W75-STR65RADAR DETECTOR

OWNER’S MANUAL STINGER S650 ALL-BAND RADAR AND LASER DETECTOR WITH VG-2, POP™ AND ULTRA-X / ULTRA-K MODES RADAR DETECTION Stinger S650 2 Radar detector Contents • Contents 2 • Congratulations! 3 • Package Contents 3 • Identifying parts of the unit 3 • Basic Features and Controls 4 • Feature descriptions 5 • Installing the Unit 5 Mounting guidelines 5 Windshield mounting 5 Hook-and-Loop Mounting 6 Changing the Panel 6 • Operation 7 • Power On 7 • Volume control 7 • Blue backlit display 7 • Mute on/off selection (Mute mode) 7 • Highway/City mode selection 7 • Tutorial mode 8 • Compass Calibration Set-up 10 • Menu Mode 10 1. Voice Alert Language selection 11 2. VG-2 detection On/Off selection 11 3. Voice Alert On/Off selection 11 4. Tone selection 11 5. Compass display selection 11 • Pulse Protection 11 • Memory confirmation 11 • Troubleshooting 12 • Care and Maintenance 13 • Specifications 14 Stinger S650 3 Radar detector Congratulations! You have purchased the STINGER S650, the newest radar/laser detector. The STINGER S650, incorporates the advanced new antenna technology and extremely low power-consuming circuitry to ensure top-class performance. The STINGER S650, is a complete integrated laser/radar detector, which detects all police radar guns, including Ultra-X and Ultra-K pulse mode radars, as well as laser guns. Besides, STINGER S650 is able to detect signals of VG-2 (devices detecting radar-detectors). The STINGER S650, provides distinct visual and audio alerts to warn you of the presence of X-, K-, Ka- band and VG2 radar signals as well as laser signals in front of you for 180º round. You can drive with confidence when you bring along the STINGER S650. Note: Some local regions and federal regulations may prohibit the use of detection device. Please check with authorities regarding the use of this device in your area before operating it. Package Contents Your STINGER radar/laser detector package includes the following components: • The STINGER S650 radar/laser detector • Changeable Panel (2ea) • Windshield mounting bracket with suction cups (3ea) and bumper • Coiled 12-volt DC power cord • Dashboard mounting hook and loop fasteners (1ea) • Operation manual Identifying parts of the unit Power Cord Spare Fuse Mounting Bracket Stinger S650 4 Radar detector Fastener Tape Changeable Panel STINGER 650 Basic Features and Controls Stinger S650 5 Radar detector Feature descriptions • protection against all radar bands (X, K, and super wide Ka) • 360° laser coverage against all laser guns • VG-2 signal Detection Capabilities • pulse signal Detection Capabilities • digital compass display mode • city mode to virtually eliminate false radar alerts • user selectable brightness and mute on/off • power on/off and volume control wheel • BLUE BACKLIT DIGITAL Text Display • tutorial mode to demonstrate operations • memory to retain previously set operational modes after power-off • corded power connection into 12-volt car lighter socket (Power cord included) Installing the Unit Mounting guidelines The STINGER radar/laser detector can be mounted on your windshield or dashboard using the mounting bracket and hook-and-loop fastener provided. • Mount on the windshield in a centered location that will not obstruct the view of the driver and is within reach, so the buttons can be easily accessed. • Do not mount behind windshield wipers, metal surfaces, ornaments, or mirrored sunscreen glass, as these affect radar/laser signals. Tinted glass does not affect radar/laser signal reception. Conceal the STINGER radar/laser detector when you leave your vehicle to prevent theft and to minimize the unit's exposure to extreme temperatures, which can temporarily impair performance. Windshield mounting 1. Install the suction cups and bumper onto the windshield mounting bracket by sliding them into their holes (if not pre-installed). 2. Press the bracket base firmly against the windshield until the suction cups securely take hold. 3. Fasten the bracket at the top sides’ slots of the unit. Stinger S650 6 Radar detector 4. Bend the angle of the windshield mounting bracket, if necessary, to adjust for best viewing and detection angle. 5. When you want to connect power from your vehicle, plug the small connector of the power cord into the 12-volt DC power input jack located on the side of the detector. 6. Plug the large adapter of the power cord into the lighter socket of your vehicle. Hook-and-Loop Mounting The hook-and-loop tape included with your detector might be the best mounting method for some dashboards. Follow these instructions to use the hook-and-loop tape. 1. Use a damp cloth to thoroughly clean both the bottom of the detector and the dashboard. 2. Peel off the tape's paper backing and apply the tape to the bottom of the detector. 3. Remove the paper backing from the other side of the tape and press the detector onto the dashboard. Changing the Panel To change the panel to another one, follow these steps. 1. Lift up the panel by forefinger or screwdriver from the slot at the mounting bracket location. The panel will pop out as follows. 2. Insert the tap of replacing panel near the display into the unit. Gently snap in the other taps to the back of the unit. Stinger S650 7 Radar detector Operation Power On Rotate the wheel controller (located on the side of the detector) until you hear it click. The STINGER radar/laser detector goes through a self-diagnosis sequence and displays the last mode previously set in memory. Volume control Use the volume thumb wheel, located on the side of the STINGER radar/laser detector to adjust volume level. Blue backlit display Press DIM/MENU button to turn on the blue backlit. Mute on/off selection (Mute mode) Press the MUTE/CITY button repeatedly to toggle between mute on (1 beep) and mute off (2 beep) modes. Mute on will silence the audio alarm for the remainder of an existing signal and for any new alert received. You may also adjust the audio level by using the volume thumb…
