VYXWIFI-010CPE 2628

Wireless 802.11a CPE User Manual Wireless 802.11a CPE User Manual Page 2 of 36 NOTICE Changes or modifications to the equipment, which are not approved by the party responsible for compliance, could affect the user's authority to operate the equipment. Company has an on-going policy of upgrading its products and it may be possible that information in this document is not up-to-date. Please check with your local distributors for the latest information. COPYRIGHT 2009 All Rights Reserved. No part of this document can be copied or reproduced in any form without written consent from the company. Trademarks: All trade names and trademarks are the properties of their respective companies. REVISION HISTORY Rev. Changes Date 0.1 Initial release August 28, 2009 Wireless 802.11a CPE User Manual Page 3 of 36 1. GETTING STARTED The WLAN Broadband CPE is delivered with the following factory default parameters on the Ethernet LAN interfaces. Default IP Address: 10.10.10.254 Default IP subnet mask: 255.255.255.0 WEB login User Name: admin WEB login Password: admin The device has four operation modes (Bridge /Gateway/WISP /AP Client). The default IP addresses for the device are 10.10.10.254, so you need to make sure the IP address of your PC is in the same subnet as the device, such as 10.10.10.X. It will take about 25 seconds to complete the boot up sequence after power on. Prepare your PC to configure the WLAN Broadband CPE For OS of Microsoft Windows 95/ 98/ Me: 1. Click the Start button and select Settings, then click Control Panel. The Control Panel window will appear. Note: Windows Me users may not see the Network control panel. If so, select View all Control Panel options on the left side of the window. 2. Move mouse and double-click the right button on Network icon. The Network window will appear. 3. Check the installed list of Network Components. If TCP/IP is not installed, click the Add button to install it; otherwise go to step 6. 4. Select Protocol in the Network Component Type dialog box and click Add button 5. Select TCP/IP in Microsoft of Select Network Protocol dialog box then click OK button to install the TCP/IP protocol, it may need the Microsoft Windows CD to complete the installation. Close and go back to Network dialog box after the TCP/IP installation. 6. Select TCP/IP and click the properties button on the Network dialog box. 7. Select Specify an IP address and type in values as following example.
IP Address: 10.10.10.1, (any IP address within 10.10.10.1 to 10.10.10.253 is good to connect the Wireless LAN Access Point).
IP Subnet Mask: 255.255.255.0 8. Click OK and reboot your PC after completes the IP parameters setting For OS of Microsoft Windows 2000, XP: 1. Click the Start button and select Settings, then click Control Panel. The Control Panel window will appear. 2. Move mouse and double-click the right button on Network and Dial-up Connections icon. Move mouse and double-click the Local Area Connection icon. The Local Area Connection window will appear. Click Properties button in the Local Area Connection window 3. Check the installed list of Network Components. If TCP/IP is not installed, click the Add button to install it; otherwise go to step 6. 4. Select Protocol in the Network Component Type dialog box and click Add button. Wireless 802.11a CPE User Manual Page 4 of 36 5. Select TCP/IP in Microsoft of Select Network Protocol dialog box then click OK button to install the TCP/IP protocol, it may need the Microsoft Windows CD to complete the installation. Close and go back to Network dialog box after the TCP/IP installation. 6. Select TCP/IP and click the properties button on the Network dialog box. 7. Select Specify an IP address and type in values as following example.
IP Address: 10.10.10.1, (any IP address within 10.10.10.1 to 10.10.10.253 is good to connect the Wireless LAN Access Point).
IP Subnet Mask: 255.255.255.0. 8. Click OK to complete the IP parameters setting. For OS of Microsoft Windows NT: 1. Click the Start button and select Settings, then click Control Panel. The Control Panel window will appear. 2. Move mouse and double-click the right button on Network icon. The Network window will appear. Click Protocol tab from the Network window. 3. Check the installed list of Network Protocol window. If TCP/IP is not installed, click the Add button to install it; otherwise go to step 6. 4. Select Protocol in the Network Component Type dialog box and click Add button. 5. Select TCP/IP in Microsoft of Select Network Protocol dialog box then click OK button to install the TCP/IP protocol, it may need the Microsoft Windows CD to complete the installation. Close and go back to Network dialog box after the TCP/IP installation. 6. Select TCP/IP and click the properties button on the Network dialog box. 7. Select Specify an IP address and type in values as following example.
IP Address: 10.10.10.1, any IP address within 10.10.10.1 to 10.10.10.253 is good to connect the Wireless LAN Access Point.
IP Subnet Mask: 255.255.255.0 8. Click OK to complete the IP parameters setting Wireless 802.11a CPE User Manual Page 5 of 36 2. CONFIGURATION OF WEB UTILITY The Wireless CPE implements a Web utility allowing user to manage the operation via a user friendly interface. This Utility provides comprehensive system management scheme, including system configuration, performance monitoring, system maintenance and administration. 2.1. Access Web Utility To access the Web Utility, you have to launch your Internet Browser. (i.e., MS. IE 5.0 or later, Netscape Navigator 4.7 or later).
Step1: Enter Wireless Router’s default IP address as http://10.10.10.254 in the Address field then press Enter.
Step2: Login dialog box will appear, enter admin as Administrator Name and admin as default administrator password, and then click “Login” to access configuration utility. - Wireless 802.11a CPE User Manual Page 6 of 36
Step3: After log in, you can see the Main menu as below. Wireless…

Text truncated - open the document above for the full version.

802.11a CPE Quick Installation Guide 1. Check the parts in your box CPE SET 1 DC 12V @ 1.25A Power Adapter 1 PoE DC Power Injector 1 Hose Clamps 2 CD user manual 1 2. How to fix the CPE on the Pole (1”- 1.5”) (For better water resistance please wrap the RJ45 connector) 3. PoE connection 1. Connect (POE) RJ45 Jack to CPE RJ45 Jack with good quality Ethernet cable. 2. Connect (LAN) Jack to PC or Switch Hub LAN port. 3. Plug in the power adaptor to PoE DC jack. 4. CPE Connection 1. Open the CPE enclosure you will find one RJ45 Jacks two LEDs and one reset button. 2. Connect the PoE cable to either LAN port. 3. To reset the CPE just press and hold the reset button for about 10 seconds and wait for 35 seconds to reboot the CPE. Notice: This CPE default operation mode is in Bridge mode. Please go to the webpage and change the operation mode to other mode for your CPE. 5. CPE configuration The WLAN Broadband Router is delivered with the following factory default parameters on the Ethernet LAN interfaces. Default IP Address: 10.10.10.254 Default IP subnet mask: 255.255.255.0 WEB login User Name: admin WEB login Password: admin The device has four operation modes (Gateway/Bridge/WISP/AP Client). Bridge/WISP/AP Client: The default IP addresses for the device are 10.10.10.254, so you need to make sure the IP address of your PC is in the same subnet as the device, such as 10.10.10.X. It will take about 25 seconds to complete the boot up sequence after power on from PoE. Gateway: The default IP addresses for the device are 172.32.1.254, so you need to make sure the IP address of your PC is in the same subnet as the device, such as 172.32.1.X. It will take about 25 seconds to complete the boot up sequence after power on from PoE.

Professional Installation Attestation Please be advised that due to the unique Market and function targeted by this product, this product will need special trained professional in configuring and installing the product. We hereby declare that the product will be distributed through controlled distribution channel which has special trained professional to install this product and will not be sold directly to the general public through retail store. FCC ID: VYXWIFI-010

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4

CPE 2628 Model name: 2*14dBi/2T2R FCC ID: VYXWIFI-010

FCC ID： ：： ：VYXWIFI-010 LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

FCC ID: VYXWIFI-010 Report No.: RF990716E10 Operational Description This device is a CPE, which operates in 5.745 ~ 5.825 GHz band; the maximum data rate could be up to 150Mbps which OFDM technique. The transmitter of the EUT is powered by 12Vdc from the power adapter which affix with this device. Please refer to below for the antenna information. The other instruction, please have a look at the users manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No.: SA990716E10 Report Format Version 4.0.0 1 RF EXPOSURE REPORT REPORT NO.: SA990716E10 MODEL NO.: 2*14dBi/2T2R FCC ID: VYXWIFI-010 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Argtek Communication Inc. ADDRESS: 8F-9,No. 4, Lane 609,Sec. 5, Chung Hsin Rd. San Chung City, Taipei Hsien ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan Report No.: SA990716E10 Report Format Version 4.0.0 2 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release NA Dec. 29, 2010 Report No.: SA990716E10 Report Format Version 4.0.0 3 1. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 3. CLASSIFICATION The antenna of this product, under normal use condition, is at least 50cm away from the body of the user. So, this device is classified as Mobile Device. 4. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745-5825 28.4 14 50 0.548 1.00 --- END ---

Report No.: RF990716E10 1 Report Format Version 4.0.0 FCC TEST REPORT (15.247) REPORT NO.: RF990716E10 MODEL NO.: 2*14dBi/2T2R FCC ID: VYXWIFI-010 RECEIVED: July 16, 2010 TESTED: Nov. 12 to 26, 2010 ISSUED: Dec. 29, 2010 APPLICANT: Argtek Communication Inc. ADDRESS: 8F-9,No. 4, Lane 609,Sec. 5, Chung Hsin Rd. San Chung City, Taipei Hsien ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 55 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF990716E10 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD................................................................................4 1. CERTIFICATION..............................................................................................5 2. SUMMARY OF TEST RESULTS.....................................................................6 2.1 MEASUREMENT UNCERTAINTY..................................................................7 3. GENERAL INFORMATION..............................................................................8 3.1 GENERAL DESCRIPTION OF EUT................................................................8 3.2 DESCRIPTION OF TEST MODES................................................................10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL..............11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS..............................14 3.4 DESCRIPTION OF SUPPORT UNITS..........................................................15 3.5 CONFIGURATION OF SYSTEM UNDER TEST..........................................16 4. TEST TYPES AND RESULTS.......................................................................18 4.1 CONDUCTED EMISSION MEASUREMENT...............................................18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT............................18 4.1.2 TEST INSTRUMENTS...................................................................................18 4.1.3 TEST PROCEDURES....................................................................................19 4.1.4 DEVIATION FROM TEST STANDARD.........................................................19 4.1.5 TEST SETUP.................................................................................................20 4.1.6 EUT OPERATING CONDITIONS..................................................................20 4.1.7 TEST RESULTS.............................................................................................21 4.2 RADIATED EMISSION MEASUREMENT.....................................................23 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT..................................23 4.2.2 TEST INSTRUMENTS...................................................................................24 4.2.3 TEST PROCEDURES....................................................................................26 4.2.4 DEVIATION FROM TEST STANDARD.........................................................26 4.2.5 TEST SETUP.................................................................................................27 4.2.6 EUT OPERATING CONDITIONS..................................................................27 4.2.7 TEST RESULTS.............................................................................................28 4.3 6dB BANDWIDTH MEASUREMENT............................................................37 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT.........................................37 4.3.2 TEST INSTRUMENTS...................................................................................37 4.3.3 TEST PROCEDURE......................................................................................37 4.3.4 DEVIATION FROM TEST STANDARD.........................................................37 4.3.5 TEST SETUP.................................................................................................37 4.3.6 EUT OPERATING CONDITIONS..................................................................37 4.3.7 TEST RESULTS.............................................................................................38 4.4 MAXIMUM PEAK OUTPUT POWER............................................................41 Report No.: RF990716E10 3 Report Format Version 4.0.0 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT...........41 4.4.2 INSTRUMENTS.............................................................................................41 4.4.3 TEST PROCEDURES....................................................................................41 4.4.4 DEVIATION FROM TEST STANDARD.........................................................41 4.4.5 TEST SETUP.................................................................................................41 4.4.6 EUT OPERATING CONDITIONS..................................................................41 4.4.7 TEST RESULTS.............................................................................................42 4.5 POWER SPECTRAL DENSITY MEASUREMENT.......................................43 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT....................43 4.5.2 TEST INSTRUMENTS...................................................................................43 4.5.3 TEST PROCEDURE.............................................................…
