X8WBM20CBluetooth 6.0, 802.15.4 Module

Bluetooth 6.0, 802.15.4 Module BM20C Draft Ver 0.81 June 2026 1 BM20C is a powerful, highly flexible, ultra low power Bluetooth Low Energy (BLE) using Nordic nRF54LM20A SoC. With a ARM Cortex TM M33 MCU at 128 MHz, a RISC-V co-processor for peripherals, embedded 2.4GHz multi-protocol transceiver, and an integrated PCB trace, chip antenna or connection for an external antenna. The nRF54LM20B variant includes an Axon Neural Processing Unit (NPU) - an edge AI accelerator. BM20C footprint is compatible with (1) BM20NE, a module with Nordic nRF21540 power amplifier; (2) BM20XE, a module with Skyworks SKY66403 power amplifier; (3) WM02C20C, a combo module with nRF7002 WiFi 6. All modules can be with or without Axon NPU. BM20C uses an nRF54LM20A SoC. The corresponding module with an nRF54LM20B is BM20BC. Specifications: BLE 6.0, IEEE 802.15.4-2020 Transceiver • Complete RF solution with integrated antenna • BLE: 2Mbps, 1Mbps, 500kbps, 125kbps. • IEEE 802.15.4-2020: 250 kbps. • Proprietary: 4Mbps, 2Mbps, 1Mbps. • 128-bit AES/ECB/CCM/AAR coprocessor. • Programmable TX power, from -10 dBm to +8 dBm, in 1 dB step. Platform Security • Secure/non-secure memory protection • Symmetric and asymmetric key crypto accelerator. • Secure key management. • Tamper detection. • Immutable boot partition. • Debug access port protection. • Individual watchdog timers for secure and non-secure context. Application processor • ARM R Cortex R M33 with TrustZone R , 128MHz. • 500 EEMBC CoreMark score running from non-volatile memory, 3.90 CoreMark per MHz. • 2036 KB non-volatile memory(RRAM), 512 KB RAM. • Floating point unit, DSP instructions. • Data watchpoint and trace. • Serial Wire Debug (SWD) Peripherals • RISC-V Coprocessor. • High-speed USB (480 Mbps), Full speed (12 Mbps), and low speed (1.5 Mbps) • A global real-time counter can run is System OFF mode. • Seven 32 bit timers with counter mode. • Six fully featured serial interfaces with EasyDMA, supporting I 2 C, SPI controller/peripheral, and UART. • One high speed capable SPIM (32 MHz) or UART with EasyDMA. • Three PWM units with EasyDMA. • Time Division Multiplexed (TDM) sound interface. • Two pulse density modulated (PDM) microphone interface, 48x, 50x, 64x, 80x, 96x, 150x, and 192x decimation ratios. • ADC with up to 8 programmable gain channels. 14-bit at 31.25 ksps, 12 bit at 250 ksps, and up to 10 bit at 2 maps. • NFC. • 2 x QDEC. • 90 LGA pins, 66 GPIOs. • 32.0 MHz and 32.768 kHz crystals embedded. • 1.8V and 3.3V supply voltage. • All evaluation boards use an nRF54LM20B module. Don’t use the Axon NPU if an nRF54LM20A module is used. • Operation temperature: - 40°C to + 125°C Model Summaries module BM20M/BM20BM BM20C/BM20BC BM20E/BM20BE BM20F/BM20BF BM20P/BM20BP SoC nRF54LM20A/B nRF54LM20A/B nRF54LM20A/B nRF54LM20A/B nRF54LM20A/B Size, mm 10.0x14.0mm 10.0x14.8mm 10.0x15.0 mm 10(15.2) x 20.8 10.0 x 10.5 Antenna PCB Trace Chip U.FL for external High perf. PCB Pads for external BLE range 300M est. 500M, est. FCC ID ISED ID CE, RCM TELEC NCC KCC Evaluation board EV-BM20BM EV-BM20BC EV-BM20BE EV-BM20BF EV-BM20BP Availability Sample/NonStock Sample/Sample Sample/NonStock NonStock/Sample Q3 NonStock/Samples Q3 Bluetooth 6.0, 802.15.4 Module BM20C Draft Ver 0.81 June 2026 2 Of Contents 1. Introduction ....................................................................................................................................................... 3 BM20C Block Diagram ...................................................................................................................................... 3 BM20M .............................................................................................................................................................. 4 BM20C and BM20BC ........................................................................................................................................ 4 BM20E .............................................................................................................................................................. 4 BM20BF ............................................................................................................................................................ 4 BM20BP ............................................................................................................................................................ 4 2. BM20C Specifications ....................................................................................................................................... 5 Nordic SoCs ...................................................................................................................................................... 5 Mechanical Drawings ........................................................................................................................................ 6 BM20C pin map .............................................................................................................................................. 11 PIN Function BM15C, BM20C, BMH20C ........................................................................................................ 12 Upgrading to BM20NE, BM20XE, WM02C20C .............................................................................................. 15 Mounting BM20C on the Host PCB ................................................................................................................ 18 Suggestion for Battery Power Application ....................................................................................................... 18 EV-BM20BC Evaluation Board Schematics .................................................................................................... 19 Evaluation Board ............................................................................................................................................. 21 3. Firmware Development ..............................…

Text truncated - open the document above for the full version.

FCC ID: X8WBM20C International Standards Laboratory Corp. 1 1. Maximum Permissible Exposure (MPE) Standard Applicable According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Mobile device, the MPE is required. According to §1.1310 and §2.1091 RF exposure is calculated. Limits for Maximum Permissive Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minute) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / F/1500 30 1500-15000 / / 1.0 30 F = frequency in MHz * = Plane-wave equipment power density The MPE was calculated at 20 cm to show compliance with the power density limit The following formula was used to calculate the Power Density. S=PG/4πR 2 Where: S = Power density P = Power input to antenna G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = Distance to the center of radiation of the antenna FCC ID: X8WBM20C International Standards Laboratory Corp. 2 Maximum Permissible Exposure (MPE) Evaluation Frequency Band (MHz) Conducted power (dBm) Antenna gain (dBi) Tune-Up Tolerance (dB) EIRP (dBm) MPE (mW/cm 2 ) LIMIT (mW/cm 2 ) 2402 - 2480 8.37 6 1 15.370 0.00685062 1 2405 - 2480 8.38 6 1 15.380 0.00686642 1 ~ End of Report ~

-96 of 102- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCZIG 11.4 Appendix D: Photographs of Setup Conducted Emission Set up Photo -97 of 102- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCZIG -98 of 102- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCZIG Radiated Emission Set up Photos -99 of 102- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCZIG -100 of 102- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCZIG -101 of 102- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCZIG -102 of 102- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCZIG 11.5 Appendix E: Photographs of EUT Please refer to the File of ISL-26LR0132P --- END ---

-164 of 170- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCBLE 11.4 Appendix D: Photographs of Setup Conducted Emission Set up Photo -165 of 170- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCBLE -166 of 170- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCBLE Radiated Emission Set up Photos -167 of 170- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCBLE -168 of 170- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCBLE -169 of 170- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCBLE -170 of 170- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCBLE 11.5 Appendix E: Photographs of EUT Please refer to the File of ISL-26LR0132P --- END ---

TEST REPORT of FCC CFR Title 47 Part 15 Subpart C Product: Bluetooth 6.0, 802.15.4 Module Brand: Fanstel Main Model: BM20BC Series Model: BM20M; BM20BM; BM20C; BM20E; BM20BE; BM20F; BM20BF; BM20P; BM20BP FCC ID: X8WBM20C Standard: §15.247, Cat: DTS Reference: ANSI C63.10: 2020 KDB 558074 D01 v05r02 Applicant: Fanstel Corporation, Taipei Address 10F-10, No. 79, Sec. 1, Hsin Tai Wu Rd., Hsi-Chih, New Taipei City 221 Taiwan Test Performed by: International Standards Laboratory Corp. LT Lab. TEL: +886-3-263-8888 FAX: +886-3-263-8899 No. 120, Lane 180, Hsin Ho Rd., Lung-Tan Dist., Tao Yuan City 325, Taiwan Report No.: ISL-26LR0132FCBLE Issue Date : August 11, 2026 FCC Registration Number: 487532 Test results given in this report apply only to the specific sample(s) tested and are traceable to national or international standard through calibration of the equipment and evaluating measurement uncertainty herein. According to customer agreement, the laboratory issues test reports based on the regulations or standards specifications, the measurement uncertainty is not considered in conformity decision rules. This test report shall not be reproduced except in full, without the written approval of International Standards Laboratory Corp. -2 of 170- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCBLE VERIFICATION OF COMPLIANCE Applicant: Fanstel Corporation, Taipei Equipment Under Test: Bluetooth 6.0, 802.15.4 Module Brand: Fanstel Main Model: BM20BC Series Model: BM20M; BM20BM; BM20C; BM20E; BM20BE; BM20F; BM20BF; BM20P; BM20BP Model Difference: Antenna Type FCC ID: X8WBM20C Date of Test: July 15, 2026 ~ August 11, 2026 Date of EUT Received: July 15, 2026 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15.247 Complied We hereby certify that: All the tests in this report have been performed and recorded in accordance with the standards described above and performed by an independent electromagnetic compatibility consultant, International Standards Laboratory Corp. The test results contained in this report accurately represent the measurements of the characteristics and the energy generated by sample equipment under test at the time of the test. The sample equipment tested as described in this report is in compliance with the limits of above standards. Prepared By: Gigi Yeh Test By: Approved By: Barry Lee Jerry Liu / Manager -3 of 170- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCBLE Version Version No. Date Description 00 August 11, 2026 Initial creation of document -4 of 170- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCBLE TABLE OF CONTENTS 1. Description of Equipment under Test (EUT) .......................................................................... 5 2. Description of Test Modes ......................................................................................................... 6 2.1 CONFIGURATION OF TESTED SYSTEM .............................................................................................. 6 2.2 DUTY FACTOR .................................................................................................................................. 7 3. Standards, reference documents and applicable test methods .............................................. 9 4. Summary of Test Results ........................................................................................................... 9 5. AC Line Conduced Emission Test .......................................................................................... 10 5.1 STANDARD APPLICABLE .................................................................................................................10 5.2 MEASUREMENT PROCEDURE...........................................................................................................10 5.3 MEASUREMENT RESULT..................................................................................................................11 6. Peak Output Power Measurement ......................................................................................... 13 6.1 STANDARD APPLICABLE .................................................................................................................13 6.2 MEASUREMENT PROCEDURE...........................................................................................................13 6.3 MEASUREMENT RESULT..................................................................................................................14 7. Radiated Spurious Emission Test ........................................................................................... 15 7.1 STANDARD APPLICABLE .................................................................................................................15 7.2 MEASUREMENT PROCEDURE...........................................................................................................15 7.3 FIELD STRENGTH CALCULATION ....................................................................................................16 7.4 MEASUREMENT RESULT..................................................................................................................17 8. 100kHz Bandwidth of Band Edges Measurement .............................................................. 115 8.1 STANDARD APPLICABLE ...............................................................................................................115 8.2 MEASUREMENT PROCEDURE.........................................................................................................115 8.3 FIELD STRENGTH CALCULATION ..................................................................................................115 8.4 MEASUREMENT RESULT................................................................................................................116 9. 6dB Bandwidth ....................................................................................................................... 150 9.1…

Text truncated - open the document above for the full version.

TEST REPORT of FCC CFR Title 47 Part 15 Subpart C Product: Bluetooth 6.0, 802.15.4 Module Brand: Fanstel Main Model: BM20BC Series Model: BM20M; BM20BM; BM20C; BM20E; BM20BE; BM20F; BM20BF; BM20P; BM20BP FCC ID: X8WBM20C Standard: §15.247, Cat: DTS Reference: ANSI C63.10: 2020 KDB 558074 D01 v05r02 Applicant: Fanstel Corporation, Taipei Address 10F-10, No. 79, Sec. 1, Hsin Tai Wu Rd., Hsi-Chih, New Taipei City 221 Taiwan Test Performed by: International Standards Laboratory Corp. LT Lab. TEL: +886-3-263-8888 FAX: +886-3-263-8899 No. 120, Lane 180, Hsin Ho Rd., Lung-Tan Dist., Tao Yuan City 325, Taiwan Report No.: ISL-26LR0132FCZIG Issue Date : August 11, 2026 FCC Registration Number: 487532 Test results given in this report apply only to the specific sample(s) tested and are traceable to national or international standard through calibration of the equipment and evaluating measurement uncertainty herein. According to customer agreement, the laboratory issues test reports based on the regulations or standards specifications, the measurement uncertainty is not considered in conformity decision rules. This test report shall not be reproduced except in full, without the written approval of International Standards Laboratory Corp. -2 of 102- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCZIG VERIFICATION OF COMPLIANCE Applicant: Fanstel Corporation, Taipei Equipment Under Test: Bluetooth 6.0, 802.15.4 Module Brand: Fanstel Main Model: BM20BC Series Model: BM20M; BM20BM; BM20C; BM20E; BM20BE; BM20F; BM20BF; BM20P; BM20BP Model Difference: Antenna Type FCC ID: X8WBM20C Date of Test: July 15, 2026 ~ August 11, 2026 Date of EUT Received: July 15, 2026 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15.247 Complied We hereby certify that: All the tests in this report have been performed and recorded in accordance with the standards described above and performed by an independent electromagnetic compatibility consultant, International Standards Laboratory Corp. The test results contained in this report accurately represent the measurements of the characteristics and the energy generated by sample equipment under test at the time of the test. The sample equipment tested as described in this report is in compliance with the limits of above standards. Prepared By: Gigi Yeh Test By: Approved By: Barry Lee Jerry Liu / Manager -3 of 102- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCZIG Version Version No. Date Description 00 August 11, 2026 Initial creation of document -4 of 102- International Standards Laboratory Corp. Report Number: ISL-26LR0132FCZIG TABLE OF CONTENTS 1. Description of Equipment under Test (EUT) .......................................................................... 5 2. Description of Test Modes ......................................................................................................... 7 2.1 CONFIGURATION OF TESTED SYSTEM .............................................................................................. 7 2.2 DUTY FACTOR .................................................................................................................................. 8 3. Standards, reference documents and applicable test methods .............................................. 9 4. Summary of Test Results ........................................................................................................... 9 5. AC Line Conduced Emission Test .......................................................................................... 10 5.1 STANDARD APPLICABLE .................................................................................................................10 5.2 MEASUREMENT PROCEDURE...........................................................................................................10 5.3 MEASUREMENT RESULT..................................................................................................................11 6. Peak Output Power Measurement ......................................................................................... 13 6.1 STANDARD APPLICABLE .................................................................................................................13 6.2 MEASUREMENT PROCEDURE...........................................................................................................13 6.3 MEASUREMENT RESULT..................................................................................................................14 7. Radiated Spurious Emission Test ........................................................................................... 15 7.1 STANDARD APPLICABLE .................................................................................................................15 7.2 MEASUREMENT PROCEDURE...........................................................................................................15 7.3 FIELD STRENGTH CALCULATION ....................................................................................................16 7.4 MEASUREMENT RESULT..................................................................................................................17 8. 100kHz Bandwidth of Band Edges Measurement ................................................................ 66 8.1 STANDARD APPLICABLE .................................................................................................................66 8.2 MEASUREMENT PROCEDURE...........................................................................................................66 8.3 FIELD STRENGTH CALCULATION ....................................................................................................66 8.4 MEASUREMENT RESULT..................................................................................................................67 9. 6dB Bandwidth ......................................................................................................................... …

Text truncated - open the document above for the full version.

CA-C03规格书 CA-C03_V02 1 SMD 天线规格书 CrossAir TM SMD天线系列 符合RoHS规范 PN:CA-C03 2.4GHzISM频段天线 CA-C03规格书 CA-C03_V02 2 特点 1. 尺寸仅 5.5X2.0X1.0mm 3 的小尺寸 SMD 贴片天线 . 2. 低能量损耗，高天线效率。 3. 在温湿度变化的情况下具有高稳定性。 应用 1.2.4GHzISM 频段天线应用 2. 蓝牙、 ZigBee 、无线应用、智能家居应用等 3.WIFI （仅 2.4G ） 结构 1、天线馈电端 2、馈电识别标志 3、天线焊接固定端 尺寸 三视图符号尺寸(mm) L5.5±0.2 w2.0±0.1 T1.0±0.1 a0.5±0.1 CA-C03规格书 CA-C03_V02 3 电气特性 CA-C03Specification 工作频率范围WorkingFrequency2450±50MHz 带宽BandWidth >100MHz 阻抗Impedance50Ω 增益Gain(dBi)4.3（peak） 驻波比VSWR <2 工作温度OperationTemperature-40°C~+95°C 可承受功率PowerCapacity 3W 天线2.4G工作频率需要通过阻抗匹配器件调试来实现. 天线焊盘和走线设计 设计尺寸图 CA-C03规格书 CA-C03_V02 4 匹配器件值串联器件Series10Ω 并联器件Shunt1 3nh 串联器件Series2 0Ω 测试板上天线测试(板厚1.0mm) CA-C03规格书 CA-C03_V02 5 天线 S11 特性 天线VSWR特性 效率和辐射图 效率、辐射图、增益等性能是基于测试板设计得到的。 CA-C03 天线的规格特性测试数据是 CA-C03规格书 CA-C03_V02 6 基于测试 PCB 板尺寸以及下图所示的测试方向所得到的。以下数据是在 ETS3D 微波暗室测 试完成的 . 增益和效率带宽 2.4G-2.5GHz 峰值增益PeakGain 4.3dBi 带内平均增益 AverageGainacrosstheband 4.1dBi 带内增益范围 GainRangeacrosstheband 3.9dBi~4.3dBi 峰值效率 PeakEfficiency 81.7% 带内平均效率 AverageEfficiencyacrosstheband 80.2% 带内效率范围 EfficiencyRangeacrosstheband 78.6%~81.7% Theta @2.45 GHz Z Y X CA-C03规格书 CA-C03_V02 7 Phi @2.45 GHz Total @2.45 GHz 焊接条件 可靠无损的典型焊接规范如下图所示： CA-C03规格书 CA-C03_V02 8 包装 塑胶载带规格 (单位:mm) IndexAoBo ΦD TW Dimension(mm) 3.0±0.16.0±0.11.55±0.051.6±0.116±0.2 IndexEFPoP1P2 Dimension(mm) 1.75 ± 0.17.0 ± 0.14.0 ± 0.14.0 ± 0.12.0 ± 0.1 卷盘尺寸 CA-C03规格书 CA-C03_V02 9 IndexABC Dimension(mm)33010013.5 标准数量：3000PCS/盘. 存储环境 产品存储时应满足下列条件： 料盘存储温度:-10°C~+40°C（非天线工作温度） 料盘存储湿度:30%至70%相对湿度（非天线工作湿度） 产品放置的位置不要接触腐蚀性气体，如硫磺等。氯气或酸可能导致产品电极氧化 造成可焊接性变差。 产品应放置在工具箱里且避免受潮、灰尘的影响。 产品应存放在仓库中且避免热、振动、阳光直射。 产品应在密闭条件下储存。

Page: 1 of 7 ANTENNA TEST REPORT Product : PCB antenna Brand: Fanstel Model: BM20BF Model Difference: N/A Applicant: Fanstel Corporation, Taipei Address: 10F-10, No. 79, Sec. 1, Hsin Tai Wu Rd., Hsi-Chih, New Taipei City 221 Taiwan Test Performed by: International Standards Laboratory <LT Lab.> *Address: No. 120, Lane 180, San Ho Tsuen, Hsin Ho Rd. Lung-Tan Hsiang, Tao Yuan County 325, Taiwan *Tel : 886-3-407-1718; Fax: 886-3-407-1738 Report No.: ISL-26LR0132ANT Issue Date : 2026/07/21 Test By: Test results given in this report apply only to the specific sample(s) tested and are traceable to national or international standard through calibration of the equipment and evaluating measurement uncertainty herein. This report MUST not be used to claim product endorsement by TAF, NEMKO or any agency of the Government. This test report shall not be reproduced except in full, without the written approval of International Standards Laboratory. -2 of 7- International Standards Laboratory Report Number: ISL-26LR0132ANT 1. Test SET-UP (Block Diagram of Configuration) Measurement Equipment Used: Equipment Name Brand Model S/N Last Cal. Date Next Cal. Date Signal Analyzer (44GHz) R&S FSV3044 101463 02/04/2026 02/04/2027 Horn antenna (1GHz - 18GHz) EM EM-AH-10180 2011071401 12/09/2025 12/09/2026 MXG Vector Signal Generator KEYSIGHT N5182B MY53052399 12/26/2025 12/26/2027 EUT Coaxial Cable Horn Antenna 1.5m 3m Turntable S.G 0dBm Spectrum Analyzer 1.5m -3 of 7- International Standards Laboratory Report Number: ISL-26LR0132ANT 2. EUT Photo Figure 1 2.4G Antenna -4 of 7- International Standards Laboratory Report Number: ISL-26LR0132ANT Figure 2 -5 of 7- International Standards Laboratory Report Number: ISL-26LR0132ANT Test Result 2.4G Antenna Maximum gain test result: Maximum antenna Gain = 4.31 dBi Antenna Gain 2400 2450 2500 Unit 4.31 4.08 3.16 dBi Figure 1. 2.4G Antenna 2400MHz Figure 2. 2.4G Antenna 2450MHz Figure 3. 2.4G Antenna 2500MHz -6 of 7- International Standards Laboratory Report Number: ISL-26LR0132ANT Figure 1 Figure 2 -7 of 7- International Standards Laboratory Report Number: ISL-26LR0132ANT Figure 3

ANT000 Antenna ANT000 antenna can be used with Fanstel module with an u.FL connector. It consists of: • an antenna with an SMA connector and + 0 dBi gain • an SMA connector to u.FL connector adaptor cable. • panel mounting hardware at SMA connector side of adaptor cable. Specifications • Frequency range: 2400 to 2500 MHz. • Gain: 0 dBi • Impedance: 50 ohm • Max power: 10W • Antenna size: 50mm x 8mm • Adaptor cable size: 100mm x 9mm. • Shell material: ABS • Operating temperature: -30 o C to + 60 o C. • Antenna gains in the table below. Antenna ANT000 with an Adaptor Cable Since 1990 Fanstel Corp. | 7466 E. Monte Cristo Ave. Scottsdale, AZ 85260 USA| t: 1 480.948.4928 | e: [email protected] | w: http://www.fanstel.com V1.0, Aug. 2019 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Fanstel: ANT000

ANT060 Antenna ANT060 antenna can be used with Fanstel module with an u.FL connector. It consists of: • an antenna with an SMA connector and + 6 dBi gain • an SMA connector to u.FL connector adaptor cable. • panel mounting hardware at SMA connector side of adaptor cable. Specifications • Frequency range: 2400 to 2500 MHz. • Gain: 6 dBi • Impedance: 50 ohm • Max power: 10W • Antenna size: 195mm x 13mm • Adaptor cable size: 100mm x 9mm. • Shell material: ABS • Operating temperature: -30 o C to + 60 o C. Antenna ANT060 with an Adaptor Cable Since 1990 Fanstel Corp. | 7466 E. Monte Cristo Ave. Scottsdale, AZ 85260 USA| t: 1 480.948.4928 | e: [email protected] | w: http://www.fanstel.com V1.0, Aug. 2017 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Fanstel: ANT060

Page: 1 of 7 ANTENNA TEST REPORT Product : PCB antenna Brand: Fanstel Model: BML20M Model Difference: N/A Applicant: Fanstel Corporation, Taipei Address: 10F-10, No. 79, Sec. 1, Hsin Tai Wu Rd., Hsi-Chih, New Taipei City 221 Taiwan Test Performed by: International Standards Laboratory <LT Lab.> *Address: No. 120, Lane 180, San Ho Tsuen, Hsin Ho Rd. Lung-Tan Hsiang, Tao Yuan County 325, Taiwan *Tel : 886-3-407-1718; Fax: 886-3-407-1738 Report No.: ISL-26LR0132ANT Issue Date : 2026/07/21 Test By: Test results given in this report apply only to the specific sample(s) tested and are traceable to national or international standard through calibration of the equipment and evaluating measurement uncertainty herein. This report MUST not be used to claim product endorsement by TAF, NEMKO or any agency of the Government. This test report shall not be reproduced except in full, without the written approval of International Standards Laboratory. -2 of 7- International Standards Laboratory Report Number: ISL-26LR0132ANT 1. Test SET-UP (Block Diagram of Configuration) Measurement Equipment Used: Equipment Name Brand Model S/N Last Cal. Date Next Cal. Date Signal Analyzer (44GHz) R&S FSV3044 101463 02/04/2026 02/04/2027 Horn antenna (1GHz - 18GHz) EM EM-AH-10180 2011071401 12/09/2025 12/09/2026 MXG Vector Signal Generator KEYSIGHT N5182B MY53052399 12/26/2025 12/26/2027 EUT Coaxial Cable Horn Antenna 1.5m 3m Turntable S.G 0dBm Spectrum Analyzer 1.5m -3 of 7- International Standards Laboratory Report Number: ISL-26LR0132ANT 2. EUT Photo Figure 1 2.4G Antenna -4 of 7- International Standards Laboratory Report Number: ISL-26LR0132ANT Figure 2 -5 of 7- International Standards Laboratory Report Number: ISL-26LR0132ANT Test Result 2.4G Antenna Maximum gain test result: Maximum antenna Gain =-1.72 dBi Antenna Gain 2400 2450 2500 Unit -4.06 -2.22 -1.72 dBi Figure 1. 2.4G Antenna 2400MHz Figure 2. 2.4G Antenna 2450MHz Figure 3. 2.4G Antenna 2500MHz -6 of 7- International Standards Laboratory Report Number: ISL-26LR0132ANT Figure 1 Figure 2 -7 of 7- International Standards Laboratory Report Number: ISL-26LR0132ANT Figure 3

Agent letter FCC attestation statement Kiwa Page 1 of 2 RF_753, Issue 2 15-02-2023 [PLACE ON APPLICANT/COMPANY LETTERHEAD] U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Kiwa Nederland B.V. Wilmersdorf 50 7327 AC Apeldoorn Postbus 137 7300 AC Apeldoorn Netherlands ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company name: Fanstel Corp. FRN: 0023143266 Contact person name: Yuan Fan Street address: 7466 E. Monte Cristo Ave. Scottsdale ZIP/City/State AZ 85260 USA Telephone number: 1 480 948 4928 Email address: [email protected] Signature: Date: 2026/09/01 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Compa…
