WIBTZW008Wireless Thermostat

Model TZ45 Z-Wave Thermostat INSTALLATION AND OPERATION MANUAL DCN: 141-01773-01 10/20/10 RCS DCN: 141-01773-01 10/20/10 2 Model: TZ45 Z-Wave Thermostat This manual applies to the following product revisions or later revisions up to the next manual revision release: Product Part No: Firmware Revision Z-Wave Thermostat 001-01773 1.00.3 Document Revision History Revision Date Changes 01 10/20/10 Original release Product Specifications Product Model: TZ45 Product: Thermostat for Heating and Cooling HVAC System control. Z-Wave RF communications enabled Thermostat Size: 5.7” wide x 4.0” height x 1.2” depth Display: Graphical LCD, 2.75” x 1.5”, 64x128 pixel Backlight: Yes, Blue/white, Controllable, on, off, timeout Contrast: Adjustable on screen Buttons: 6 LEDs: 4 (3 green, 1 red) Power: 24VAC from HVAC System Temperature Sensing Range: -40F to +190F HVAC System Type Compatible: Standard (gas/electric) or Heat Pump Multistage System Compatible: Standard HVAC Systems: 2 stage heating, 2 stage cooling Heat Pump Systems: 3 stage heating (2 compressor, 1 aux heat), 2 stage cooling Heat Pump change over valve: Selectable change over with cool or with heat Remote Sensors: 2 connections, two wire, remote primary or averaging Communications: Z-Wave RF DCN: 141-01773-01 10/20/10 3 Table of Contents Overview...................................................................................................................................................... 4 Z-Wave® Installation................................................................................................................................... 5 Setback Mode Operation ........................................................................................................................... 5 Inclusion and Exclusion ............................................................................................................................. 5 Thermostat Control Screen........................................................................................................................ 6 Temperature Display ................................................................................................................................. 6 Setpoint Display .........................................................................................................................................6 Thermostat Operation Buttons .................................................................................................................. 7 Setpoint Up/Down Buttons......................................................................................................................... 7 Clock Display ............................................................................................................................................. 7 LED Displays .............................................................................................................................................7 Setting Heating or Cooling Setpoints ......................................................................................................... 8 Schedules Screen.................................................................................................................................... 13 User Settings Screen............................................................................................................................... 16 Thermostat Info Screen ........................................................................................................................... 22 Main Menu > Installer Settings (Hidden Screen)................................................................................. 23 Installer Settings Summary...................................................................................................................... 26 HVAC System Connection........................................................................................................................ 27 HVAC System Compatibility .................................................................................................................... 27 Remote Communications ........................................................................................................................ 27 HVAC System Operation and Setup........................................................................................................ 28 Standard HVAC System Types ............................................................................................................... 28 Heat Pump HVAC System Types ............................................................................................................ 28 Power....................................................................................................................................................... 30 Standard Gas/Electric HVAC System Wiring .......................................................................................... 31 Heat Pump HVAC System Wiring ........................................................................................................... 32 FCC............................................................................................................................................................. 33 DCN: 141-01773-01 10/20/10 4 Overview Z-Wave Thermostat The Z-Wave thermostat provides for typical thermostat control of a central heating and cooling HVAC system plus has the added feature of Z-Wave communications for remote control. The thermostat has a large, backlit graphical display, control buttons, status LEDs and a temperature sensor. The thermostat can display multiple screens for different functions of the thermostat. The default thermostat control screen shown below, will display the current room temperature, heating and cooling setpoints, system mode, manual-fan mode, time, and status information. Display operation Thermostat control screen Normally the thermo…

Text truncated - open the document above for the full version.

RCS October 26, 2010 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification FCC ID: WIBTZW008 IC: _____n/a____________ Authority to Act as Agent On our behalf, I appoint Alan Laudani of Nemko USA Inc., 11696 Sorrento Valley Rd, San Diego, CA, USA to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in Federal Communication Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Michael Hoffman, 11481 Sunrise Gold Circle Suite 1 Rancho Cordova, CA 95742, expiring (input date 6 months from now) Sincerely, Michael Hoffman VP Engineering Residential Control Systems

RCS October 26, 2010 To: Nemko 11696 Sorrento Valley Rd. San Diego CA, 92121 USA Re: Request of Confidentiality for FCC ID#: WIBTZW008 Pursuant to Sections 0.457(d)(I)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying as outlined below: Schematics, Parts List, Operating Description, Block Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(I)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Michael Hoffman VP Engineering Residential Control Systems 11481 Sunrise Gold Circle Suite 1 Rancho Cordova, California (800) 952-24258 Fax (916) 635-7668

RCS TZ45 Exterior Photos Page 1 10/26/10 RCS TZ45 Exterior Photos Page 2 10/26/10

LABEL REQUIREMENTS RF IC & FCC Model No.: TZ45 RCS FCC ID: WIBTZW008 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. LABEL LOCATION

RCS TZ45 Product Photos Page 1 10/26/10 RCS TZ45 Product Photos Page 2 10/26/10 RCS TZ45 Product Photos Page 3 10/26/10 RCS TZ45 Product Photos Page 4 10/26/10 RF Module Assembly

Nemko USA, Inc. 11696 Sorrento Valley Rd., Suite F San Diego, CA 92121-1024 Phone (858) 755-5525 Fax (858) 452-1810 FCC Part 15 Subpart C, 15.249 : 02/11/2010 CERTIFICATION TEST REPORT In Accordance With: FCC Part 15 Subpart C, 15.249 Applicant: Residential Control Systems 11481 Sunrise Gold Circle, Ste. 1 Rancho Cordova, CA 95742 Equipment Under Test (EUT): Thermostat Model: TZ45 FCC ID Number: WIBTZW008 Tested By: Nemko USA Inc. 11696 Sorrento Valley Road, Suite F San Diego, CA 92121 Test Report: 2010 10159492 FCC Date: October 25, 2010 Project number: 58365-1 Total Number of Pages: 18 Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 Fax (858) 452-1810 Report Number: 2010 10159492 FCC FCC ID: WIBTZW008 Specification: FCC Part 15 Subpart C, 15.249 Page 2 of 18 Section 1. Summary of Test Results General All measurements are traceable to national standards These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15; Subpart C. Radiated tests were conducted is accordance with ANSI C63.4-2003. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. The assessment summary is as follows: Apparatus Assessed: Thermostat TZ45 Specification: FCC Part 15 Subpart C, 15.249 Compliance Status: Complies Exclusions: None Non-compliances: None Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 Fax (858) 452-1810 Report Number: 2010 10159492 FCC FCC ID: WIBTZW008 Specification: FCC Part 15 Subpart C, 15.249 Page 3 of 18 Report Release History: REVISION DATE COMMENTS - October 25, 2010 Prepared By: Alan Laudani - October 25, 2010 Initial Release: Alan Laudani Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. Nemko USA Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. Alan Laudani, RF/EMC Test Engineer Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 Fax (858) 452-1810 Report Number: 2010 10159492 FCC FCC ID: WIBTZW008 Specification: FCC Part 15 Subpart C, 15.249 Page 4 of 18 TABLE OF CONTENTS Section 1. Summary of Test Results....................................................................... 2 Section 2: Equipment Under Test ................................................................................ 5 2.1 Theory of Operation.............................................................................................. 5 2.4 Technical Specifications of the EUT ..................................................................... 5 Section 3: Test Conditions ........................................................................................... 6 3.1 Specifications ....................................................................................................... 6 3.2 Deviations From Laboratory Test Procedures...................................................... 6 3.3 Test Environment ................................................................................................. 6 3.4 Test Equipment .................................................................................................... 7 Section 4: Observations ............................................................................................... 8 4.1 Modifications Performed During Assessment....................................................... 8 4.2 Record Of Technical Judgements ........................................................................ 8 4.3 EUT Parameters Affecting Compliance ................................................................ 8 4.4 Tests Deleted ....................................................................................................... 8 4.5 Additional Observations........................................................................................ 8 Section 5: Results Summary ........................................................................................ 9 5.1 FCC Part 15 Subpart C Test Results.................................................................... 9 Appendix A: Test Results........................................................................................... 10 Conducted Emissions Test Data ................................................................................... 10 Clause 15.215(c) Occupied Bandwidth ......................................................................... 11 Radiated Emissions within Restricted Bands................................................................ 12 Radiated Emissions....................................................................................................... 12 Conducted Emissions Test Data—Receive Mode......................................................... 17 Radiated Emissions Test Data—Receive Mode............................................................ 18 Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 Fax (858) 452-1810 Report Number: 2010 10159492 FCC FCC ID: WIBTZW008 Specification: FCC Part 15 Subpart C, 15.249 Page 5 of 18 Section 2: Equipment Under Test 2.1 Theory of Operation The TZ45 is a Thermostat. Its function is to communicate set point data with a furnace or air conditioner system. Unterminated typical wiring was added to ensure worst case spurious emiss…

Text truncated - open the document above for the full version.

CONDUCTED EMISSIONS CONDUCTED EMISSIONS BACKVIEW RADIATED EMISSIONS, BANDWIDTH, BANDEDGE
