X58-ECG10XCardio Care

ECG/EKG Recorder 01 CONTENTS Package Content and Know Your Unit 02 Package Content Main Unit Battery Replacement Getting Started 03 The LCM Display Introduction Operating Instructions 04 Power on/off Measurement Historical Record 07 ．Review Measurement Record ．Delete Record Setting 09 ．Date and Time ．Alarm ．Bluetooth 10 Bluetooth: (Upload record to PC/server) 11 USB: (Upload record to PC/server) 13 Important Safety Note 15 Maintenance and Storage 17 Troubleshooting 18 Warranty Information 19 Manufature Date 19 Specifications 20 Package Content and Know Your UnitGetting Started Package Content Main Unit Battery Replacement Introduction The Principle of ECG/EKG Human heart is able to beat as the electrical impulse passes across and through it, and the beat accompanies producing electric activity. An ECG/EKG does not measure the movement of your heartbeat but rather the electrical activity, it is recorded by measuring the potential difference of particular surface part of body by the electronics instrument. Intended use Cardio Care is a non-invasive and easy to use electrocardiograph unit that you can use indoor environment. It records and stores electrocardiogram (ECG) measurements of your heart rhythm of each 30 second period. These ECG readings can monitor your condition more easily. Cardio care unit is designed for prescription purpose, record, store and display the ECG waveform and heart rate that it can help doctor to know the patient's condition. This unit is intended for use on the adult population over 20 years old. <NOTE> Please note that while the measurement from an ECG/EKG recorder is an useful guide for your doctor. They cannot detect all changes in heart conditions. Always consult your doctor if you notice any changes in your condition, regardless of the measurement results. Instruction ManualAAA BatteriesCardio Care UnitProtective Pouch Low Battery Indicator Left Electrode USB Port Right Electrode Up\Increase Down\decrease Enter Exit Chest (back) Electrode Power 0203 The LCM Display Bluetooth Alarm 1. Remove the battery cover. 2. Put 2 new 1.5V AAA alkaline batteries. 3. Put the battery cover back. Power on / off Press to turn on / off Cardio Care. After the welcome message, You will enter main menu automatically, where you can proceed on taking measurement, checking historical record or adjusting setting. Measurement A. Make sure to be in a relaxed condition. The ideal posture of being seated comfortably with your back straight is suggested. However, measurement can still be made while you are standing, lying down or in other comfortable positions. B. Use your right hand to hold the unit properly with your fingers gently pressed on the side electrodes. Please refer to the figure. C. Press and it will start measuring with a beep sound after 5 seconds. Place the unit with the back end electrode against the spot slightly below your chest, The measurement will stop after 30 seconds of recording automatically and is accompanied with a beep sound,The heart rate will be shown on the page and press . D. The unit will ask automatically if you want to upload the record to server, press to upload or to skip. E. After selection, it will go into the page of showing historical record list immediately. More details about the record reading will be shown in the “Historical Record” section. <NOTE> Please use ONLY your right hand to take the measurement Operating Instructions 0405 About 2 inches below your left nipple < main menu > Press button and start to measurement. After press the device will show the loading page, and then start to measurement. <NOTE> If the ECG is interfered by electrostatic discharge, the LCM may show "analysis failed" as follow: Please wait 30 seconds and then measure again. Important Notes on Taking Measurement In order to obtain an accurate ECG/EKG reading, it is important that measurement is taken correctly. Before taking measurement for the first time, read these instructions carefully and make sure you observe the following points each time you take measurement. ．Make sure that the electrodes are directly touching your skin. ．If your hand or skin is dry, wipe them with a damp towel so that they are slightly moist. ．If the electrodes are dirty, wipe any dirt off with a soft cloth or a cotton swab moistened with disinfectant alcohol. ．Do not use disinfectant alcohol to clean the unit except the electrodes. ．Do not move during measurement. ．Movement including talking, coughing, or sneezing during measurement can affect the measurement results. ．If the position of your finger or arm is inappropriate during measurement, the results may be inaccurate, so be sure to check their positions before taking a measurement. ．After taking measurement, disinfect the electrodes by wiping them with a soft cloth or cotton swab moistened with disinfectant alcohol. If you do not disinfect the electrodes there is a risk of skin disease. ．Review Measurement Record Historical record page will show all record that is stored within the device, press to select the desired record for clearer ECG/EKG data. The ECG/EKG record will start playing automatically, press to slow down, press to pause /resume and to exit. Please note that if the record hasn’t been uploaded, it will confirm repeatedly. Historical Record Historical record page can be accessed directly after measurement or through Menu selection. 0607 Heart Rate Scale Indicator ECG/EKG Waveform Measurement Time Indicator => ．Delete Record (A) Delete All Record Please go to the historical record page, then press and hold key for 2 seconds to delete all record stored in this unit. (B) Delete Single Record Press and hold key for 2 seconds to delete while playing the record. Setting Setting page can be accessed directly through Menu selection. ．Date and Time: Press to set date and time and to confirm. Press to return to the previous step. Press to decrease the number. Press to increase the number. ．Alarm: Press to set the alarm time. Press…

Text truncated - open the document above for the full version.

Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group LAB CODE 20050712-00 Report No.: EO/2011/70032 IssuedDate:July22, 2011 Page :1of11 AntennaTest Report Report No.: EO/2011/70032 Test Plan: Non-compliance with ISO17025 Applicant Name:EGIGA TECHNOLOGIES CO LTD Manufacturer Name:EGIGA TECHNOLOGIES CO LTD / STOLLMANN E+V GmbH Product Name: Bluetooth Module ModelNumber:eGM-A03(BlueMod+B20) Measurements performed at SGSTaiwan Ltd. Taipei, Taiwan Issued Date:July22, 2011 NameDate & SignatureDistribution Prepared by: Jacob Chiou Engineer July 22, 2011 Approved by: Nick Hsu Supervisor July 22, 2011 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group LAB CODE 20050712-00 Report No.:EO/2011/70032 Page No.:2 of11 Measurement System Information General Information Testing Condition: Temperature: 25±3 ̊C Humidity:<80% Measurement Facility: Measurement Chamber: ETS-Lindgren 3D fully anechoic chamber and its measuring system(AMS-8500) Base Station Simulator:Agilent E5515C (orR&S CMU200) ETS-Lindgren EMCO-2090 Auxiliary Ports RF Relay Switches Spectrum Analyzer:Agilent E4405B Network Analyzer: Agilent E5071C Fiber Optics for MAPS system Measurement Antenna GPIB-Bus Spectrum Analyzer Universal Radio Communication Tester MAPS Controller Communication Antennaon ceiling Communication Antenna on MAPS Mobile Phone RF Relay Switch Control PC Limiting Amplifier Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 除非另有說明，此報告結果僅對測試之樣品負責，同時此樣品僅保留90天。本報告未經本公司書面許可，不可部份複製。 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134, Wu Kung Road, Wuku Industrial Zone, Taipei County, Taiwan /台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3279 f (886-2) 2298-0488 www.tw.sgs.com Member of SGS Group LAB CODE 20050712-00 Report No.:EO/2011/70032 Page No.:3 of11 Measurements are performed ina ETS-LindgrenAMS-85003Dfully anechoictest system. The test system includes a high-performance RF-shielded, rectangular anechoic chamber, a Multi-Axis Positioning System (MAPS), andEMQuest TM EMQ-100data acquisition a…

Text truncated - open the document above for the full version.

RF_160, Issue 02 Declaration of Authorization We Name: digiO2 International Co., Ltd. Address: 4F-13, No. 79, Sec. 1, Hsin Tai Wu Rd., Hsi Chih Dist., New Taipei City 22101, Taiwan City: New Taipei City Country: Taiwan Declare that: Name：SGS Taiwan Ltd. Address：134, Wu Kung Road, Wuku Industrial Zone TW- New Taipei City 24803 City：New Taipei City Country：Taiwan is authorized to apply for Certification of the following product(s): Product description：Cardio Care Type designation：ECG-102 / ECG-111 Trademark：digiO2 on our behalf. Date： Aug 05, 2013 City： New Taipei City Name：Karen Lin Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Attestation Letter Date: Aug 09, 2013 To Whom It May Concern： We, digiO2 International Co., Ltd.. declare on our sole responsibility that the product, Type: Cardio Care Model: ECG-102 is in all relevant parts equivalent to the product, Model：ECG-111 The difference between ECG-102 and ECG-111 are: Different internal components: ECG-111 has a headphone jack. Different appearance: ECG-111 has a headphone jack outside its shell. Different function: ECG-111 can be measured by an external connection with Pad. Regards, _______________________________________ Karen Lin digiO2 International Co., Ltd. 4F-13, No. 79, Sec. 1, Hsin Tai Wu Rd., Hsi Chih Dist., New Taipei City 22101, Taiwan

FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) Equipment: ECG-102 / ECG111 Trademark(s) and Model(s): digiO2 Manufacturer: digiO2 International Co., Ltd. FCC ID in case other parts of this equipment are subject to certification: X58-ECG10X This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The following test reports are subject to this declaration: Test report number: Issue date: EI-2012-C0007 Aug 05, 2013 The following manufacturer/importer/entity (located in the USA) is responsible for this declaration: Company name: digiO2 International Co., Ltd. Name/Title (legal representative): Karen Lin Address: 4F-13, No. 79, Sec. 1, Hsin Tai Wu Rd., Hsi Chih Dist., New Taipei City 22101, Taiwan Phone: +886-2-2698-5769 Fax: +886-2-2698-9216 E-mail: [email protected] Date: Aug 09, 2013 Signature: FCC

digiO2 International Co., Ltd. Date：Aug 12, 2013 Federal Communications Commission Authorization and Evaluation Division FCC ID： X58-ECG10X Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Block Diagram 3. Operational Description 4. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _____________________________________ Karen Lin digiO2 International Co., Ltd.. 4F-13, No. 79, Sec. 1, Hsin Tai Wu Rd., Hsi Chih Dist., New Taipei City 22101, Taiwan

Report No.: ER/2012/C0012 Issue Date: Aug. 05, 2013 FCC ID: X58-ECG10X Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group APPENDIX 2 EXTERNAL PHOTOGRAPHS OF EUT Report No.: ER/2012/C0012 Issue Date: Aug. 05, 2013 FCC ID: X58-ECG10X Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group ECG-102 Front View of EUT Back View of EUT Report No.: ER/2012/C0012 Issue Date: Aug. 05, 2013 FCC ID: X58-ECG10X Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Side View of EUT – 1 Side View of EUT – 2 Report No.: ER/2012/C0012 Issue Date: Aug. 05, 2013 FCC ID: X58-ECG10X Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134…

Text truncated - open the document above for the full version.

Report No.: ER/2012/C0012 Issue Date: Aug. 05, 2013 FCC ID: X58-ECG10X Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group APPENDIX 2 INTERNAL PHOTOGRAPHS OF EUT Report No.: ER/2012/C0012 Issue Date: Aug. 05, 2013 FCC ID: X58-ECG10X Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Open View of EUT – 1 Open View of EUT – 2 Report No.: ER/2012/C0012 Issue Date: Aug. 05, 2013 FCC ID: X58-ECG10X Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group Open View of EUT – 3 Open View of EUT – 4 Report No.: ER/2012/C0012 Issue Date: Aug. 05, 2013 FCC ID: X58-ECG10X Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 …

Text truncated - open the document above for the full version.

Report No.: ER/2012/C0012 Issue Date: Aug. 05, 2013 FCC ID: X58-ECG10X Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group 15. RF EXPOSURE 15.1. Standard Applicable According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Portable device with its physical nature to be used nearby, the distance between radiating structure and human is less than 20cm. As per KDB 447498 D01 $4.3.1, The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 15.2. Measurement Result: Step 1: (<50mW) This is a portable device and the Max peak output power is (2.38mW) lower than the threshold given and derived as formula given above, where = 1.79 (mW)/5 (mm)*√24…

Text truncated - open the document above for the full version.
