VXPGDP-04IGSM Desktop Phone

User’s Guide GSM Desktop Phone GDP-04i xXC_GDP-04i.ENG.MAN.Manual.10.C - 1 - EN User‘s Guide INDEX Getting Started – first using Check the contents of the package Insert the SIM card Open the battery cover at the bottom of the phone, open the SIM holder by sliding it out along the arrow marked “OPEN”. Insert the SIM card into the SIM holder with the golden contact area facing upwards and the cut corner up on the left. Close the SIM holder and secure it by sliding it back until you feel a click. If you want to remove the SIM card, open the SIM holder in the same way and take out your SIM card. SIM card detail INDEX ..........................................................................1 Getting Started – first using ...................................1 Check the contents of the package ................................1 Insert the SIM card ..........................................................1 Install the backup battery ...............................................2 Connect the receiver cord ..............................................2 Connect the power adaptor – switch the phone ON ....2 Charge the battery ...........................................................2 Your Phone ................................................................3 BASIC call functions and phone book ....................4 Making a call ....................................................................4 Adding a new contact into the phonebook ...................4 Dialing a number from the phonebook .........................4 Text Messages (SMS) ..................................................4 Sending a text message ...................................................4 Opening an incoming message .......................................5 Other functions ........................................................5 Speed dial buttons ...........................................................5 Options .............................................................................6 Advanced call functions ..........................................6 Call Waiting ......................................................................6 Conference Call ................................................................6 Call Transfer .....................................................................7 Call Register ......................................................................7 Mute .................................................................................7 Headset Mode .................................................................7 Phonebook .................................................................7 Settings ......................................................................8 Phone settings ..................................................................8 Call settings ......................................................................8 Message settings .............................................................9 Sound settings .................................................................9 Security .............................................................................9 Service ..............................................................................9 PC interface .............................................................10 JabloTool call management software ...........................10 Connection with PC via USB ..........................................10 Connecting PC ................................................................11 Firmware update ...........................................................12 PC-fax ..............................................................................12 Connecting an analog phone (GDP-04Ai only) ............12 Troubleshooting ....................................................12 GDP-04i RF – wireless control guide .....................13 Social security alarm – PANIC button ...........................13 Remote control ..............................................................13 Technical Specifications .........................................14 Certification and Warranty ..................................14 Safety instructions ................................................15 xXC_GDP-04i.ENG.MAN.Manual.10.C - 2 - EN User‘s Guide Install the backup battery Connect the receiver cord Connect the power adaptor – switch the phone ON The message “Phone is starting...” appears on the LCD after con- necting the power adaptor. If your SIM card is protected by a PIN code, the phone will require it. Enter the PIN code and confirm it by pressing the green key or the OK selection key. If you enter an incorrect PIN code three times in a row, the PIN code will be blocked. To unblock it, you need to enter your PUK (Personal Unblocking Key) – check your SIM card documentation for details. Language The phone will set the language automatically according to the country code of your SIM card. Language can be changed manually in the Settings menu. Charge the battery The battery is empty on delivery and needs to be charged before the first using. The battery should be charged for about 5 hours to reach its full capacity. The battery is being charged whenever the phone is connected to the power adaptor – even when the phone is switched off. Use the battery and power adaptor only for its intended purpose. Never use any adaptor or battery that is damaged. Your phone may become warm during charging and during normal use. The phone is designed to be powered from the power adaptor. The limited capacity of the backup battery should only cover emergency calls in case of electricity failure. The standard talking time for a fully charged battery is about 3 hours. The standard standby time is about 48 hours. The battery gradually decreases its capacity during its lifetime. To reach the optimal parameters the battery should be kept in an environment between 5°C and 35°C. Never expose the battery to temperature out of the operati ng temp…
