WOR-0501PIWireless IP CAM

IP1000/1050 Clause Description EN 60950-1: 2001 Safety of Information Technology Equipment EN 50392: 2004 Generic standard to demonstrate the compliance of electronic and electrical apparatus with the basic restrictions related to human exposure to electromagnetic fields (0 Hz - 300 GHz) EN 300 328 V (2004-11) Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband transmission systems; Data transmission equipment operating in the 2,4 GHz ISM band and using wide band modulation techniques; Harmonized EN covering essential requirements under article 3.2 of the R&TTE Directive EN 301 489-17 V (2002-08) and EN 301 489-1 V1.5.1 (2004-11) Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 17: Specific conditions for 2,4 GHz wideband transmission systems and 5 GHz high performance RLAN equipment This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC: This device is a 2.4 GHz wideband transmission system (transceiver), intended for use in all EU member states and EFTA countries, except in France and Italy where restrictive use applies. In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain authorization to use the device for setting up outdoor radio links and/or for supplying public access to telecommunications and/or network services. This device may not be used for setting up outdoor radio links in France and in some areas the RF output power may be limited to 10 mW EIRP in the frequency range of 2454 – 2483.5 MHz. For detailed information the end-user should contact the national spectrum authority in France. Europe – EU Declaration of Conformity 3 Česky [Czech] [Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shodě se základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Lietuvių [Lithuanian] Šiuo [manufacturer name] deklaruoja, kad šis [equipment type] atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. Dansk [Danish] Undertegnede [fabrikantens navn] erklæ rer herved, at følgende udstyr [udstyrets typebetegnelse] overholder de væ sentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Nederlands [Dutch] Hierbij verklaart [naam van de fabrikant] dat het toestel [type van toestel] in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG. Deutsch [German] Hiermit erklärt [Name des Herstellers], dass sich das Gerät [Gerätetyp] in Ü bereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet. Malti [Maltese] Hawnhekk, [isem tal-manifattur], jiddikjara li dan [il-mudel tal-prodott] jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC. Eesti [Estonian] Käesolevaga kinnitab [tootja nimi = name of manufacturer] seadme [seadme tüüp = type of equipment] vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. Magyar [Hungarian] Alulírott, [gyártó neve] nyilatkozom, hogy a [... típus] megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. English Hereby, [name of manufacturer], declares that this [type of equipment] is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Polski [Polish] Niniejszym [nazwa producenta] oświadcza, że [nazwa wyrobu] jest zgodny z zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC. Español [Spanish] Por medio de la presente [nombre del fabricante] declara que el [clase de equipo] cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Português [Portuguese] [Nome do fabricante] declara que este [tipo de equipamento] está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. Ελληνική [Greek] ΜΕ ΣΗΝ ΠΑΡΟΤ΢Α [name of manufacturer] ΔΗΛΩΝΕΙ ΟΣΙ [type of equipment] ΢ΤΜΜΟΡΦΩΝΕΣΑΙ ΠΡΟ΢ ΣΙ΢ ΟΤ΢ΙΩΔΕΙ΢ ΑΠΑΙΣΗ΢ΕΙ΢ ΚΑΙ ΣΙ΢ ΛΟΙΠΕ΢ ΢ΧΕΣΙΚΕ΢ ΔΙΑΣΑΞΕΙ΢ ΣΗ΢ ΟΔΗΓΙΑ΢ 1999/5/ΕΚ. Slovensko [Slovenian] [Ime proizvajalca] izjavlja, da je ta [tip opreme] v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES. Français [French] Par la présente [nom du fabricant] déclare que l'appareil [type d'appareil] est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Slovensky [Slovak] [Meno výrobcu] týmto vyhlasuje, že [typ zariadenia] spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES. Italiano [Italian] Con la presente [nome del costruttore] dichiara che questo [tipo di apparecchio] è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Suomi [Finnish] [Valmistaja = manufacturer] vakuuttaa täten että [type of equipment = laitteen tyyppimerkintä] tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Latviski [Latvian] Ar šo [name of manufacturer / izgatavotāja nosaukums] deklarē, ka [type of equipment / iekārtas tips] atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem noteikumiem. Svenska [Swedish] Härmed intygar [företag] att denna [utrustningstyp] står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. Europe – EU Declaration of Conformity 4 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designe…

Text truncated - open the document above for the full version.

Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents 51 Network DDNS Server name Choose the DDNS Server from the list. User ID Enter the user ID for authentication necessary for DDNS connections. Type it up to 64 characters. Password Enter the password for authentication necessary for DDNS connections. Type it up to 32 characters. Re-type password Re-type the password to confirm. Host name Enter the host name that is registered to the DDNS server. DDNS is a system which allows the domain name data held in a name server to be updated in real time. The most common use for DDNS is allowing an internet domain name to be assigned to a computer with a varying / dynamic IP Address. This makes it possible for other sites on the internet to establish connection to the machine without needing to track the IP Address themselves. Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents 52 Network UPnP HTTP port The default HTTP port is 80. Or the port number can be entered, ranged from 1024 to 65535. SSL port The default SSL port is 443. Or the port number can be entered, ranged from 1024 to 65535. MPEG4 RTSP port The default MPEG-4 RTSP Port is 554. Or the port number can be entered, ranged from 1024 to 65535. You can select UPnP function “On” or “Off”. If a ROUTER is used to access to internet and it supports UPnP IGD function, please turn on the UPnP Port Forwarding function. Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents 53 Network IP Notification SMTP Select if SMTP authentication is necessary when an e- mail is sent. POP before SMTP Select if POP before SMTP authentication is necessary when an e-mail is sent. POP server name Type the POP server name of the user. User name, Password Type the user name and Password of the user. Recipient e-mail address Type up to 3 recipient e-Mail addresses. Administrator e-mail address This address is used for reply mail and sending system messages from the SMTP server. Subject Type the subject/title of the e-Mail. Message Type the text of the E-mail. Default provides network information including IP, Port, MAC, Model, Firmware Version and Web Version. When network notify type is set to “ON”, you can send an e-mail notification of the completion of the network setting. If you use g-mail as your mail server, you should set 587 as your port number and tick SSL box. Note Notify Type Select the notify type SMTP Server Name Type the SMTP server name or the IP address SMTP Server Port Set port number of your mail server. The default value is 25. Tick SSL box if the mail server you use has security restriction. Authentication Required when you send an email. Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents 54 Network WPS WPS Enable/disable the WPS function. Configure via Push button Click “Start” Configure via Pin code password for this msn account. WPS (Wi-Fi Protected Setup ) also known as a standard for easy and secure establishment of a wireless home network. Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents 55 Network Wireless 3.Enter password at active transmit key if you need. If you don't know the setting of the wireless AP, please ask your network administrator. 4.Choose the option of Obtain an IP address automatically (DHCP). 5.Choose the option of Obtain DNS server address automatically. Use the following IP address Select this when the fixed IP address is set. IP address: Enter the IP address of the device. Subnet mask: Enter the subnet mask. Default gateway: Enter the default gateway. Use the following DNS server address Select this when you set the fixed address as the IP address of DNS server. Primary DNS server: Enter the IP address of the primary DNS server. Secondary DNS server: Enter the IP address of the secondary DNS server, if necessary. 6.Connect to the IP camera with wireless IP address, then you can remove the Ethernet connection. The wireless network has to be set up by using cable network connection. After setting the camera correctly, the wireless function can work without cable network connection. Please follow the setting process below step by step: 1.See the wireless setting page. Then click “Refresh”. All access points (AP) around you will show up. 2.Select the AP you wish to connect. Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents 56 Network Messenger Protocol support MSN only. Login Account Camera will use this account to login MSN server. Password password for this msn account. Re-type password re-type password to double confirm. Alias This alias will display on MSN nickname. Port range Select one port range for video transmission. IP Notification Switch the IP notification On / Off. If this feature switches On, camera will send IP notification to the users who are allowed. Privacy Switch privacy On / Off. When privacy turns on, only those users in allowed list can access the camera. User Input to this blank to edit allow list. Allow list When privacy turns on, only those users in allow list can access the camera. If Messenger option is selected On, you can set out the setting of MSN account. Messenger function provide an easy-connect feature. User can easy to know what camera’s private and public IP address is. Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents 57 Events FTP Client – general FTP server name Type the FTP server name to upload still images up to 64 characters, or the IP address of the FTP server. User name Type the user name for the FTP server. Password Type the password for the FTP server. Retype password To confirm the password, type the same characters as you typed in the Password box. Passive mode Set whether you use the passive mode of FTP server or not when c…

Text truncated - open the document above for the full version.

Subject: DoC declaration To Whom it may concern, We, as the grantee of this project FCC ID: WOR-0501PI , would like to declare that the composite portion categorized as computer peripheral has been authorized under the Declaration of Conformity procedures. Regards,

Subject: Ad Hoc Mode Function Declaration FCC ID: WOR-0501PI To Whom it may concern, This device is acting as master and operating on 2.4GHz band. Ad Hoc function is available on client mode and not able to work on non-US frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, ( Signature Here) Name: ZAVIO INC Title: Chief Technology Officer Tel: 886 3 5790275 E-mail: [email protected] Date: 2011.04.08

ZAVIO Inc. B3 Sec 1F, No.1, Lixing 1st Rd. , Science-Based Industrial Park, Hsinchu, Taiwan March 23, 2011 Federal Communications Commission Authorization and Evaluation Division FCC ID：WOR-0501PI Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below : 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Signature Name/Title: Minar Lin/ Chief Technology Officer Applicant: Minar Lin Company Name: ZAVIO INC. ADDRESS: B3 Sec 1F, No.1, Lixing 1st Rd., Science-Based Industrial Park, Hsinchu, Taiwan TEL: 886 3 5790275 FAX: 886 3 6686845 Email: [email protected]

ZAVIO Inc. B3 Sec 1F, No.1, Lixing 1st Rd. , Science-Based Industrial Park, Hsinchu, Taiwan March 23, 2011 FCC ID：WOR-0501PI Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Compliance Certification Services Inc. Address: No.8, Jiu Cheng Ling, Jiaokeng Village,Sinhua Township, Tainan Hsien 712,Taiwan R.O.C. Name: Daphne Liang Job Title: Section Manager Email: [email protected] I am therefore responsible for the contents of the application. Brand Name and Model Name of the specified radio equipment: ZAVIO / IP1050 FCC ID: WOR-0501PI Product Name: Wireless IP CAM Signature FCC grantee contact person information : Name/Title: Minar Lin/ Chief Technology Officer Company Name: ZAVIO INC. ADDRESS:B3 Sec 1F, No.1, Lixing 1st Rd. , Science-Based Industrial Park, Hsinchu, Taiwan TEL: 886 3 5790275 FAX: 886 3 6686845 Email: [email protected]

Report No.T110309304 Page 1 of 13 External Photo Report No.T110309304 Page 2 of 13 Report No.T110309304 Page 3 of 13

Label Location

Report No.T110309304 Page 4 of 13 Internal Photo Report No.T110309304 Page 5 of 13 Report No.T110309304 Page 6 of 13 Report No.T110309304 Page 7 of 13 Report No.T110309304 Page 8 of 13 Report No.T110309304 Page 9 of 13 Report No.T110309304 Page 10 of 13 Report No.T110309304 Page 11 of 13 Report No.T110309304 Page 12 of 13 Power Adapter Photo Report No.T110309304 Page 13 of 13

- RALINK PROPRIETARY & CONFIDENTIAL- 1 Ralink’s Printed Antenna Report for USB 2.4GHz ISM Band Working Frequency -- RT3070 Editor : Claire Date: 20080704 - RALINK PROPRIETARY & CONFIDENTIAL- 2 Measurement Items z Measurement Items : z a. Return loss z b. Radiation pattern Y Z X Printed Antenna - RALINK PROPRIETARY & CONFIDENTIAL- 3 Return Loss - RALINK PROPRIETARY & CONFIDENTIAL- 4 Radiation pattern - RALINK PROPRIETARY & CONFIDENTIAL- 5 X-Y Plane Horizontal Polarization - RALINK PROPRIETARY & CONFIDENTIAL- 6 X-Y Plane Vertical Polarization - RALINK PROPRIETARY & CONFIDENTIAL- 7 Y-Z Plane Horizontal Polarization - RALINK PROPRIETARY & CONFIDENTIAL- 8 Y-Z Plane Vertical Polarization - RALINK PROPRIETARY & CONFIDENTIAL- 9 X-Z Plane Horizontal Polarization - RALINK PROPRIETARY & CONFIDENTIAL- 10 X-Z Plane Vertical Polarization - RALINK PROPRIETARY & CONFIDENTIAL- 11 Gain( Hor. & Ver.) YZ –Hor. YZ –Ver. XY –Hor. XY –Ver. XZ –Hor. XZ –Ver.

FCC IDWOR-0501PI Report No.T110309304-RP1 Page 98 of 104 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. APPENDIX I MAXIMUM PERMISSIBLE EXPOSURE According to FCC 1.1310 : The criteria listed in the following table shall be used to evaluate theenvironment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b)LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (A) Limits for Occupational / Control Exposures 300-1,500 -- -- F/300 6 1,500-100,000 -- -- 5 6 (B) Limits for General Population / Uncontrol Exposures 300-1,500 -- -- F/1500 6 1,500-100,000 -- -- 1 30 CALCULATIONS Given d G×P×30 =E & 3770 E =S 2 Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 d3770 G×P×30 =S Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields () () 22 d G×P ×0796.0= 100/d×3770 G×1000/P×30 =S Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm2 FCC IDWOR-0501PI Report No.T110309304-RP1 Page 99 of 104 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. LIMIT Power Density Limit, S=1.0mW/cm 2 TEST RESULTS Mode Antenna Gain (dBi) Minimum separation distance (cm) Output Power (dBm) Numeric antenna gain (mW) Power Density Limit (mW/cm 2 ) Power Density at 20cm (mW/cm 2 ) IEEE 802.11b 1.71 20.0 17.021.48 1.00 0.014850 IEEE 802.11g 1.71 20.0 17.751.48 1.00 0.017568 IEEE 802.11n HT201.71 20.0 18.121.48 1.00 0.019130 IEEE 802.11n HT401.71 20.0 17.961.48 1.00 0.018438 Remark: For mobile or fixed location transmitters, the maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger.

FCC IDWOR-0501PI Report No.T110309304-RP1 Page 1 of 104 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. FCC 47 CFR PART 15 SUBPART C AND ANSI C63.4:2003 TEST REPORT For Wireless IP CAM Model : IP1050 Trade Name : ZAVIO Issued for ZAVIO Inc. 2F, No.13, R&D Rd.II, Science Based Industrial Park, Hsinchu, Taiwan Issued by Compliance Certification Services Inc. Hsinchu Lab. NO. 989-1 Wen Shan Rd., Shang Shan Village, Qionglin Shiang Hsinchu County 30741, Taiwan, R.O.C TEL: +886-3-5921698 FAX: +886-3-5921108 http://www.ccsrf.com E-Mail : [email protected] Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF or any government agencies. The test results of this report relate only to the tested sample identified in this report. FCC IDWOR-0501PI Report No.T110309304-RP1 Page 2 of 104 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 03/18/2011 Initial Issue All Page 104 Winnie Chen FCC IDWOR-0501PI Report No.T110309304-RP1 Page 3 of 104 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. TABLE OF CONTENTS TITLE PAGE NO. 1. TEST REPORT CERTIFICATION ................................................................................ 4 2. EUT DESCRIPTION ..................................................................................................... 5 2.1 DESCRIPTION OF EUT & POWER ....................................................................... 5 3. DESCRIPTION OF TEST MODES ............................................................................... 6 4. TEST METHODOLOGY ............................................................................................... 7 5. FACILITIES AND ACCREDITATION ........................................................................... 7 5.1 FACILITIES ............................................................................................................ 7 5.2 ACCREDITATIONS................................................................................................ 7 5.3 MEASUREMENT UNCERTAINTY ......................................................................... 8 6. SETUP OF EQUIPMENT UNDER TEST......................................................................9-10 7. FCC PART 15.247 REQUIREMENTS.......................................................................... 11 7.1 6dB BANDWIDTH .................................................................................................. 11-20 7.2 MAXIMUM PEAK OUTPUT POWER..................................................................... 21-31 7.3 AVERAGE POWER ............................................................................................... 32-34 7.4 POWER SPECTRAL DENSITY............................................................................. 35-45 7.5 CONDUCTED SPURIOUS EMISSION .................................................................. 46-58 7.6 RADIATED EMISSION........................................................................................... 59-92 7.7 CONDUCTED EMISSION ...................................................................................... 93-97 APPENDIX I MAXIMUM PERMISSIBLE EXPOSURE ..................................................... 98-99 APPENDIX II SETUP PHOTOS .......................................................................................100-104 FCC IDWOR-0501PI Report No.T110309304-RP1 Page 4 of 104 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 1. TEST REPORT CERTIFICATION Applicant ZAVIO Inc. Address 2F, No.13, R&D Rd.II, Science Based Industrial Park, Hsinchu, Taiwan Equipment Under Test Wireless IP CAM Model IP1050 Trade Name ZAVIO Tested Date March 08 ~ 17, 2011 APPLICABLE STANDARD Standard Test Result FCC Part 15 Subpart C AND ANSI C63.4:2003 PASS WE HEREBY CERTIFY THAT: The above equipment has been tested by Compliance Certification Services Inc., and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by: Reviewed by: Sb. Lu Gundam Lin Sr. Engineer Team Leader FCC IDWOR-0501PI Report No.T110309304-RP1 Page 5 of 104 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 2. EUT DESCRIPTION 2.1 DESCRIPTION OF EUT & POWER Product Name Wireless IP CAM Model Number IP1050 Received Date March 08, 2011 IEEE 802.11b/g, 802.11n HT20 : 2412MHz～2462MHz Frequency Range IEEE 802.11n HT40 : 2422MHz～2452MHz IEEE 802.11b : 17.02 dBm (0.0504W) IEEE 802.11g : 17.75 dBm (0.0596W) IEEE 802.11n HT20 : 18.12 dBm (0.0649W) Transmit Power IEEE 802.11n HT40 : 17.96 dBm (0.0625W) Channel Spacing IEEE 802.11b/g, 802.11n HT20/HT40 : 5MHz IEEE 802.11b/g, 802.11n HT20 : 11 Channels Channel Number IEEE 802.11n HT40 : 7 Channels IEEE 802.11b : 11, 5.5, 2, 1 Mbps IEEE 802.11g : 54, 48, 36, 24, 18, 12, 9, 6 Mbps IEEE 802.11n HT20 : 65, 58.5, 52, 39, 26, 19.5, 13, 6.5 Mbps Transmit Data Rate IEEE 802.11n HT40 : 135, 121.5, 108, 81, 54, 40.5, 27, 13.5Mbps IEEE 802.11b : DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g : OFDM (64QAM, 16QAM, QPSK, BPSK) Type of Modulation IEEE 802.11n HT20/40 : OFDM (64QAM, 16QAM, QPSK, BPSK) Antenna Type Printed Antenna, Antenn…
