VXPEYE-02GSM Security Camera

GSM Security Camera EYE-02 Camera EYE-02: Package content: II. B A 1 2 4 3 EYE-02 camera 1 Camera lens 2 PIR motion sensor 3 Green light 4 Red light 5 Infra red ilumination 6 GSM Antenna 7 Power button 8 AC adaptor socket 9 USB connector 10 Battery cover Battery Instalation CD Key-fob 6 8 9 7 10 5 Screwdriver User manual AC adapter Wall mounting screws Connecting cable USB cable JR_EYE-02.ENG.MAN.Manual.12.D- 1 - Index 1. EYE-02 Camera - Introduction 1.1 Basic Features EYE-02 is a security and monitoring camera which communicates wirelessly via the GSM network. EYE-02 integrates the following built-in detectors that allows to detect an intruder: PIR motion detector Detects movement by sensitive detection of human body temperature. Glass-break detector Recognizes the specific sound of breaking window glass Tilt and vibration detector Recognizes any unwanted change in the camera‘s position and angle Motion-in-Picture detector Detects changes in a scene by taking snapshots regularly and comparing them • EYE-02 is simple to install and configure (suitable for DIY installations) • EYE-02 sends an alarm record using MMS, e-mail, SMS or voice call. Copies of pictures and videos can be stored on the memory card or can be stored at a web server. Alarm Receiving Centers are also supported. • EYE-02 allows 24 hour monitoring via its night view mode. • EYE-02 is compatible with a wide range of external wireless devices (refer to the table on the inside back cover of this manual). Index ................................................................1 1. EYE-02 Camera - Introduction ..................1 1.1 Basic Features ...........................................................1 1.2 EYE-02 Camera Description .....................................2 1.3 EYE-02 Camera Internal Parts .................................2 2. Camera Installation ...................................2 2.1 Package Contents .....................................................2 2.2 Installation ................................................................3 3. Camera Function ........................................4 3.1 Remote Control ........................................................4 3.2 Working Modes ........................................................4 3.3 CONFIG Mode ...........................................................5 3.4 Detectors ..................................................................5 3.5 Profiles ......................................................................6 3.6 Reports .....................................................................7 3.7 SECURITY SETTINGS .................................................8 4. Camera Configuration ...............................8 4.1 Set-Up and Configuration via PC .............................8 4.2 SMS Commands .......................................................9 4.3 Event Reports .........................................................11 4.4 Video Record Setting (Available through JabloTool only) .......................................................................12 4.5 GSM Network Setting ...........................................13 5. Other Features ..........................................14 5.1 Call Control .............................................................14 5.2 Night View ..............................................................14 5.3 Monitoring .............................................................14 5.4 Switching OFF and ON ............................................14 5.5 Battery Mode .........................................................15 5.6 Micro SD card .........................................................15 5.7 Reset to Factory Defaults ......................................16 5.8 External Wireless Devices .....................................16 5.9 Outdoor Installation...............................................17 6. Maintenance ............................................17 7. Troubleshooting .......................................17 8. Technical Specification .............................18 8.1 Battery Information ...............................................18 8.2 Warranty.................................................................18 8.3 Safety Instructions .................................................19 JR_EYE-02.ENG.MAN.Manual.12.D- 2 - 1.2 EYE-02 Camera Description Please refer to the picture A on the inside front cover of this manual. 1Camera lens6GSM Antenna 2PIR motion sensor7Power button 3Green light (LED)8AC adaptor socket 4Red light (LED)9USB connector 5Infra red illumination (LEDs)10Battery cover 1.3 EYE-02 Camera Internal Parts Please refer to the EYE-02 camera picture D on the back cover of this manual. 1Dual band GMS antenna7 Microphone + digital signal processing • Glass-break detection 2 EDGE/GSM module - Picture transfer to mobile phones via MMS or e-mail - Data connection to monitoring servers and ARC 8 Short range radio • Free band 868 MHz • Allows cooperation with remote controls • Possible extension with JABLOTRON professional wireless security system 3 Buzzer • Built-in acoustic indicator 9 Tilt and vibration detector • Protects against intruder manipulation with the camera 4 Li-Ion battery • Provides back-up energy during electricity failure 10 Infrared reflector • Illuminates the scene by non-visible beams for camera night vision 5 SD memory card • Extends memory capacity up to 4 GB 11 PIR infrared detector • Excellent sensitivity for human body detection 6 SIM holder • For a standard GSM SIM card 12 VGA camera • CMOS chip with 2.9 mm lens 2. Camera Installation Before installing the camera, ensure you have a SIM card provided by your GSM operator with an activate the EDGE/GPRS internet connection and the MMS service. Some SIM cards are protected by PIN code. It is necessary to disable the PIN code protection of the SIM card. To do this, insert the SIM into your mobile phone and disable the PIN security code. If this is not observed, the EYE-02 …

Text truncated - open the document above for the full version.

From: JABLOCOM s.r.o. - Filip Kopriva V Nivach 12 46601Jablonec nad Nisou Czech Republic To: 7layers AG - Yao Jing Borsigstr. 11 40880 Ratingen Germany In Jablonec nad Nisou 2010-02-04 POWER OF ATTORNEY We, the undersigned, hereby authorize 7layers AG (Yao Jing) on our behalf, for handling with the TCB Service in all issues belongs to the FCC approval of product EYE-02. Any and all acts carried out by 7layers AG on our behalf shall have the same effect as acts of our own. This authorization expires once the whole FCC certification process is finished. Sincerely, JABLOCOM s.r.o. ______________________ Filip Kopriva - HW engineer JABLOCOM s.r.o.T.: +420 483 559 711CZK account355896470277/0100 V Nivách 12F.: +420 483 559 713EUR account355902870227/0100 46601 Jablonec nad Nisouwww.jablocom.comSWIFTKOMB CZ PP XXX Czech RepublicDIČ (VAT)CZ27275841

Request for confidentiality CONFIDENTIALITY REQUEST FOR , FCC-ID: VXPEYE-02 To Whom It May Concern: In accordance with provisions of Section 0.457(d) of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for transmitter’s exhibits, which contain Operation Description, Parts Lists, Block Diagram and Schematic Diagram. These exhibits contain proprietary, confidential and trade secrets material, which would not be routinely made available for public inspection. Also, in accordance with FCC Public DA 04-1705, we request short-term confidentiality until 2010/05/31 for exhibits, which contain External Photographs, Internal Photographs and the User Manual. These exhibits contain pre-market information, which could give our competitors unfair advantage should this information be released before this product is actually introduced into the common marketplace Do not hesitate to contact me if you have any additional questions. Company : JABLOCOM s.r.o V Nivách 12 46601 Jablonec nad Nisou Czech Republic Point of contact : Filip Kopřiva Signed, JABLOCOM s.r.o. JABLOCOM s.r.o.T.: +420 483 559 711CZK account355896470277/0100 V Niv ch 12 áF.: +420 483 559 713EUR account355902870227/0100 46601 Jablonec nad Nisouwww.jablocom.comSWIFTKOMB CZ PP XXX Czech RepublicDI (VAT) ČCZ27275841

Final Report on EYE-02 MDE_JABLO_0902_FCCaReport Reference: Februar y 05, 2010Date: Test Laboratory: 7 layers AG Borsigstr. 11 DGA-PL-192/99-02 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7 layers AGAufsichtsratsvorsitzender hRegistergerichthregistered in: Borsigstrasse 11Chairman of the Supervisory Board:Düsseldorf, HRB 44096 40880 Ratingen, GermanyMarkus BeckerUSt-IdNr hVAT No.: Phone: +49 (0) 2102 749 0Vorstand h Board:DE 203159652 Fax: +49 (0) 2102 749 350Dr. Hermann BuitkampTAX No. 147/5869/0385 www.7Layers.comWilfried Klassmann Reference: MDE_JABLO_0902_FCCa 2Test Object Data 2.1General OUT Description The following section lists all OUTs (Object's Under Test) involved during testing. OUT: EYE-02 Product Category:Camera and Video Manufacturer: JabloCOM s.r.o.Company Name: Street:V Nivách 12 City:466 01 Jablonec nad Nisou Country:Czech Republic http://www.jablocom.comCompany URL: Contact Person:Mr. Ing. Filip Kopriva Function:Hardware Engineer Phone:+420 483 559 711 Fax:+420 483 559 713 E-Mail:[email protected] ValueParameter name Parameter List: dedicated AC/DC adapterAC Power Supply Max. +2.5 (dBi)Antenna gain 1900 band Max. +2.5 (dBi)Antenna gain 850 band 6 (V)DC Power Supply 251 (848.8MHz) for GSM850, 810 (1909.8MHz) for GSM1900, 4233 (846.6MHz) for FDD5, 9538 (1907.6MHz) for FDD2, 1513 (1752.6MHz) for FDD4 highest channel 128 (824.2MHz) for GSM850, 512 (1850.2MHz) for GSM1900, 4132 (826.4MHz) for FDD5, 9262 (1852.4MHz) for FDD2, 1312 (1712.4MHz) for FDD4 lowest channel 190 (836.6MHz) for GSM850, 661 (1880.0MHz) for GSM1900, 4183 (836.6MHz) for FDD5, 9400 (1880MHz) for FDD2, 1412 (1732.4MHz)/1450 (1740.0MHz) for FDD4 mid channel type: integral, frequency: 868 (MHz)SRD antenna 868 (MHz)SRD transceiver Ancillary Equipment: Adapter Type / Model / Family:Accessory Made by UMEC Product Category:Others ValueParameter name Parameter List: AC 120VAC mains Voltage Ancillary Equipment: External GSM antenna Type / Model / Family:Accessory Product Category:Mobile Phone Accessory ValueParameter name Parameter List: 2.5 (dBi)Antenna gain 1900 band 2.5 (dBi)Antenna gain 850 band Ancillary Equipment: USB Page 4 of 26 Reference: MDE_JABLO_0902_FCCa Type / Model / Family:Accessory Product Category:Others 2.2Detailed Description of OUT Samples Sample : a05 OUT IdentifierEYE-02 Sample DescriptionCamera Serial No.000000042126 HW StatusJR12004-4 SW StatusJR601.1.5.8.f6_9 Nominal Voltage6 V DC Sample : ADA_a01 OUT IdentifierAdapter Sample DescriptionUMEC AC adapter Serial No.CJ122J776 52G HW StatusUP0121A-06PE Sample : Ant01 OUT IdentifierExternal GSM antenna Sample Descriptionexternal GSM antenna Serial No.- HW Status- SW Status- Sample : USB_a01 OUT IdentifierUSB Sample DescriptionUSB cable 2.3OUT Features Features for OUT:EYE-02 Allowed ValuesDesignationDescriptionSupported Value(s) Features for scope: FCC_v2 DCThe OUT is powered by or connected to DC Mains GSM850EUT supports GSM850 band 824MHz - 849MHz IantIntegral Antenna: permanent fixed antenna, which may be built-in, designed as an indispensable part of the equipment PantCpermanent fixed antenna connector, which may be built-in, designed as an indispensable part of the equipment PCS1900EUT supports PCS1900 band 1850MHz - 1910MHz SRDEUT is a short range device Page 5 of 26 Reference: MDE_JABLO_0902_FCCa 2.4Auxiliary Equipment AE No.Serial No.SW StatusHW StatusDescriptionType Designation AE monitorFlatron L1740BQ509WANF1W607 --TFT Monitor LG AE compps2 lenovo 90W 20V11S92P1103Z1ZB EF7161JH Rev 05-Power Supply lenovo AE comp2lenovo R60 9461-54G L3-AA471 06/10-WinXP Prof. Engl. Laptop IBM AE mouseM-BB48LZC90505478--Mouse Logitech AE compps1 PA3378E-3AC3- (P/N: G71C0006R310) --Power Supply Toshiba AE keybrdRS 6000G 0000273 2P28 --Keyboard CHERRY AE comp1Tecra M987060248H-WinXP Prof. Ger. Laptop Toshiba 2.5Operating Mode(s) Ref.-No.Description TCH190Sample is transmitting on channel TCH 190 GSM850 (836.6 MHz), connected to a computer via USB while transfering a video stream (1 fps), transmitting test signal on 868.5 MHz AM 105 kHz 14% mod. depth, charging from AC mains. TCH661Sample is transmitting on channel TCH 661 GSM1900 (1880.0 MHz), connected to a computer via USB while transfering a video stream (1 fps), transmitting test signal on 868.5 MHz AM 105 kHz 14% mod. depth, charging from AC mains. 2.6Setups used for Testing For each setup a relation is given to determine if and which samples and auxiliary equipment is used. The left side list all OUT samples and the right side lists all auxiliary equipment for the given setup. Sample No.Sample DescriptionAE No.AE Description Setup No.List of OUT samplesList of auxiliary equipment conducted_A05 (FCC 15B cond. setup) AE monitorTFT Monitor LGADA_a01UMEC AC adapterSample: AE compps2 Power Supply lenovoAnt01external GSM antennaSample: AE comp2Laptop IBMUSB_a01USB cableSample: AE mouseMouse Logitecha05CameraSample: AE keybrdKeyboard CHERRY radiated_A05 (FCC 15B rad. setup) AE monitorTFT Monitor LGADA_a01UMEC AC adapterSample: AE mouseMouse LogitechAnt01external GSM antennaSample: AE compps1 Power Supply ToshibaUSB_a01USB cableSample: AE keybrdKeyboard CHERRYa05CameraSample: AE comp1Laptop Toshiba Page 6 of 26 Reference: MDE_JABLO_0902_FCCa 3Results 3.1General Available at the test laboratory. The results of the inspection are described on the following pages, where 'Conformity' or 'Passed' means that the certification criteria were verified and that the tested device is conform to the applied standard. In cases where 'Declaration' is printed, the required documents are available in the manufacturers product documentation. In cases where 'not applicable' is printed, the test case requirements are not relevant to the specific equipment implementation. Documentation of tested devices: Interpretation of the test results: 3.2List of the Applica…

Text truncated - open the document above for the full version.

Reference: MDE_JABLO_0902 1Annex 1.1 Additional Information for Test Plan setup for radiated tests Page 1 of 2 Reference: MDE_JABLO_0902 setup for conducted tests Page 2 of 2
