W75-RL-RCUREMOTE RADAR

RCU Operation Manual 1. MUTE Button Press and release MUTE button to turn off the audio for any alert. When an audio alert is sounded, you can silence the alarm by pressing MUTE button. Press MUTE button again to turn on the audio alert. 2. Mark Button Press and release MARK button to memory the location you have selected. This location is stored in the memory and give an audio alert when you pass the marked location. 3. Volume Up Button Press Volume Up button to increase the audio volume. 4. Volume Down Button Press Volume down button to decrease the audio volume. 5. CITY/HIGHWAY Button City mode reduces the annoyance of false alerts typically encountered in urban driving areas. Highway mode provides full audio warning any time radar(X, K, Ka) or laser signals are detected, and is recommended for open road driving. 6. Power Button Press and release the POWER button to turn the unit on or off. INSTALLATION Mounting Guidelines • Mount the RCU near the driver’s seat or host board. • Do not mount your unit behind any objects. These obstructions have metal surfaces which can affect communication with host board. • To reduce the possibility of theft, conceal your unit when not in use. • Make sure the mounting location you have chosen is relatively level and is clean and dry. Clean with isopropyl alcohol if necessary to remove any waxes or polishes. • Separate the fastener strips. Peel the paper backing off each strip and adhere one piece to the place and the other piece to the bottom of the unit. Battery Replacement The battery is equipped with the unit. To replace the battery, carefully open the battery door. LIMITED WARRANTY The manufacturer warrants this product against all defects in materials and workmanship for a period of one (1) year from the date of the original purchase, subject to the following terms and conditions: The sole responsibility of the manufacturer under this Warranty is limited to either repair or, at the option of the manufacturer, replacement of the unit. There are no expressed or implied warranties, including those of fitness for a particular purpose of merchantability, which extend beyond the face hereof. SPECIFICATIONS Carrier Frequencies: 433.92 MHz (Single Channel) Frequency Stabilization Scheme : High-Q SAW Resonator Stabilization Modulation Method : Amplitude Shift Keying (By Carrier ON/OFF) Bit Duration : “1” – 2.25msec / “0” – 1.125msec Operating Temperature Range: -10° C to +80° C Storage Temperature Range: -20° C to +90° C Power Requirements: 3 V CR2032-type Li-Battery FCC INFORMATION This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Date : July 02, 2010 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ATTOWAVE CO., LTD. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): REMOTE RADAR / RL360 (FCC ID: W75-RL-RCU) We affirm that between SIEMIC and ATTOWAVE CO., LTD., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Hyun Joo, Cho / Director ATTOWAVE CO., LTD. 1005, 10F Leader’s Tower, 60-15 Gasan-dong, Gumchun-gu, Seoul, 153-801 Korea

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Date : July 02, 2010 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: W75-RL-RCU We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Circuit Diagram - Operational description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Hyun Joo, Cho / Director ATTOWAVE CO., LTD. 1005, 10F Leader’s Tower, 60-15 Gasan-dong, Gumchun-gu, Seoul, 153-801 Korea

Appendix C. External Photographs Report no. ETLE100607.0124, Page C1 of C3 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID:W75-RL-RCU Front view of EUT Rear view of EUT Appendix C. External Photographs Report no. ETLE100607.0124, Page C2 of C3 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID:W75-RL-RCU Left side view of EUT Right side view of EUT Appendix C. External Photographs Report no. ETLE100607.0124, Page C3 of C3 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID:W75-RL-RCU Top view of EUT Bottom view of EUT

Appendix A. FCC ID Label and Location Report no. ETLE100607.0124, Page A1 of A1 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID:W75-RL-RCU Product Label Sample with FCC Label information Following is a sample copy of the label that will be placed on the rear cabinet of the product. The FCC ID Label and compliance statement are marked in the product label. The warning statement and Information to the User are described in the user manual. ATTOWAVE CO., LTD. REMOTE RADAR FCC ID : W75-RL-RCU Model No. : RL360 POWER : DC 3 V Li-Battery Serial No. : Proto-type This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Manufacturer : ATTOWAVE CO., LTD. Made in Korea Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) Label here

Appendix D. Internal Photographs Report no. ETLE100607.0124, Page D1 of D3 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID:W75-RL-RCU Inside view EUT Appendix D. Internal Photographs Report no. ETLE100607.0124, Page D2 of D3 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID:W75-RL-RCU Top side view of main board Appendix D. Internal Photographs Report no. ETLE100607.0124, Page D3 of D3 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC ID:W75-RL-RCU Bottom side view of main board

This report only responds to the tested sample and may not be reproduced, except in full, without written approval of the ETL Inc. www.etl.re.kr Electromagnetic Emission FCC MEASUREMENT REPORT CERTIFICATION OF COMPLIANCE FCC Part 15 Certification Measurement This is REMOTE RADAR, Model RL360 has been tested in accordance with the measurement procedures specified in ANSI C63.4-2003 at the ETL Test Laboratory and has been shown to be complied with the electromagnetic radiated emission limits specified in FCC Rule Part15 Subpart C section 15.231. I attest to the accuracy of data. All measurement herein was performed by me or was made under my supervision and is correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Hyung Seok, Lee / Chief Engineer ETL Inc. #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel: 82-2-858-0786 Fax: 82-2-858-0788 PRODUCT : REMOTE RADAR MODEL/TYPE NO : RL360 / Proto-type FCC ID : W75-RL-RCU BRAND NAME : CALIBRE APPLICANT : ATTOWAVE CO., LTD. 1005, 10F Leader’s Tower, 60-15 Gasan-dong, Gumchun-gu, Seoul, 153-801 Korea Attn. : Hyun Joo, Cho / Director MANUFACTURER : ATTOWAVE CO., LTD. 1005, 10F Leader’s Tower, 60-15 Gasan-dong, Gumchun-gu, Seoul, 153-801 Korea FCC CLASSIFICATION : DSC : Part 15 Security/Remote Control Transmitter FCC RULE PART(S) : FCC Title 47, Part 15 Subpart C FCC PROCEDURE : ANSI C63.4-2003 TEST REPORT No. : ETLE100607.0124 DATES OF TEST : June 23, 2010 to June 24, 2010 REPORT ISSUE DATE : July 02, 2010 TEST LABORATORY : ETL Inc. (FCC Designation Number : KR0022) Report no. ETLE100607.0124, Page 2 of 23 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC TEST REPORT FCC ID: W75-RL-RCU Table of Contents FCC Measurement Report 1. Introduction 2. Product Information 3. Description of Tests 4. Test Condition 5. Test Results 5.1 Summary of Test Results 5.2 Radiated Emissions Measurement 5.3 Occupied Bandwidth Measurement 5.4 Radiated Emissions for Periodic radiators 5.5 Periodic Operation Measurement Plot 6. Sample Calculation 7. List of test Equipment used for Measurement Appendix A. FCC ID Label and Location Appendix B. Test Setup Photographs Appendix C. External Photographs Appendix D. Internal Photographs Appendix E. Block Diagram Appendix F. Circuit Diagram Appendix G. Operating Description Appendix H. User Manual Appendix I. Antenna Requirement Report no. ETLE100607.0124, Page 3 of 23 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC TEST REPORT FCC ID: W75-RL-RCU FCC MEASUREMENT REPORT Scope – Measurement and determination of electromagnetic emission(EME) of radio frequency devices including intentional radiators and/or unintentional radiators for compliance with the technical rules and regulations of the U.S Federal Communications Commission(FCC) General Information z EUT Type : REMOTE RADAR z Model Number : RL360 z FCC ID : W75-RL-RCU z S/N : Proto-type z Freq. Range : 433.92 MHz z FCC Rule Part(s) : FCC Part 15 Subpart C section 15.231 z Test Procedure : ANSI C63.4-2003 z FCC Classification : DSC: Part 15 Security/Remote Control Transmitter z Dates of Tests : June 23, 2010 to June 24, 2010 z Place of Tests : ETL Inc. Testing Lab. Radiated Emission test; #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea Conducted Emission test; ETL Inc. Testing Lab. 371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea z Test Report No. : ETLE100607.0124 Applicant Name : ATTOWAVE CO., LTD. Address : 1005, 10F Leader’s Tower, 60-15 Gasan-dong, Gumchun-gu, Seoul, 153-801 Korea Attention : Hyun Joo, Cho / Director Report no. ETLE100607.0124, Page 4 of 23 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC TEST REPORT FCC ID: W75-RL-RCU 1. INTRODUCTION The measurement test for radiated and conducted emission test was conducted at the ETL Inc. The site is constructed in conformance with the requirements of the ANSI C63.4-2003 and CISPR Publication 16. The ETL has site descriptions on file with the FCC for 3 m and 10 m site configurations. Detailed description of test facility was found to be in compliance with FCC Rules according to the ANSI C63.4-2003 and registered to the Federal Communications Commission (FCC Designation Number : KR0022). The measurement procedure described in American National Standard for Method of Measurement of Radio- Noise Emission from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz (ANSI C63.4-2003) was used in determining radiated and conducted emissions from the ATTOWAVE CO., LTD. Model: RL360 Report no. ETLE100607.0124, Page 5 of 23 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC TEST REPORT FCC ID: W75-RL-RCU 2. PRODUCT INFORMATION 2.1 Equipment Description The Equipment Under Test (EUT) is the REMOTE RADAR, Model: RL360 2.2 General Specification - Carrier Frequencies: 433.92 MHz (Single Channel) - Frequency Stabilization Scheme: High-Q SAW Resonator Stabilization - Modulation Method: Amplitude Shift Keying (By Carrier ON/OFF) - Bit Duration: “1” - 2.25 msec / “0” - 1.125 msec - Operating Temperature Range: -10 °C to +80 °C - Storage Temperature Range: -20 °C to +90 °C - Power Requirements: 3 V CR2032-type Li-Battery Report no. ETLE100607.0124, Page 6 of 23 Head Office: # 371-51 Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 ETLQP-21-F22-0 FCC TEST REPORT FCC ID: W75-RL-RCU 3. DESCR…
