X6HS500Bluetooth Headset

USER MANUAL Bluetooth Headset Model Name: S500 FCC ID : X6HS500 S500 stereo Bluetooth headset Operation Instructions Power on When the headset is off, press and hold the Multi-function Button (MFB) for 2 seconds, the LED indicator will flash slowly in blue. Meantime, you will hear a tone ”Hello” from the speaker of the headset; the headset will be paired with last connected bluetooth devices or mobile phones automatically when it’s on. Power off When the headset is power on, press and hold the MFB for 4 seconds, the LED indicator will flash slowly in red. Meantime, you will hear a tone “Goodbye” from the speaker, the headset will be turned off when disconnected with any phone. Pairing mode When the headset is off, press and hold MFB for 5 seconds until LED flashes red and blue in alternating colors, together with a tone “discovering”. ※ If you release the MFB before headset goes into pairing mode, it will power on and connect with the last paired devices, if you want to pair the headset with a new phone, please power it off and then enter into pairing mode, the headset will stop pairing when fail to connect with any phone in 3 minutes. Easy connect function If the headset doesn’t connect with any phone when it’s on, it will be entering into pairing mode by pressing V+& V- concurrently. Answering calls If a call comes in when listening to the music or headset standing by, press MFB to answer the incoming call, together with a tone “call answered”, the music will be paused during this time, indicator light V+(next) MFB V-(previous) after finished your call the music will be playing on automatically. Reject calls If a call comes in when listening to the music or headset standing by, press and hold MFB for 2 seconds to reject the call, meantime you can hear a tone “call rejected” from the speaker of the headset. End calls Press MFB button to terminate a phone call, meantime you can hear a tone “call terminated” from the speaker, at the same time, music will restart automatically if you are listening to previously. Volume adjust when talking on the phone By pressing the V+/V- to make volume up/down, you’ll hear a warning tone when reaching max/min volume. Last number redials When listening to the music or headset standing by, double click MFB to redial the last number, meantime you can hear a tone “last number redial” from the speaker, t he music will be paused during this time. Mute When talking on the phone, press and hold Vol+ or Vol- for 2 seconds to hold your microphone, you can hear from the caller but the caller fails to hear from you, there will be a warning tone from the headset every 3 seconds. Quit mute By pressing and holding Vol+ or Vol- for 2 seconds to quite the mute mode. Switching between your mobile phone and headset When talking on the phone, double-click the MFB to switch the voice from your headset to mobile phone, by double click MFB again, the voice will back to the headset together with a tone “transfer audio”. Reconnect: When the headset and mobile phone are disconnected, you can hear a tone “your device is disconnected”, meantime if you press MFB, it will be reconnect together with a tone “your device is connected”, some phones may be prompted whether you’d like to be paired. Voice dial If your mobile phone supports this function, press and hold V+ or V- for 2 seconds to activate voice commands when the headset standby or music playing, meantime you will hear a tone “voice dial”, by re-pressing and re-holding V+ or V- for 2 seconds during the voice dialing, the voice dial will be cancelled, please refer to the manual of your mobile phone for support about voice commands Pause and restart music： When listening to the music, click MFB to pause, click MFB again to restart it. Play previous song Press V+ for 2 seconds, play PREV song. Play next song Press V- for 2 seconds, play next song. Connect with 2 mobile phones A, please disconnect the Bluetooth device from your phone 1 if it’s connected already. B, by pressing V+&V- concurrently to make the headset in pairing mode. C, Turn on& search Bluetooth device on your second phone until you find “S500”, and then please make pairing till success. D, please do pairing with your phone 2. E, now 2 mobile phones connecting finished. Transfer call. When you’re talking on the phone and another call coming in, press MFB for 2 seconds to reject the incoming call, if you click V+& V- concurrently, you can receive the incoming call, your first call will be hold on, when you click V+& V- concurrently again, you’ll back to the first call. To switch back to the first call, click V+V- concurrently until you hear a beep again, you can answer the second call by ending the first call with a simple click on MFB, press and hold V+& MFB for 2 seconds until you hear a beep again. Note: this operation requires that your mobile phone supports the call waiting feature. LED indicator status Charging Red LED lights Charging complete Blue LED lights Power on (Connected) Blue LED flashes once every 3 seconds Power on (Talking) Blue LED flashes once every three seconds Power on (Incoming call) Blue LED flashes continuously Music playing Blue LED flashes twice every 4 seconds Power on (Not connected) Blue LED flashes once every 5 seconds Battery low Red LED flashes once every 20 seconds with a tone “battery low” Pairing mode LED flashes in red and blue alternatively Specifications V3.0+V4.0 Bluetooth Technology Profile supports: HSP、HFP、A2DP、AVRCP Transmission Distance: 10m Model: S500 Pin Code: 0000 Transmission range: 2.402GHz～2.480GHz Music time: about 4.5 hours Talk time: about 4 hours Standby time: about 100 hours Operating temperature: 0～40°C(charging)、-20～60°C(peacetime)。 Important Regulatory Information This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that ma…

Text truncated - open the document above for the full version.

Oct. 19, 2013 Federal Communication Commission Authorization and Evaluation Division FCC ID: X6HS500 Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Operational Description 4: Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Alpha Comm Enterprises, Inc. Contact person: Frank Piraino Title: Manager

FCC ID Label Location Note: The label is printed by silk-screen Bluetooth Headset Model: S500 FCC ID: X6HS500

Internal Photos OPEN VIEW OF EUT‐1 OPEN VIEW OF EUT‐2 INTERNAL VIEW OF EUT‐1 INTERNAL VIEW OF EUT‐2 BUTTON VIEW OF EUT‐3 BT Antenna

Report No.: AGC00625130901FE03 Page 1 of 52 FCC Test Report Report No.: AGC00625130901FE03 FCC ID : X6HS500 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Bluetooth Headset BRAND NAME : N/A MODEL NAME : S500 CLIENT : Alpha Comm Enterprises, Inc. DATE OF ISSUE : Oct.14, 2013 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC00625130901FE03 Page 2 of 52 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Oct.14, 2013 Valid Original Report Report No.: AGC00625130901FE03 Page 3 of 52 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY ......................................................................................5 2. GENERAL INFORMATION ..................................................................................................6 2.1. PRODUCT DESCRIPTION ............................................................................................................ 6 2.2. TABLE OF CARRIER FREQUENCYS ........................................................................................... 6 2.3. RECEIVER INPUT BANDWIDTH .................................................................................................. 7 2.4. EXAMPLE OF A HOPPING SEQUENCY IN DATA MODE ............................................................ 7 2.5. EQUALLY AVERAGE USE OF FREQUENCIES AND BEHAVIOUR ............................................ 7 2.6. RELATED SUBMITTAL(S) / GRANT (S) ........................................................................................ 8 2.7. TEST METHODOLOGY ................................................................................................................. 8 2.8. SPECIAL ACCESSORIES .............................................................................................................. 8 2.9. EQUIPMENT MODIFICATIONS ..................................................................................................... 8 3. MEASUREMENT UNCERTAINTY .......................................................................................9 4. DESCRIPTION OF TEST MODES .......................................................................................9 5. SYSTEM TEST CONFIGURATION ....................................................................................10 5.1. CONFIGURATION OF EUT SYSTEM ......................................................................................... 10 5.2. EQUIPMENT USED IN EUT SYSTEM ........................................................................................ 10 5.3. SUMMARY OF TEST RESULTS .................................................................................................. 10 6. TEST FACILITY .................................................................................................................11 7. PEAK OUTPUT POWER ....................................................................................................12 7.1. MEASUREMENT PROCEDURE ................................................................................................. 12 7.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................... 12 7.3. LIMITS AND MEASUREMENT RESULT ..................................................................................... 13 8. 20DB BANDWIDTH............................................................................................................19 8.1. MEASUREMENT PROCEDURE ................................................................................................. 19 8.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................... 19 8.3. LIMITS AND MEASUREMENT RESULTS ................................................................................... 19 9. CONDUCTED SPURIOUS EMISSION ...............................................................................26 9.1. MEASUREMENT PROCEDURE ................................................................................................. 26 9.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................... 26 9.3. MEASUREMENT EQUIPMENT USED ........................................................................................ 26 9.4. LIMITS AND MEASUREMENT RESULT ..................................................................................... 26 10. RADIATED EMISSION .....................................................................................................30 10.1. MEASUREMENT PROCEDURE ............................................................................................... 30 10.2. TEST SETUP .............................................................................................................................. 32 Report No.: AGC00625130901FE03 Page 4 of 52 10.3. TEST RESULT ............................................................................................................................ 33 11. BAND EDGE EMISSION ..................................................................................................37 11.1. MEASUREMENT PROCEDURE ................................................................................................ 37 11.2. TEST SET-UP ............................................................................................................................. 37 11.3. TEST RESULT ............................................................................................................................ 38 12. NUMBER OF HOPPING FREQUENCY ............................................................................42 12.1. MEASUREMENT PROCEDURE ............................................................................................... 42 12.2. TEST SETUP (BLOCK D…

Text truncated - open the document above for the full version.

Te s t Setup Photos FCC RADIATED EMISSION TEST SETUP
