WOR-6013FWireless IP CAM

F3101/3106 Clause Description EN 60950-1: 2001 Safety of Information Technology Equipment EN 50392: 2004 Generic standard to demonstrate the compliance of electronic and electrical apparatus with the basic restrictions related to human exposure to electromagnetic fields (0 Hz - 300 GHz) EN 300 328 V (2004-11) Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband transmission systems; Data transmission equipment operating in the 2,4 GHz ISM band and using wide band modulation techniques; Harmonized EN covering essential requirements under article 3.2 of the R&TTE Directive EN 301 489-17 V (2002-08) and EN 301 489-1 V1.5.1 (2004-11) Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 17: Specific conditions for 2,4 GHz wideband transmission systems and 5 GHz high performance RLAN equipment This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC: This device is a 2.4 GHz wideband transmission system (transceiver), intended for use in all EU member states and EFTA countries, except in France and Italy where restrictive use applies. In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain authorization to use the device for setting up outdoor radio links and/or for supplying public access to telecommunications and/or network services. This device may not be used for setting up outdoor radio links in France and in some areas the RF output power may be limited to 10 mW EIRP in the frequency range of 2454 – 2483.5 MHz. For detailed information the end-user should contact the national spectrum authority in France. Europe – EU Declaration of Conformity 3 Česky [Czech] [Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shodě se základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Lietuvių [Lithuanian] Šiuo [manufacturer name] deklaruoja, kad šis [equipment type] atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. Dansk [Danish] Undertegnede [fabrikantens navn] erklæ rer herved, at følgende udstyr [udstyrets typebetegnelse] overholder de væ sentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Nederlands [Dutch] Hierbij verklaart [naam van de fabrikant] dat het toestel [type van toestel] in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG. Deutsch [German] Hiermit erklärt [Name des Herstellers], dass sich das Gerät [Gerätetyp] in Ü bereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet. Malti [Maltese] Hawnhekk, [isem tal-manifattur], jiddikjara li dan [il-mudel tal-prodott] jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC. Eesti [Estonian] Käesolevaga kinnitab [tootja nimi = name of manufacturer] seadme [seadme tüüp = type of equipment] vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. Magyar [Hungarian] Alulírott, [gyártó neve] nyilatkozom, hogy a [... típus] megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. English Hereby, [name of manufacturer], declares that this [type of equipment] is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Polski [Polish] Niniejszym [nazwa producenta] oświadcza, że [nazwa wyrobu] jest zgodny z zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC. Español [Spanish] Por medio de la presente [nombre del fabricante] declara que el [clase de equipo] cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Português [Portuguese] [Nome do fabricante] declara que este [tipo de equipamento] está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. Ελληνική [Greek] ΜΕ ΣΗΝ ΠΑΡΟΤ΢Α [name of manufacturer] ΔΗΛΩΝΕΙ ΟΣΙ [type of equipment] ΢ΤΜΜΟΡΦΩΝΕΣΑΙ ΠΡΟ΢ ΣΙ΢ ΟΤ΢ΙΩΔΕΙ΢ ΑΠΑΙΣΗ΢ΕΙ΢ ΚΑΙ ΣΙ΢ ΛΟΙΠΕ΢ ΢ΧΕΣΙΚΕ΢ ΔΙΑΣΑΞΕΙ΢ ΣΗ΢ ΟΔΗΓΙΑ΢ 1999/5/ΕΚ. Slovensko [Slovenian] [Ime proizvajalca] izjavlja, da je ta [tip opreme] v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES. Français [French] Par la présente [nom du fabricant] déclare que l'appareil [type d'appareil] est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Slovensky [Slovak] [Meno výrobcu] týmto vyhlasuje, že [typ zariadenia] spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES. Italiano [Italian] Con la presente [nome del costruttore] dichiara che questo [tipo di apparecchio] è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Suomi [Finnish] [Valmistaja = manufacturer] vakuuttaa täten että [type of equipment = laitteen tyyppimerkintä] tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Latviski [Latvian] Ar šo [name of manufacturer / izgatavotāja nosaukums] deklarē, ka [type of equipment / iekārtas tips] atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem noteikumiem. Svenska [Swedish] Härmed intygar [företag] att denna [utrustningstyp] står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. Europe – EU Declaration of Conformity 4 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed…

Text truncated - open the document above for the full version.

Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents System 41 The Information page provides the product factory information which includes Product Name, Firmware Version and Web Version. Information Day/Time Date / Time format Pull down box to select different time display formats. Adjust Keep current setting Keep the current date and time of this IP Camera. Synchronize with PC Keep the date and time the same PC. Manual setting Adjust manually the date and time of this IP Camera. Synchronize with NTP Specify the NTP server name and the Refresh Interval to synchronize. Time Zone You can select the Time Zone. Daylight Saving Time There are two modes to choose for setting up daylight saving time. By Date Set the start and end time by select month, day, hour, and minute. By Week Number Set the start and end time by select month, week, hour, and minute. Current date / time Display the current date and time of this IP Camera. PC clock Display the date and time of the monitoring PC clock. Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents 42 Account The device fault account and password setting is “admin / admin”. That means everyone who knows IP address can access the device including all configuration. It is necessary to assign a password if the device is intended to be accessed by others. User name Set a user name between 4-16 characters. Password Set a password between 4-16 characters. Re-type Password Re-type the password to confirm. Viewer Mode Set the user mode among Admin, Operator, and Viewer. Different viewer mode has different limits of authority. Admin mode Has all authority of configuration. Operator mode View the Live View and Use Control Panel. Viewer mode View the Live View only. Viewer Authentication Allows any viewer direct access to Live View. System Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents 43 System Log The System Log function allows users to review any changes and events happened. The system starts logging automatically after started. Enable remote log Enables user to send the log data to a specified log server. Initialize Reboot Reboot this IP Camera and it takes two minutes to reboot this IP Camera. Factory Default Reset this IP Camera to the factory default setting.. Don't turn off this IP Camera until the device reboots. Backup Setting Backup the setting data of this IP Camera. Restore Setting Click “Browse” to restore setting and then restart automatically. Firmware Update Click “Browse” to upgrade firmware. Upload Language Pack Upgrade the device language pack. Use only upgrade files that are special for this IP Camera. Otherwise problems may occur. Don't turn off the IP Camera power or disconnect the network until the upgrading is completed. Note System Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents 44 Camera General LED Indicator Turn on/off the LED indicator. Text Overlay You can see some information on the display screen which includes Date / Time and user-defined text. Also, you can change the background color. Privacy Mask You can cover a specific area of the video image. RTSP (Real Time Streaming Protocol) is a protocol for use in streaming media system which allows clients to remotely control a streaming video server. RTSP is supports by most of the media clients such as Real Player, QuickTime and VLC...etc. Note RTSP Switch RTSP “On” or “Off.” The default value is 554. Image Rotate You can mirror or flip the display screen. Audio Codec Select one audio codec among G.711 U-law, G.711 A- law and AMR Audio. Or select off to disable sound reception. Audio Mode select Full duplex or Half duplex for your camera. Video Clip Format Select H.264 or MPEG-4 as recording compression format. Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents 45 Profile 1 Image Size Specify the image size from 1280x1024 to 320x240 of profile 1. Frame Rate Set the frame rate of profile 1. Quality Auto The quality and bitrate will be adjusted automatically according to the frame rate. Fixed Quality You can select the value of quality. Fixed Bitrate Set the bitrate of profile 1 transmission for a line. Streaming The streaming of profile 1 is fixed MPEG4. 1.Concerning how to select the suitable image quality for Fixed Quality or Fixed Bitrate, please refer to APPENDIX / A. Frame-rate & Bitrate Table. 2.The frame rate is up to 15 fps at 1280x1024, and up to 30 fps at 640x480. However, if you would like choose frame rate over 15 fps, the IMAGE SIZE of profile1 and profile 2 setting page has to been selected 320x240 or 640x480 at the same time. Note Viewer Authentication If the viewer authentication is On, the users will be requested to key-in username and password when viewing through RTSP. Camera Product Overview Hardware Installation Easy Access EZvuu Setting Live View Appendix Table of Contents 46 Profile 2 Camera Image Size Specify the image size from 1280x1024 to 320x240 of profile 1. Frame Rate Set the frame rate of profile 1. Quality Auto The quality and bitrate will be adjusted automatically according to the frame rate. Fixed Quality You can select the value of quality. Fixed Bitrate Set the bitrate of profile 1 transmission for a line. Streaming Select H.264, MJPEG or 3GPP as streaming of profile 2. 1.Concerning how to select the suitable image quality for Fixed Quality or Fixed Bitrate, please refer to APPENDIX / A. Frame-rate & Bitrate Table. 2.The frame rate is up to 15 fps at 1280x1024, and up to 30 fps at 640x480. However, if you would like choose frame rate over 15 fps, the IMAGE SIZE of profile1 and profile 2 setting page has to been selected 320x240 or 640x480 at the same time. Note Viewer Authentication If the viewer authentication is On, the users will be requested to key-in username and password when viewing thro…

Text truncated - open the document above for the full version.

Subject: DoC declaration To Whom it may concern, We, as the grantee of this project FCC ID: WOR-6013F , would like to declare that the composite portion categorized as computer peripheral has been authorized under the Declaration of Conformity procedures. Regards,

Subject: Ad Hoc Mode Function Declaration FCC ID: WOR-6013F To Whom it may concern, This device is acting as master and operating on 2.4GHz band. Ad Hoc function is available on client mode and not able to work on non-US frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, ( Signature Here) Name: ZAVIO INC Title: Chief Technology Officer Tel: 886 3 5790275 E-mail: [email protected] Date: 2011.04.08

ZAVIO Inc. B3 Sec 1F, No.1, Lixing 1st Rd. , Science-Based Industrial Park, Hsinchu, Taiwan March 23, 2011 Federal Communications Commission Authorization and Evaluation Division FCC ID：WOR-6013F Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below : 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Signature Name/Title: Minar Lin/ Chief Technology Officer Applicant: Minar Lin Company Name: ZAVIO INC. ADDRESS: B3 Sec 1F, No.1, Lixing 1st Rd., Science-Based Industrial Park, Hsinchu, Taiwan TEL: 886 3 5790275 FAX: 886 3 6686845 Email: [email protected]

ZAVIO Inc. B3 Sec 1F, No.1, Lixing 1st Rd. , Science-Based Industrial Park, Hsinchu, Taiwan March 23, 2011 FCC ID：WOR-6013F Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Compliance Certification Services Inc. Address: No.8, Jiu Cheng Ling, Jiaokeng Village,Sinhua Township, Tainan Hsien 712,Taiwan R.O.C. Name: Daphne Liang Job Title: Section Manager Email: [email protected] I am therefore responsible for the contents of the application. Brand Name and Model Name of the specified radio equipment: ZAVIO / F3106 FCC ID: WOR-6013F Product Name: Wireless IP CAM Signature FCC grantee contact person information : Name/Title: Minar Lin/ Chief Technology Officer Company Name: ZAVIO INC. ADDRESS:B3 Sec 1F, No.1, Lixing 1st Rd. , Science-Based Industrial Park, Hsinchu, Taiwan TEL: 886 3 5790275 FAX: 886 3 6686845 Email: [email protected]

Report No.T101203305 Page 1 of 14 External Photo Report No.T101203305 Page 2 of 14

Label Location

Report No.T101203305 Page 3 of 14 Internal Photo Report No.T101203305 Page 4 of 14 Report No.T101203305 Page 5 of 14 Report No.T101203305 Page 6 of 14 Report No.T101203305 Page 7 of 14 Report No.T101203305 Page 8 of 14 Report No.T101203305 Page 9 of 14 Report No.T101203305 Page 10 of 14 Report No.T101203305 Page 11 of 14 Power Adapter Photo (Model : DSA-12CA-12 120100) Report No.T101203305 Page 12 of 14 Report No.T101203305 Page 13 of 14 Power Adapter Photo (Model : AH1212-B) Report No.T101203305 Page 14 of 14

- RALINK PROPRIETARY & CONFIDENTIAL- 1 Ralink’s Printed Antenna Report for USB 2.4GHz ISM Band Working Frequency -- RT3070 Editor : Claire Date: 20080704 - RALINK PROPRIETARY & CONFIDENTIAL- 2 Measurement Items z Measurement Items : z a. Return loss z b. Radiation pattern Y Z X Printed Antenna - RALINK PROPRIETARY & CONFIDENTIAL- 3 Return Loss - RALINK PROPRIETARY & CONFIDENTIAL- 4 Radiation pattern - RALINK PROPRIETARY & CONFIDENTIAL- 5 X-Y Plane Horizontal Polarization - RALINK PROPRIETARY & CONFIDENTIAL- 6 X-Y Plane Vertical Polarization - RALINK PROPRIETARY & CONFIDENTIAL- 7 Y-Z Plane Horizontal Polarization - RALINK PROPRIETARY & CONFIDENTIAL- 8 Y-Z Plane Vertical Polarization - RALINK PROPRIETARY & CONFIDENTIAL- 9 X-Z Plane Horizontal Polarization - RALINK PROPRIETARY & CONFIDENTIAL- 10 X-Z Plane Vertical Polarization - RALINK PROPRIETARY & CONFIDENTIAL- 11 Gain( Hor. & Ver.) YZ –Hor. YZ –Ver. XY –Hor. XY –Ver. XZ –Hor. XZ –Ver.

FCC IDWOR-6013F Report No.T101203305-RP1 Page 100 of 106 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. APPENDIX I MAXIMUM PERMISSIBLE EXPOSURE According to FCC 1.1310 : The criteria listed in the following table shall be used to evaluate theenvironment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b)LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (A) Limits for Occupational / Control Exposures 300-1,500 -- -- F/300 6 1,500-100,000 -- -- 5 6 (B) Limits for General Population / Uncontrol Exposures 300-1,500 -- -- F/1500 6 1,500-100,000 -- -- 1 30 CALCULATIONS Given d G×P×30 =E & 3770 E =S 2 Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 d3770 G×P×30 =S Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields () () 22 d G×P ×0796.0= 100/d×3770 G×1000/P×30 =S Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm2 FCC IDWOR-6013F Report No.T101203305-RP1 Page 101 of 106 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. LIMIT Power Density Limit, S=1.0mW/cm 2 TEST RESULTS Mode Antenna Gain (dBi) Minimum separation distance (cm) Output Power (dBm) Numeric antenna gain (mW) Power Density Limit (mW/cm 2 ) Power Density at 20cm (mW/cm 2 ) IEEE 802.11b 1.71 20.0 17.021.48 1.00 0.014850 IEEE 802.11g 1.71 20.0 17.751.48 1.00 0.017568 IEEE 802.11n HT201.71 20.0 18.121.48 1.00 0.019130 IEEE 802.11n HT401.71 20.0 17.961.48 1.00 0.018438 Remark: For mobile or fixed location transmitters, the maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger.

FCC IDWOR-6013F Report No.T101203305-RP1 Page 1 of 106 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. FCC 47 CFR PART 15 SUBPART C AND ANSI C63.4:2003 TEST REPORT For Wireless IP CAM Model : F3106 Trade Name : ZAVIO Issued for ZAVIO Inc. 2F, No.13, R&D Rd.II, Science Based Industrial Park, Hsinchu, Taiwan Issued by Compliance Certification Services Inc. Hsinchu Lab. NO. 989-1 Wen Shan Rd., Shang Shan Village, Qionglin Shiang Hsinchu County 30741, Taiwan, R.O.C TEL: +886-3-5921698 FAX: +886-3-5921108 http://www.ccsrf.com E-Mail : [email protected] Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF or any government agencies. The test results of this report relate only to the tested sample identified in this report. FCC IDWOR-6013F Report No.T101203305-RP1 Page 2 of 106 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 02/14/2011 Initial Issue All Page 106 Winnie Chen FCC IDWOR-6013F Report No.T101203305-RP1 Page 3 of 106 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. TABLE OF CONTENTS TITLE PAGE NO. 1. TEST REPORT CERTIFICATION ................................................................................ 4 2. EUT DESCRIPTION ..................................................................................................... 5 2.1 DESCRIPTION OF EUT & POWER ....................................................................... 5 3. DESCRIPTION OF TEST MODES ............................................................................... 6 4. TEST METHODOLOGY ............................................................................................... 7 5. FACILITIES AND ACCREDITATION ........................................................................... 7 5.1 FACILITIES ............................................................................................................ 7 5.2 ACCREDITATIONS................................................................................................ 7 5.3 MEASUREMENT UNCERTAINTY ......................................................................... 8 6. SETUP OF EQUIPMENT UNDER TEST......................................................................9-10 7. FCC PART 15.247 REQUIREMENTS.......................................................................... 11 7.1 6dB BANDWIDTH .................................................................................................. 11-20 7.2 MAXIMUM PEAK OUTPUT POWER..................................................................... 21-31 7.3 AVERAGE POWER ............................................................................................... 32-34 7.4 POWER SPECTRAL DENSITY............................................................................. 35-45 7.5 CONDUCTED SPURIOUS EMISSION .................................................................. 46-58 7.6 RADIATED EMISSION........................................................................................... 59-92 7.7 CONDUCTED EMISSION ...................................................................................... 93-99 APPENDIX I MAXIMUM PERMISSIBLE EXPOSURE..................................................... 100-101 APPENDIX II SETUP PHOTOS .......................................................................................102-106 FCC IDWOR-6013F Report No.T101203305-RP1 Page 4 of 106 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 1. TEST REPORT CERTIFICATION Applicant ZAVIO Inc. Address 2F, No.13, R&D Rd.II, Science Based Industrial Park, Hsinchu, Taiwan Equipment Under Test Wireless IP CAM Model F3106 Trade Name ZAVIO Tested Date December 03, 2010 ~ February 11, 2011 APPLICABLE STANDARD Standard Test Result FCC Part 15 Subpart C AND ANSI C63.4:2003 PASS WE HEREBY CERTIFY THAT: The above equipment has been tested by Compliance Certification Services Inc., and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by: Reviewed by: Sb. Lu Gundam Lin Sr. Engineer Team Leader FCC IDWOR-6013F Report No.T101203305-RP1 Page 5 of 106 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 2. EUT DESCRIPTION 2.1 DESCRIPTION OF EUT & POWER Product Name Wireless IP CAM Model Number F3106 Received Date December 03, 2010 IEEE 802.11b/g, 802.11n HT20 : 2412MHz～2462MHz Frequency Range IEEE 802.11n HT40 : 2422MHz～2452MHz IEEE 802.11b : 17.02 dBm (0.0504W) IEEE 802.11g : 17.75 dBm (0.0596W) IEEE 802.11n HT20 : 18.12 dBm (0.0649W) Transmit Power IEEE 802.11n HT40 : 17.96 dBm (0.0625W) Channel Spacing IEEE 802.11b/g, 802.11n HT20/HT40 : 5MHz IEEE 802.11b/g, 802.11n HT20 : 11 Channels Channel Number IEEE 802.11n HT40 : 7 Channels IEEE 802.11b : 11, 5.5, 2, 1 Mbps IEEE 802.11g : 54, 48, 36, 24, 18, 12, 9, 6 Mbps IEEE 802.11n HT20 : 65, 58.5, 52, 39, 26, 19.5, 13, 6.5 Mbps Transmit Data Rate IEEE 802.11n HT40 : 135, 121.5, 108, 81, 54, 40.5, 27, 13.5Mbps IEEE 802.11b : DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g : OFDM (64QAM, 16QAM, QPSK, BPSK) Type of Modulation IEEE 802.11n HT20/40 : OFDM (64QAM, 16QAM, QPSK, BPSK) Antenna Type Printed A…

Text truncated - open the document above for the full version.

FCC IDWOR-6013F Report No.T101203305-RP1 Page 102 of 106 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. APPENDIX II SETUP PHOTOS RADIATED EMISSION SETUP Below 1 GHz FCC IDWOR-6013F Report No.T101203305-RP1 Page 103 of 106 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Above 1 GHz FCC IDWOR-6013F Report No.T101203305-RP1 Page 104 of 106 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. FCC IDWOR-6013F Report No.T101203305-RP1 Page 105 of 106 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. ANTENNA PORT CONDUCTED RF MEASUREMENT SETUP FCC IDWOR-6013F Report No.T101203305-RP1 Page 106 of 106 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. CONDUCTED EMISSION SETUP
