboratory: DEKRA Date: 2026-06-01 6_WLAN5GHz_802.11ac80-VHT0_CH58_Right-side_5mm_Ant 2 Communication System: UID 10544-AAD, WLAN; Frequency: 5290.000 MHz Medium parameters used: f = 5290.000 MHz; Conductivity = 4.74 S/m; Permittivity = 36.7 Phantom section: Flat DASY Configuration: • Probe: EX3DV4 - SN7784; ConvF(5.14, 5.35, 5.18); Calibrated: 2026-04-21 • Sensor-Surface: 1.4 mm • Electronics: DAE4 Sn1791; Calibrated: 2026-04-22 • Phantom: ELI V8.0 (20deg probe tilt) • Measurement SW: V16.4.0.5005 Area Scan (100.0 mm x 100.0 mm ): Measurement grid: 10.0 mm x 10.0 mm SAR (1 g) = 0.970 W/kg; SAR (10 g) = 0.310 W/kg Zoom Scan (22.0 mm x 22.0 mm x 22.0 mm ): Measurement grid: 4.0 mm x 4.0 mm x 1.4 mm Power Drift = 0.03 dB SAR(1 g) = 1.06 W/kg; SAR(10 g) = 0.340 W/kg Smallest distance from peaks to all points 3 dB below = 7.4 Ratio of SAR at M2 to SAR at M1 = 60.3 Report No.: 2630679R-SAUSV01S-A Page: 4 of 15 Test Laboratory: DEKRA Date: 2026-06-01 11_WLAN5GHz_802.11ac80-VHT0_CH106_Right-side_5mm_Ant 2 Communication System: UID 10544-AAD, WLAN; Frequency: 5530.000 MHz Medium parameters used: f = 5530.000 MHz; Conductivity = 5.07 S/m; Permittivity = 36.0 Phantom section: Flat DASY Configuration: • Probe: EX3DV4 - SN7784; ConvF(4.55, 4.74, 4.59); Calibrated: 2026-04-21 • Sensor-Surface: 1.4 mm • Electronics: DAE4 Sn1791; Calibrated: 2026-04-22 • Phantom: ELI V8.0 (20deg probe tilt) • Measurement SW: V16.4.0.5005 Area Scan (80.0 mm x 100.0 mm ): Measurement grid: 10.0 mm x 10.0 mm SAR (1 g) = 0.832 W/kg; SAR (10 g) = 0.271 W/kg Zoom Scan (22.0 mm x 22.0 mm x 22.0 mm ): Measurement grid: 4.0 mm x 4.0 mm x 1.4 mm Power Drift = 0.09 dB SAR(1 g) = 0.954 W/kg; SAR(10 g) = 0.294 W/kg Smallest distance from peaks to all points 3 dB below = 7.4 Ratio of SAR at M2 to SAR at M1 = 58.1 Report No.: 2630679R-SAUSV01S-A Page: 5 of 15 Test Laboratory: DEKRA Date: 2026-06-01 14_WLAN5GHz_802.11ac80-VHT0_CH155_Right-side_5mm_Ant 2 Communication System: UID 10544-AAD, WLAN; Frequency: 5775.000 MHz Medium parameters used: f = 5775.000 MHz; Conductivity = 5.39 S/m; Permittivity = 35.3 Phantom section: Flat DASY Configuration: • Probe: EX3DV4 - SN7784; ConvF(4.62, 4.82, 4.66); Calibrated: 2026-04-21 • Sensor-Surface: 1.4 mm • Electronics: DAE4 Sn1791; Calibrated: 2026-04-22 • Phantom: ELI V8.0 (20deg probe tilt) • Measurement SW: V16.4.0.5005 Area Scan (80.0 mm x 100.0 mm ): Measurement grid: 10.0 mm x 10.0 mm SAR (1 g) = 0.802 W/kg; SAR (10 g) = 0.244 W/kg Zoom Scan (22.0 mm x 22.0 mm x 22.0 mm ): Measurement grid: 4.0 mm x 4.0 mm x 1.4 mm Power Drift = 0.07 dB SAR(1 g) = 0.919 W/kg; SAR(10 g) = 0.273 W/kg Smallest distance from peaks to all points 3 dB below = 7.2 Ratio of SAR at M2 to SAR at M1 = 54.7 Report No.: 2630679R-SAUSV01S-A Page: 6 of 15 Test Laboratory: DEKRA Date: 2026-06-02 9_WLAN6GHz_802.11ax160-HE0_CH47_Right-side_5mm_Ant 2 Communication System: UID 10755-AAC, WLAN; Frequency: 6185.000 MHz Medium parameters used: f = 6185.000 MHz; Conductivity = 5.56 S/m; Permittivity = 35.8 Phantom section: Flat DASY Configuration: • Probe: EX3DV4 - SN7784; ConvF(4.86, 5.07, 4.9); Calibrated: 2026-04-21 • Sensor-Surface: 1.4 mm • Electronics: DAE4 Sn1791; Calibrated: 2026-04-22 • Phantom: ELI V8.0 (20deg probe tilt) • Measurement SW: V16.4.0.5005 Area Scan (85.0 mm x 102.0 mm ): Measurement grid: 8.5 mm x 8.5 mm SAR (1 g) = 0.421 W/kg; SAR (10 g) = 0.130 W/kg Zoom Scan (22.0 mm x 22.0 mm x 22.0 mm ): Measurement grid: 3.4 mm x 3.4 mm x 1.4 mm Power Drift = -0.04 dB SAR(1 g) = 0.463 W/kg; SAR(10 g) = 0.140 W/kg psAPD (4.0cm2, sq) = 3.24 W/m2 Smallest distance from peaks to all points 3 dB below = 7.7 Ratio of SAR at M2 to SAR at M1 = 50.7 Report No.: 2630679R-SAUSV01S-A Page: 7 of 15 Test Laboratory: DEKRA Date: 2026/06/03 2_RFID_CH902750_Top_0mm_ANT Main Communication System: UID 0, RFID; Frequency: 902.75 MHz Communication System PAR: 0 dB Medium parameters used: f = 902.75 MHz; σ = 0.99 S/m; ε r = 41.22; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2011) DASY Configuration: • Probe: EX3DV4 - SN7631; ConvF(10.66, 9.88, 9.61) @ 902.75 MHz; Calibrated: 2026/02/20 • Sensor-Surface: 1.4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1651; Calibrated: 2026/02/16 • Phantom: ELI V8.0; Type: QD OVA 004 AA; Serial: 2139 • Measurement SW: DASY52, Version 52.10 (4); Configuration/Flat/Area Scan (10x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.00680 W/kg Configuration/Flat/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 3.742 V/m; Power Drift = -0.16 dB Peak SAR (extrapolated) = 0.0140 W/kg SAR(1 g) = 0.00542 W/kg; SAR(10 g) = 0.00258 W/kg Smallest distance from peaks to all points 3 dB below: Larger than measurement grid (> 16 mm) Ratio of SAR at M2 to SAR at M1 = 47.1% Maximum value of SAR (measured) = 0.0106 W/kg Report No.: 2630679R-SAUSV01S-A Page: 8 of 15 Test La…

Text truncated - open the document above for the full version.

Report No.: 2630679R-RFUSV01S-A Page : 18 of 51 802.11ac/20MHz/MCS0/2412MHz/Ch1 (Ref.) 802.11ac/20MHz/MCS0/2412MHz/Ch1 802.11ac/20MHz/MCS0/2437MHz/Ch6 (Ref.) 802.11ac/20MHz/MCS0/2437MHz/Ch6 802.11ac/20MHz/MCS0/2462MHz/Ch11 (Ref.) 802.11ac/20MHz/MCS0/2462MHz/Ch11 Report No.: 2630679R-RFUSV01S-A Page : 19 of 51 802.11ac/40MHz/MCS0/2422MHz/Ch3 (Ref.) 802.11ac/40MHz/MCS0/2422MHz/Ch3 802.11ac/40MHz/MCS0/2437MHz/Ch6 (Ref.) 802.11ac/40MHz/MCS0/2437MHz/Ch6 802.11ac/40MHz/MCS0/2452MHz/Ch9 (Ref.) 802.11ac/40MHz/MCS0/2452MHz/Ch9 Report No.: 2630679R-RFUSV01S-A Page : 20 of 51 802.11ax/20MHz/MCS0/2412MHz/Ch1 (Ref.) 802.11ax/20MHz/MCS0/2412MHz/Ch1 802.11ax/20MHz/MCS0/2437MHz/Ch6 (Ref.) 802.11ax/20MHz/MCS0/2437MHz/Ch6 802.11ax/20MHz/MCS0/2462MHz/Ch11 (Ref.) 802.11ax/20MHz/MCS0/2462MHz/Ch11 Report No.: 2630679R-RFUSV01S-A Page : 21 of 51 802.11ax/40MHz/MCS0/2422MHz/Ch3 (Ref.) 802.11ax/40MHz/MCS0/2422MHz/Ch3 802.11ax/40MHz/MCS0/2437MHz/Ch6 (Ref.) 802.11ax/40MHz/MCS0/2437MHz/Ch6 802.11ax/40MHz/MCS0/2452MHz/Ch9 (Ref.) 802.11ax/40MHz/MCS0/2452MHz/Ch9 Report No.: 2630679R-RFUSV01S-A Page : 22 of 51 802.11b/20MHz/1M/2412MHz/Ch1(Band Edge) 802.11b/20MHz/1M/2462MHz/Ch11(Band Edge) 802.11g/20MHz/6M/2412MHz/Ch1(Band Edge) 802.11g/20MHz/6M/2462MHz/Ch11(Band Edge) 802.11ac/20MHz/MCS0/2412MHz/Ch1(Band Edge) 802.11ac/20MHz/MCS0/2462MHz/Ch11(Band Edge) Report No.: 2630679R-RFUSV01S-A Page : 23 of 51 802.11ac/40MHz/MCS0/2422MHz/Ch3(Band Edge) 802.11ac/40MHz/MCS0/2452MHz/Ch9(Band Edge) 802.11ax/20MHz/MCS0/2412MHz/Ch1(Band Edge) 802.11ax/20MHz/MCS0/2462MHz/Ch11(Band Edge) 802.11ax/40MHz/MCS0/2422MHz/Ch3(Band Edge) 802.11ax/40MHz/MCS0/2452MHz/Ch9(Band Edge) Report No.: 2630679R-RFUSV01S-A Page : 24 of 51 Appendix F. Test Result of Radiated Emission TX_b_2412MHz_H TX_b_2412MHz_V TX_b_2437MHz_H TX_b_2437MHz_V Report No.: 2630679R-RFUSV01S-A Page : 25 of 51 TX_b_2462MHz_H TX_b_2462MHz_V TX_g_2412MHz_H TX_g_2412MHz_V Report No.: 2630679R-RFUSV01S-A Page : 26 of 51 TX_g_2437MHz_H TX_g_2437MHz_V TX_g_2462MHz_H TX_g_2462MHz_V Report No.: 2630679R-RFUSV01S-A Page : 27 of 51 TX_ac20_2412MHz_H TX_ac20_2412MHz_V TX_ac20_2437MHz_H TX_ac20_2437MHz_V Report No.: 2630679R-RFUSV01S-A Page : 28 of 51 TX_ac20_2462MHz_H TX_ac20_2462MHz_V TX_ac40_2422MHz_H TX_ac40_2422MHz_V Report No.: 2630679R-RFUSV01S-A Page : 29 of 51 TX_ac40_2437MHz_H TX_ac40_2437MHz_V TX_ac40_2452MHz_H TX_ac40_2452MHz_V Report No.: 2630679R-RFUSV01S-A Page : 30 of 51 TX_ax20_2412MHz_H TX_ax20_2412MHz_V TX_ax20_2437MHz_H TX_ax20_2437MHz_V Report No.: 2630679R-RFUSV01S-A Page : 31 of 51 TX_ax20_2462MHz_H TX_ax20_2462MHz_V TX_ax40_2422MHz_H TX_ax40_2422MHz_V Report No.: 2630679R-RFUSV01S-A Page : 32 of 51 TX_ax40_2437MHz_H TX_ax40_2437MHz_V TX_ax40_2452MHz_H TX_ax40_2452MHz_V Report No.: 2630679R-RFUSV01S-A Page : 33 of 51 TX_ax40_2437MHz_H TX_ax40_2437MHz_V TX_b_2412MHz_H_Average TX_b_2412MHz_H_Peak Report No.: 2630679R-RFUSV01S-A Page : 34 of 51 TX_b_2412MHz_V_Average TX_b_2412MHz_V_Peak TX_b_2462MHz_H_Average TX_b_2462MHz_H_Peak Report No.: 2630679R-RFUSV01S-A Page : 35 of 51 TX_b_2462MHz_V_Average TX_b_2462MHz_V_Peak TX_g_2412MHz_H_Average TX_g_2412MHz_H_Peak Report No.: 2630679R-RFUSV01S-A Page : 36 of 51 TX_g_2412MHz_V_Average TX_g_2412MHz_V_Peak TX_g_2462MHz_H_Average TX_g_2462MHz_H_Peak Report No.: 2630679R-RFUSV01S-A Page : 37 of 51 TX_g_2462MHz_V_Average TX_g_2462MHz_V_Peak TX_ac20_2412MHz_H_Average TX_ac20_2412MHz_H_Peak Report No.: 2630679R-RFUSV01S-A Page : 38 of 51 TX_ac20_2412MHz_V_Average TX_ac20_2412MHz_V_Peak TX_ac20_2462MHz_H_Average TX_ac20_2462MHz_H_Peak Report No.: 2630679R-RFUSV01S-A Page : 39 of 51 TX_ac20_2462MHz_V_Average TX_ac20_2462MHz_V_Peak TX_ac40_2422MHz_H_Average TX_ac40_2422MHz_H_Peak Report No.: 2630679R-RFUSV01S-A Page : 40 of 51 TX_ac40_2422MHz_V_Average TX_ac40_2422MHz_V_Peak TX_ac40_2452MHz_H_Average TX_ac40_2452MHz_H_Peak Report No.: 2630679R-RFUSV01S-A Page : 41 of 51 TX_ac40_2452MHz_V_Average TX_ac40_2452MHz_V_Peak TX_ax20_2412MHz_H_Average TX_ax20_2412MHz_H_Peak Report No.: 2630679R-RFUSV01S-A Page : 42 of 51 TX_ax20_2412MHz_V_Average TX_ax20_2412MHz_V_Peak TX_ax20_2462MHz_H_Average TX_ax20_2462MHz_H_Peak Report No.: 2630679R-RFUSV01S-A Page : 43 of 51 TX_ax20_2462MHz_V_Average TX_ax20_2462MHz_V_Peak TX_ax40_2422MHz_H_Average TX_ax40_2422MHz_H_Peak Report No.: 2630679R-RFUSV01S-A Page : 44 of 51 TX_ax40_2422MHz_V_Average TX_ax40_2422MHz_V_Peak TX_ax40_2452MHz_H_Average TX_ax40_2452MHz_H_Peak Report No.: 2630679R-RFUSV01S-A Page : 45 of 51 TX_ax40_2452MHz_V_Average TX_ax40_2452MHz_V_Peak Report No.: 2630679R-RFUSV01S-A Page : 46 of 51 Worst-Case Emissions Above 18 GHz TX_ac40_2437MHz_H TX_ac40_2437MHz_V TX_ax40_2437MHz_H TX_ax40_2437MHz_V Report No.: 2630679R-RFUSV01S-A Page : 47 of 51 Docking mode Docking mode Above 30MHz_H Docking mode Above 30MHz_V

Report No.: 2630679R-RFUSV01S-A Page : 1 of 51 Appendix A. Test Result of AC Power Line Conducted Emission TX_ax40_2437MHz_Line TX_ax40_2437MHz_Neutral Report No.: 2630679R-RFUSV01S-A Page : 2 of 51 Docking mode Docking mode_Line Docking mode_Neutral Report No.: 2630679R-RFUSV01S-A Page : 3 of 51 Appendix B. Test Result of Occupied Bandwidth & DTS Bandwidth Modulation Frequency (MHz) 99% Occupied Bandwidth (MHz) DTS Bandwidth (MHz) Limit (MHz) Ant. 1 Ant. 2 Ant. 1 Ant. 2 99% Occupied Bandwidth DTS Bandwidth 802.11b (20MHz) 2412 13.07 13.15 8.08 8.08 - ≧ 0.5 2437 13.07 13.11 8.12 8.56 - ≧ 0.5 2462 13.03 13.07 8.08 8.08 - ≧ 0.5 802.11g (20MHz) 2412 16.46 16.38 16.32 16.32 - ≧ 0.5 2437 16.46 16.54 16.36 16.36 - ≧ 0.5 2462 16.42 16.42 16.36 16.36 - ≧ 0.5 802.11ac (20MHz) 2412 17.62 17.62 17.56 17.60 - ≧ 0.5 2437 17.58 17.62 17.64 17.56 - ≧ 0.5 2462 17.58 17.62 17.60 17.56 - ≧ 0.5 802.11ac (40MHz) 2422 36.12 36.20 36.40 36.32 - ≧ 0.5 2437 36.28 36.20 36.32 36.32 - ≧ 0.5 2452 36.20 36.20 36.40 36.40 - ≧ 0.5 802.11ax (20MHz) 2412 19.06 18.94 19.04 19.00 - ≧ 0.5 2437 18.94 19.10 19.00 18.64 - ≧ 0.5 2462 18.94 18.94 18.68 18.84 - ≧ 0.5 802.11ax (40MHz) 2422 37.80 38.04 38.16 36.08 - ≧ 0.5 2437 37.80 37.88 38.16 37.68 - ≧ 0.5 2452 37.88 38.04 37.60 37.60 - ≧ 0.5 Report No.: 2630679R-RFUSV01S-A Page : 4 of 51 For 99% Occupied Bandwidth: 802.11b/20MHz/1M/2412MHz/Ch1 802.11b/20MHz/1M/2437MHz/Ch6 802.11b/20MHz/1M/2462MHz/Ch11 802.11g/20MHz/6M/2412MHz/Ch1 802.11g/20MHz/6M/2437MHz/Ch6 802.11g/20MHz/6M/2462MHz/Ch11 Report No.: 2630679R-RFUSV01S-A Page : 5 of 51 802.11ac/20MHz/MCS0/2412MHz/Ch1 802.11ac/20MHz/MCS0/2437MHz/Ch6 802.11ac/20MHz/MCS0/2462MHz/Ch11 802.11ac/40MHz/MCS0/2422MHz/Ch3 802.11ac/40MHz/MCS0/2437MHz/Ch6 802.11ac/40MHz/MCS0/2452MHz/Ch9 Report No.: 2630679R-RFUSV01S-A Page : 6 of 51 802.11ax/20MHz/MCS0/2412MHz/Ch1 802.11ax/20MHz/MCS0/2437MHz/Ch6 802.11ax/20MHz/MCS0/2462MHz/Ch11 802.11ax/40MHz/MCS0/2422MHz/Ch3 802.11ax/40MHz/MCS0/2437MHz/Ch6 802.11ax/40MHz/MCS0/2452MHz/Ch9 Report No.: 2630679R-RFUSV01S-A Page : 7 of 51 For DTS Bandwidth: 802.11b/20MHz/1M/2412MHz/Ch1 802.11b/20MHz/1M/2437MHz/Ch6 802.11b/20MHz/1M/2462MHz/Ch11 802.11g/20MHz/6M/2412MHz/Ch1 802.11g/20MHz/6M/2437MHz/Ch6 802.11g/20MHz/6M/2462MHz/Ch11 Report No.: 2630679R-RFUSV01S-A Page : 8 of 51 802.11ac/20MHz/MCS0/2412MHz/Ch1 802.11ac/20MHz/MCS0/2437MHz/Ch6 802.11ac/20MHz/MCS0/2462MHz/Ch11 802.11ac/40MHz/MCS0/2422MHz/Ch3 802.11ac/40MHz/MCS0/2437MHz/Ch6 802.11ac/40MHz/MCS0/2452MHz/Ch9 Report No.: 2630679R-RFUSV01S-A Page : 9 of 51 802.11ax/20MHz/MCS0/2412MHz/Ch1 802.11ax/20MHz/MCS0/2437MHz/Ch6 802.11ax/20MHz/MCS0/2462MHz/Ch11 802.11ax/40MHz/MCS0/2422MHz/Ch3 802.11ax/40MHz/MCS0/2437MHz/Ch6 802.11ax/40MHz/MCS0/2452MHz/Ch9 Report No.: 2630679R-RFUSV01S-A Page : 10 of 51 Appendix C. Test Result of Maximum Peak Conducted Output Power Modulation Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Limit (dBm) Result Ant. 1 Ant. 2 Total 802.11b (20MHz) 2412 15.65 14.87 18.29 30.00 Pass 2437 15.31 14.96 18.15 30.00 Pass 2462 15.55 15.02 18.30 30.00 Pass 802.11g (20MHz) 2412 20.86 20.72 23.80 30.00 Pass 2437 21.21 20.84 24.04 30.00 Pass 2462 21.12 20.68 23.92 30.00 Pass 802.11ac (20MHz) 2412 20.45 20.16 23.32 30.00 Pass 2437 20.56 20.19 23.39 30.00 Pass 2462 20.41 20.25 23.34 30.00 Pass 802.11ac (40MHz) 2422 20.35 20.11 23.24 30.00 Pass 2437 20.35 20.19 23.28 30.00 Pass 2452 20.12 20.06 23.10 30.00 Pass 802.11ax (20MHz) 2412 21.02 20.89 23.97 30.00 Pass 2437 21.35 20.89 24.14 30.00 Pass 2462 21.05 20.94 24.01 30.00 Pass 802.11ax (40MHz) 2422 20.67 20.26 23.48 30.00 Pass 2437 20.86 20.46 23.67 30.00 Pass 2452 20.56 20.36 23.47 30.00 Pass Report No.: 2630679R-RFUSV01S-A Page : 11 of 51 Average for reference only Modulation Frequency (MHz) Maximum Conducted Output Power (dBm) Limit (dBm) Result Ant. 1 Ant. 2 Total 802.11b (20MHz) 2412 12.98 12.47 15.74 30.00 Pass 2437 12.72 12.54 15.64 30.00 Pass 2462 12.95 12.56 15.77 30.00 Pass 802.11g (20MHz) 2412 12.96 12.82 15.90 30.00 Pass 2437 12.93 12.86 15.91 30.00 Pass 2462 12.98 12.82 15.91 30.00 Pass 802.11ac (20MHz) 2412 12.95 12.65 15.81 30.00 Pass 2437 12.76 12.79 15.79 30.00 Pass 2462 12.92 12.66 15.80 30.00 Pass 802.11ac (40MHz) 2422 12.74 12.68 15.72 30.00 Pass 2437 12.75 12.69 15.73 30.00 Pass 2452 12.74 12.65 15.71 30.00 Pass 802.11ax (20MHz) 2412 12.95 12.68 15.83 30.00 Pass 2437 12.84 12.77 15.82 30.00 Pass 2462 12.93 12.76 15.86 30.00 Pass 802.11ax (40MHz) 2422 12.85 12.75 15.81 30.00 Pass 2437 12.81 12.76 15.80 30.00 Pass 2452 12.76 12.69 15.74 30.00 Pass Report No.: 2630679R-RFUSV01S-A Page : 12 of 51 Appendix D. Test Result of Maximum Power Spectral Density Modulation Frequency (MHz) Maximum Power Spectral Density (dBm/3kHz) Limit (dBm/3kHz) Result Ant. 1 Ant. 2 Total 802.11b (20MHz) 2412 -6.56 -6.98 -3.77 6.74 Pass 2437 -7.44 -7.73 -4.58 6.74 Pass 2462 -7.38 -7.88 -4.64 6.74 Pass 802.11g (20MHz) 2412 -8.83 -9.26 -6.28 6.74 Pass 2437 -8.53 -9.31 -5.91 6.74 Pass 2462 -9.70 -8.63 -6.60 6.74 Pass 802.11ac (20MHz) 2412 -7.62 -8.19 -4.89 6.74 Pass 2437 -8.50 -7.79 -6.27 6.74 Pass 2462 -8.44 -8.78 -5.70 6.74 Pass 802.11ac (40MHz) 2422 -12.15 -11.97 -9.85 6.74 Pass 2437 -11.20 -11.35 -9.52 6.74 Pass 2452 -11.63 -12.29 -9.78 6.74 Pass 802.11ax (20MHz) 2412 -8.19 -9.58 -6.45 6.74 Pass 2437 -9.19 -9.75 -6.63 6.74 Pass 2462 -8.74 -9.83 -7.53 6.74 Pass 802.11ax (40MHz) 2422 -12.16 -12.73 -10.32 6.74 Pass 2437 -12.14 -12.31 -9.78 6.74 Pass 2452 -13.38 -12.43 -10.22 6.74 Pass Note: Trace bin-by-bin of each transmits port summing can be performed maximum power density. Report No.: 2630679R-RFUSV01S-A Page : 13 of 51 802.11b/20MHz/1M/2412MHz/Ch1 802.11b/20MHz/1M/2437MHz/Ch6 802.11b/20MHz/1M/2462MHz/Ch11 802.11g/20MHz/6M/2412MHz/Ch1 802.11g/20MHz/6M/2437MHz/Ch6 802.11g/20MHz/6M/2462MHz/Ch11 Report No.: 2630679R-RFUSV01S-A Page : 14 of 51 802.11ac/20MHz/MCS0/2412MHz/Ch1 802.11ac/20MHz/MCS0/2437MHz/Ch6 802.11ac/20MHz/MCS0/2462MHz/Ch11 802.11ac/40MHz/MCS0/2422MHz/Ch3 802.11ac/40MHz/MCS0/2437MHz/Ch6…

Text truncated - open the document above for the full version.

Report No.: 2630679R-RFUSV01S-A Page: 1 of 26 Test Report No: 2630679R-RFUSV01S-A TEST REPORT FCC Rules & Regulations Product Name Pathfinder Edge (Handheld Barcode Printer) Brand Name Model No. Pathfinder Edge, Pathfinder Edge RFID, PFE FCC ID VTV-T097 Applicant ́s Name / Address TSC Auto ID Technology Co., Ltd. 9F., No. 95, Minquan Rd., Xindian Dist., New Taipei City 231041, Ta i w a n Manufacturer’s Name TSC Auto ID Technology Co., Ltd. Test Method Requested, Standard FCC CFR Title 47 Part 15 Subpart C Section 15.247 Verdict Summary IN COMPLIANCE Documented By Genie Chang Approved By Steven Tsai Date of Receipt 2026/03/24 Date of Issue 2026/06/08 Report Version V1.0 Report No.: 2630679R-RFUSV01S-A Page: 2 of 26 INDEX page Competences and Guarantees ................................................................................................................................ 4 General Conditions .................................................................................................................................................. 4 Revision History ....................................................................................................................................................... 5 Summary of Test Result .......................................................................................................................................... 6 1. General Information .................................................................................................................................. 7 1.1. EUT Description ....................................................................................................................................... 7 1.2. EUT Information ....................................................................................................................................... 9 1.3. Testing Applied Standards ........................................................................................................................ 9 1.4. Testing Location Information .................................................................................................................. 10 1.5. Ambient Conditions In The Laboratory ................................................................................................... 11 1.6. Measurement Uncertainty ...................................................................................................................... 11 1.7. List of Test Equipment ............................................................................................................................ 12 2. Test Configuration of EUT ...................................................................................................................... 13 2.1. Test Condition ......................................................................................................................................... 13 2.2. Test Frequency Mode ............................................................................................................................. 13 2.3. Duty Cycle .............................................................................................................................................. 14 2.4. Measurement Configuration ................................................................................................................... 16 2.5. Tested System Details ............................................................................................................................ 17 2.6. Configuration of Tested System ............................................................................................................. 17 3. AC Power Line Conducted Emission ..................................................................................................... 19 3.1. Test Setup ............................................................................................................................................... 19 3.2. Test Limit ................................................................................................................................................ 19 3.3. Test Procedure ....................................................................................................................................... 19 3.4. Test Result of AC Power Line Conducted Emission ............................................................................... 19 4. Occupied Bandwidth & DTS Bandwidth ................................................................................................. 20 4.1. Test Setup ............................................................................................................................................... 20 4.2. Test Limit ................................................................................................................................................ 20 4.3. Test Procedures ...................................................................................................................................... 20 4.4. Test Result of Occupied Bandwidth & DTS Bandwidth .......................................................................... 20 5. Maximum Peak Conducted Output Power ............................................................................................. 21 5.1. Test Setup ............................................................................................................................................... 21 5.2. Test Limit ................................................................................................................................................ 21 5.3. Test Procedures ...................................................................................................................................... 21 5.4. Test Result of Maximum Peak Conducted Output Power ...................................................................... 21 6. Maximum Power …

Text truncated - open the document above for the full version.

-1- -1- ANT 2 Frequency ( GHz ) Efficiency ( % ) Peak Gain ( dBi ) 2.4 65 4.1 2.45 65 4.1 2.5 60 3.6 5.15 71 4.0 5.35 70 3.8 5.5 73 3.9 5.65 73 3.6 5.85 73 4.5 5.895 73 4.5 5.9 79 4.5 5.925 77 4.4 6.35 67 3.0 6.525 68 3.5 6.55 69 3.5 6.95 68 3.9 7.125 67 4.2 Antenna Information Item Brand Name Model No. Type Antenna Gain (dBi) 1 WHA YU 98-0970095-00LF (ANT1) PCB 2.4G 4.4 U-NII 1 4.5 U-NII 2A 4.0 U-NII 2C 4.6 98-0970096-00LF (ANT2) 2.4G 4.1 U-NII 1 4.0 U-NII 2A 3.8 U-NII 2C 3.9 Peak gain & Efficiency – ANT 1 & ANT 2 Test Item Specification Remark Return Loss > 10 dB Isolation > 20 dB Peak gain -- Efficiency > 60% Radiation pattern Scale: +10 ~ 40dBi, Angle step size: 15 degree ANT 1 Frequency ( GHz ) Efficiency ( % ) Peak Gain ( dBi ) 2.4 70 3.8 2.45 72 4.4 2.5 71 4.4 5.15 72 4.5 5.35 73 4.0 5.5 77 4.6 5.65 78 4.3 5.85 78 4.4 5.895 79 4.4 5.9 79 4.4 5.925 78 4.5 6.35 67 4.2 6.525 72 4.3 6.55 72 4.3 6.95 71 4.2 7.125 74 4.4

U.S. Agent Authorized Letter Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: June 30, 2026 Subject: Attestation Statements Part 2.911(d)(7) Filing FCC ID: VTV-T097 To Whom It May Concern: TSC Auto ID Technology Co., Ltd. certifies that, as of the date of the filing of the application, TSC Auto ID Technology, Inc is our designated U.S. agent for service of process for the above referenced FCC ID. TSC Auto ID Technology Co., Ltd. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. TSC Auto ID Technology, Inc accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Sincerely, Applicant: U.S. Agent: Company: TSC Auto ID Technology Co., Ltd. Company: TSC Auto ID Technology, Inc FRN: 0017220849 FRN: 0033688763 Address: 9F., No. 95, Minquan Rd., Xindian Dist., New Taipei City 231041, Taiwan Address: 3040 Saturn Street, Suite 200 Brea, CA 92821 , United States Contact Name: Roger Wu Contact Name: Andrew Edwards Tel.: +886-3-990-6677 Ext. 5307 Tel.: +1 714-585-5349 Email: [email protected] Email: [email protected] (Signature) (Signature)

Report No.: 2630679R-SAUSV01S-A Page: 1 of 8 Appendix A. System Check Data Report No.: 2630679R-SAUSV01S-A Page: 2 of 8 Test Laboratory: DEKRA Date: 2026/06/03 System Performance Check_900MHz-Head Communication System: UID 0, CW; Frequency: 900 MHz Communication System PAR: 0 dB Medium parameters used: f = 900 MHz; σ = 0.97 S/m; ε r = 42.09; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2011) DASY Configuration: • Probe: EX3DV4 - SN7631; ConvF(10.66, 9.88, 9.61) @ 900 MHz; Calibrated: 2026/02/20 • Sensor-Surface: 1.4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1651; Calibrated: 2026/02/16 • Phantom: ELI V8.0; Type: QD OVA 004 AA; Serial: 2139 • Measurement SW: DASY52, Version 52.10 (4); Configuration/900MHz Head/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.91 W/kg Configuration/900MHz Head/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 60.07 V/m; Power Drift = 0.03 dB Peak SAR (extrapolated) = 3.51 W/kg SAR(1 g) = 2.46 W/kg; SAR(10 g) = 1.64 W/kg Smallest distance from peaks to all points 3 dB below = 16 mm Ratio of SAR at M2 to SAR at M1 = 70% Maximum value of SAR (measured) = 3.21 W/kg Report No.: 2630679R-SAUSV01S-A Page: 3 of 8 Test Laboratory: DEKRA Date: 2026-05-28 System Performance Check_2450MHz-Head Communication System: UID 0--, CW; Frequency: 2450.000 MHz Medium parameters used: f = 2450.000 MHz; Conductivity = 1.83 S/m; Permittivity = 40.2 Phantom section: Flat DASY Configuration: • Probe: EX3DV4 - SN7784; ConvF(6.9, 7.19, 6.96); Calibrated: 2026-04-21 • Sensor-Surface: 1.4 mm • Electronics: DAE4 Sn1791; Calibrated: 2026-04-22 • Phantom: ELI V8.0 (20deg probe tilt) • Measurement SW: V16.4.0.5005 Area Scan (40.0 mm x 80.0 mm ): Measurement grid: 10.0 mm x 10.0 mm SAR (1 g) = 12.3 W/kg; SAR (10 g) = 5.67 W/kg Zoom Scan (30.0 mm x 30.0 mm x 30.0 mm ): Measurement grid: 5.0 mm x 5.0 mm x 1.5 mm Power Drift = -0.01 dB SAR(1 g) = 12.5 W/kg; SAR(10 g) = 6.21 W/kg Smallest distance from peaks to all points 3 dB below = 9.1 Ratio of SAR at M2 to SAR at M1 = 84.8 Report No.: 2630679R-SAUSV01S-A Page: 4 of 8 Test Laboratory: DEKRA Date: 2026-06-01 System Performance Check_5250MHz-Head Communication System: UID 0--, CW; Frequency: 5250.000 MHz Medium parameters used: f = 5250.000 MHz; Conductivity = 4.69 S/m; Permittivity = 36.8 Phantom section: Flat DASY Configuration: • Probe: EX3DV4 - SN7784; ConvF(5.14, 5.35, 5.18); Calibrated: 2026-04-21 • Sensor-Surface: 1.4 mm • Electronics: DAE4 Sn1791; Calibrated: 2026-04-22 • Phantom: ELI V8.0 (20deg probe tilt) • Measurement SW: V16.4.0.5005 Area Scan (40.0 mm x 80.0 mm ): Measurement grid: 10.0 mm x 10.0 mm SAR (1 g) = 6.81 W/kg; SAR (10 g) = 1.98 W/kg Zoom Scan (22.0 mm x 22.0 mm x 22.0 mm ): Measurement grid: 4.0 mm x 4.0 mm x 1.4 mm Power Drift = -0.02 dB SAR(1 g) = 7.60 W/kg; SAR(10 g) = 2.23 W/kg Smallest distance from peaks to all points 3 dB below = 7.4 Ratio of SAR at M2 to SAR at M1 = 64.4 Report No.: 2630679R-SAUSV01S-A Page: 5 of 8 Test Laboratory: DEKRA Date: 2026-06-01 System Performance Check_5600MHz-Head Communication System: UID 0--, CW; Frequency: 5600.000 MHz Medium parameters used: f = 5600.000 MHz; Conductivity = 5.16 S/m; Permittivity = 35.8 Phantom section: Flat DASY Configuration: • Probe: EX3DV4 - SN7784; ConvF(4.55, 4.74, 4.59); Calibrated: 2026-04-21 • Sensor-Surface: 1.4 mm • Electronics: DAE4 Sn1791; Calibrated: 2026-04-22 • Phantom: ELI V8.0 (20deg probe tilt) • Measurement SW: V16.4.0.5005 Area Scan (40.0 mm x 80.0 mm ): Measurement grid: 10.0 mm x 10.0 mm SAR (1 g) = 7.74 W/kg; SAR (10 g) = 2.20 W/kg Zoom Scan (22.0 mm x 22.0 mm x 22.0 mm ): Measurement grid: 4.0 mm x 4.0 mm x 1.4 mm Power Drift = -0.02 dB SAR(1 g) = 8.38 W/kg; SAR(10 g) = 2.37 W/kg Smallest distance from peaks to all points 3 dB below = 7.4 Ratio of SAR at M2 to SAR at M1 = 63.4 Report No.: 2630679R-SAUSV01S-A Page: 6 of 8 Test Laboratory: DEKRA Date: 2026-06-01 System Performance Check_5800MHz-Head Communication System: UID 0--, CW; Frequency: 5800.000 MHz Medium parameters used: f = 5800.000 MHz; Conductivity = 5.42 S/m; Permittivity = 35.3 Phantom section: Flat DASY Configuration: • Probe: EX3DV4 - SN7784; ConvF(4.62, 4.82, 4.66); Calibrated: 2026-04-21 • Sensor-Surface: 1.4 mm • Electronics: DAE4 Sn1791; Calibrated: 2026-04-22 • Phantom: ELI V8.0 (20deg probe tilt) • Measurement SW: V16.4.0.5005 Area Scan (40.0 mm x 80.0 mm ): Measurement grid: 10.0 mm x 10.0 mm SAR (1 g) = 7.24 W/kg; SAR (10 g) = 2.08 W/kg Zoom Scan (22.0 mm x 22.0 mm x 22.0 mm ): Measurement grid: 4.0 mm x 4.0 mm x 1.4 mm Power Drift = 0.03 dB SAR(1 g) = 8.14 W/kg; SAR(10 g) = 2.38 W/kg Smallest distance from peaks to all points 3 dB below = 7.4 Ratio of SAR at M2 to SAR at M1 = 64.4 Report No.: 2630679R-SAUSV01S-A Page: 7 of 8 Test Labo…
