1 Wireless Remote Control For Automotive Winches 1. 2. Wireless Remote Control Kit includes: 1. PC board kit.884134 / 12V 884242 / 24V 2. Control pack.884128 3. Wireless Transmitter.883822 4. Lithium Battery: 3V CR2032 5. Handsaver Strap 3. 4. 5. I.Specifications 1. Transmission range:15 ~ 27 m (50 ~ 90 ft) 2. Receiver operation voltage: 8 ~ 12 V 3. Receiver fuse current rating: 7.5 A 4. Protection: IP67 5. Operating temperature range: -30°C ~ +80°C 6. LED indication: Green light for power on; Red light for winching; Blinking green for low battery life; Blinking red light for poor signal received II.Installation Guide Step 1: Installation a. Connect the PC board kit and Control pack harness plugs. b. Secure the PC board kit on the Control pack. Part No.884134、884242 INSTALLATION GUIDE LED indication 2 Step 2: Connect the vehicle battery a. Connect thermal sensor harness plug, control ground, and cable A/F1/F2 to the motor. b. Connect the Red wire to the negative (+) terminal of the battery. c. Connect the Black wire to the negative (-) terminal of the battery. III Operation 1. Install and replace battery. a. Turn cover counterclockwise to open. b. Replace new battery and put the cover back. c. Turn cover clockwise to close. 2. Start a. Turn on the Vehicle. b. Press the Power Buttons for 5 seconds until Green light comes on. c. Press the Cable In or Cable Out button , then the Red light comes on. 3. Stop a. The system will be automatically shutting down the operation after a silence of operation for 5 minutes. b. Press and hold the Power Button for 5 seconds for shutting down the operation. 4. Additional Emergency Stop Function: The power button also works as an emergency stop if the radio control is in malfunction of any reason. While the radio control is in operation (either winch in or winch out, the red light is on), once power button is pressed, the radio control will be forced to power off immediately. Winch will stop running accordingly. Cable OUT Cable OUT Cable IN Power Button LED Indicator Lithium Battery: CR2032 (3V) Cable IN 3 5. Reset a. Press the cutout switch and turn it on for reset, Buzzer will alarm 10 seconds for pairing. b. Press the Power Buttons for 5 seconds until the Green lights up. c. Press the Cable In or Out button until the Red lights on the receiver turns off. d. Reset is now completed. Please note only one remote can be reset for each receiver. 6. Notes a. The wireless remote control and handlebar rocker switch can be exchanged for activating the winch, but it takes about 10 seconds for exchanging。 b. Blinking Green LED light shows batter low, the battery should be replaced immediately. c. Please note only one remote can be reset for each receiver d. Blinking Red LED for poor signal. FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/ TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. RF Exposure warning This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. FCC and Industry Canada (IC) Warning: • This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Cut-out Switch
Report No.: 2280856R-Product Photos Page: 1 of 3 (1) EUT Photo (2) EUT Photo Report No.: 2280856R-Product Photos Page: 2 of 3 (3) EUT Photo (4) EUT Photo Report No.: 2280856R-Product Photos Page: 3 of 3 (5) EUT Photo (6) EUT Photo
WIRELESS REMOTE MODULE www.comeupwinch.com Model No:884134 Made in Taiwan Product: Wireless Remote ControlTransmission range: 15-27m(50-90ft)Receiver operation voltage: 8- V 12 Protection: IP67FCC ID: X96884134Serial NO: CE Mark WarningThis is a Class B product, in a domestic environment,this productmay cause radio interference, in which case the user may berequired to take adequate measures.FCC and Industry Canada (IC) Warning:This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions: (1) Thisdevice may not cause harmful interference, and (2) this devicemust accept any interference received, including interferencethat may cause undesired operation. : 7
Report No.: 2280856R-Product Photos Page: 1 of 5 (1) EUT Photo (2) EUT Photo Report No.: 2280856R-Product Photos Page: 2 of 5 (3) EUT Photo (4) EUT Photo RF Module & Antenna Report No.: 2280856R-Product Photos Page: 3 of 5 (5) EUT Photo (6) EUT Photo Report No.: 2280856R-Product Photos Page: 4 of 5 (7) EUT Photo (8) EUT Photo Report No.: 2280856R-Product Photos Page: 5 of 5 (9) EUT Photo
Report No.: 2280856R-RFUSMPEV02-A Page: 1 of 7 RF Exposure Evaluation Report Product Name : Wireless Remote Control Model No. : 884134 FCC ID : X96884134 Applicant : Comeup Industries Inc. Address : No.139, Jieyukeng Rd., Ruifang Dist., New Taipei City 22453, Taiwan Date of Receipt : Aug. 26, 2022 Date of Declaration : Dec. 30, 2022 Report No. : 2280856R-RFUSMPEV02-A Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of DEKRA Testing and Certification Co., Ltd. Measurement uncertainties evaluated for each testing system and associated connections are given here to provide the system information for reference. Compliance determinations do not take into account measurement uncertainties for each testing system, but are based on the results of the compliance measurement. Report No.: 2280856R-RFUSMPEV02-A Page: 2 of 7 Product Name Wireless Remote Control Applicant Comeup Industries Inc. Address No.139, Jieyukeng Rd., Ruifang Dist., New Taipei City 22453, Taiwan Manufacturer Comeup Industries Inc. Model No. 884134 FCC ID X96884134 Trade Name COMEUP Applicable Standard KDB 447498 D01 v06 Minimum test separation distance ≥ 20 cm For low power devices Test Result Complied Documented By : ( Senior Project Specialist / Genie Chang ) Tested By : ( Senior Engineer / Bill Lin ) Approved By : ( Senior Engineer / Alan Chen ) Report No.: 2280856R-RFUSMPEV02-A Page: 3 of 7 Revision History Report No. Ve r s i o n Description Issued Date 2280856R-RFUSMPEV02-A V1.0 Initial issue of report. Dec. 30, 2022 Report No.: 2280856R-RFUSMPEV02-A Page: 4 of 7 1. General Information 1.1. EUT Description Product Name Wireless Remote Control Trade Name COMEUP Model No. 884134 FCC ID X96884134 Note: For more detailed information please refer to report No.: 2280856R-RFUSOTHV05-A.. Report No.: 2280856R-RFUSMPEV02-A Page: 5 of 7 1.2. Test Facility USA : FCC Registration Number: TW0033 Canada : CAB Identifier Number: TW3023 / Company Number: 26930 Site Description : Accredited by TAF Accredited Number: 3023 Test Laboratory : DEKRA Testing and Certification Co., Ltd Address : No. 5-22, Ruishukeng Linkou District, New Taipei City, 24451, Taiwan Performed Location : No. 26, Huaya 1st Rd., Guishan Dist.,Taoyuan City 333411, Taiwan, R.O.C. Phone Number : +886-3-275-7255 Fax Number : +886-3-327-8031 Email Address : [email protected] Website : http://www.dekra.com.tw Report No.: 2280856R-RFUSMPEV02-A Page: 6 of 7 2. RF Exposure Evaluation 2.1. Standard Applicable According to KDB 447498 D01 (7.1), A minimum test separation distance ≥ 20 cm is required between the antenna and radiating structures of the device and nearby persons to apply mobile device exposure limits. 2.2. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in a host device is ≤ 1.0 Report No.: 2280856R-RFUSMPEV02-A Page: 7 of 7 2.3. Test Result of RF Exposure Evaluation Product : Wireless Remote Control Test Item : RF Exposure Evaluation Band Frequency (MHz) E.I.R.P (dBm) E.I.R.P (mW) Power Density at R = 20 cm (mW/cm2) Limit (mW/cm2) 2.4 GHz Wireless 2480 2.030 1.596 0.0003 1 Note: The conducted output power is refer to report No.: 2280856R-RFUSOTHV05-A from the DEKRA. Results PASS
