WL6-TC80RA1Tablet PC

Quick StartGuide For Android Tablet TC80RA1 1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation 2 RF Exposure Information (SAR) This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The exposure standard employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating positions accepted by the FCC with the EUT transmitting at the specified power level in different channels. The highest SAR value for the device as reported to the FCC is 1.46 W/kg when placed next to the body. This symbolindicates this Tablet PC complies with the Directive 2004/108/EC, 1999/5/EC and the European Union’s Low Voltage Directive 2006/95/EC. BATTERY CAUTION ※ Risk of explosion if the battery is replaced with an incorrect type one. ※ Dispose of used batteries according to the instructions. ※ Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. ※ Do not remove any batteries from the computer while it is powered on. ※ Recharge the batteries using the Tablet PC system. Incorrect recharging may make the battery explode. 3 ※ Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel. To prevent possible hearing damage, do not listen at high volume levels for long periods. Package contents Carefully unpack your box and take out the items listed below. If any of the items are missing or damaged, please contact your dealer immediately: • One tablet • One AC adapter • One USB cable • This guide 4 Tablet layout No. Name No. Name 1 Touchscreen 4 Micro USB DC IN / Micro USB port 2 Front facing camera 5 Headphone jack 3 Speaker 5 No. Name No. Name 1 Microphone 4 Power button 2 Micro SD card slot 5 Rear facing camera 3 Volume up/down 6 Charging your tablet If your tablet is just being unpacked from the box, you need to charge the tablet first. It will take around 4 to 5 hours to be fully charged. 1. Plug the USB head of the cable into the adapter. 2. Plug the micro-USB head of the cable- with the side marked with “B” or an icon facing down - into the micro-USB port on your tablet. 3. Plug the adapter into a wall-socket. 7 Powering ON/OFF your tablet To power on your tablet Press and hold the power button down until the screen turn on. To power off your tablet To turn off your tablet, follow these steps: 1. Press and hold the Power Lock button. 2. The Power-off menu appears as shown below. Touch Power off. 3. Touch OK to power down your tablet. 8 Inserting a storage card Your tablet supports micro-SD cards with maximum storage space up to 32G. You can insert the micro SD card and pull it out without powering down the tablet. To do so, follow the steps below. Install your Micro SD Card 1. Hold your tablet with front side up. You can find the micro SD card slot on the same side with the power button. (For detail, see page 4) 2. Insert your micro SD card in the direction as shown. Remove your Micro SD Card 1. Push and release the micro SD card. This will unlock the card. 2. Pull out the micro SD card. 9 Specifications Processor  Intel® Bay Trail-T Z3735G  Base 1.33 GHz, Burst to 1.83GHz  2MB L2 Cache Memory  DDR3L- 1333  Default1 GB Storage  eMMC v4.4.1  Default: 8GB (for KK 4.4), up to 16GB (for Win8.1) Wireless  Wi-Fi 802.11 b/g/n  Bluetooth 4.0 Touchscreen  8-inch 1280 x 800IPS  5-point multi-touch  Capacitive pen support Cameras  Front: 0.3M  Rear: 2.0M Battery  1Cell , 1S1P  Li-polymer  3900mAh Input/Output  1 x micro-USB 2.0 OTG port (Type B)  1 x Mic/head phone jack combo  1 x micro-SD card slot(32G max)  1 x MIC 10 Speaker& Mic  Build-in Speaker x 2  Analog MIC x 1 AC-Adapter  DC Output: 5V/2A  Input Voltage: 100 ~ 240VAC  Input Frequency: 47 ~ 63Hz Dimension (mm)  213 (W) x 129 (H) x 10 (D) Weight  0.34kg (w/o adapter)

Page 1 of 1 QuieTek Corporation Test Lab Attestation Letter Date of Test: 2014-09-12 Applicant Name: ELITEGROUP COMPUTER SYSTEMS CO., LTD. FCC ID: WL6-TC80RA1 Test Items: FCC SAR Name of Engineer Performing Test: Frank He Statement of Compliance: QuieTek Technology (Suzhou) Co., Ltd. declares that this Unit has been tested in accordance with the test method identified in this test report and that we observed it being tested. It also declares that the Unit complies with the relevant limits. All instrumentation and accessories used to test this unit for compliance to the indicated test method are calibrated regularly in accordance with ISO 17025:2005 requirements by laboratories accredited by A2LA, NVLAP, or ACLAS for the measurement parameters. The measurements were made at: QuieTek Technology (Suzhou) Co., Ltd. No.99 Hongye RD.Suzhou Industrial Park Loufeng Hi-New-Tech Development Area, Suzhou, China Test Lab Witness- Signature of Test Lab Witness: Full Name, Typed: Harry Zhao Title of Witness: Manager Email Address: [email protected] Phone No.: +86-512-62515088

ELITEGROUP COMPUTER SYSTEMS CO., LTD No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan ----------------------------------------------------------------------------------------------------------------------------------- Declaration of Authorization We Name: ELITEGROUP COMPUTER SYSTEMS CO., LTD Address: No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan Declare that: Name Representative of agent: Wu Jian Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone, City: Suzhou Country China is authorized to apply for Certification of the following product(s): Product description: Tablet PC FCC ID: WL6-TC80RA1 Model: TC80RA1 Brand: ECS ELITEGROUP on our behalf. Date: 2014-09-09

ELITEGROUP COMPUTER SYSTEMS CO., LTD No.239, Sec. 2, Tiding Blvd., Neihu Dist, Taipei City 14, Taiwan (R.O.C) ------------------------------------------------------------------------------------------------------- Date: 2014-09-09 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: WL6-TC80RA1 To Whom It May Concern: This letter is to ascertain that the following information of applicant, proudct with model(s) have been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. Applicant: ELITEGROUP COMPUTER SYSTEMS CO., LTD Product Name: Tablet PC Model: TC80RA1 Brand: ECS ELITEGROUP If you have any question or concerns, pls. contact us. Sincerely,

ELITEGROUP COMPUTER SYSTEMS CO., LTD No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan --------------------------------------------------------------------------------------------------------------------- Date: September 09, 2014 Federal Communications Commission Authorization and Evaluation Division FCC ID: WL6-TC80RA1 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 DFR § 2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant 180 days short-term confidentiality request on the following: attachments: 1. External Photo 2. Internal Photo 3. Test Setup Photo 4. User Manual The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ELITEGROUP COMPUTER SYSTEMS CO., LTD

External Photo (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo (Adapter #1) (9) EUT Photo (Adapter #1) (10) EUT Photo (Adapter #2) (11) EUT Photo (Adapter #2)

Label Label Location

Internal Photo (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo (9) EUT Photo (10) EUT Photo (11) EUT Photo (12) EUT Photo (13) EUT Photo (14) EUT Photo (15) Wi-Fi & Bluetooth Antenna (INNETECH) (16) Wi-Fi & Bluetooth Antenna (JEM) (17) GPS Antenna (INNETECH) (18) GPS Antenna (JEM)

FCC SAR Test Report Product Name : Tablet PC Model No. : TC80RA1 FCC ID : WL6-TC80RA1 Applicant : ELITEGROUP COMPUTER SYSTEMS CO., LTD Address : No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan Date of Receipt : Sep. 12, 2014 Date of Test : Sep. 12, 2014 Issued Date : Sep. 26, 2014 Report No. : 1490334R-HP-US-P03V01 Report Version : V1.1 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No.: 1490334R-HP-US-P03V01 Page: 2 of 99 Test Report Certification Issued Date: Sep. 26, 2014 Report No.: 1490334R-HP-US-P03V01 Product Name : Tablet PC Applicant : ELITEGROUP COMPUTER SYSTEMS CO., LTD Address : No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan Manufacturer : ELITEGROUP COMPUTER SYSTEMS CO., LTD Address : No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan Model No. : TC80RA1 FCC ID : WL6-TC80RA1 Brand Name : ECS ELITEGROUP EUT Voltage : DC 5V Applicable Standard : FCC KDB Publication 447498 D01v05r02 FCC KDB Publication 865664 D01v01r03 FCC KDB Publication 248227 D01v01r02 FCC KDB Publication 616217 D04v01r01 Test Result : Max. SAR Measurement (1g) 1.46 W/kg Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392 Documented By : Reviewed By : Approved By : Report No.: 1490334R-HP-US-P03V01 Page: 3 of 99 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC Japan :VCCI China :CNAS Report No.: 1490334R-HP-US-P03V01 Page: 4 of 99 TABLE OF CONTENTS Description Page 1. General Information ................................................................................................. 7 1.1. EUT Description .................................................................................................. 7 1.2. Antenna List ........................................................................................................ 8 1.3. Test Environment ................................................................................................. 9 1.4. EUT Antenna Locations ....................................................................................... 9 1.5. Simultaneous Transmission Configurations ....................................................... 10 1.6. SAR Test Exclusions Applied ............................................................................. 10 1.7. Power Reduction for SAR .................................................................................. 10 1.8. Guidance Documents ........................................................................................ 10 2. SAR Measurement System .................................................................................... 11 2.1. DASY5 System Description ............................................................................... 11 2.1.1. Applications ................................................................................................... 12 2.1.2. Area Scans .................................................................................................... 12 2.1.3. Zoom Scan (Cube Scan Averaging) .............................................................. 12 2.1.4. Uncertainty of Inter-/Extrapolation and Averaging ......................................... 12 2.2. DASY5 E-Field Probe ........................................................................................ 13 2.2.1. Isotropic E-Field Probe Specification ............................................................. 13 2.3. Boundary Detection Unit and Probe Mounting Device ...................................... 14 2.4. DATA Acquisition Electronics (DAE) and Measurement Server ........................ 14 2.5. Robot ................................................................................................................. 15 2.6. Light Beam Unit ................................................................................................. 15 2.7. Device Holder .................................................................................................... 16 2.8. SAM Twin Phantom ........................................................................................... 16 3. Tissue Simulating Liquid ....................................................................................... 17 3.1. The composition of the tissue simulating liquid ................................................. 17 3.2. Tissue Calibration Result ................................................................................... 17 3.3. Tissue Dielectric Paramet…

Text truncated - open the document above for the full version.

MRT Technology (Suzhou) Co., Ltd Report No.: 1408RSU03705 Phone: +86-512-66308358 Report Version: V01 Fax: +86-512-66308368 Issue Date: 09-29-2014 Web: www.mrt-cert.com FCC ID: WL6-TC80RA1 Page Number: 1 of 111 FCC ID: WL6-TC80RA1 APPLICANT: ELITEGROUP COMPUTER SYSTEMS CO., LTD. Application Type: Certification Product: Tablet PC Model No.: TC80RA1 FCC Classification: Digital Transmission System (DTS) FCC Rule Part(s): Part 15.247 Test Procedure(s): ANSI C63.10-2009, KDB 558074 D01v03r02 Test Date: Sep. 03 ~ 27, 2014 MEASUREMENT REPORT FCC PART 15.247 WLAN 802.11b/g/n & BLE Reviewed By : ( Robin Wu ) Approved By : ( Marlin Chen ) The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in KDB 558074 D01v03r02. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 2 of 111 Revision History Report No. Version Description Issue Date 1408RSU03705 Rev. 01 Initial report 09-29-2014 Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 3 of 111 CONTENTS Description Page 1. INTRODUCTION ..................................................................................................................... 6 1.1. Scope ........................................................................................................................... 6 1.2. MRT Test Location ....................................................................................................... 6 2. PRODUCT INFORMATION ..................................................................................................... 7 2.1. Equipment Description .................................................................................................. 7 2.2. Device Capabilities ....................................................................................................... 9 2.3. Test Configuration ........................................................................................................ 9 2.4. EMI Suppression Device(s)/Modifications ..................................................................... 9 2.5. Labeling Requirements ................................................................................................. 9 2.6. Test Software ............................................................................................................. 10 3. DESCRIPTION OF TEST ....................................................................................................... 11 3.1. Evaluation Procedure .................................................................................................. 11 3.2. AC Line Conducted Emissions .................................................................................... 11 3.3. Radiated Emissions .................................................................................................... 12 4. ANTENNA REQUIREMENTS ................................................................................................ 13 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................ 14 6. MEASUREMENT UNCERTAINTY ......................................................................................... 15 7. TEST RESULT ...................................................................................................................... 16 7.1. Summary .................................................................................................................... 16 7.2. 6dB Bandwidth Measurement ..................................................................................... 17 7.2.1. Test Limit ................................................................................................................ 17 7.2.2. Test Procedure used ............................................................................................... 17 7.2.3. Test Setting ............................................................................................................. 17 7.2.4. Test Setup ............................................................................................................... 17 7.2.5. Test Result .............................................................................................................. 18 7.3. Output Power Measurement ....................................................................................... 22 7.3.1. Test Limit ................................................................................................................ 22 7.3.2. Test Procedure Used .............................................................................................. 22 7.3.3. Test Setting ............................................................................................................. 22 7.3.4. Test Setup ............................................................................................................... 22 7.3.5. Test Result of Output Power ................................................................................... 23 7.4. Power Spectral Density Measurement ........................................................................ 26 7.4.1. Test Limit ................................................................................................................ 26 Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 4 of 111 7.4.2. Test Procedure Used .............................................................................................. 26 7.4.3. Test Setting ............................................................................................................. 26 7.4.4. Test Setup ........................................................…

Text truncated - open the document above for the full version.

Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 38 of 111 Channel 11 (2462MHz) 100kHz PSD reference Level High Band Edge Spurious Emission 30MHz ~ 25GHz 802.11n-HT40 Out-of-Band Emissions Channel 03 (2422MHz) 100kHz PSD reference Level Low Band Edge Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 39 of 111 Spurious Emission 30MHz ~ 25GHz Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 40 of 111 Channel 06 (2437MHz) 100kHz PSD reference Level Spurious Emission 30MHz ~ 25GHz Channel 09 (2452MHz) 100kHz PSD reference Level High Band Edge Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 41 of 111 Spurious Emission 30MHz ~ 25GHz BLE Out-of-Band Emissions Channel 00 (2402MHz) 100kHz PSD reference Level Low Band Edge Spurious Emission 30MHz ~ 25GHz Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 42 of 111 Channel 19 (2440MHz) 100kHz PSD reference Level Spurious Emission 30MHz ~ 25GHz Channel 39 (2480MHz) 100kHz PSD reference Level High Band Edge Spurious Emission 30MHz ~ 25GHz Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 43 of 111 7.6. Radiated Spurious Emission Measurement 7.6.1. Test Limit All out of band emissions appearing in a restricted band as specified in Section 15.205 of the Title 47 CFR must not exceed the limits shown in Table per Section 15.209. FCC Part 15 Subpart C Paragraph 15.209 Frequency [MHz] Field Strength [V/m] Measured Distance [Meters] 0.009 - 0.490 2400/F (kHz) 300 0.490 - 1.705 24000/F (kHz) 30 1.705 - 30 30 30 30 - 88 100 3 88 - 216 150 3 216 - 960 200 3 Above 960 500 3 7.6.2. Test Procedure Used KDB 558074 D01v03r02 - Section 12.2.3 (quasi-peak measurements) KDB 558074 D01v03r02 - Section 12.2.4 (peak power measurements) KDB 558074 D01v03r02 - Section 12.2.5 (average power measurements) 7.6.3. Test Setting Peak Field Strength Measurements per Section 12.2.4 of KDB 558074 D01v03r02 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. RBW = as specified in Table 1 3. VBW = 3MHz 4. Detector = peak 5. Sweep time = auto couple Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 44 of 111 6. Trace mode = max hold 7. Trace was allowed to stabilize Table 1 - RBW as a function of frequency Frequency RBW 9 ~ 150 kHz 200 ~ 300 Hz 0.15 ~ 30 MHz 9 ~ 10 kHz 30 ~ 1000 MHz 100 ~ 120 kHz > 1000 MHz 1 MHz Average Field Strength Measurements per Section 12.2.5.1 of KDB 558074 D01v03r02 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. RBW = 1MHz 3. VBW ≥ 1/T 4. De As an alternative, the instrument may be set to linear detector mode. Ensure that video filtering is applied in linear voltage domain (rather than in a log or dB domain). Some instruments require linear display mode in order to accomplish this. Others have a setting for Average-VBW Type, which can be set to “Voltage” regardless of the display mode 5. Detector = Peak 6. Sweep time = auto 7. Trace mode = max hold 8. Allow max hold to run for at least 50 times (1/duty cycle) traces Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 45 of 111 7.6.4. Test Setup 9kHz ~ 30MHz Test Setup: 30MHz ~ 1GHz Test Setup: Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 46 of 111 1GHz ~ 25GHz Test Setup: Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 47 of 111 7.6.5. Test Result Test Mode: 802.11b Test Site: AC1 Test Channel: 01 Test Engineer: Roy Cheng Remark: 1. Average measurement was not performed if peak level lower than average limit. 2. Other frequency was 20dB below limit line within 1-18GHz, there is not show in the report. Mark Frequency (MHz) Reading Level (dBμV) Factor (dB) Measure Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Polarization * 3108.0 38.0 3.5 41.5 87.8 -46.3 Peak Horizontal * 3526.4 37.2 4.0 41.2 87.8 -46.6 Peak Horizontal 4825.0 40.6 6.4 47.0 74.0 -27.0 Peak Horizontal 8344.0 36.1 14.4 50.5 74.0 -23.5 Peak Horizontal * 3057.0 37.9 3.5 41.4 87.8 -46.4 Peak Vertical * 3512.4 36.5 3.9 40.4 87.8 -47.4 Peak Vertical 4825.0 38.8 6.4 45.2 74.0 -28.8 Peak Vertical 8214.4 34.4 14.6 49.0 74.0 -25.0 Peak Vertical Note 1: “*” is not in restricted band, its limit is 20dBc of the fundamental emission level (107.8dBμV/m). Note 2: Measure Level (dBμV/m) = Reading Level (dBμV) + Factor (dB) Factor (dB) = Cable Loss (dB) + Antenna Factor (dB/m) - Pre_Amplifier Gain (dB) Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 48 of 111 Test Mode: 802.11b Test Site: AC1 Test Channel: 06 Test Engineer: Roy Cheng Remark: 1. Average measurement was not performed if peak level lower than average limit. 2. Other frequency was 20dB below limit line within 1-18GHz, there is not show in the report. Mark Frequency (MHz) Reading Level (dBμV) Factor (dB) Measure Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Polarization * 3142.4 37.9 3.6 41.5 87.5 -46.0 Peak Horizontal * 3341.3 36.7 3.1 39.8 87.5 -47.7 Peak Horizontal 4876.0 40.9 6.6 47.5 74.0 -26.5 Peak Horizontal 7315.5 36.7 14.0 50.7 74.0 -23.3 Peak Horizontal * 3102.4 37.0 3.5 40.5 87.5 -47.0 Peak Vertical * 3526.4 37.3 4.0 41.3 87.5 -46.2 Peak Vertical 4874.0 38.3 6.6 44.9 74.0 -29.1 Peak Vertical 7311.0 35.5 14.0 49.5 74.0 -24.5 Peak Vertical Note 1: “*” is not in restricted band, its limit is 20dBc of the fundamental emission level (107.5dBμV/m). Note 2: Measure Level (dBμV/m) = Reading Level (dBμV) + Factor (dB) Factor (dB) = Cable Loss (dB) + Antenna Factor (dB/m) - Pre_Amplifier Gain (dB) Report No.: 1408RSU03705 FCC ID: WL6-TC80RA1 Page Number: 49 of 111 Test Mode: 802.11b Test Site: AC1 Test Channel: 11 Test Engineer: Roy Cheng Remark: 1. Average measurement was not performed if peak level lower than average limit. 2. Other frequency was 20dB below limit line within 1-18GHz, there is not show in the report. Mark Frequency (MHz) Reading Level (dBμV) Factor (dB) Measure Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Polarization * 3142.7 37.0 3.6 40.6 87.0 -46.4 Peak Horizont…

Text truncated - open the document above for the full version.

Test Setup Photo Description: Front View of the Conducted Emission Test Setup Description: Back View of the Conducted Emission Test Setup Description: Radiated Emission Test Setup for 9kHz ~ 30MHz Description: Radiated Emission Test Setup for 30MHz ~ 1GHz Description: Radiated Emission Test Setup for 1GHz ~ 18GHz Description: Radiated Emission Test Setup for 18GHz ~ 25GHz Body SAR Bottom Body SAR Secondary landscape SAR Test Setup Photo Body SAR Primary portrait
