VU65792M5792 Modular Radio Transceiver

SHoW DMX Neo ® OEM Guide Rev 2.2 ©2014 City Theatrical Inc. SHoW DMX Neo devices are covered by U.S. Patent #7,432,803. Table of Contents 1 Revision History .............................................................................................................. 5 2 Product Overview ........................................................................................................... 6 2.1 Part Numbers ................................................................................................................... 6 2.1.1 5792 SHoW DMX Neo Radio Module for OEM ......................................................... 6 2.1.2 5794 SHoW DMX Neo Radio Module for W-DMX .................................................... 6 3 About this Manual .......................................................................................................... 7 4 Specifications ................................................................................................................. 8 4.1 Regulatory Specifications ................................................................................................. 8 4.1.1 FCC Part 15 ................................................................................................................ 8 4.1.2 Radio Frequency Notifications .................................................................................. 9 5 Neo Operation Mode Implementation .......................................................................... 13 5.1 SHoW DMX Neo Radio for OEM (P/N 5792) .................................................................. 13 Table 4: SHoW DMX Neo Radio for OEM Signal Descriptions ................................................ 14 5.1.1 Description of Signal Pins ........................................................................................ 14 5.1.2 Recommended Interface Connection Examples ..................................................... 20 5.2 SHoW DMX Neo Radio for W-DMX (P/N 5794) ............................................................. 22 5.2.1 Description of Signal Pins ........................................................................................ 24 6 Classic Operation Mode Implementation ...................................................................... 26 7 Serial Configuration Protocol ........................................................................................ 27 7.1 SHoW ID to Register Tables ............................................................................................ 37 List of Figures Figure 1: SHoW DMX Neo Radio for OEM to Host Interface ........................................................ 13 Figure 2: SHoW Baby 5 Signal Implementation ............................................................................ 21 Figure 3: Minimum Signal Implementation .................................................................................. 22 Figure 4: Config Register Read & Write Protocol ......................................................................... 28 List of Tables Table 1: Revision History ................................................................................................................. 5 Table 2: Radio Module Specifications ............................................................................................. 8 Table 3: List of Approved Antennas .............................................................................................. 10 Table 4: SHoW DMX Neo Radio for OEM Signal Descriptions ...................................................... 14 Table 5: Signal Strength Truth Table ............................................................................................. 15 Table 6: GPI RDM Personality Selection ....................................................................................... 17 Table 7: GPI Function after Power-Up .......................................................................................... 18 Table 8: SHoW DMX Neo Mode Selection Table .......................................................................... 20 Table 9: SHoW DMX Radio for W-DMX Signal Descriptions ......................................................... 24 Table 10: Status LED function ....................................................................................................... 24 Table 11: Config Error Codes ........................................................................................................ 27 Table 12: Overview of Configuration Registers ............................................................................ 28 Table 13: Detailed Description of Configuration Registers .......................................................... 29 Table 14: SHoW DMX Neo ID to Radio Registers .......................................................................... 37 Table 15: SHoW DMX Classic ID to Radio Registers ...................................................................... 38 1 Revision History Table 1: Revision History Revision Date Description Author/Changed 1.0 Oct. 12, 2011 Initial Release P. Kleissler 1.1 Oct. 24, 2011 Moved Logic Level Specification in Table 2 to DC Characteristics section. Updated Table 4 for internal pull-ups and removed 3.3v references P. Kleissler 2.0 May 12, 2014 Split Classic from Neo. Added Neo examples P. Kleissler 2.1 June 30, 2014 Minor edits and revisions V. Tisdale 2.2 Dec 08, 2014 Added extended frequency range and 5-channel sub- bands Updated approved antennas list Removed “and other patents pending” from cover page B. Au 2 Product Overview The SHoW DMX Neo (Neo) radio module was designed by City Theatrical, Inc. (CTI) to use in the SHoW DMX line of wireless theatre lighting control equipment. This equipment is used for wireless transmission and reception of DMX512-A and RDM protocol data. The Neo radio module was designed to provide enhanced interference rejection, to reduce latency of both DMX and RDM packet delivery and provide…

Text truncated - open the document above for the full version.

5792 SHoW DMX Neo™ Radio Module User’s Manual Rev 1.11 © 2014 City Theatrical, Inc. SHoW DMX Neo™ devices are covered by U.S. Patent # 7,432,803. 2 Table of Contents Specifications................................................................................................................ 3 Regulatory Specifications ............................................................................................ 4 FCC Part 15 ............................................................................................................ 4 Radio Frequency Notifications ................................................................................. 4 Introduction ................................................................................................................... 8 Features ......................................................................................................................... 8 Important Information for OEM Integrators ............................................................... 10 Regulatory Module Integration Instructions ............................................................... 10 Device Classifications ............................................................................................... 11 FCC Definitions ......................................................................................................... 12 Simultaneous Transmission Evaluation ..................................................................... 12 OEM Instruction Manual Content .............................................................................. 14 Radio Configuration and Control ............................................................................... 15 Classic Mode Operation ............................................................................................ 15 Neo Mode Operation ................................................................................................. 15 Neo-Adaptive Mode Operation .................................................................................. 15 Supported RDM PIDs ................................................................................................ 15 Antennas and Antenna Connectors .......................................................................... 16 Additional Support ...................................................................................................... 17 3 Specifications Table 1: Radio Module Specifications Physical Characteristics Size 1.65 x 2.7 x 0.26 ” [42.0 x 68.75 x 6.5mm] Mounting holes Compatible with Aerocomm AC5124 Connector 40 pin header – Amp P/N 177986-1 Antenna connector Horizontal MMCX coaxial receptacle Operating Temperature -20° to +70° C [-4 to 158° F] Storage Temperature -40° to +85° C [-40 to 185° F] DC Characteristics Input Voltage 5 Volts DC ±2%, ±5mV ripple Current draw 250mA maximum Sleep mode current 20mA maximum Transmitter Characteristics TX power Selectable 1mW to 75mW in four steps Frequency range 2406 to 2480 MHz Channels Odd and Even sets with 2 MHz channel spacing in each set (75 channels total) Modulation FSK frequency hopping Over-the-air data rate 1 Mbps Channel coding 8B/10B line coding See note 1 Hopping patterns 2 sets of 36 full band, 2 sets of 16 low, mid, & high partial band selectable patterns with low cross-correlation and selectable adaptive hopping algorithms; 2 sets of partial band fixed patterns Receiver Characteristics RX sensitivity -95 dBm @ 1% PER Hop timing Synchronized with master transmitter Error checking CRC16 Serial Interface Logic levels 3.3 Volt / 5V Tolerant Bit rate Classic: 1.25 Mbps Neo: 250Kbps Data Format Classic: 8 N 1; Neo: 8 N 2 Flow Control None Note 1: Since there could be long stretches of continuous 1s or 0s in the transmitted data the radio transceiver IC will use 8B/10B line coding to ensure a more even distribution of 1s and 0s in the transmitted signal. This will provide better radio performance at the expense of a lower effective over-the-air bit rate. 8B/10B line coding is a method that encodes a symbol of 8 bits in to a 10 bit symbol and ensures that on average there is an even number over 1’s and 0’s and a minimum number of transitions. The effective bit rate becomes 8/10s of the radio bit rate so it will be 800kbps rather than 1Mbps. 4 Regulatory Specifications FCC Part 15 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. Radio Frequency Notifications FCC Notifications RF Radiation: The Product is an intentional radiator of Radio Frequency (RF) energy. In order to limit RF exposure to personnel in the immediate area, the Product should be located and installed such that a separation of at least 20 centimeters is maintained between the Product’s antenna and personnel in the vicinity of the device. The antenna used for this transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. Modification warning: Caution - changes or modification…

Text truncated - open the document above for the full version.

December 03, 2014 To Whom It May Concern, RE: Request for Single-Modular Approval for FCC ID: VU65792M This application is being submitted for certification of a device to receive Single-Modular Approval. An itemized list documenting compliance with the modular approval requirements in the Section 15.212 rules for unlicensed modules can be found in a separate exhibit within this application titled, “5792_FCC_Modular Approval Letter.pdf” Sincerely, Paul Kleissler Head of Engineering City Theatrical, Inc.

December 03, 2014 To Whom It May Concern, RE: City Theatrical, Inc. Model 5792 Modular Radio Transceiver: FCC ID, Grantee Code, Grantee Code Registration Number and FRN This is to confirm: City Theatrical, Inc. Grantee Code: VU6 City Theatrical, Inc. FCC ID for this product: VU65792M City Theatrical, Inc. Grantee Code Registration Number: GC446799 City Theatrical, Inc. FRN: 0017163338 City Theatrical, Inc. Contact Name: Mr. Paul Kleissler City Theatrical, Inc. Contact Email: [email protected] Sincerely, Paul Kleissler Head of Engineering City Theatrical, Inc.

P:\2014\City Theatrical\Ferengi FW\Docs\PDE Docs\Regulatory Certification\Docs for Submission\Administrative Docs\Modular Approval Letters\5792_FCC_Modular Approval Letter .docx MODULAR APPROVAL LETTER FCC Part 15 Unlicensed Modular Transmitter Approval Justification December 03, 2014 To: Federal Communications Commission Equipment Authorization Branch Laboratory Division Office of Engineering and Technology 7435 Oakland Mills Road Columbia, Maryland 21046 Applicant: City Theatrical, Inc. 475 Barell Avenue Carlstadt, New Jersey 07072 Tel: (201) 549-1160 Fax: (201) 549-1161 www.citytheatrical.com FCC IDENTIFIER: VU65792M Model: 5792 Dear Sir or Madam: This product is a Wireless module that will be used in various City Theatrical, Inc. (CTI) products. It is also marketed to external Original Equipment Manufacturers (OEM) to be used in their own host equipment. It is only installed into the final CTI product at the place of manufacture. Instructions will be provided to OEMs so that the product can be professionally installed into their host equipment. Modular Approval Requirement Yes No (i) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. x (ii) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. x (iii) The modular transmitter must have its own power supply regulation. x (iv) The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a ‘‘unique’’ antenna coupler (at all connections between the x P:\2014\City Theatrical\Ferengi FW\Docs\PDE Docs\Regulatory Certification\Docs for Submission\Administrative Docs\Modular Approval Letters\5792_FCC_Modular Approval Letter .docx module and the antenna, including the cable). The ‘‘professional installation’’ provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. (v) The modular transmitter must be tested in a stand- alone configuration x (vi) The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. x (vii) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. x (viii) The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. x Please contact the undersigned if you have any questions or need any further information. Regards, Paul Kleissler Head of Engineering City Theatrical, Inc.

External Photos – Antennas for City Theatrical, Inc. Model 5792 Radio Module Antenna # Manufacturer Model Type Connector Gain (dBi) 1 Nearson S151AH-2450S Omni whip SMA plug reverse polarity 5 Antenna # Manufacturer Model Type Connector Gain (dBi) 2 Nearson DG102N-2.4/5.25 Omni whip SMA plug reverse polarity via provided antenna cable 5 Antenna # Manufacturer Model Type Connector Gain (dBi) 3 Tekfun F40-N Omni whip SMA plug reverse polarity via provided antenna cable 4.5 Antenna # Manufacturer Model Type Connector Gain (dBi) 4 Nearson S152AH-2450S Omni whip SMA plug reverse polarity 4 Antenna # Manufacturer Model Type Connector Gain (dBi) 5 Nearson S141AH-2450 Omni whip SMA plug reverse polarity 2 Antenna # Manufacturer Model Type Connector Gain (dBi) 6 Nearson S131AH-2450S Omni whip SMA plug reverse polarity 2 Antenna # Manufacturer Model Type Connector Gain (dBi) 7 Centurion WCP2400- MMCX4 Omni whip MMCX jack on 4” coax pigtail 2.5 Antenna # Manufacturer Model Type Connector Gain (dBi) 8 Nearson SPCB07257 Omni Printed Trace MMCX jack on 4” coax pigtail 2 Antenna # Manufacturer Model Type Connector Gain (dBi) 9 PCTEL Maxrad MP24008XFPT Panel SMA plug reverse polarity via provided antenna cable 8 Antenna # Manufacturer Model Type Connector Gain (dBi) 10 PCTEL Maxrad MYP24010PT Yagi SMA plug reverse polarity via provided antenna cable 10 Antenna # Manufacturer Model Type Connector Gain (dBi) 11 PCTEL Maxrad MYP24014PT Yagi SMA plug reverse polarity via provided antenna cable 14

City Theatrical 5792 Radio Module bottom side City Theatrical 5792 Radio Module, component side, no shield City Theatrical 5792 Radio Module, component side, with shield 5dBi Omni antenna and MMCX -> reverse SMA cable

City Theatrical, Inc. Model 5792 Modular Radio Transceiver – Label Location Information & Label Samples Below are illustrations of labels showing FCC and IC ID markings on a typical host product and on the 5792 Modular Radio Transceiver printed circuit board assembly (PCBA). Sample of Host Product Marking Label The label shall be either permanently molded or engraved into the case of the Host product or be printed on a permanent label in which the ink and label material is of a quality and type that will last the life of the device. In addition to being visible to the consumer, the label shall not be located on a removable part such as a battery cover. Sample of Model 5792 Modular Radio PCBA Solder-Side Silkscreen Markings Label information containing FCC ID, IC ID and Model of the modular radio transceiver is permanently etched onto the PCBA as a part of the solder-side silkscreen. The label information will be visible when the modular radio PCBA is unplugged from the host product’s main or carrier PCBA. Please note the above illustration is a checkplot of the PCBA solder-side silkscreen. The three circular marks are fiducial points of the checkplot, and are not part of the actual silkscreen. The next two photographs illustrate the actual physical location on the PCBA where the label information containing FCC ID, IC ID and Model of the modular radio resides. Please note the information contained in the two photos is not up-to-date. For the actual information pertaining to this certification, please see “Sample of Model 5792 Modular Radio PCBA Solder-Side Silkscreen Markings” on the previous page of this document. Photo of Actual 5792 Modular Radio PCBA, Solder Side Close-up Photo of FCC ID, IC ID & Model Information Will Be

City Theatrical 5792 Radio Module bottom side City Theatrical 5792 Radio Module, component side, no shield City Theatrical 5792 Radio Module, component side, with shield 5dBi Omni antenna and MMCX -> reverse SMA cable

19473 Fraser Way Pitt Meadows, BC Canada V3Y 2V4 ph. 604-527-8378 |fx. 604 527 8388 Electromagnetic Compatibility Test Report IC RSS-210 & FCC CFR47 Part 15/C 15.247 Report Reference No. .....................: E10671-1401-FCC-IC Rev 2.0 Date of issue ........................................: Dec 17 2014 Total number of pages................: 67 Testing Laboratory........................ : Quality Auditing Institute Address................................................ : 1 6 – 211 Schoolhouse Street, Coquitlam, BC, V3K 4X9, Canada Accreditations (ISO 17025): Standard Council of Canada: Accredited Laboratory No. 743 International Accreditation Service Inc: Accredited Laboratory: No. TL-239 This report has been completed in accordance with the requirements of ISO/IEC 17025. Test results contained in this report are within QAI Laboratories ISO/IEC 17025 accreditation. QAI Laboratories authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for the use by the company’s employees only. Applicant’s name ..............................: City Theatrical Inc. Address......................................: 475 Barell Ave. Carlstadt, NJ, USA, 07072 Contact.......................................: Mr Paul Kleissler Email................................................: [email protected] Phone.........................................: (201)549-1160 Fax..................................................: (201) 549-1161 Test Standards................................ : IC RSS-210 Issue 8 IC RSS-Gen Issue 4 FCC CFR47 Part 15/C 15.247 Test item description....................... : Modular Wireless Transceiver Model Number..................................: 5792 Manufacturer....................................: City Theatrical Inc. FCC ID.......................................: VU65792M IC .............................................: 7480A-5792M Client: City Theatrical Inc. Job No.: E10671-1401 Date: December 16, 2014 Page 2 of 67 Top side of Module Module installed onto Test Fixture PCB Client: City Theatrical Inc. Job No.: E10671-1401 Date: December 16, 2014 Page 3 of 67 Revision History Date Report Number Rev # Details Authors Initials Nov-25- 2014 E10671-1401-FCC-IC 0.0 Draft Test Report JQ Dec-10-2014 E10671-1401-FCC-IC 0.1 Revised Draft and released to client DJ Dec-16-2014 E10671-1401-FCC-IC 1.0 Released version with clients comments DJ Dec-17-2014 E10671-1401-FCC-IC 2.0 Revised reference document dates On multiple pages DJ All previous versions of this Report have been superseded by the latest dated Revision as listed in the above table. Please dispose of all previous electronic and paper printed revisions accordingly. Client: City Theatrical Inc. Job No.: E10671-1401 Date: December 16, 2014 Page 4 of 67 Index Section I: GENERAL INFORMATION ................................................................................................. 7 PRODUCT DESCRIPTION ................................................................................................. 7 FACILITIES AND ACCREDITATION .................................................................................. 9 ENVIROMENTAL CONDITIONS: ....................................................................................... 9 MEASUREMENT UNCERTAINTY ..................................................................................... 9 TEST EQUIPMENT LIST .................................................................................................. 10 Section II: Test Information ................................................................................................................ 11 Part 1 - Radiated Emissions Testing ( Receive Mode ) .................................................... 12 Part 2 - Intentional Radiated Emissions Testing (Transmit Mode) ................................... 14 Part 3 - Restricted Frequency Bands ................................................................................ 19 Part 4 - Channel Bandwidth .............................................................................................. 20 Part 5 - Channel Separation ............................................................................................. 23 Part 6 - Hopping Channels ................................................................................................ 28 Part 7 - Occupancy Time .................................................................................................. 32 Part 8 - Conducted Output Power ..................................................................................... 40 Part 9 - EIRP Emissions ................................................................................................... 55 Part 10 - Out of Band Emissions ....................................................................................... 56 Part 11 - Antenna Requirement ........................................................................................ 58 Part 12 - RF Exposure Evaluation .................................................................................... 60 Appendix A: Test Setup Pictures ........................................................................................................... 61 Client: City Theatrical Inc. Job No.: E10671-1401 Date: December 16, 2014 Page 5 of 67 The following tests demonstrate the testimony to “IC and FCC” Mark Electromagnetic compatibility testing for “CTI 5792” manufactured by City Theatrical Inc. The testing was performed pursuant to RSS-210 Issue 8 & FCC CFR47, PART 15/C 15.247 Test Applicable Standard Description Result Radiated Emissions (Receive Mode) ICES-003 Issue 5, RSS-Gen Issue 4, FCC Part 15/B Class B The radiated emissions are measured in the 9kHz‐26GHz range Complies Channel Bandwidth RSS-210 Iss.8 A8.1 FCC Part 15/C 15.247 The channel bandwidth is measured at ‐20dB. Minimum 500kHz for DTS Complies Channel Separation RSS-210 Iss.8 A8.1 FCC Part 15/C 15.247 The channel separation s…

Text truncated - open the document above for the full version.

19473 Fraser Way Pitt Meadows, BC Canada V3Y 2V4 ph. 604-527-8378 |fx. 604 527 8388 Appendix A: E10671-1401 Test Setup Photos Setup for Radiated emissions when using EUT is using typical Antenna Client: City Theatrical Inc. Job No.: E10671-1401 Setup Photos Date: December 16, 2014 Page 2 of 7 Close-up of EUT with typical antenna Client: City Theatrical Inc. Job No.: E10671-1401 Setup Photos Date: December 16, 2014 Page 3 of 7 Auxilliary power supply used with EUT Client: City Theatrical Inc. Job No.: E10671-1401 Setup Photos Date: December 16, 2014 Page 4 of 7 Typical Low frequency measurement test setup Client: City Theatrical Inc. Job No.: E10671-1401 Setup Photos Date: December 16, 2014 Page 5 of 7 Client: City Theatrical Inc. Job No.: E10671-1401 Setup Photos Date: December 16, 2014 Page 6 of 7 Client: City Theatrical Inc. Job No.: E10671-1401 Setup Photos Date: December 16, 2014 Page 7 of 7
