WL6-RTL8188CUSElitePad S10

[鍵入文字] ElitePad S10 User Manual [鍵入文字] Registered Trademarks and Warranty The company is entitled to change and revise the information in this user manual on regular basis without prior notice. All the changed or revised information will be incorporated in the new version of user manual or incorporated within the supplementary files and publications. The warranties for product and service are only set forth in the express warranty statements accompanying such product and service. Nothing herein should be construed as constituting an additional warranty. The company shall not be liable for technical or editorial errors or omissions contained herein. Please fill in the space below with the product model, serial number, purchase date and place of purchase and other related purchase information. The Serial number and model can be found on the label affixed to the computer. The information in this manual should include serial number, model number and purchase information. The liability of Elitegroup Computer Systems Co., Ltd. is limited to the compensation limitation set forth within the application product warranty of this manual. You may not reproduce, store, or transmit the confidential information in any form or by any means (electronic, mechanical, photocopying, recording or otherwise) of this manual without the prior written permission of Elitegroup Computer Systems Co., Ltd. ElitePad S10 Product model: Product serial number: Date of purchase: Place of purchase: The logo of Elitegroup Computer Systems Co., Ltd. belongs to Elitegroup Computer Systems Co., Ltd. All trademarks and registered trademarks belong to the company. [鍵入文字] Contents FEDERAL COMMUNICATIONS COMMISSION, FCC .............................................................. 5 FCC STATEMENT ............................................................................................................................. 5 FCC RADIATION EXPOSURE STATEMENT .............................................................................................. 5 PRODUCT MAINTENANCE ................................................................................................. 7 MAINTAINING YOUR ELITEPAD S10 ................................................................................................... 7 MAINTAINING YOUR AC ADAPTER ..................................................................................................... 8 GENERAL INFORMATION OF ELITEPAD S10 ...................................................................... 10 SPECIFICATION .............................................................................................................................. 10 ACCESSORIES................................................................................................................................ 11 THE APPEARANCE ......................................................................................................................... 12 BATTERY CHARGING ...................................................................................................................... 14 COMBINATION KEYS ...................................................................................................................... 15 LED STATUS ................................................................................................................................. 16 SYSTEM INSTALLATION ................................................................................................... 18 INSTALLING WINDOWS 7 ................................................................................................................ 18 INSTALLING ELITEPAD S10 DRIVERS ................................................................................................. 20 GETTING STARTED WITH ELITEPAD S10 ........................................................................... 22 TURN ON/ TURN OFF ELITEPAD S10 ............................................................................................... 22 FUNCTIONALITY ............................................................................................................................ 23 TYPING ....................................................................................................................................... 25 CONNECTING TO THE WIRELESS INTERNET .......................................................................................... 25 APPENDIX....................................................................................................................... 27 FREQUENT ASKED QUESTIONS ........................................................................................................ 27 COMFORT RELATED INFORMATION ................................................................................................... 29 SAFETY AND PRECAUTIONS ............................................................................................................. 31 [鍵入文字] Federal Communications Commission, FCC FCC Statement FCC Radiation Exposure Statement [鍵入文字] Federal Communications Commission, FCC FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipme…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Project No.: 1102C032 Page 2 of 29 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 2 of 29 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 3 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 3 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 4 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 4 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 3 of 29 Without SIM Card Slot With SIM Card Slot 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 3 of 29 Without SIM Card Slot With SIM Card Slot 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 4 of 29 Adapter : DARFON 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 4 of 29 Adapter : DARFON 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 5 of 29 Adapter : ENG 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 5 of 29 Adapter : ENG 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 6 of 29 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 7 of 29 Adapter : Huntkey 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 7 of 29 Adapter : Huntkey 1102C032 1102C032

Pantone 8202C Pantone 8202C Panton8202C 3131777 CONFORMS TO ANSI/UL STD. 60950-1 CERTIFIED TO CAN/CSA STD. C22.2 NO 60950-1 Elitegroup Computer Systems Co., Ltd. Made in China This equipment complies with Par t15 of the FCC rules. Oper ation is subject to the following two conditions: (1) This device may not cause hanmful interfer ence, and (2) This device must accept any interfer ence received, including interfer ence that may cause undesired oper ation. Rating : 12V 2A FCC ID:WL6-RTL8188CUS Proudut Name: E litePad S10 Model No. : S10OT1

Neutron Engineering Inc. Project No.: 1102C032 Page 10 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 10 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 11 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 11 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 12 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 12 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 13 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 13 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 14 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 14 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 15 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 15 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 16 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 16 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 17 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 17 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 18 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 18 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 19 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 19 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 20 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 20 of 31 1102C032 1102C032

Neutron Engineering Inc. Project No.: 1102C032 Page 21 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 21 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 22 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 22 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 23 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 23 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 24 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 24 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 25 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 25 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 26 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 26 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 27 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 27 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 28 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 28 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 29 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 29 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 30 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 30 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 31 of 31 1102C032 1102C032 Neutron Engineering Inc. Project No.: 1102C032 Page 31 of 31 1102C032 1102C032

Report Reference: MCN_ELITE_1101_FCC SAR Page 1 of 33 SAR Test Report Annex on ELITE S10OT1 Report Reference: MCN_ELITE_1101_FCC SAR Date: 3, 25, 2011 Test Laboratory: Beijing 7 layers Huarui Communications Technology Co., Ltd. No.11 Yue Tan Nan Street, Xi Cheng District Beijing 100045 China P.R. Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. Beijing 7layers Huarui Communications Technology Co., Ltd. No11 Yue Tan Nan Street, Xi Cheng District Chairman of the Board: Beijing, China 100045 Mr. Yang Zemin Phone: +86 010 68050368 Vice Chairman of Board: Fax: +86 010 68050370 Dr. Hans-Jürgen Meckelburg www.7Layers.cn Report Reference: MCN_ELITE_1101_FCC SAR Page 2 of 33 Appendix A: Dipole Certification Report Reference: MCN_ELITE_1101_FCC SAR Page 3 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 4 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 5 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 6 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 7 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 8 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 9 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 10 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 11 of 33 Appendix B: Probe Certification Report Reference: MCN_ELITE_1101_FCC SAR Page 12 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 13 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 14 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 15 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 16 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 17 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 18 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 19 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 20 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 21 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 22 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 23 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 24 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 25 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 26 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 27 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 28 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 29 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 30 of 33 Appendix C: Phantom Conformity Report Reference: MCN_ELITE_1101_FCC SAR Page 31 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 32 of 33 Report Reference: MCN_ELITE_1101_FCC SAR Page 33 of 33

Report Reference: MCN_ELITE_1101_FCC SAR Page 1 of 11 SAR Test Report Plots on ELITE S10OT1 FCC ID: WL6-RTL8188CUS Report Reference: MCN_ELITE_1101_FCC SAR Date: 3, 11, 2011 Test Laboratory: Beijing 7 layers Huarui Communications Technology Co., Ltd. No.11 Yue Tan Nan Street, Xi Cheng District Beijing 100045 China P.R. Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. Beijing 7layers Huarui Communications Technology Co., Ltd. No11 Yue Tan Nan Street, Xi Cheng District Chairman of the Board: Beijing, China 100045 Mr. Yang Zemin Phone: +86 010 68050368 Vice Chairman of Board: Fax: +86 010 68050370 Dr. Hans-Jürgen Meckelburg www.7Layers.cn Report Reference: MCN_ELITE_1101_FCC SAR Page 2 of 11 Appendix A: SAR plots for other position 1 Left side – middle channel DASY4 Configuration: - Probe: ES3DV3 - SN3109; ConvF(4.26, 4.26, 4.26); Calibrated: 2010-8- 25 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn685; Calibrated: 2010-8-19 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 171 low/Area Scan (61x131x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (interpolated) = 0.651 mW/g low/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 17.4 V/m; Power Drift = -0.043 dB Peak SAR (extrapolated) = 1.12 W/kg SAR(1 g) = 0.547 mW/g; SAR(10 g) = 0.259 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.611 mW/g Report Reference: MCN_ELITE_1101_FCC SAR Page 3 of 11 0 dB = 0.611mW/g Report Reference: MCN_ELITE_1101_FCC SAR Page 4 of 11 2 Bottom side – middle channel DASY4 Configuration: - Probe: ES3DV3 - SN3109; ConvF(4.26, 4.26, 4.26); Calibrated: 2010-8- 25 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn685; Calibrated: 2010-8-19 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 171 low/Area Scan (61x211x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (interpolated) = 0.014 mW/g low/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 1.43 V/m; Power Drift = -0.091 dB Peak SAR (extrapolated) = 0.026 W/kg SAR(1 g) = 0.013 mW/g; SAR(10 g) = 0.0075 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.014 mW/g Report Reference: MCN_ELITE_1101_FCC SAR Page 5 of 11 0 dB = 0.014mW/g Report Reference: MCN_ELITE_1101_FCC SAR Page 6 of 11 3 Top side – middle channel DASY4 Configuration: - Probe: ES3DV3 - SN3109; ConvF(4.26, 4.26, 4.26); Calibrated: 2010-8- 25 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn685; Calibrated: 2010-8-19 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 171 low/Area Scan (61x211x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (interpolated) = 0.008 mW/g low/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 1.74 V/m; Power Drift = -0.164 dB Peak SAR (extrapolated) = 0.014 W/kg SAR(1 g) = 0.00401 mW/g; SAR(10 g) = 0.00175 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.005 mW/g Report Reference: MCN_ELITE_1101_FCC SAR Page 7 of 11 0 dB = 0.005mW/g Report Reference: MCN_ELITE_1101_FCC SAR Page 8 of 11 4 Back side – low channel DASY4 Configuration: - Probe: ES3DV3 - SN3109; ConvF(4.26, 4.26, 4.26); Calibrated: 2010-8- 25 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn685; Calibrated: 2010-8-19 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 171 low/Area Scan (131x201x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 1.35 mW/g low/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 5.94 V/m; Power Drift = 0.182 dB Peak SAR (extrapolated) = 3.35 W/kg SAR(1 g) = 1.36 mW/g; SAR(10 g) = 0.544 mW/g Maximum value of SAR (measured) = 1.30 mW/g 0 dB = 1.30mW/g Report Reference: MCN_ELITE_1101_FCC SAR Page 9 of 11 5 Back side – middle channel DASY4 Configuration: - Probe: ES3DV3 - SN3109; ConvF(4.26, 4.26, 4.26); Calibrated: 2010-8- 25 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn685; Calibrated: 2010-8-19 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 171 mid/Area Scan (131x201x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (interpolated) = 1.32 mW/g mid/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 6.10 V/m; Power Drift = 0.166 dB Report Reference: MCN_ELITE_1101_FCC SAR Page 10 of 11 Peak SAR (extrapolated) = 3.33 W/kg SAR(1 g) = 1.35 mW/g; SAR(10 g) = 0.542 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 1.30 mW/g 0 dB = 1.30mW/g Report Reference: MCN_ELITE_1101_FCC SAR Page 11 of 11

Report Reference: MCN_ELITE_1101_FCC SAR Page 1 of 34 SAR Test Report on ELITE S10OT1 FCC ID: WL6-RTL8188CUS Report Reference: MCN_ELITE_1101_FCC SAR Date: 3, 25, 2011 Test Laboratory: Beijing 7 layers Huarui Communications Technology Co., Ltd. No.11 Yue Tan Nan Street, Xi Cheng District Beijing 100045 China P.R. Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. Beijing 7layers Huarui Communications Technology Co., Ltd. No11 Yue Tan Nan Street, Xi Cheng District Chairman of the Board: Beijing, China 100045 Mr. Yang Zemin Phone: +86 010 68050368 Vice Chairman of Board: Fax: +86 010 68050370 Dr. Hans-Jürgen Meckelburg www.7Layers.cn Report Reference: MCN_ELITE_1101_FCC SAR Page 2 of 34 Table of Contents 1 General Information .......................................................................... 4 1.1 Tester .......................................................................................... 4 1.2 Test laboratory information ............................................................. 5 1.3 Details of applicant and manufacturer ............................................... 5 2 Object Under Test .............................................................................. 6 2.1 General OUT Description ................................................................. 6 2.2 Identification of OUT ...................................................................... 6 2.3 OUT Photographs ........................................................................... 7 3 Standard ............................................................................................ 9 3.1 Distinction between exposed population, duration of exposure and frequencies ........................................................................................... 9 3.2 Distinction between Maximum Permissible Exposure and SAR Limits ... 10 3.3 SAR limit .................................................................................... 10 4 Test Requirements .......................................................................... 12 4.1 General requirements ................................................................... 12 4.2 Phantom requirements ................................................................. 12 4.3 Brain & Muscle Simulating Mixture Characterization .......................... 13 4.4 Test positions .............................................................................. 13 4.5 Liquid Depth ............................................................................... 14 5 Test Procedure ................................................................................ 15 5.1 Test Equipment List ..................................................................... 15 5.2 Test System Setup ....................................................................... 16 5.3 Measurement Procedure ............................................................... 16 5.4 Test to be performed .................................................................... 16 5.5 Test positions for device under test ................................................ 18 5.6 Test environment ........................................................................ 21 5.7 Liquid parameters ........................................................................ 21 5.8 System performance check ........................................................... 22 5.9 Conducted power ......................................................................... 23 5.10 Antenna Seperation ................................................................... 26 6 SAR test results and evaluation ....................................................... 27 Report Reference: MCN_ELITE_1101_FCC SAR Page 3 of 34 6.1 Measurement Result ..................................................................... 27 6.1.1 Body SAR test results ............................................................. 27 6.2 Summary and comparison to the limit ............................................ 27 7 Reports of DASY4 system ................................................................ 28 7.1 Detailed Measurement Report ........................................................ 28 7.1.1 Maximum body SAR of 802.11b ................................................ 28 7.2 System performance check report .................................................. 31 8 Uncertainty budget .......................................................................... 33 9 Reference Document ....................................................................... 34 Report Reference: MCN_ELITE_1101_FCC SAR Page 5 of 34 1.2 Test laboratory information Lab Name: Beijing 7 layers Huarui Communications Technology Co., Ltd. Address: No.11, Yue Tan Nan Street, Xi Cheng District, Beijing P. R. CHINA, 100045 Tel: +86 10 68050369 Fax: +86 10 68050370 Web: www.7layers.cn Accredited by: China National Accreditation Service for Conformity Assessment (CNAS) Registration number: No. CNAS L4320 1.3 Details of applicant and manufacturer Name: ELITEGROUP COMPUTER SYSTEMS CO., LTD Address: No.239,Sec.2,Ti Din g Blvd., Taipei, Taiwan Contact Person: CK Huang Telephone: +886 2 2162 1177, Ext. 23665 Fax: +886 2 2797 2829 E-mail: [email protected] Report Reference: MCN_ELITE_1101_FCC SAR Page 6 of 34 2 Object Under Test 2.1 General OUT Description Manufacturer: ELITEGROUP COMPUTER SYSTEMS CO., LTD Model Name: S10OT1 S10OTxxxxx;S10OTxxxxx series;S10 series (The X means 0-9,A-Z,or blank for any characteristic for marketing purpose) Product Category: Tablet computer Serial Number: N.A HW version: N.A SW version: N.A 2.2 Identification of OUT Item Description Manufacturer Type Serial Number Remark 1 adapter ENG 3A- 242WU12 N.A N.A 2 adapter Huntkey HKA02412 020-2C N.A N.A 3 adapter Darfon BU24-120 N.A N.A 4 battery ATL S20- 5159B5N- 0100 N.A N.A Report Reference:…

Text truncated - open the document above for the full version.

Report Reference: MCN_ELITE_1101_FCC SAR Page 7 of 34 2.3 OUT Photographs Report Reference: MCN_ELITE_1101_FCC SAR Page 8 of 34 Report Reference: MCN_ELITE_1101_FCC SAR Page 26 of 34 5.10 Antenna Seperation According to FCC KDB 447498 section 4 requirements: 1) and the separation of the Wifi and BT antenna is 61mm, large than 50mm, as specified in the documents. 2) The sum of the 1-g SAR is < 1.6 W/kg for all of all simultaneous transmitting antennas that require stand-alone SAR evaluation. 3) the conducted power of Bluetooth is is 3.56 mW less than 60/f(GHz)， so the stand-alone SAR for BT is not required So the SAR is not required for the simultaneous transmission. 255mm 5mm 43mm 61mm 5mm 58mm 255mm Wifi antenna BT antenna Report Reference: MCN_ELITE_1101_FCC SAR Page 18 of 34 5.5 Test positions for device under test Position 1 :Back side Position 2 :Bottom side Wifi antenna Wifi antenna 4mm 43mm Report Reference: MCN_ELITE_1101_FCC SAR Page 19 of 34 Position 3 :Top side Position4 :Left side Wifi antenna 119mm Wifi antenna 5mm Report Reference: MCN_ELITE_1101_FCC SAR Page 20 of 34 Position5 :Right side According to KDB 447498 4)ii)(2)SAR is required only for the edge with the most conservative exposure condition. No SAR at this position. Wifi antenna 255mm

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1102C032 Page 2 of 121 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1102C032 Page 3 of 121 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 12 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 13 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 14 3.5 DESCRIPTION OF SUPPORT UNITS 15 4 . EMC EMISSION TEST 16 4.1 CONDUCTED EMISSION MEASUREMENT 16 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 16 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 16 4.1.3 TEST PROCEDURE 17 4.1.4 DEVIATION FROM TEST STANDARD 17 4.1.5 TEST SETUP 17 4.1.6 EUT OPERATING CONDITIONS 17 4.1.7 TEST RESULTS 18 4.2 RADIATED EMISSION MEASUREMENT 24 4.2.1 RADIATED EMISSION LIMITS 24 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 25 4.2.3 TEST PROCEDURE 26 4.2.4 DEVIATION FROM TEST STANDARD 26 4.2.5 TEST SETUP 27 4.2.6 EUT OPERATING CONDITIONS 27 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 28 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 30 5 . BANDWIDTH TEST 78 5.1 APPLIED PROCEDURES / LIMIT 78 5.1.1 MEASUREMENT INSTRUMENTS LIST 78 5.1.2 TEST PROCEDURE 78 5.1.3 DEVIATION FROM STANDARD 78 5.1.4 TEST SETUP 78 5.1.5 EUT OPERATION CONDITIONS 78 5.1.6 TEST RESULTS 79 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1102C032 Page 4 of 121 Table of Contents Page 6 . PEAK OUTPUT POWER TEST 87 6.1 APPLIED PROCEDURES / LIMIT 87 6.1.1 MEASUREMENT INSTRUMENTS LIST 87 6.1.2 TEST PROCEDURE 87 6.1.3 DEVIATION FROM STANDARD 87 6.1.4 TEST SETUP 87 6.1.5 EUT OPERATION CONDITIONS 87 6.1.6 TEST RESULTS 88 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 90 7.1 APPLIED PROCEDURES / LIMIT 90 7.1.1 MEASUREMENT INSTRUMENTS LIST 90 7.1.2 TEST PROCEDURE 90 7.1.3 DEVIATION FROM STANDARD 90 7.1.4 TEST SETUP 90 7.1.5 EUT OPERATION CONDITIONS 90 7.1.6 TEST RESULTS 91 8 . POWER SPECTRAL DENSITY TEST 111 8.1 APPLIED PROCEDURES / LIMIT 11…

Text truncated - open the document above for the full version.
