WUS00027RFID Receiver

USER MANUAL ID‐R1000 USER MANUAL Contents PREFACE Trademarks FCC Compliance Copyright Statement ID‐R1000 Introduction Features Hardware LED Indicators Data Connections Antennas Environmental Limits CUSTOMER SERVICE airPointe Customer Support USER MANUAL PREFACE Trademarks airPointe of New Hampshire and the airPointe of New Hampshire logo are trademarks of airPointe of New Hampshire. All other product names are copyright and registered trademarks or trade names of their respective owners. Information in this document is provided solely to enable system and software implementers to use the airPointe of New Hampshire system. There are no express or implied copyright licenses granted hereunder to design or fabricate any integrated circuits or integrated circuits based on the information in this document. airPointe of New Hampshire reserves the right to make changes without further notice to any products herein. airPointe of New Hampshire makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does airPointe of New Hampshire assume any liability arising out of the application or use of any product, and specifically disclaims any and all liability, including without limitation consequential or incidental damages. The user of this system is cautioned that any changes or modifications to this system, not expressly approved by airPointe of New Hampshire could void the warranty. FCC COMPLIANCE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ‐‐Reorient or relocate the receiving antenna. ‐‐Increase the separation between the equipment and receiver. ‐‐Connect the equipment into an outlet on a circuit different from that which the receiver is connected. ‐‐Consult the dealer or an experienced radio/TV technician for help. ‐‐Changes or modifications not expressly approved by airPointe of New Hampshire could void the user’s authority to operate the equipment This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. USER MANUAL PREFACE COPYRIGHT STATEMENT Copyright © 2009 airPointe of New Hampshire. All Rights Reserved. This document, as well as the hardware and firmware described therein, are furnished under license and may only be used or copied in accordance with the terms of such license. The information in these pages are furnished for informational use only, are subject to change without notice, and should not be construed as a commitment by airPointe of New Hampshire, airPointe of New Hampshire assumes no responsibility or liability for any errors or inaccuracies that may appear in these pages. Every effort has been made to supply complete and accurate information. However, airPointe of New Hampshire assumes no responsibility for its use, or for any infringements of patents or other rights of third parties, which would result. airPointe of New Hampshire 35E Industrial Way Suite 101 Rochester, NH 03867 USER MANUAL ID‐R1000 INTRODUCTION airPointe delivers software and hardware solutions that enable healthcare organizations to streamline operations, improve quality‐of‐care, reduce costs and generate additional revenue. airPointe develops an innovative next generation Intelligent Real‐Time Location System (i‐RTLS) which can gather data on high‐value assets within an organization, including medical equipment, clinical staff, patients and visitors. An active tag is placed on an item or person that requires monitoring. The battery powered active tags can transmit information throughout a secure wireless router network. Information, or data, that is intelligently and automatically collected by the ID‐R1000, from each tag, will identify the asset type, the location, movement timestamp and other desired device attributes. This data allows items to be easily located anywhere within the wireless network, as well as their proximity relationship to each other. ID‐R1000 FEATURES ‐ Embedded LAN – 10/100/1000Mbps full duplex Ethernet WAN port ‐ IP v4 ‐ UDP ‐ DHCP Client ‐ Remote software image upgrade ‐ 315MHz ISM Band RFID Receiver ‐ Power Supply: Wall Adaptor or PoE (Power‐over‐Ethernet) port ID‐R1000 HARDWARE The ID‐R1000 units are incased in a 9 .5” x 9.5” x 2.0” (8.1cm x 4.1cm x 1.3cm) UL rated ABS Cellcore plastic housing and contain the internal components. USER MANUAL LED Indicators STATUS LED: ‐ Non‐flashing LED indicates that the device is powered and initialized. ‐ Flashing LED indicated the device is powered and initialization failed. RF LED: ‐ Flashing LED indicates RFID tag activity WAN LED: ‐ Flashing LED indicates a WAN link is established and Rx/Tx packet activity. WIFI LED: ‐ This LED is currently non‐operational Data Connections WAN PORT: ‐ The WAN port supports a single 10/100/1Gbps Ethernet RJ‐45 connection. This port also supports PoE (Power‐over‐Ethernet). USER MANUAL EXTERNAL POWER SUPPLY: ‐ The External Power Supply included with the device, can be used as an alternative to PoE. Antennas The ID‐R1000 features dual fixed position embedded antennas. ID‐R1000 ENVIRONMENTAL LIMITS Humidity: 0%‐95% no…

Text truncated - open the document above for the full version.

Curtis-Straus LLC is accredited by the American Association for Laboratory Accreditation for the specific scope of accreditation under Certificate Number 1627-01. This report may contain data which is not covered by the A2LA accreditation. ____________________________________________________________ LLC • •• • Curtis-Straus LLC, a wholly owned subsidiary of BV CPS One Distribution Center Circle, #1 • •• • Littleton, MA • •• • TEL (978) 486-8880 • •• • FAX (978) 486-8828 page 1 of 24 Test Report Curtis-Straus LLC, a wholly owned subsidiary of BV CPS Report No EK1259-1 Client airPointe Don Proulx Address 35E Industrial Way Rochester, NH 03867 Phone 603-994-2200 Items tested ID-R1000 Standards 47 CFR FCC Part 15 Test Dates September 23, 2010 FCC ID WUS00027 Prepared by Edward Breen – Test Engineer Authorized by John Underwood – EMC Manager Issue Date 12/1/2010 Conditions of Issue This Test Report is issued subject to the conditions stated in the ‘Conditions of Testing’ section on page 23 of this report. Test Report for airPointe • •• • Report No. EK1259-1 December 2, 2010 ______________________________________________________________________ ____________________________________________________________ Curtis-Straus LLC, a wholly owned subsidiary of BV CPS One Distribution Center Circle, #1 • •• • Littleton, MA • •• • TEL (978) 486-8880 • FAX (978) 486-8828 page 2 of 24 Contents Contents..................................................................................................................................2 Summary.................................................................................................................................3 Product Tested ........................................................................................................................4 Configuration Documentation...............................................................................................4 Block Diagram .....................................................................................................................5 Compliance Statement ............................................................................................................6 Modifications Required for Compliance ...................................................................................6 RADIATED EMISSIONS..........................................................................................................7 CONDUCTED EMISSIONS ...................................................................................................15 Jurisdictional Labeling and Required Instruction Manual Inserts............................................20 FCC Requirements ............................................................................................................20 Conditions Of Testing ............................................................................................................23 REV 11-MAR-10 (SC) Test Report for airPointe • •• • Report No. EK1259-1 December 2, 2010 ______________________________________________________________________ Issue No. Reason for change Date Issued 1 Original Release December 2, 2010 _____________________________________________________________ Curtis-Straus LLC, a wholly owned subsidiary of BV CPS One Distribution Center Circle, #1 • •• • Littleton, MA • •• • TEL (978) 486-8880 • •• • FAX (978) 486-8828 page 3 of 24 Summary On September 23, 2010 we tested the ID-R1000 for compliance with the following requirements: EMC Emissions: • 47 CFR FCC Part 15 Class B emissions requirements (USA) We found that the product met the above requirements without modification. Don Proulx from airPointe was present during the testing. The test sample was received in good condition. The sample was received on September 23, 2010. This report supports an application for certification of a receiver. The CRUSH RF receive range is 300-348MHz. Please note that the EUT was tested in 2 power modes, using an external AC/DC supply and using Power-Over-Ethernet. Test Report for airPointe • •• • Report No. EK1259-1 December 2, 2010 ______________________________________________________________________ _____________________________________________________________ Curtis-Straus LLC, a wholly owned subsidiary of BV CPS One Distribution Center Circle, #1 • •• • Littleton, MA • •• • TEL (978) 486-8880 • •• • FAX (978) 486-8828 page 4 of 24 Product Tested Configuration Documentation EUT Configuration Work Order: K1259 Company: airPointe Company Address: 35E Industrial Way Rochester, NH 03867 Contact: Don Proulx Person Present: Don Proulx MNSN EUT: ID-R1000sample 1 Power Supply: GS18U48R091255282 EUT Description: Reader EUT Max Frequency:492MHz EUT Min Frequency:25MHz Support Equipment: MNSN Sony LaptopPCG51211L27516330 3050019 D-Link POE AdapterDWL-P200F370174001985 Trendnet 10/100 Ethernet SwitchTE100-S8PCA06468P07104 EUT Ports: Port LabelPort Type No. of ports No. PopulatedCable TypeShieldedFerritesLength Max Length In/Out NEBS TypeUnpopulated Reason AC PowerPower AC112-wire ACnonone0m0minNot used for POE mode DC Power (from Brick)Power DC112-wire DCno1, molded2m2minNot used for POE mode EthernetEthernet11cat5nonone10m100min Software / Operating Mode Description: EUT is in receive mode waiting for a transmission from an RF tag while pinging between itself and the support laptop Test Report for airPointe • •• • Report No. EK1259-1 December 2, 2010 ______________________________________________________________________ _____________________________________________________________ Curtis-Straus LLC, a wholly owned subsidiary of BV CPS One Distribution Center Circle, #1 • •• • Littleton, MA • •• • TEL (978) 486-8880 • •• • FAX (978) 486-8828 page 5 of 24 Block Diagram AC voltage configuration Power Over Ethernet configuration Test Report for airPointe • •• • Report No. EK1259-1 December 2, 2010 ______________________________________________________________________ ________________________…

Text truncated - open the document above for the full version.

Radiated Emissions, AC Voltage Configuration, Front Radiated Emissions, AC Voltage Configuration, Back Radiated Emissions, Power-Over-Ethernet Configuration, Front Radiated Emissions, Power-Over-Ethernet Configuration, Back AC Mains Conducted Emissions, AC Voltage Configuration, Front AC Mains Conducted Emissions, AC Voltage Configuration, Back AC Mains Conducted Emissions, Power-Over-Ethernet Configuration, Front AC Mains Conducted Emissions, Power-Over-Ethernet Configuration, Back
